SPECIFICATION General specs 19,22 m / 63 1 LOA : 18,30 m / 60 Hull length 17,62 m / 578 Waterline length 5,48 m / 19 Max beam Light displacement 24 150 kg 2,80 m / 92 Draft

slide-1
SLIDE 1
slide-2
SLIDE 2

6

SPECIFICATION

  • LOA :

19,22 m / 63’’ 1

  • Hull length

18,30 m / 60’’

  • Waterline length

17,62 m / 57’’8

  • Max beam

5,48 m / 19’’

  • Light displacement

24 150 kg

  • Draft (mixed keel)

2,80 m / 9’’2

  • Keel weight (mixed keel) 6 500 kg (option)
  • Fuel tank capacity

830 L / 219 gal

  • Water tank capacity

780 L / 206 gal

  • Engine power

180 cv / 180 hp

  • Sail area

184m2 / 1 980 ft2

  • Mainsail

104m2 / 1 119 ft2

  • Genoa

80m2 / 861 ft2

  • I

23,6 m / 77’’5

  • J

6,25m / 20’’5

  • P

23,30m / 76’’5

  • E

7,20m / 23’’6 General specs Sails dimensions Designer

  • Felci Yachts Design
slide-3
SLIDE 3

8

slide-4
SLIDE 4

9

KEY POINTS : EXTERIOR

Innovative cockpit

  • Confort
  • Orientation of elements ( bed, barbecue, sits, table)

Easy circulation on deck oboard

  • From the cockpit to front deck
  • On the wide and flat side decks

Easy to sail

  • Easy manoeuvering from Helmsman position
  • Possible single handling

Pure design

  • Monobloc structure
  • Clear deck plan – (hidden haylards)
  • Dufour signature : curved hull line – lateral porthole

« half butter fly »

slide-5
SLIDE 5

10

KEY POINTS : EXTERIOR

Sun Bath area Helmsman area 2 Helmsman area 1 Guest /confort area Sun bath area

slide-6
SLIDE 6

11

5,75m 0,62 m 1,62m 0,62 m 2,89 m 0,79 m 0,79 m

slide-7
SLIDE 7

12

slide-8
SLIDE 8

14

KEY POINTS : EXTERIOR

D530

Half Butterfly porthole

  • Dufour’s signature

Roof plexiglass

  • One molded plexiglass
slide-9
SLIDE 9

15

KEY POINTS : EXTERIOR

D61

Large sunbed

  • (dimensions)

Convertible into a table

  • (dimensions)
slide-10
SLIDE 10

16

KEY POINTS : EXTERIOR

D61

GRP bulwark

  • Bulwark are no longer made with wood elements

= less maintenance

  • Bulwark integrated into the hull.
  • Smart integrated courtesy lights

Standard on this market (60 ‘)

  • On the Dufour 61 the link between

the hull and the deck is fully hidden (the teak is overpassing it)

slide-11
SLIDE 11

17

KEY POINTS : EXTERIOR

1 3 2 1

Modern shaped plexiglass

  • ffers a natural light inside

Bright roof

2

  • Carbon Arch
  • Better confort : clew at the back
  • f the boom for less pressure
  • Clear cockpit and entrance

Arch

3

Large side decks, for crew confort and manoeuvring

Side decks

1

slide-12
SLIDE 12

18

KEY POINTS : EXTERIOR

1

Recessed halyards running back below the deck into the comings – accessible from helmstation

Halyard

2

New large sunbed Convertible into table + 2 long seats

Sun bed

3

Full secured cockpit on both side

Safety feature

1 2 3 4

Easy access to the garage area

Garage access

4

slide-13
SLIDE 13

19

KEY POINTS : EXTERIOR

1

Easier circulation / communication between cockpit and side-deck

Large step

2

To offer natural light into the aft cabins

Large window

3

Recessed halyards running back below the deck into the comings – accessible from helmstation

