Sprayed Seal Design AAPA training Design of Rates of Application Primes Primerseals Seals C170 binder Polymer modified binder Geotex3le reinforced seals (GRS)
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Design of Rates of Application
- Primes ¡
- Primerseals ¡
- Seals ¡
– C170 ¡binder ¡ – Polymer ¡modified ¡binder ¡ – Geotex3le ¡reinforced ¡seals ¡(GRS) ¡
- Surface ¡enrichment ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Priming
- Design ¡of ¡Rates ¡of ¡Applica3on ¡based ¡on ¡
experience ¡with ¡type ¡of ¡pavement ¡ ¡and ¡
- primer. ¡
- No ¡formal ¡design ¡method ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Priming
- Rate ¡of ¡Set-‑Up ¡for ¡cutback ¡primes: ¡
– Hot ¡weather ¡ ¡ ¡– ¡ ¡ ¡6 ¡to ¡12 ¡hrs ¡ – Cool ¡Weather ¡ ¡ ¡– ¡ ¡12 ¡to ¡24 ¡hrs ¡ – Cold ¡or ¡cool ¡and ¡damp ¡– ¡ ¡24 ¡to ¡48 ¡hrs ¡
- Time ¡before ¡applying ¡next ¡treatment ¡
– Cutback ¡prime ¡-‑ ¡3 ¡days ¡(minimum) ¡ – Emulsion ¡prime ¡ ¡ ¡-‑ ¡12 ¡to ¡24 ¡hrs ¡
¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Primer Pavement Grade Rate (L/m²) Tightly bonded Medium porosity Porous Limestone Sandstone Hill gravel, sand Stabilised Concrete Light Medium Heavy to v. heavy Heavy to v. heavy Medium to heavy Light Very light to light Very light 0.6 – 1.1 0.8 – 1.1 0.9 – 1.3 0.7 – 0.9/0.5 – 0.7 0.7 – 0.9/0.5 – 0.7 0.8 – 1.1 0.5 – 0.8 0.2 – 0.4
Guide to Rates of Application of Primer
Priming – small scale trial
- Small scale trial
- Apply measured quantity
by hand
- Distribute evenly
- Observe performance
- Design rate
§ ¡ ¡Apply ¡measured ¡quanMty ¡ ¡ ¡ ¡ ¡by ¡hand ¡(say ¡1L) ¡ ¡ § ¡ ¡Distribute ¡evenly ¡with ¡brush ¡ § ¡ ¡Observe ¡performance ¡ § ¡ ¡Decide ¡on ¡grade ¡and ¡rate ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Primersealing
Primerbinder ¡-‑ ¡Rates ¡of ¡ApplicaMon ¡
- No ¡formal ¡design ¡procedure ¡
- AUSTROADS ¡design ¡based ¡on: ¡
¡ ¡
– Traffic ¡ranges(v/l/d) ¡ – Nominal ¡aggregate ¡size ¡ – Type ¡of ¡primerbinder ¡ – Pavement ¡condiMon ¡ – Local ¡experience ¡ ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Primersealing
Primerbinder ¡– ¡Rates ¡of ¡ApplicaMon ¡
- Determine ¡base ¡rates ¡from ¡AP-‑T68 ¡
- Add ¡allowances ¡for: ¡
– ¡Pavement ¡texture ¡ – ¡Possible ¡absorpMon ¡ – ¡Possible ¡aggregate ¡embedment ¡based ¡on ¡using ¡ball ¡ embedment ¡test ¡
- Total ¡allowances: ¡
– ¡generally ¡averages ¡ ¡ ¡+ ¡0.2 ¡to ¡+ ¡0.3 ¡L/m² ¡
Primersealing
Primerbinder application rate L/m² @ 15 °C
DesignTraffic
(v/l/d)
