Speculative Taint Tracking (STT TT): A Comprehensive Protection for - - PowerPoint PPT Presentation
Speculative Taint Tracking (STT TT): A Comprehensive Protection for Speculatively Accessed Data JIYONG YU, , MENGJIA YAN, ARTEM KHYZHA*, ADAM MORRISON*, JOSEP TORRELLAS, CHRISTOPHER W. FLETCHER UNIVERSITY OF ILLINOIS AT URBANA-CHAMPAIGN
JIYONG YU, , MENGJIA YAN, ARTEM KHYZHA*, ADAM MORRISON*, JOSEP TORRELLAS, CHRISTOPHER W. FLETCHER
UNIVERSITY OF ILLINOIS AT URBANA-CHAMPAIGN ∗TEL AVIV UNIVERSITY
1
Introduction Speculative Taint Tracking Evaluation Conclusion
2
2
Introduction Speculative Taint Tracking Evaluation Conclusion
// Spectre Variant 1 if (addr < N) { // speculation // access instruction spec_val = load [addr]; // covert channel load [spec_val]; }
Speculation starts
3
Introduction Speculative Taint Tracking Evaluation Conclusion
// Spectre Variant 1 if (addr < N) { // speculation // access instruction spec_val = load [addr]; // covert channel load [spec_val]; }
3
*: Kiriansky, Vladimir, et al. "DAWG: A defense against cache timing attacks in speculative execution processors." MICRO-51, 2018.
Speculation starts Speculative access instruction* accesses secret
Introduction Speculative Taint Tracking Evaluation Conclusion
// Spectre Variant 1 if (addr < N) { // speculation // access instruction spec_val = load [addr]; // covert channel load [spec_val]; }
3
*: Kiriansky, Vladimir, et al. "DAWG: A defense against cache timing attacks in speculative execution processors." MICRO-51, 2018.
Speculation starts Creates a covert channel to leak secret
Introduction Speculative Taint Tracking Evaluation Conclusion
Speculative access instruction* accesses secret
// Spectre Variant 1 if (addr < N) { // speculation // access instruction spec_val = load [addr]; // covert channel load [spec_val]; }
addr = N+1
3
*: Kiriansky, Vladimir, et al. "DAWG: A defense against cache timing attacks in speculative execution processors." MICRO-51, 2018.
Speculation starts Speculation ends - misspeculation! Creates a covert channel to leak secret
Introduction Speculative Taint Tracking Evaluation Conclusion
Speculative access instruction* accesses secret
// Spectre Variant 1 if (addr < N) { // speculation // access instruction spec_val = load [addr]; // covert channel load [spec_val]; }
Speculation starts Speculation ends - misspeculation! Creates a covert channel to leak secret
3
*: Kiriansky, Vladimir, et al. "DAWG: A defense against cache timing attacks in speculative execution processors." MICRO-51, 2018.
Introduction Speculative Taint Tracking Evaluation Conclusion
Speculative access instruction* accesses secret
4
Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
4
Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
4
Creates a covert channel? Input
a secret? Requires protection? Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
prediction
Speculation starts
4
Creates a covert channel? Input
a secret? Requires protection? Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
4
Creates a covert channel? Input
a secret? Requires protection? Yes No No Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
4
Creates a covert channel? Input
a secret? Requires protection? Yes No No No Yes No Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
4
Creates a covert channel? Input
a secret? Requires protection? Yes No No No Yes No Yes Yes Yes Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
Non-speculative
4
Correct Prediction! Creates a covert channel? Input
a secret? Requires protection? Yes No No No No No Yes No No Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
Non-speculative
Correct Prediction!
4
Creates a covert channel? Input
a secret? Requires protection? Yes No No No No No Yes No No Introduction Speculative Taint Tracking Evaluation Conclusion
“Sufficient for security: prevent secrets from reaching covert channels”
if (addr < N) { // access instruction spec_val = load [addr]; // simple arithmetic spec_val = spec_val + 4; // cache/mem covert channel load [spec_val]; } ……
Speculation starts
Squashed!
