SLIDE 1

spcl.inf.ethz.ch @spcl_eth

Tal Ben-Nun, Johannes de Fine Licht, Alexandros-Nikolaos Ziogas, Timo Schneider, Torsten Hoefler

Stateful Dataflow Multigraphs: A Data-Centric Model for Performance Portability on Heterogeneous Architectures

This project has received funding from the European Research Council (ERC) under grant agreement "DAPP (PI: T. Hoefler)".

SLIDE 2

spcl.inf.ethz.ch @spcl_eth

Motivation

4 Slide courtesy of NVIDIA

SLIDE 3

spcl.inf.ethz.ch @spcl_eth

6

Source: US DoE

Computational Scientist

SLIDE 4

spcl.inf.ethz.ch @spcl_eth

7

Domain Scientist Performance Engineer

SLIDE 5

spcl.inf.ethz.ch @spcl_eth

Optimization Techniques

▪ Multi-core CPU

▪ Tiling for complex cache hierarchies ▪ Register optimizations ▪ Vectorization

▪ Many-core GPU

▪ Coalesced memory access ▪ Warp divergence minimization, register tiling ▪ Task fusion

▪ FPGA

▪ Maximize resource utilization (logic units, DSPs) ▪ Streaming optimizations, pipelining ▪ Explicit buffering (FIFO) and wiring

8

SLIDE 6

spcl.inf.ethz.ch @spcl_eth

9

aCe Overview

System Domain Scientist Performance Engineer

Data-Centric Intermediate Representation (SDFG)

𝜖𝑣 𝜖𝑢 − 𝛽𝛼2𝑣 = 0

…

FPGA Modules CPU Binary Runtime Hardware Information

Graph Transformations

Compiler

Transformed Dataflow Performance Results

GPU Binary Python

𝑴 𝑺

* * * * * *

TensorFlow DSLs MATLAB Scientific Frontend

Problem Formulation

SLIDE 7

spcl.inf.ethz.ch @spcl_eth

Dataflow Programming in DaCe

10

𝑧 = 𝑦2 + sin 𝑦 𝜌

x y

Tasklet Memlets

SLIDE 8

spcl.inf.ethz.ch @spcl_eth

Parallel Dataflow Programming

11

…

B

Tasklet

A[1] B[1] A[0] B[0] A[N-1] B[N-1]

A

Tasklet Tasklet

SLIDE 9

spcl.inf.ethz.ch @spcl_eth

Parallel Dataflow Programming

12

A B

[i=0:N] Tasklet

A[i] B[i]

[i=0:N] A[0:N] B[0:N]

…

B

Tasklet Tasklet Tasklet

A[1] B[1] A[0] B[0] A[N-1] B[N-1]

A

Scope

SLIDE 10

spcl.inf.ethz.ch @spcl_eth

Stateful Parallel Dataflow Programming

13

A B

[i=0:N] Tasklet

A[i] B[i]

[i=0:N] A[0:N] B[0:N]

C A

[i=0:N] Tasklet

C[i] A[i]

[i=0:N] C[0:N] A[0:N]

SLIDE 11

spcl.inf.ethz.ch @spcl_eth

State s1 State s0

Stateful Parallel Dataflow Programming

14

A B

[i=0:N] Tasklet

A[i] B[i]

[i=0:N] A[0:N] B[0:N]

C A

[i=0:N] Tasklet

C[i] A[i]

[i=0:N] C[0:N] A[0:N]

SLIDE 12

spcl.inf.ethz.ch @spcl_eth

Example: 2D Stencil

15

State s1 State s0

[y=0:H,x=0:W] Initialize

B[y,x]

[y=0:H,x=0:W]

B[0:H,0:W] B

t < T t < T; t++

A

B

[y=0:H, x=0:W] [y=0:H,x=0:W] Jacobi

A

t ≥ T t=0

A[y-1,x] A[y+1,x] A[y,x-1] A[y,x+1] B[y,x]