Aggregate size (mm)
Cutback bitumen Bitumen emulsion
60%
- 150
7 or 5 10 1.3 1.4 1.6 1.8 150 - 1200 7 or 5 10 1.2 1.3 1.5 1.6 1200+ 7 or 5 10 1.1 1.2 1.4 1.5
Aggregate spread rates
Size of aggregate mm Aggregate spread rate m²/m³ Sand, size 5, size 7 Size 10 130 – 150 110 – 120
Primersealing
Typical Aggregate Spread Rates
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Update ¡of ¡the ¡ Austroads ¡ Sprayed ¡Seal ¡ Design ¡Method ¡ AP-‑T68/06 ¡ ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Design Philosophy
Basis ¡for ¡method: ¡
- Use ¡of ¡one-‑sized ¡aggregate ¡ ¡
- Binder ¡should ¡be ¡50 ¡to ¡60% ¡up ¡the ¡height ¡of ¡the ¡aggregate ¡
- Aggregate ¡parMcles ¡may ¡embed ¡into ¡base ¡
- Binder ¡may ¡be ¡absorbed ¡into ¡base ¡
- Reseals ¡interlock ¡into ¡the ¡substrate ¡
Design Philosophy
14
Texture ¡for ¡skid ¡ resistance ¡ Maximum ¡binder ¡ level ¡(65%) ¡ Void ¡loss ¡due ¡to ¡ meshing ¡with ¡exisMng ¡ surface ¡ex. ¡concrete ¡ (different ¡to ¡ embedment ¡in ¡ “green” ¡base) ¡ Minimum ¡ binder ¡level ¡to ¡ provide ¡ adhesion ¡of ¡ aggregate ¡to ¡ base ¡(30%) ¡ ALD 100% ReorientaMon ¡
- nto ¡ALD ¡
(most ¡stable ¡ posiMon) ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
AP-T68/06 Design
- Sprayed ¡seals ¡are ¡a ¡system ¡
– Binder ¡and ¡aggregate ¡spread ¡rate ¡are ¡both ¡important ¡
- Binder ¡design ¡rate ¡of ¡applicaMon ¡for ¡ ¡
– S/S ¡ ¡ – Unmodified, ¡modified, ¡emulsion ¡binders ¡ – GeotexMle ¡and ¡Fibre ¡Reinforced ¡Seal ¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Ae Existing surface condition allowance
As
Absorption allowance
Basic voids factor: Vf
Design voids factor:
VF (Vf+Va
+Vt)
Design Traffic volume
ALD
Basic binder application rate:
Bb
Design binder application rate;
Bd
DESIGN ¡FLOW ¡ CHART ¡
Binder ¡applicaMon ¡rate ¡ Treatment ¡known ¡ AADT ¡known ¡
¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf
Design voids factor: VF (Vf+Va+Vt)
Design Traffic volume (v/l/d)
ALD Basic binder application rate: Bb
Design binder application rate; Bd
Step ¡1 ¡-‑ ¡Collect ¡input ¡data ¡ Aggregate ¡
- Grading ¡(one ¡sized) ¡
- Flakiness ¡Index ¡(FI) ¡
- ALD ¡(A) ¡
Design ¡Traffic ¡
- Vehicles/lane/day ¡calculated ¡
from ¡AADT ¡
- Commercial ¡vehicles ¡
Road ¡geometry ¡
- Climbing/channelised ¡lanes ¡
Surface ¡effects ¡ ¡
- Texture ¡(sand ¡patch) ¡
- Aggregate ¡embedment
¡ ¡(new ¡ work) ¡
- Pavement ¡absorp3on ¡(not ¡
applicable ¡if ¡correctly ¡primed) ¡
Design Input Data - Traffic
- Annual ¡Average ¡Daily ¡Traffic ¡
