Split your database

Nicolai Plum Booking.com Database Engineering

Before

2

After

3

Why?

• Size
• Query time, query latency
• … conflicting workloads
• Business or architecture reasons
• Regulatory compliance
• Easier PCI DSS, GDPR compliance, PII...

4

Choosing tables to split out

• Minimise joins
• Maximise gains
• Split out biggest, fastest-growing, busiest, most-

regulated, …

• Size and activity: ps-top
• https://github.com/sjmudd/ps-top
• Design requirements, current system structure
• Based on code analysis, application knowledge

5

ps-top

ps-top 0.7.5 - 18:44:30 db-101 / 5.7.19-log, up 31d 9h 39m 2 Table (table_io_waits_summary_by_table) 44 rows Ops %| Fetch Insert Update Delete|Table Name 13.49 k 50.6%| 99.8% 0.1% 0.1%|bdb.Inventory 6.97 k 26.1%| 2.6% 94.8% 2.5% 0.1%|bdb.Catalogue 1.36 k 5.1%| 50.9% 24.5% 24.5%|bdb.Transaction 963 3.5%| 66.7% 33.3% |bdb.Delivery 597 2.2%| 51.1% 25.3% 23.6% |bdb.Customer 396 1.4%| 4.5% 94.4% 1.0%|bdb.Reviews

6

Application and code

• Application queries must go to different master for some

tables after split

• Code change
• Proxy magic (untested!)
• (almost certainly) Need to change your code
• Try to separate read and write database handles in code
• Try to use application feature switch, A/B experiment

framework, or other runtime new-old switch mechanism

• Implement in your test environment first

7

Joins & code changes

• Writes:
• Scan (statement) binlog
• Preferably get rid of update clauses with joins altogether
• Code analysis
• Reads
• Code analysis
• Query sampling
• Performance_Schema, proxies
• Perfection is difficult, you may have fixes after split

8

Foreign keys, triggers, stored procedures

• Foreign Keys between the schemas will not work
• Remove them and refactor code
• Move relational integrity checks and enforcement to application

layers

• Reflect upon your life and give up using FKs
• Check stored procedures and triggers for use of both

schemas

• Implement triggers and stored procedures on product

schema as necessary

• No Percona Online Schema change during split

9

Replication topology

10

Translation Master

• Schema translation
• replicate-rewrite-db=’Sales->Product'
• Replication filter
• replicate-wild-do-table = Product.Catalogue
• replicate-wild-do-table = Product.Inventory
• replicate-wild-do-table = Product.Reviews

11

Schema name translation

12

Scheme name translation

13

Preparing Translation master

• Make a slave, with binlog enabled
• Shut down MySQL
• Configuration: Add
• skip-slave-start
• replicate-rewrite-db=’sales->product’
• replicate-wild-do-table…

14

Preparing Translation master

• Create new schema (product)
• Rename all tables that are being split to the new

schema

• Drop old schema (sales) from translation master
• Start replication slave
• Remove skip-slave-start
• If replication stops with missing table errors, find the

bad query, fix up (skip) or make a new translation master again

15

Preparing new replication chain

• Clone the translation master to new

(product) master

• Remove the database translate and

replication filter statements

• Clone more slave databases as needed

16

Client connections

• Sales clients
• Write connection to

sales master

• Read connection to

sales slaves

• Product clients
• Write connection to

sales master

• Read connetion to

product slaves

17

Clients

18

So, how do clients see it?

• Sales clients
• Write sales schema in

sales master

• Read sales schema in

sales slaves

• Product clients
• Write sales schema in

sales master

• Read product schema

in product slaves

19

Better client access

• Create a view on the sales master of the

tables in a product schema

• Simple view is updatable, so UPDATE/

INSERT/DELETE succeed

• product client code can be changed to use

new schema name before split

• Change product clients to use product on

sales master before split

20

Schemas with views

21

Creating views

• Sys schema tool

use sys; call create_synonym_db(’sales', ’product');

• Cannot handle views in sales
• View of view is not possible
• product views must be built on the same real sales tables

as sales views

• Drop views of tables not moving
• Or create database product then

create view…

22

Views on slaves also

• Updates are executed properly in SBR
• Slave can be promoted to master
• Using Orchestrator or similar

23

So, how do clients see it now?

• Sales clients
• Write sales schema in

sales master

• Read sales schema in

sales slaves

• Product clients
• Write product schema

in sales master

• Read product schema

in product slaves

24

Decreased redundancy

• Failover of the translation master is hard
• Keep the intermediate stage short-lived
• Probably best to prepare to repoint slaves

in a hurry if translation master dies

• Keep sufficient capacity in parent chain for

total load

25

Grants

• MySQL users of the sales tables will need

privileges on product tables on the sales master

• Separate grants for sales and product

makes the split easier and safer

• Grants (mysql schema) do not replicate

through translation master

• product master will need matching grants

26

Client database server configuration

• Need a way to change server name

quickly

• DNS CNAME or A record
• Preferably without application restart

27

Client access while split is ongoing

28

?

Choice

• Disconnect ALL

product clients from sales master BEFORE connecting to product master

• More downtime
• More data integrity
• Allow some product

clients to connect to product master while

• thers still use sales

master

• Less downtime
• Less data integrity

29

Choice

• Disconnect first
• No chance of conflicting

transactions

• Auto-increment counter

columns

• Complex less-

understood application

• Low risk appetite
• Lower cost of downtime
• Disconnect later
• Some chance of

conflicting transactions

• Fixed or external counter

and id sources

• More-understood

application

• Higher risk appetite
• High cost of downtime

30

Disconnect first

• Disable product client access to sales master – use

separate user grants if possible, lock the user

• Kill all connections from product clients
• Wait for translation master replication pointer to catch

up past the point where product clients were blocked

• Stop replication on the translation master
• Change product client configuration to use product

master

• (going back is now hard)

31

Disconnect first

32

Disconnect first

33

Disconnect first

34

Disconnect later

• Change product client configuration to use product master
• Wait for product clients to make new connections to product

master

• Disable product client access to sales master – use separate

user grants if possible, lock the user

• Kill all connections from product clients
• Wait for translation master replication pointer to catch up
• Stop replication on the translation master
• (going back is now hard)

35

Disconnect later

36

Disconnect later

37

Disconnect later

38

After split

39

Cleanup

• Remove translation master
• Drop views and grants for product on the

sales master

• Rename, then drop tables from the sales

master

40

Final state

41