4
Incorrect Prediction! Creates a covert channel? Input
a secret? Requires protection? Yes No No No Yes No Yes Yes Yes Introduction Speculative Taint Tracking Evaluation Conclusion
5
Secret
(speculatively accessed data)
Covert channels
Introduction Speculative Taint Tracking Evaluation Conclusion
5
Secret
(speculatively accessed data)
Covert channels
Introduction Speculative Taint Tracking Evaluation Conclusion
5
Secret
(speculatively accessed data)
Covert channels
What are the covert channels?
Introduction Speculative Taint Tracking Evaluation Conclusion
5
Secret
(speculatively accessed data)
Covert channels
What are the covert channels? A new classification to understand covert channels in speculative machines
Introduction Speculative Taint Tracking Evaluation Conclusion
5
Secret
(speculatively accessed data)
Covert channels
What are the covert channels? How to identify all the secrets? A new classification to understand covert channels in speculative machines
Introduction Speculative Taint Tracking Evaluation Conclusion
What are the covert channels? How to identify all the secrets? A new classification to understand covert channels in speculative machines A new taint/untaint mechanism to track secrets in hardware
5
Secret
(speculatively accessed data)
Covert channels
Introduction Speculative Taint Tracking Evaluation Conclusion
6
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels Implicit channels
7
Introduction Speculative Taint Tracking Evaluation Conclusion
Explicit branches Implicit branches Leak on prediction Leak on resolution Leak on prediction Leak on resolution
Covert channels Explicit channels Implicit channels Explicit branches Implicit branches Leak on prediction Leak on resolution
New!
Leak on prediction Leak on resolution
7
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage
load [secret];
8
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
8
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
secret = load [addr]; if (secret == 1) load [0x00];
8
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute Examples: branch/jump instructions
8
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
8
Explicit branches
Examples: Branch/jump instructions
New!
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
8
Explicit branches
Examples: Branch/jump instructions
Leak on prediction Leak on resolution
New!
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: The predictor state becomes a function of secret
// Visibility point … … … … if ( secret ) … … … … if ( public ) load [0x00]; else load [0x10];
9
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: The predictor state becomes a function of secret
Resolve and update branch predictor // Visibility point … … … … if ( secret ) … … … … if ( public ) load [0x00]; else load [0x10]; idx | taken Branch Predictor Unit (BPU)
9
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: The predictor state becomes a function of secret
idx | taken Branch Predictor Unit (BPU) // Visibility point … … … … if ( secret ) … … … … if ( public ) load [0x00]; else load [0x10];
9
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
10
Explicit branches
Examples: Branch/jump instructions
Leak on prediction Leak on resolution
New!
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: The resolution of a mis-speculation triggers a pipeline squash and alternation of control flow
if (secret) { y++; } z = load [0x00]
11
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: The resolution of a mis-speculation triggers a pipeline squash and alternation of control flow
if (secret) { y++; } z = load [0x00]
secret != prediction → squash → load executes twice!
11
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
12
Explicit branches
Examples: Branch/jump instructions
Implicit branches
Example: Store-load pairs
Leak on prediction Leak on resolution
New!
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels:
Secret inputs are directly leaked by operand-dependent hardware resource usage Examples: memory loads data-dependent arithmetic
Implicit channels:
Secret inputs are indirectly leaked by how (or that) one or several instructions execute
Explicit branches
Examples: Branch/jump instructions
Implicit branches
Example: Store-load pairs
Leak on prediction Leak on resolution Leak on prediction Leak on resolution
12
New!
Introduction Speculative Taint Tracking Evaluation Conclusion
store [secret] = foo; bar = load [0x00];
13
Introduction Speculative Taint Tracking Evaluation Conclusion
Cause: Non-control flow instructions create branch-like behaviors.
