Mitglied der Helmholtz-Gemeinschaft The STT Geometry Description in PANDAroot Thanachot Nasawasd 05 June 2018 Outline Straw Tube Tracker STT in Pandaroot (curent model) STT modeling I. Tubes II. Straw tube arangment III.

slide-1
SLIDE 1

Mitglied der Helmholtz-Gemeinschaft

Thanachot Nasawasd

The STT Geometry Description in PANDAroot

05 June 2018

slide-2
SLIDE 2

2

  • Straw Tube Tracker
  • STT in Pandaroot (curent model)
  • STT modeling
  • I. Tubes
  • II. Straw tube arangment
  • III. Mechanical frame
  • IV. Gas systems
  • Outlooks

Outline

05 June 2018 The STT Geometry Description in PANDAroot

slide-3
SLIDE 3

3

Straw Tube Tracker (STT)

STT measure the particle momentum from the reconstructed trajectory and the specific energy loss of the particles

05 June 2018 The STT Geometry Description in PANDAroot

slide-4
SLIDE 4

4

Straw Tube Tracker (STT)

  • Straw Tubes
  • Mechanical Frame
  • Gas system

05 June 2018 The STT Geometry Description in PANDAroot

slide-5
SLIDE 5

5

STT in PANDAroot: curent model

  • Gases in cylindrical shape
  • Wires

Differences from real STT

  • Tube wall and end-caps
  • Mechanical frame
  • Gas system
  • Tube arrangement

05 June 2018 The STT Geometry Description in PANDAroot

slide-6
SLIDE 6

6

  • I. Tubes
  • II. Straw tube arangment
  • III. Mechanical Frame
  • IV. Gas system

STT Modeling

05 June 2018 The STT Geometry Description in PANDAroot

slide-7
SLIDE 7

7

  • I. Tube

STT Modeling: Tube

  • Film tube
  • End plug
  • Electric contact
  • Wire
  • Crimp pin
  • Fixation ring
  • Gases

~ 10 mm

Tube in PANDAroot The prototype

05 June 2018 The STT Geometry Description in PANDAroot

slide-8
SLIDE 8

8

Film tube The thin Mylar layer (27 um) is coated with AL (0.03 um) Wire Crimp pin The wire is made from a gold-plated tungsten-rhenium

  • Ignore the coated gold layer

The crimp pin is made of copper, holding the wire

STT Modeling: Tube

05 June 2018 The STT Geometry Description in PANDAroot

slide-9
SLIDE 9

9

  • Fixation ring

End plug End plug is made from Acrylonitrile butadiene styrene(ABS).

  • In the simulation we use the sharp edges instead of smooth edges.

Fixation ring is made from PVC.

STT Modeling: Tube

slide-10
SLIDE 10

10

Electric contact

  • Electric contact is made from a gold-plated copper-beryllium.
  • In PANDAroot we use a ring shape instead of spring

and ignore the coated gold layer.

STT Modeling: Tube

05 June 2018 The STT Geometry Description in PANDAroot

slide-11
SLIDE 11

11

  • Gases

Mixed gases Ar 90% / CO2 10%

STT Modeling: Tube

05 June 2018 The STT Geometry Description in PANDAroot 05 June 2018 The STT Geometry Description in PANDAroot

slide-12
SLIDE 12

12

  • II. Straw tube arangment

STT Modeling: Straw tube arrangement

~410

  • The STT detector consists of 4576 tubes arranged in 29 layers.

29 layers ~160

05 June 2018 The STT Geometry Description in PANDAroot

slide-13
SLIDE 13

13

Parallel straw

STT Modeling: Straw tube arrangement

  • The straw are skewed relative to

the aligned straws in the same sector by a small angle of +2.9 ◦ and −2.9 ◦.

  • The straw are parallel with the

beam axis, to detect radial positions. Skewed straw

05 June 2018 The STT Geometry Description in PANDAroot

slide-14
SLIDE 14

14

Tubes Length

1400 mm

1185 mm 985 mm 785 mm 385 mm 785 mm 585 mm 185 mm

The border region of each skewed layer

STT Modeling: Straw tube arrangement

05 June 2018 The STT Geometry Description in PANDAroot

slide-15
SLIDE 15

15

STT Modeling: Straw tube arrangement

1 2 3 4 5 6 Group 1-6

05 June 2018 The STT Geometry Description in PANDAroot

slide-16
SLIDE 16

16

STT Modeling: Straw tube arrangement

1 2 3 4 5 6 Sector 1 Sector 2 Flip

05 June 2018 The STT Geometry Description in PANDAroot

slide-17
SLIDE 17

17

STT Modeling: Straw tube arrangement

s1 s2 s3 s4 s5 s6 s1 s2 s3 s4 s5 s6 1 2

05 June 2018 The STT Geometry Description in PANDAroot

slide-18
SLIDE 18

18

  • III. Mechanical Frame
  • In PANDAroot
  • Model
  • Prototype

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: Mechanical Frame

slide-19
SLIDE 19

19

  • III. Mechanical Frame
  • Stainless Frame
  • Gas pipe holder
  • Carbon-fiber tube

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: Mechanical Frame

slide-20
SLIDE 20

20

Stainless Frame

  • In PANDAroot
  • Model

Complicated shape Smooth edges

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: Mechanical Frame

slide-21
SLIDE 21

21

Gas pipe holder

Stainless ABS plastic

Smooth edge

  • In PANDAroot
  • Model

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: Mechanical Frame

slide-22
SLIDE 22

22

  • The inner and outer surfaces of STT will be covered by a composite material,

consisting of a 1 mm Rohacell layer with a 0.17 mm carbon fiber.

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: Mechanical Frame

slide-23
SLIDE 23

23

  • IV. The gas system

Stainless-steel pipe Thermoplastic tubes (capillaries) *** Thermoplastic tubes are connected to the individual straws.

  • In PANDAroot

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: The gas system

slide-24
SLIDE 24

24

  • IV. The gas system

4 mm

  • Stainless-steel pipe

Curved pipe

  • Model
  • In PANDAroot

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: The gas system

slide-25
SLIDE 25

25

  • IV. The gas system
  • We use the plate shape instead of the

small thermoplastic tubes. Thermoplastic tubes in PANDAroot

05 June 2018 The STT Geometry Description in PANDAroot

STT Modeling: The gas system

slide-26
SLIDE 26

26

Outlooks

Digitization

  • Straw number
  • ADC deposit energy
  • Time Over Threshold
  • Waveform

Local Reconstruction

  • Position
  • Energy
  • Time

05 June 2018 The STT Geometry Description in PANDAroot 05 June 2018 The STT Geometry Description in PANDAroot