– Representa3ve ¡ – Current ¡
¡
- AADT ¡is ¡over ¡all ¡lanes ¡
- Design ¡traffic ¡
– Vehicles ¡in ¡each ¡lane ¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf Design Traffic volume (v/l/d)
ALD
Basic binder application rate: Bb
Design binder application rate; Bd
Design voids factor: VF (Vf+Va+Vt)
Step ¡2 ¡– ¡Determine ¡basic ¡ voids ¡factor ¡Vf ¡ Charts ¡using ¡design ¡traffic ¡
- Two ¡charts ¡for ¡different ¡traffic ¡
ranges ¡
- Use ¡target ¡line ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf Design Traffic volume (v/l/d)
ALD
Basic binder application rate: Bb
Design binder application rate; Bd
Design voids factor: VF (Vf+Va+Vt)
Step ¡3 ¡– ¡Determine ¡ adjustments ¡Va ¡& ¡Vt ¡ Aggregate ¡shape ¡Va ¡
- Table ¡2.1 ¡
- Flakiness ¡index ¡
Traffic ¡Vt ¡
- Table ¡2.2 ¡
- Heavy ¡vehicles ¡
- Climbing ¡lanes ¡
- Channelised ¡lanes ¡
Table 2.1: Adjustment to Basic Voids Factor for Aggregate Shape (Va)
Aggregate type Aggregate shape Flakiness index (%) Shape adjustment Va (L/m2/mm) Crushed or partly crushed Very Flaky > 35
Not ¡recommended ¡for ¡ sealing ¡
Flaky 26 to 35 0 to - 0.01 Angular 15 to 25 Nil Cubic < 15 + 0.01 Rounded NA 0 to + 0.01 Not crushed Rounded NA + 0.01
Table 2.2: Adjustment to Basic Voids Factor for Traffic Effects (Vt)
Traffic
Adjustment to Basic Voids Factor (L/m2/mm) Flat or downhill Slow moving – climbing lanes Normal Channelised* Normal Channelised* On overtaking lanes of multi-lane rural roads where traffic is mainly cars with ≤10% of HV
+0.01 0.00 N/A
N/A Non-trafficked areas such as shoulders, medians, parking areas
+0.02 N/A N/A N/A 0 to 15% Equivalent Heavy vehicles (EHV) Nil
- 0.01
- 0.01
- 0.02
16 to 25% Equivalent Heavy vehicles (EHV)
- 0.01
- 0.02
- 0.02
- 0.03
26 to 45% Equivalent Heavy vehicles (EHV)
- 0.02
- 0.03
- 0.03
- 0.04**
> 45% Equivalent Heavy vehicles (EHV)
- 0.03
- 0.04**
- 0.04**
- 0.05**
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf Design Traffic volume (v/l/d)
ALD Design voids factor: VF (Vf+Va+Vt)
Basic binder application rate:
Bb
Design binder application rate;
Bd
Step ¡4 ¡– ¡Determine ¡design ¡ voids ¡factor ¡VF ¡ VF ¡ ¡= ¡ ¡Vf ¡ ¡+ ¡Va ¡ ¡+ ¡Vt ¡
- Is ¡VF ¡outside ¡of ¡upper ¡& ¡lower ¡
limits? ¡
Step ¡5 ¡– ¡Basic ¡binder ¡ applicaMon ¡rate ¡Bb ¡ Bb ¡(L/m2) ¡= ¡VF ¡x ¡ ¡ALD ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Design Input Data - Aggregate
- Average ¡Least ¡Dimension ¡
– May ¡use ¡typical ¡values ¡for ¡ini3al ¡design ¡
