Speeding up Asset Connectivity and Management by EdgeLink

Scott Sun Wireless sensing & iGateway, Advantech IIOT

Paradigm shift—Device as a Service

Business Transformation Hardware Service Higher

• Automation
• Digitalization
• Systematism

Batter

• Post service
• Advance function
• Product offer

The main problem of the current equipment maker and system integrator is how to find the new business model and enlarge the revenue with low risk. Remote Connection Project upload/download Configuration Phase I Phase II Phase III Phase IV Eco-partner / Ecosystem Equipment management Data analysis Interconnection with PLM / CRM / ERP / MES Real time status monitoring Alarm management

Multi-site Operation Operation & maintenance management

Water pump station Smart City

Equipment and operations magt. Maintenance services Big data operation supervision Lease sales operation mode Energy & Environment

Water Treatment Integrated energy Distributed PV Water Pump Generator Rent Water station

Digital transformation for Equipment industry

• peration and maintenance

From Edge Intelligent Device to Cloud without Coding !

Connected by

Edge DAQ & Protocol Gateway

 Easy to Get Data From Field-site

Data connectivity Data processing Data publish service Public cloud service Private cloud service 3rd party Add-on service

• WISE-PaaS
• Azure/AWS/Cumulocity
• OPC-UA/MQTT
• DNP3/IEC-60870-5-104
• ODBC/JDBC
• FTP
• 阿里/百度

Remote monitoring & management

• Device management
• OTA/FOTA
• Wireless communication checking
• Power management

Data Framework

• Sensor data buffer
• Store and forward

Edge Intelligent

• IEC-61103-3
• Event Manager
• Scheduling
• Logical Data Flow
• Port mapping(NAT)
• Data interface
• AI inference engine

Security

Secure boot Secure chip White list Backup/ Recovery Additional services Additional services Additional services MODBUS PLC/CNC Meter Database/ OPC Sensing 3rd party device 3rd party device 3rd party device

Web Visualization

• Remote access with standard

browser

• ƒ

Support HTTPS by SSL

• ƒ

Online monitoring for system status and all I/O channel.

• Support FOTA, OTA

SCADA based facility monitoring system

Edge Intelligent Communication SCADA Server

• Unified the protocol at field site

RS-485

Chamber

• ECU-1000 series with EdgeLink
• Flexible connection interface (LAN, RS-232/485,

Wireless)

• SDK for third party engagement
• Industrial protocol support

Temperature controller Temp./Humility Sensor Pressure Sensor leakage detection

Chamber

LAN

Web Visualization

• Remote access with standard

browser

• ƒ

Support HTTPS by SSL

• ƒ

Online monitoring for system status and all I/O channel.

• Support FOTA, OTA

SCADA based power consumption monitoring system

Edge Intelligent Communication SCADA Server

IEC-60870-5-104

• Unified the protocol at field site
• IEC-6870-5-104
• Time and data sync by 104 protocol

RS-485 Smart Meter Smart Meter DL/T 645 DLMS(IEC-62056-21)

• ECU-1000 series with EdgeLink
• Flexible connection interface (LAN/Wireless)
• SDK for third party engagement
• Industrial protocol support (Serial/TCP)

Web Visualization

• Remote access with standard

browser

• ƒ

Support HTTPS by SSL

• ƒ

Online monitoring for system status and all I/O channel.

• Support FOTA, OTA

IOT based power consumption monitoring system

Edge Intelligent Communication RS-485 Smart Meter Smart Meter DL/T 645 DLMS(IEC-62056-21)

• Store and forward
• High reliability connection by wireless check
• SDK for third party engagement
• Industrial protocol support (Serial/TCP)

IED Cloud Service

• Unified the protocol at field site
• MQTT for public cloud service
• Lightweight IOT protocol

Successful story：Energy monitoring in airport

• Performance monitoring
• Optimization
• Energy saving control

 Acquisition, local storage and control, communication all-in-

• ne compact device

 Direct to Cloud w/o gateway  Support LwM2M

Commu nication

LwM2M

Cooling tower online monitoring

Field site Edge Intelligence Cloud

Contents

Integrated Management from all aspects

Equipment Facilities Site

• Machines Online

 Abnormal Event / Alarm  Overall Equipment Effectiveness

• Overall Operation Stats

 Power consumption  Operation efficiency

• High Scalability

 Grouped management  Discrete Devices

Portal configuring snapshots

Edit Organization Setup Edge Connection Configure Object

Co-Creating the Future

• f the IoT World

Co-Creating the Future

• f the IoT World
