ST. MARTINS ANGLICAN CHURCH PREPARED FOR: ST. MARTINS ANGLICAN CHURCH JUNE 26, 2016 1 SITE LOCATION 17TH AVE SW SITE SITE LOCATION S T M O R I T Z D R I V E S W ST MARTINS ANGLICAN CHURCH EXISTING SITE PLAN 2 1221.995

slide-1
SLIDE 1
  • ST. MARTINS ANGLICAN CHURCH

PREPARED FOR: ST. MARTINS ANGLICAN CHURCH JUNE 26, 2016

slide-2
SLIDE 2

ST MARTINS ANGLICAN CHURCH

SITE

SITE LOCATION 17TH AVE SW S T M O R I T Z D R I V E S W

SITE LOCATION 1

slide-3
SLIDE 3

ST MARTINS ANGLICAN CHURCH

1223.205 1222.233 1223.626 1223.696 1223.206 1219.892 1219.267 1221.032 1221.212 1223.559 1223.445 1221.723 1219.980 1224.041 1223.818 1224.009 1223.664 1223.829 1224.248 1223.792 1223.866 1223.667 1223.805 1221.909 1221.510 1218.878 1222.193 1221.995 1220.742 1219.435 1219.020

17TH AVE SW ST MORITZ DRIVE SW

EXISTING SITE PLAN 2

slide-4
SLIDE 4

ST MARTINS ANGLICAN CHURCH 1 2 3 4 4 5 6 7 8 9 10 11 12 13 14 15 1 18 17 4 8 6 5 10 9 1 2 3 7 18 17 18 17 12 15 4 3 11 13 14 14 LEGEND: 1 VESTIBULE 2 COAT CHECK 3 STAIRS/ ELEVATOR 4 WASHROOMS 5 NARTHEX/ CIRCULATION 6 NAVE 7 SACRISTY 8 STORAGE 9 PASTOR 10 ASSISTANT PASTOR 11 KITCHEN 12 MULTIPURPOSE HALL 13 SUNDAY SCHOOL 14 LIBRARY & STORAGE 15 DIOCESE OFFICE 16 CHAPEL 17 PEDESTRIAN AREA 18 PARKING

SITE OPTIONS

OPTION 1: SINGLE LEVEL OPTION 2: STACKED

MAIN LEVEL MAIN LEVEL LOWER LEVEL 16

3

VEHICULAR ACCESS PEDESTRIAN ACCESS VEHICULAR ACCESS PEDESTRIAN ACCESS

slide-5
SLIDE 5

ST MARTINS ANGLICAN CHURCH

ANATOMY OF DESIGN 4

a b c d e f g h i

slide-6
SLIDE 6

ST MARTINS ANGLICAN CHURCH

PLANNING PRINCIPLES

  • Versatile, sacred space of worship
  • Unique and meaningful
  • Noticeable
  • Clean, simple lines
  • Attractive in form
  • Symbols and metaphors that reflect Christian faith
  • Strong presence in the community with curbside appeal
  • Well lit - especially at night
  • Open, warm, welcoming entrance and narthex, encouraging people to look up
  • Entrance: easily accessible to everyone with clarity in circulation
  • Altar area: focal point with play of natural light
  • barrier free altar area with no altar rail
  • Meeting and gathering space for various organizations
  • “Wow Factor”, a place where people feel it is “Home”, a place to reflect and feel the “Holy”