[y=0:H, x=0:W] [y=0:H,x=0:W] Jacobi

A[y,x] B[y-1,x] B[y+1,x] B[y,x-1] B[y,x+1] ∅ A[0:H,0:W] B[0:H,0:W] B[0:H,0:W] A[0:H,0:W]

SLIDE 13

spcl.inf.ethz.ch @spcl_eth

Conflict Resolution

Meet the Nodes

16

State

State machine element

Tasklet

Fine-grained computational block

Array

N-dimensional data container

Stream

Streaming data container

Consume

Exit

Dynamic mapping of computations on streams Defines behavior during conflicting writes

Map

Exit

Parametric graph abstraction for parallelism

SLIDE 14

spcl.inf.ethz.ch @spcl_eth

Conflict Resolution

Meet the Nodes

17

State

State machine element

Tasklet

Fine-grained computational block

Array

N-dimensional data container

Stream

Streaming data container

Consume

Exit

Dynamic mapping of computations on streams Defines behavior during conflicting writes

Map

Exit

Parametric graph abstraction for parallelism

State s0

[i=0:N] Filter

B[0:N]

B

A[i]

Bsize S

S S Bsize(+) Bsize(+)

A

[i=0:N]

A[0:N]

SLIDE 15

spcl.inf.ethz.ch @spcl_eth

Hierarchical Parallelism and Heterogeneity

▪ Maps have schedules, arrays have storage locations

18

[i=0:N:TN]

A[i:i+TN]

A

A[0:N]

CPU

[ti=0:TN]

Core

ut = in_A * in_A

A[i+ti] …

SLIDE 16

spcl.inf.ethz.ch @spcl_eth

Hierarchical Parallelism and Heterogeneity

▪ Maps have schedules, arrays have storage locations

19

// ... #pragma omp parallel for for (int i = 0; i < N; i += TN) { vec<double, 4> tA[TN]; Global2Stack_1D<double, 4, 1> ( &A[i], min(N – i, TN), tA); for (int ti = 0; ti < TN; ti += 1) { vec<double, 4> in_A = tA[ti]; auto out = (in_A * in_A); tC[ti] = out; }

[i=0:N:TN]

A[i:i+TN]

tA A

A[0:N]

CPU

[ti=0:TN]

Core

ut = in_A * in_A

tA[0:TN] tA[ti] …

SLIDE 17

spcl.inf.ethz.ch @spcl_eth

Hierarchical Parallelism and Heterogeneity

20

[i=0:N:TN]

A[i:i+TN]

tA A

A[0:N]

CPU

[ti=0:TN]

Core

ut = in_A * in_A

tA[0:TN] tA[ti] …

SLIDE 18

spcl.inf.ethz.ch @spcl_eth

Hierarchical Parallelism and Heterogeneity

21

__global__ void multiplication_1(...) { int i = blockIdx.x * TN; int ti = threadIdx.y + 0; if (i+ti >= N) return; __shared__ vec<double, 2> tA[TN]; GlobalToShared1D<double, 2, TN, 1, 1, false>(gA, tA); vec<double, 2> in_A = tA[ti]; auto out = (in_A * in_A); tC[ti] = out; }

[i=0:N:TN]

gA[i:i+TN]

tA gA

gA[0:N]

GPU Device

[ti=0:TN]

GPU Block

ut = in_A * in_A

tA[0:TN] tA[ti] …

A

A[0:N]

SLIDE 19

spcl.inf.ethz.ch @spcl_eth

Mapping to Reconfigurable Hardware

▪ Module generation with HDL and HLS

Xilinx SDAccel Intel FPGA (experimental)

▪ Parallelism

Exploiting temporal locality: pipelines Exploiting spatial locality: vectorization, replication

▪ Replication

Enables parametric systolic array generation

23

SLIDE 20

spcl.inf.ethz.ch @spcl_eth

Data-centric Parallel Programming for Python

▪ Programs are integrated within existing codes

In Python, integrated functions in existing code In MATLAB, separate .m files In TensorFlow, takes existing graph

