Pavement Preservation

Overband Crack Seal – ODOT Spec #423 Fog Seal – ODOT “Special Provision” Onyx – ODOT “Special Provision” Chip Seal – ODOT Spec #422 Micro Surfacing – ODOT Spec #421

slide-2
SLIDE 2

Overband Crack Seal – ODOT Spec #423

slide-3
SLIDE 3

Overband Crack Seal

Type 1 – “BLOCKED” with 18% Rubber

  • Routing and “Filling”

Type 2 – “LIQUID” with 5% Polyester Type 3 – “LIQUID” with 7% Polypropylene Type 4 – “BLOCKED” with 2% Polyester

slide-4
SLIDE 4

Overband Crack Seal

Temperature - 45 degrees and rising Width of Crack – 1/4” – 1” Product Thickness – 1/16” – 1/8” Bandwidth - 5” disc installs 4” wide product Pay Item – Pound or Square Yard

slide-5
SLIDE 5

Overband Crack Seal - Blocked

5,000 lbs. / day @ 7 ft. / lb..

slide-6
SLIDE 6

Overband Crack Seal - Liquid

7,000 lbs. / day @ 5 ft. / lb..

slide-7
SLIDE 7

Overband Crack Seal - Bad

slide-8
SLIDE 8

Overband Crack Seal - Optimum

slide-9
SLIDE 9

Overband Crack Seal

City of Columbus, OH

slide-10
SLIDE 10

Overband Crack Seal

When: 2-4 years after new pavement is installed Result: Additional 5 years Pavement Service Life

slide-11
SLIDE 11

Fog Seal – ODOT “Special Provision” “Green Grass and Black Roads”

slide-12
SLIDE 12

Fog Seal

Inexpensive Asphalt Emulsion

  • Diluted 50% with Water

Shot at .1 to .12 gallons / sy “Locks Down” Chip Seals Not Intended for Asphalt Surfaces Pay Item - Square Yard

slide-13
SLIDE 13

Fog Seal

3 Main Concerns Dry Time – Multiple Hours Loss of Friction - Slick Service Life – +/- 1 year

slide-14
SLIDE 14

Fog Seal

slide-15
SLIDE 15

Fog Seal

Caesar Creek State Park, OH

slide-16
SLIDE 16

Onyx – Frictional Mastic Surface Treatment

slide-17
SLIDE 17

Onyx Components

  • Cationic Polymer Modified Asphalt Emulsion

– .25 gallons / sy – Double Application – Both Directions in Each Lane

  • Quality “Fine” Aggregate – Silica
  • Dark Color Enhancers
  • Breaking and Setting Additives - Catalysts
slide-18
SLIDE 18

Onyx

Addressing 3 Main Concerns

Dry Time – 30 to 60 Minutes Loss of Friction – Aggregate Inclusion Service Life – 3 to 4 Years

slide-19
SLIDE 19

Excellent Price Point Fills Pavement Cycle Need

Chip Seal $1.50-$2.25 Fog Seal $0.40-$0.75 Onyx $1.00-1.25 Micro $2.50-$3.25 Ultra Thin $4.00-$4.75 Stand: HMA $5.25-$7.00

*Prices based on Square Yard

slide-20
SLIDE 20

Onyx - Equipment

slide-21
SLIDE 21

Onyx – Side Panel Protection

slide-22
SLIDE 22

Onyx - Handwork

slide-23
SLIDE 23

Onyx - Applications

State, County and Townships

  • High-Volume Priority Shoulders
  • Low-Volume General Mainline
  • Chip Seal “Seal”

Local

  • Low to Medium Volume Residential Streets
  • Parks and Cemeteries
  • Large Commercial Parking Lots
slide-24
SLIDE 24

State, County and Township Roads – “Before”

slide-25
SLIDE 25

State, County and Township Roads – “After”

slide-26
SLIDE 26

Local Residential – “Before”

slide-27
SLIDE 27

Local Residential – “During”

slide-28
SLIDE 28

Local Residential – “After”

slide-29
SLIDE 29

National, State and Local Parks – “Before”

slide-30
SLIDE 30

National, State and Local Parks – “After”

slide-31
SLIDE 31

Chip Seal – ODOT Spec #422

slide-32
SLIDE 32

Chip Seal

Polymerized Asphalt Emulsion .37 - .42 gallons/sy

Anionic – Neg. (-)Charge RS-2 RS-2P HFRS-2P Cationic – Pos. (+) Charge CRS-2 CRS-2P SAM-C

slide-33
SLIDE 33

Chip Seal

Limestone - Porous Slag - Durable Natural Gravel – Economical

Cover Aggregate #9 or ¼” #8 or ½”

slide-34
SLIDE 34

Chip Seal

Two 9-Wheel Rubber Tire Rollers

slide-35
SLIDE 35

Chip Seal – “Little Known Spec Facts”

  • May 1st to September 1st

– 1 month to cure emulsion

  • 50% stone embedment
  • 150 ft. – distributor to chipper
  • 2 roller passes - 3 is ideal
slide-36
SLIDE 36