Cause: Non-control flow instructions create branch-like behaviors.
if (secret == 0x00) { forward from store queue } else { cache_load [0x00] }
Can be thought as:
store [secret] = foo; bar = load [0x00];
13
Introduction Speculative Taint Tracking Evaluation Conclusion
14
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
STT taints:
1) Output of speculative access instructions (a)
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
STT taints:
1) Output of speculative access instructions (a) 2) Output of instructions with tainted inputs (b)
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
STT taints:
1) Output of speculative access instructions (a) 2) Output of instructions with tainted inputs (b)
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
Resolved! speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
STT taints:
1) Output of speculative access instructions (a) 2) Output of instructions with tainted inputs (b)
STT untaints when:
1) A speculative access instruction becomes non- speculative (a)
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
Resolved! speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Basic idea: taint all the secrets
STT taints:
1) Output of speculative access instructions (a) 2) Output of instructions with tainted inputs (b)
STT untaints when:
1) A speculative access instruction becomes non- speculative (a) 2) An instruction has all its input untainted (b)
if (addr < N) { // access instruction a = load [addr]; // simple arithmetic b = a + 4; // cache/mem covert channel load [b]; } …… …… ……
Resolved! speculative
15
Introduction Speculative Taint Tracking Evaluation Conclusion
Instructions forming explicit channels
Instructions forming implicit channels
16
Introduction Speculative Taint Tracking Evaluation Conclusion
Explicit channels:
17
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels Implicit channels Leak on prediction Leak on resolution
Explicit channels:
Implicit channels:
17
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels Implicit channels Leak on prediction Leak on resolution
Explicit channels:
Implicit channels:
17
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels Implicit channels Leak on prediction Leak on resolution
Explicit channels:
Implicit channels:
17
Introduction Speculative Taint Tracking Evaluation Conclusion
Covert channels Explicit channels Implicit channels Leak on prediction Leak on resolution
18
Introduction Speculative Taint Tracking Evaluation Conclusion
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative
19
Introduction Speculative Taint Tracking Evaluation Conclusion Delay execution!
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative
19
Introduction Speculative Taint Tracking Evaluation Conclusion Delay execution!
Observation: All instructions turn non- speculative in-order
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative
19
Introduction Speculative Taint Tracking Evaluation Conclusion Delay execution!
Observation: All instructions turn non- speculative in-order
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative
19
→ resolved!
Introduction Speculative Taint Tracking Evaluation Conclusion Delay execution!
Observation: All instructions turn non- speculative in-order
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative
19
→ resolved!
Introduction Speculative Taint Tracking Evaluation Conclusion Execute!
Observation: All instructions turn non- speculative in-order Each instruction tracks the “youngest access instruction” it depends on -- “Youngest Root
YRoT of 7 is 4
19
Introduction Speculative Taint Tracking Evaluation Conclusion
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative Execute!
20
Introduction Speculative Taint Tracking Evaluation Conclusion
No change to the memory subsystem!