- Need ¡values ¡for ¡lot ¡to ¡be ¡used ¡for ¡final ¡design ¡
7mm ¡ 3.5 ¡– ¡4.5 ¡mm ¡ 10mm ¡ 5.0 ¡– ¡6.0 ¡mm ¡ 14mm ¡ 7.5 ¡– ¡9.0 ¡mm ¡ 20mm ¡ 10.5 ¡– ¡12.0 ¡mm ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Polymer Modified Binder & Emulsion Seals
- Apply ¡a ¡Polymer ¡Factor ¡(PF) ¡varies ¡with ¡PMB ¡& ¡type ¡
- f ¡seal ¡
- Add ¡normal ¡allowances ¡
- Aggregate ¡design ¡spread ¡rate: ¡
– 10% ¡heavier ¡than ¡normal ¡
- Emulsion ¡seals ¡– ¡replace ¡PF ¡with ¡EF ¡
Step ¡5 ¡– ¡Modified ¡Basic ¡binder ¡applicaMon ¡rate ¡Bbm ¡ Bbm ¡(L/m2) ¡= ¡VF ¡x ¡ ¡ALD ¡x ¡PF ¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf Design Traffic volume (v/l/d)
ALD Design voids factor: VF (Vf+Va+Vt)
Basic binder application rate:
Bb
Design binder application rate;
Bd
Step ¡6 ¡– ¡Design ¡binder ¡ applicaMon ¡rate ¡Bd ¡ Bd ¡ ¡= ¡ ¡Bb ¡ ¡+ ¡As ¡ ¡+ ¡Ae ¡
- Round ¡to ¡nearest ¡0.1 ¡l/m2 ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Allowances (L/m2)
- As ¡-‑ ¡Surface ¡texture ¡
– Sand ¡patch ¡texture ¡depth ¡(mm) ¡
- Ae ¡-‑ ¡Aggregate ¡embedment ¡
– Ball ¡penetraMon ¡test ¡ – NegaMve ¡allowance ¡
- AbsorpMon ¡of ¡binder ¡by: ¡
– pavement ¡ – aggregate ¡(not ¡common) ¡
Allowances ¡are ¡cumulaMve ¡
¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Sand patch test – 50cc spread uniformly to calculate texture in mm – determine AS allowance from Table
Aggregate size
- f proposed
seal Measured texture depth (mm) Surface texture allowance (L/ m2) Aggregate size
- f proposed
seal Measured texture depth (mm) Surface texture allowance (L/m2)
Existing: 14, 16 or 20 mm seal Existing: 5 or 7 mm seal
5 or 7 mm
0 to 0.3 Note 1
5 or 7 mm
0 to 0.3 Note 1 0.4 to 0.6 Note 2 0.4 to 0.9 +0.1 0.7 to 0.9 +0.1 1.0 to 1.5 +0.2 1.0 to 1.3 +0.2 1.6 to 2.2 +0.3 1.4 to 1.9 +0.3 2.3 to 3.2 +0.4 2.0 to 2.9 +0.4 >3.2 +0.5 >2.9 +0.5
10 mm
0 to 0.3 Note 1
10 mm
0 to 0.3
- 0.1
0.4 to 0.7 +0.1 0.4 to 0.5 0.8 to 1.1 +0.2 0.6 to 0.7 +0.1 1.2 to 1.8 +0.3 0.8 to 0.9 +0.2 >1.8 Note 3 1.0 to 1.3 +0.3
14 mm
0 to 0.2 Note 1 1.4 to 1.8 +0.4 0.3 to 0.6 +0.1 >1.8 Note 3 0.7 to 0.9 +0.2
14 mm
0 to 0.3
- 0.1
1.0 to 1.4 +0.3 0.4 to 0.5 1.5 to 2.0 +0.4 0.5 to 0.6 +0.1 >2.0 +0.5 0.6 to 0.7 +0.2
Existing: asphalt/slurry surfacing
0.8 to 0.9 +0.3
All
0 to 0.1 1.0 to 1.3 +0.4 0.2 to 0.4 +0.1 1.4 to 1.8 +0.5 0.5 to 0.8 +0.2 >1.8 Note 3 0.9 to 1.4 +0.3
Existing: 10 mm seal
>1.4 +0.4
5 or 7 mm
0 to 0.3 Note 1 Notes: Embedment considerations dominant Specialised pre-treatments may be necessary This treatment might not be advisable depending on the shape and interlock