5

slide-7
SLIDE 7

ST MARTINS ANGLICAN CHURCH

DN

VEHICULAR ACCESS PEDESTRIAN ACCESS DROP OFF 6 M SETBACK 3 M SETBACK PARKING- 66 STALLS

URW # 741070439

MAIN ENTRY PROPERTY LINE

17TH AVE SW ST MORITZ DRIVE SW

SITE PLAN

PEDESTRIAN ACCESS

6

PEDESTRIAN ACCESS W&R 1.2 M SETBACK

slide-8
SLIDE 8

ST MARTINS ANGLICAN CHURCH

SITE PERSPECTIVE 9

slide-9
SLIDE 9

ST MARTINS ANGLICAN CHURCH

DN

FLOOR PLANS - OPTION 01

UP

LEGEND: 1 VESTIBULE 2 COAT CHECK 3 STAIRS/ ELEVATOR 4 WASHROOMS(LADIES, GENTS & FAMILY /DISABLED) 5 NARTHEX/ CIRCULATION 195 SM/ 2,098 SFT 6 NAVE 313 SM/ 3,369 SFT 7 SACRISTY 22 SM/ 236 SFT 8 STORAGE 30 SM/ 322 SFT 9 CHAPEL 33 SM/ 355 SFT 10 PASTOR 22 SM/ 236 SFT 11 ASSISTANT PASTOR 13 SM/ 140 SFT 12 MULTIPURPOSE HALL 209 SM/ 2,250 SFT 13 SUNDAY SCHOOL 57 SM/ 613 SFT 14 LIBRARY & STORAGE 13 SM/ 140 SFT 15 DIOCESE OFFICE BISHOP 19 SM/ 140 SFT ASST BISHOP 13 SM/204 SFT

  • EXEC. OFFICER13 SM/ 140 SFT

FINANCE DIRECTOR 13 SM/ 140 SFT

  • ASST. FINANCE DIRECTOR 13 SM/ 140 SFT

SWING OFFICE13 SM/ 140 SFT SWING OFFICE13 SM/ 140 SFT 16 MEETING ROOM 20 SM/ 215SFT 17 MUSIC/CHOIR ROOM 16 SM/172 SFT 18 BOARD ROOM 26 SM/ 279 SFT 19 KITCHEN & STORGE 54 SM/ 581 SFT 20 STORAGE / BUILDING SUPPORT 11 SM / 118 SFT

TOTAL AREA = 1,532 SM/ 16,490 SFT MAIN LEVEL - Polyline Building Area = 766 sm, 8,245 sft LOWER LEVEL - Polyline Building Area = 766 sm/ 8,245 sft

1 2 3 3 9 6 7 5 8 10 19 12 13 15 14 3 3 4

8

16 11 4 17 18 20 20

slide-10
SLIDE 10

ST MARTINS ANGLICAN CHURCH

FLOOR PLANS - OPTION 02 9

MAIN LEVEL - Polyline Building Area = 757 sm, 8,148 sft LOWER LEVEL - Polyline Building Area = 757sm/ 8,148 sft

DN UP

LEGEND: 1 VESTIBULE 2 COAT CHECK 3 STAIRS/ ELEVATOR 4 WASHROOMS(LADIED, GENTS & FAMILY /DISABLED) 5 NARTHEX/ CIRCULATION 200 SM/ 2,152 SFT 6 NAVE 305 SM/ 3,283 SFT 7 SACRISTY 16 SM/ 172 SFT 8 STORAGE 21 SM/ 226 SFT 9 CHAPEL 33 SM/ 355 SFT 10 PASTOR 22 SM/ 236 SFT 11 ASSISTANT PASTOR 13 SM/ 140 SFT 12 MULTIPURPOSE HALL 200 SM/ 2,152 SFT 13 SUNDAY SCHOOL 51 SM/ 550 SFT 14 LIBRARY & STORAGE 13 SM/ 140 SFT 15 DIOCESE OFFICE BISHOP 19 SM/ 140 SFT ASST BISHOP 13 SM/204 SFT

  • EXEC. OFFICER13 SM/ 140 SFT

FINANCE DIRECTOR 13 SM/ 140 SFT

  • ASST. FINANCE DIRECTOR 13 SM/ 140 SFT

SWING OFFICE13 SM/ 140 SFT SWING OFFICE13 SM/ 140 SFT 16 MEETING ROOM 16 SM/ 172SFT 17 MUSIC/CHOUR ROOM 21 SM/226 SFT 18 BOARD ROOM 26 SM/ 279 SFT 19 KITCHEN & STORGE 54 SM/ 581 SFT 20 STORAGE / BUILDING SUPPORT 11 SM / 118 SFT

TOTAL AREA = 1,514 SM/ 16,297 SFT

1 2 3 3 4 6 7 5 20 10 19 12 13 13 15 14 3 3 4 16 11 11 17 18 9 8 20 15

slide-11
SLIDE 11

ST MARTINS ANGLICAN CHURCH

VIEW FROM SOUTH EAST 10

slide-12
SLIDE 12

ST MARTINS ANGLICAN CHURCH

PEDESTRIAN ENTRY 11

slide-13
SLIDE 13

ST MARTINS ANGLICAN CHURCH

ALTAR TO NARTHEX 12

slide-14
SLIDE 14

ST MARTINS ANGLICAN CHURCH

NARTHEX TO ALTAR 13