Security definition:
Arbitrary speculative execution can only leak retired register file state (not arbitrary program memory)
To prove it: STT enforces a non-interference property w.r.t speculatively accessed data The link to the detailed formal analysis and security proof is in the paper
21
Introduction Speculative Taint Tracking Evaluation Conclusion
Consider control-flow speculation Consider all types of speculation
22
Introduction Speculative Taint Tracking Evaluation Conclusion
40.2% 8.5% 182.0% 14.5%
0.0% 20.0% 40.0% 60.0% 80.0% 100.0% 120.0% 140.0% 160.0% 180.0% 200.0%
DelayExecute STT DelayExecute STT
Perf Overhead over Insecure Baseline
STT Blocks leakage of speculatively accessed data over any uarch covert channels with: 1) High performance 2) Provable security protection 3) No software change; No memory subsystem change
23
Introduction Speculative Taint Tracking Evaluation Conclusion
STT Blocks leakage of speculatively accessed data over any uarch covert channels with: 1) High performance 2) Provable security protection 3) No software change; No memory subsystem change
23
Introduction Speculative Taint Tracking Evaluation Conclusion
69
A powerful attacker who:
Introduction Threat model Speculative Taint Tracking Evaluation Conclusion
70
71
72
Introduction Threat Model Speculative Taint Tracking Evaluation Conclusion
Introduction Threat model Speculative Taint Tracking Evaluation Conclusion
73
A new classification of covert channels in HW ➔ Specify instructions with explicit or implicit channels
74
Executes all instructions w/ untainted inputs Executes non-transmit instructions w/ tainted inputs Predicts explicit/implicit branches w/ tainted predicates
Introduction Speculative Taint Tracking Security Definition Evaluation Conclusion
81
Executes all instructions w/ untainted inputs Executes non-transmit instructions w/ tainted inputs Predicts explicit/implicit branches w/ tainted predicates Delay executing transmit instructions w/ tainted inputs Delay resolution/predictor updates of explicit/implicit branches w/ tainted predicates
Block explicit channel Introduction Speculative Taint Tracking Security Definition Evaluation Conclusion
82
Executes all instructions w/ untainted inputs Executes non-transmit instructions w/ tainted inputs Predicts explicit/implicit branches w/ tainted predicates Delay executing transmit instructions w/ tainted inputs Delay resolution/predictor updates of explicit/implicit branches w/ tainted predicates
Block explicit channel Block implicit channel TODO: spend a little bit more time on this slide? TODO: what is transmit instruction? Introduction Speculative Taint Tracking Security Definition Evaluation Conclusion
83
(YRoT)
For each (transmit) instruction: Input is secret YRoT is still speculative Visibility point is ahead of YRoT
1) branch 2) a = load [0x00] // YRoT = -1 3) branch_1 4) b = load [0x04] // YRoT = -1 5) branch 6) c = a + b // YRoT = max(2, 4) = 4 > 1 7) d = load [c] // YRoT = 4 > 1
program order
89
(YRoT)
For each (transmit) instruction: Input is secret YRoT is still speculative Visibility point is ahead of YRoT
1) branch_0 2) a = load [0x00] // YRoT = -1 3) branch_1 4) b = load [0x04] // YRoT = -1 5) branch_2 6) c = a + b // YRoT = max(2, 4) = 4 > 3 7) d = load [c] // YRoT = 4 > 3
program order
90
(YRoT)
For each (transmit) instruction: Input is secret YRoT is still speculative Visibility point is ahead of YRoT
1) branch_0 2) a = load [0x00] // YRoT = -1 3) branch_1 4) b = load [0x04] // YRoT = -1 5) branch_2 6) c = a + b // YRoT = max(2, 4) = 4 < 5 7) d = load [c] // YRoT = 4 < 5
program order
VP
91
Observation: All instructions turn non-speculative in-order Each instruction tracks the “youngest access instruction” it depends on -- “Youngest Root of Taint” (YRoT) For each instruction: Input is tainted Input depends on some speculative access instruction YRoT is still speculative Visibility point is ahead of YRoT
19
Introduction Speculative Taint Tracking Evaluation Conclusion YRoT of 7 is 4
1) branch 2) a = load [0x00] 3) branch 4) b = load [0x04] 5) branch 6) c = a + b 7) load [c] program order
speculative Visibility point (VP) Execute! TODO: remove this
Arbitrary speculative execution can
(not arbitrary program memory)
93
Arbitrary speculative execution can
(not arbitrary program memory)
The Universal Read Gadget == many Spectre variants (1, 3, 4, ..), MDS attacks, Meltdown, etc.
94
STT enforces a non-interference property w.r.t speculatively accessed data:
time Retired Will eventually retire Will eventually squash time = t Processor state @ t
95
STT enforces a non-interference property w.r.t speculatively accessed data:
time Retired Will eventually retire time = t Processor state @ t Will eventually squash
96