Chip Seal

Historical Issues

  • Dust
  • Loose Stone
  • Delamination
  • Short Life Expectancy
slide-37
SLIDE 37

Chip Seal

Present Solutions

  • Fog Seal / “Onyx”
  • Line Striping Removal
  • Material Compatibility
  • Polymerization
slide-38
SLIDE 38

Micro Surfacing – ODOT Spec #421

slide-39
SLIDE 39

Micro Surfacing

  • Polymerized Asphalt Emulsion
  • Natural Latex
  • Limestone Aggregate
  • 3/8” to P200’s
  • Breaking and Setting Additives
  • Chemical Break and Cure
  • Portland Cement
  • Cohesiveness
slide-40
SLIDE 40

Micro Surfacing

slide-41
SLIDE 41

Micro Surfacing

slide-42
SLIDE 42

Micro Surfacing

Truck Mount Unit

slide-43
SLIDE 43

Micro Surfacing

Continuous Unit

slide-44
SLIDE 44

Micro Surfacing – Features and Benefits

  • Surface Friction Correction
  • Rut Fill – Cross Slope Correction
  • Arrest Oxidation / Minor Raveling
  • Fast Installation and Cure Time
  • No Berm Material Required
  • ½ the cost of 1 ½” of asphalt
slide-45
SLIDE 45

Micro Surfacing – Surface Prep

  • Quality Patching and Crack Sealing
  • Remove Plastic Markings
  • Remove Grass and Vegetation
  • Cover All Structures
  • Tack Coat - Option
slide-46
SLIDE 46

Micro Surfacing – Protecting Structures

slide-47
SLIDE 47

Micro Surfacing – Surface Course

  • Single Course – 18 lbs. /sy
  • Heavy Single Course – 20 to 24 lbs. / sy
  • Pay Item – Square Yard
slide-48
SLIDE 48

Micro Surfacing – Double Course

  • Level – 14 lbs. / sy
  • Surface - 16 lbs. / sy
  • Pay Item – Square Yard
slide-49
SLIDE 49

Micro Surfacing

Good Candidates:

  • 5-8 Years Old
  • Oxidized
  • Minor Raveling
  • Minor Rutting
  • Good Sub Base
  • Cracks Treated
slide-50
SLIDE 50

Good Micro Surfacing Candidate

slide-51
SLIDE 51

Overband Crack Seal Micro Surfacing – Surface Course

slide-52
SLIDE 52

Polymerized Chip Seal Micro Surfacing – Surface Course

slide-53
SLIDE 53

Base Course Asphalt Micro Surfacing – Surface Course (Tack Coat)

slide-54
SLIDE 54

Micro Surfacing – Quality Control

  • Alignment of each paving pass
  • Surface Texture
  • Properly constructed paving joints
  • Uniform finish of hand work
slide-55
SLIDE 55

Micro Surfacing – Quality Control

  • Alignment of each paving pass
  • Surface Texture
  • Properly constructed joints
  • Uniform finish of hand work
slide-56
SLIDE 56

Micro Surfacing – Quality Control

  • Alignment of each Paving Pass
  • Surface Texture
  • Properly Constructed Joints
  • Transversely
  • Good Quality Hand Work
slide-57
SLIDE 57

Micro Surfacing – Quality Control

  • Alignment of each paving pass
  • Surface Texture
  • Properly constructed joints
  • Longitudinally
  • Uniform finish of hand work
slide-58
SLIDE 58

Micro Surfacing – Quality Control

  • Alignment of each paving pass
  • Surface Texture
  • Properly constructed joints
  • Uniform finish of hand work
slide-59
SLIDE 59

Micro Surfacing – Quality Control

  • Alignment of each paving pass
  • Surface Texture
  • Properly constructed joints
  • Uniform finish of hand work
slide-60
SLIDE 60

Micro Surfacing

ODOT – District 3 I-71

slide-61
SLIDE 61

Micro Surfacing

ODOT – District 6 SR 35

slide-62
SLIDE 62

Micro Surfacing

Delaware County Engineer, OH

slide-63
SLIDE 63

Micro Surfacing

Erie County Engineer, OH

slide-64
SLIDE 64

Micro Surfacing

City of Loveland, OH

slide-65
SLIDE 65

Micro Surfacing

City of Wooster, OH

slide-66
SLIDE 66

Micro Surfacing – Black Aggregate

  • Ontario Trap Rock - 50% of mix
  • Improves Surface Friction
  • Keeps Pavement Darker Longer
  • Better Line Delineation - Safety
  • Helps Melting of Snow (Less Salt)
slide-67
SLIDE 67

Micro Surfacing – Ontario Traprock

Anderson Township, Hamilton County, OH

slide-68
SLIDE 68

Micro Surfacing – Ontario Traprock

Cowan Lake State Park, OH

slide-69
SLIDE 69

ODOT Pavement Preservation Study

2010 Chip Seal and Micro Surfacing Study Thin HMA (< 1 ½”) $66,358/lm 9 Years Micro (4 Lane) $26,350/lm 8 Years Micro (2 Lane) $17,450/lm 9 Years Chip Seal $11,500/lm 3-5 Years