- f aggregates so alternative treatments (surface enrichment, small
size seal or others) should be considered For application of aggregate sizes greater than 14 mm, adopt allowances applicable to 14 mm aggregate. 0.4 to 0.9 +0.1 1.0 to 1.4 +0.2 1.5 to 2.0 +0.3 2.1 to 2.7 +0.4 >2.7 +0.5
10 mm
0 to 0.3 Note 1 0.4 to 0.7 +0.1 0.8 to 1.1 +0.2 1.2 to 1.7 +0.3 >1.7 Note 3
14 mm
0 to 0.2 Note 1 0.3 to 0.6 +0.1 0.7 to 0.9 +0.2 1.0 to 1.2 +0.3 1.3 to 1.7 +0.4 >1.7 Note 3
Surface ¡texture ¡ allowance ¡takes ¡into ¡ account ¡ ¡
- Exis3ng ¡surface ¡
- Proposed ¡seal ¡
Gives ¡us ¡warnings ¡ about ¡our ¡seal ¡ selec3on ¡ ¡ ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Allowances (L/m2)
- As ¡-‑ ¡Surface ¡texture ¡
– Sand ¡patch ¡texture ¡depth ¡(mm) ¡
- Ae ¡-‑ ¡Aggregate ¡embedment ¡
– Ball ¡penetraMon ¡test ¡ – NegaMve ¡allowance ¡
- AbsorpMon ¡of ¡binder ¡by: ¡
– pavement ¡ – aggregate ¡(not ¡common) ¡
Allowances ¡are ¡cumulaMve ¡
¡
Ae – Aggregate Embedment Allowance
1 2 3 4 1000 2000 3000 4000 5000 Traffic volume (vehicles/lane/day) Ball penetration (mm) Nil
- 0.1 L/m2
See note
- ‑ ¡0.2 ¡l/m2 ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Allowances (L/m2)
- As ¡-‑ ¡Surface ¡texture ¡
– Sand ¡patch ¡texture ¡depth ¡(mm) ¡
- Ae ¡-‑ ¡Aggregate ¡embedment ¡
– Ball ¡penetraMon ¡test ¡ – NegaMve ¡allowance ¡
- AbsorpMon ¡of ¡binder ¡by: ¡
– pavement ¡ – aggregate ¡(not ¡common) ¡
Allowances ¡are ¡cumulaMve ¡
¡
Aggregate shape adjustment: Va Traffic adjustment: Vt
Embedment allowance Existing surface condition allowance Absorption allowance
Basic voids factor: Vf Design Traffic volume (v/l/d)
ALD Design voids factor: VF (Vf+Va+Vt)
Basic binder application rate:
Bb
Design binder application rate;
Bd
Step ¡6 ¡– ¡Design ¡binder ¡ applicaMon ¡rate ¡Bd ¡ Bd ¡ ¡= ¡ ¡Bb ¡ ¡+ ¡As ¡ ¡+ ¡Ae ¡
- Round ¡to ¡nearest ¡0.1 ¡l/m2 ¡
Reality ¡Check ¡
Will ¡this ¡work ¡considering ¡ ¡
- The ¡condi3ons ¡at ¡3me ¡of ¡
placement ¡
- The ¡resources ¡that ¡will ¡be ¡
available ¡
- The ¡traffic ¡stresses ¡
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Double/double Seal Design
Design method applies if both applications applied within 24 hours
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Double/double Seal Design
- First Application (larger aggregate)
– Vf1 reduced as voids are partly filled by smaller aggregate – Solid line in Figure 2.1 & 2.2 (Update to D/D design) – Same adjustments & allowances as single/single design added