▪ In Python: Implicit and Explicit Dataflow

Implicit: numpy syntax Explicit: Enforce memory access decoupling from computation

▪ Output compatible with existing programs

C-compatible SO/DLL file with autogenerated include file

24

@dace.program def program_explicit(A, B): @dace.map def transpose(i: _[0:N], j: _[0:M]): a << A[i,j] b >> B[j,i] b = a @dace.program def program_numpy(A, B): B[:] = np.transpose(A)

SLIDE 21

spcl.inf.ethz.ch @spcl_eth

Matrix Multiplication SDFG

25

@dace.program def gemm(A: dace.float64[M, K], B: dace.float64[K, N], C: dace.float64[M, N]): # Transient variable tmp = np.ndarray([M, N, K], dtype=A.dtype) @dace.map def multiplication(i: _[0:M], j: _[0:N], k: _[0:K]): in_A << A[i,k] in_B << B[k,j]

ut >> tmp[i,j,k]
ut = in_A * in_B

dace.reduce(lambda a, b: a + b, tmp, C, axis=2)

State s0

A

[i=0:M, j=0:N, k=0:K] multiplication

B[k,j]

[i=0:M, j=0:N, k=0:K]

A[0:M,0:K] tmp[0:M,0:N,0:K]

B

B[0:K,0:N] A[i,k] tmp[i,j,k]

C

tmp

tmp[0:M,0:N,0:K] C[0:M,0:N]

Reduce

[axis: 2, sum]

SLIDE 22

spcl.inf.ethz.ch @spcl_eth

Matrix Multiplication SDFG

26

State s0

A

[i=0:M, j=0:N, k=0:K] multiplication

B[k,j]

[i=0:M, j=0:N, k=0:K]

A[0:M,0:K]

B

B[0:K,0:N] A[i,k] C (+) [i,j]

C

C[0:M,0:N]

@dace.program def gemm(A: dace.float64[M, K], B: dace.float64[K, N], C: dace.float64[M, N]): # Transient variable tmp = np.ndarray([M, N, K], dtype=A.dtype) @dace.map def multiplication(i: _[0:M], j: _[0:N], k: _[0:K]): in_A << A[i,k] in_B << B[k,j]

ut >> tmp[i,j,k]
ut = in_A * in_B

dace.reduce(lambda a, b: a + b, tmp, C, axis=2)

SLIDE 23

spcl.inf.ethz.ch @spcl_eth

MapReduceFusion Transformation

27

$A $A[:] $A[:] *

$REDUCE

$B[$br] $A[$ar] $B[$br] $B[$ar] $B my_tasklet

arr

my_tasklet

$B arr

*

X

SLIDE 24

spcl.inf.ethz.ch @spcl_eth

Programming Model Challenges

29

[j=prow[0]:prow[1]] multiply

b[i] (Sum) b[:] (Sum) prow[0:2] val[:] col[:] x[:] indirection

x_in

val[j] col[j] x(1)[:]

[j=prow[0]:prow[1]] [y=0:H,x=0:W]

image[0:H,0:W]

[y=0:H,x=0:W] image

∅

𝒚𝟑 + 𝒛𝟑 < 𝟓; i = i + 1

i

init

x y x y

image[y,x]

x y

update

i = 0

Indirect memory access Nested state machines

SLIDE 25

spcl.inf.ethz.ch @spcl_eth

DIODE (or: Data-centric Integrated Optimization Development Environment)

32

SLIDE 26

spcl.inf.ethz.ch @spcl_eth

DIODE (or: Data-centric Integrated Optimization Development Environment)

33

Source Code Transformation History SDFG (malleable) SDFG Properties Generated Code Transformations