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Double/double Seal Design
- Second Application (smaller aggregate)
– Vf2 dotted line in Figure 2.1 & 2.2 (Update to D/D design) – Same process as single/single design – BUT NO ALLOWANCES for
- Surface texture
- Embedment
- Pavement absorption
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Basic Voids Factor Vf for D/D Seal 0 – 500 v/l/d
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Basic Voids Factor Vf for D/D Seal 500 – 15000 v/l/d
Australian ¡Asphalt ¡Pavement ¡Associa3on ¡
Geotextile Reinforced Seals
Design ¡procedure ¡
- 1. Seal ¡design ¡as ¡described ¡
- 2. Add ¡fabric ¡retenMon ¡allowance ¡AR ¡ ¡
¡(for ¡a ¡140g/m2 ¡~ ¡0.9 ¡L/m²) ¡
- 3. ApporMon ¡binder ¡to ¡bond ¡coat ¡
¡Bond ¡coat ¡-‑ ¡0.6 ¡L/m2 ¡
- 4. Second ¡applicaMon ¡of ¡binder ¡ ¡
¡Total ¡minus ¡bond ¡coat ¡applica0on ¡(e.g. ¡ ¡2.8 ¡– ¡0.6 ¡= ¡2.2) ¡
Hot ¡day ¡+ ¡heavy ¡bond ¡coat ¡rate ¡+ ¡traffic ¡on ¡a ¡bare ¡geotex3le ¡
Aggregate spread rate (m²/m³)
- Calculated ¡from ¡ALD ¡of ¡aggregate ¡
- Spread ¡rate ¡(ASR) ¡in ¡m²/m³ ¡
- General ¡work ¡= ¡900/ALD ¡
– varies ¡for ¡traffic ¡and ¡type ¡of ¡binder ¡ – ranges ¡from ¡900/ALD ¡to ¡750/ALD ¡ – in ¡prac3ce, ¡designed ¡to ¡nearest ¡10 ¡m²/m³ ¡
Example of S/S seal design
Site ¡Details ¡
Traffic ¡
- 2 ¡lanes, ¡each ¡3.6m ¡ ¡
- AADT ¡– ¡800 ¡
- % ¡EHV ¡= ¡10% ¡
¡ ExisMng ¡surface ¡ ¡
- Aggregate: ¡10mm ¡
- Texture: ¡1.2mm ¡
- No ¡cracking ¡
Proposed ¡Reseal: ¡14mm ¡ Binder: ¡C170 ¡
Example of S/S seal design
Step ¡1 ¡– ¡Input ¡InformaMon ¡
- Design ¡Traffic ¡
– For ¡2 ¡lanes ¡= ¡½ ¡AADT ¡ – DT ¡= ¡½ ¡x ¡800 ¡= ¡400 ¡v/l/d ¡ – EHV ¡= ¡10% ¡
- Aggregate ¡ ¡
– Crushed ¡ – FI ¡ ¡-‑ ¡22% ¡ – ALD ¡– ¡8.5mm ¡
Example of S/S seal design
Step ¡2 ¡– ¡Determine ¡Vf ¡
Vf ¡= ¡0.18 ¡L/m2/mm ¡
Example of S/S seal design
Step ¡3 ¡– ¡Adjustments ¡for ¡aggregate ¡& ¡traffic ¡
- Va ¡– ¡Table ¡2.1 ¡
– FI ¡– ¡22% ¡ – Va ¡= ¡0 ¡
- Vt ¡– ¡Table ¡2.2 ¡ ¡
– EHV ¡= ¡10% ¡ – Road ¡geometry ¡– ¡ ¡ – ¡Vt ¡= ¡0 ¡ flat, not channelised
Example of S/S seal design
Step ¡4 ¡– ¡Determine ¡design ¡voids ¡factor ¡VF ¡
- VF ¡= ¡ ¡Vf ¡+ ¡Va ¡+ ¡Vt ¡
– Vf ¡= ¡0.18 ¡ – Va ¡= ¡0 ¡ – Vt ¡= ¡0 ¡
VF ¡= ¡0.18 ¡L/m2/mm ¡ Step ¡5 ¡– ¡Calculate ¡basic ¡binder ¡rate ¡ ¡Bb
- Bb = VF x ALD = 0.18 x 8.5
Bb = 1.53 L/m2
Example of S/S seal design
Step ¡6 ¡– ¡Calculate ¡design ¡binder ¡rate ¡Bd ¡
- Bd ¡= ¡ ¡Bb ¡+ ¡As ¡+ ¡Ae ¡