SLIDE 27

spcl.inf.ethz.ch @spcl_eth

34

Performance

SDFG

Naïve

SLIDE 28

spcl.inf.ethz.ch @spcl_eth

35

Performance

SDFG

MapReduceFusion Naïve

SLIDE 29

spcl.inf.ethz.ch @spcl_eth

36

Performance

SDFG

LoopReorder MapReduceFusion Naïve

SLIDE 30

spcl.inf.ethz.ch @spcl_eth

37

Performance

SDFG

BlockTiling LoopReorder MapReduceFusion Naïve

SLIDE 31

spcl.inf.ethz.ch @spcl_eth

38

Performance

SDFG

RegisterTiling BlockTiling LoopReorder MapReduceFusion Naïve

SLIDE 32

spcl.inf.ethz.ch @spcl_eth

39

Performance

SDFG

LocalStorage RegisterTiling BlockTiling LoopReorder MapReduceFusion Naïve

SLIDE 33

spcl.inf.ethz.ch @spcl_eth

40

Performance

SDFG

PromoteTransient LocalStorage RegisterTiling BlockTiling LoopReorder MapReduceFusion Naïve

SLIDE 34

spcl.inf.ethz.ch @spcl_eth

41

Performance

Intel MKL OpenBLAS 25% difference DaCe

With tuning: 98.6% of MKL

SLIDE 35

spcl.inf.ethz.ch @spcl_eth

42

SDFG

General Compilers

GCC 8, Clang 6, icc 18, NVCC 9.2, SDAccel

Polyhedral Optimizers

Polly 6, Pluto 0.11.4, PPCG 0.8 HPX, Halide, Intel MKL, CUBLAS, CUSPARSE, CUTLASS, CUB

Intel Xeon E5-2650 v4 NVIDIA Tesla P100 Xilinx VU9P Frameworks & Libraries

SLIDE 36

spcl.inf.ethz.ch @spcl_eth

Performance Evaluation: Fundamental Kernels (CPU)

Database Query: roughly 50% of a 67,108,864 column Matrix Multiplication (MM): 2048x2048x2048 Histogram: 8192x8192 Jacobi stencil: 2048x2048 for T=1024 Sparse Matrix-Vector Multiplication (SpMV): 8192x8192 CSR matrix (nnz=33,554,432)

43

99.9% of MKL 8.12x faster 98.6% of MKL 2.5x faster 82.7% of Halide

SLIDE 37

spcl.inf.ethz.ch @spcl_eth

Performance Evaluation: Fundamental Kernels (GPU, FPGA)

44

GPU FPGA 19.5x of Spatial 90% of CUTLASS

SLIDE 38

spcl.inf.ethz.ch @spcl_eth

Performance Evaluation: Fundamental Kernels (GPU, FPGA)

45

GPU FPGA 19.5x of Spatial 90% of CUTLASS

SLIDE 39

spcl.inf.ethz.ch @spcl_eth

Performance Evaluation: Polybench (CPU)

▪ Polyhedral benchmark with 30 applications ▪ Without any transformations, achieves 1.43x (geometric mean) over general-purpose compilers

46

SLIDE 40

spcl.inf.ethz.ch @spcl_eth

Performance Evaluation: Polybench (GPU, FPGA)

▪ Automatically transformed from CPU code

47

GPU

(1.12x geomean speedup)

FPGA

The first full set of placed-and-routed Polybench

11.8x

SLIDE 41

spcl.inf.ethz.ch @spcl_eth

Case Study: Parallel Breadth-First Search

▪ Compared with Galois and Gluon ▪ Graphs:

Road maps: USA, OSM-Europe Social networks: Twitter, LiveJournal Synthetic: Kronecker Graphs

48

SLIDE 42

spcl.inf.ethz.ch @spcl_eth

Conclusions

49 This project has received funding from the European Research Council (ERC) under grant agreement "DAPP (PI: T. Hoefler)".

@dapp.program def program(A, B): @dapp.map(_[0:N,0:M]) def transpose(i, j): a << A[i,j] b >> B[j,i] ...