Halyard

1 2 3

slide-14
SLIDE 14

20

KEY POINTS : EXTERIOR

1

Large seats for helmstation for a better confort while sailing

Helmsman

2

Deep and large seats for the guests

Guest area

1 1 2

slide-15
SLIDE 15

21

slide-16
SLIDE 16

22

KEY POINTS : EXTERIOR

1

Folding BBQ cover

2 3

2,8 mt tender garage – 8,5 m2 (to confirm ) Easy access : From the aft platform & the cockpit ( port and starboard access to confirm )

Garage

1 2 3 4

Sink & BBQ

4

Folding step

Famous Grand Large feature, cook and keep sharing with guests ( same direction)

slide-17
SLIDE 17

23

KEY POINTS : EXTERIOR Folding ladder Integrated hydraulic gangway

  • Remotely controled
  • Stainless steel
slide-18
SLIDE 18

24

KEY POINTS : EXTERIOR

2

Dimensions 2,8 m // 8m² 2 access from the cockpit Easy access to lifecraft

Garage

3

Large steps

1

Cockpit Shower

1 3 4

Hydraulic system Dimensions ?

Aft Platform

2 4

slide-19
SLIDE 19

25

Key points

Interior - Layouts

slide-20
SLIDE 20

26

LAYOUTS

Forward Galley Aft Galley

3 cabins + pullman 3 heads 3 cabins Complete galley 3 heads 2 double cabins + 1 guest cabin + 1 crew cabin heads 4 head 1 L shape sofa & adjustable table + 1 U shape sofa 1 bench to either convert the sofa in bed or ad a bench to the table

slide-21
SLIDE 21

27

Key points

Interior- Forward galley layout

slide-22
SLIDE 22

28

KEY POINTS : INTERIOR Natural light Comfort

Built and think to welcome guests in the very best conditions

2 Interior layouts

Optimized for different use

  • Forward galley
  • Aft galley
  • Saloon positioned in the beamier part of

the boat

slide-23
SLIDE 23

29

KEY POINTS : INTERIOR – Forward galley layout

GUEST CABIN HEAD SALOON OPEN forward GALLEY OWNER CABIN CREW CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Version 1 : Forward galley + pullman

PULLMAN CABIN

slide-24
SLIDE 24

30

GUEST CABIN HEAD SALOON OPEN GALLEY OWNER CABIN CREW CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Version 1 : forward galley + pullman

PULLMAN CABIN

160x200 160x200 70x200

KEY POINTS : INTERIOR – forward galley layout

2,45 m 1,65m 2 m 1,75m 1,6m

slide-25
SLIDE 25

31

GUEST CABIN HEAD SALOON FULL OPEN GALLEY OWNER CABIN CREW CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Version 2 : Complete forward galley

KEY POINTS : INTERIOR – forward galley layout

slide-26
SLIDE 26

32

GUEST CABIN HEAD SALOON OPEN GALLEY OWNER CABIN CREW CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Version 2 : Complete forward galley 160x200 160x200 70x200

KEY POINTS : INTERIOR – forward galley layout

2,45 m 1,65m 2 m 1,75m 1,6m 1,87m

slide-27
SLIDE 27

33

1

Complete double forward galley

2

Galley + pullman

2 1 2

slide-28
SLIDE 28

34

Version 1 : complete forward galley

1

Corian with integrated

1 2

Integrated microwave

2 3 3

Very large fridge (195L)

4 4

Deep and large storage

5 5

Natural light in the galley

slide-29
SLIDE 29

35

2

Version 1 : complete forward galley

1

Deep and large storage

2

New sliding storages access

1 1 1 3 3

Optional wine cellar

slide-30
SLIDE 30

36

Version 1 : complete forward galley

1 2 3 1

Confortable chart table

2

New electric panel

3

360 ° Natural light

  • Home automation system (domotic

Scheiber system)

  • Touchscreen monitor ( size..)

3 3

slide-31
SLIDE 31

37

Version 1 : complete forward galley

1 1

Handrails

2

360 ° Natural light

2 2 2 2

From

  • the the frontdeck
  • above the aft cabins
  • The saloon

Better security inside the boat

3

Large stairs

Large and welcoming stable staircase

3

slide-32
SLIDE 32

38

Version 2 : Forward galley + pullman

slide-33
SLIDE 33

39

Version 2 : Forward galley + pullman

1

Pullman cabin

1

slide-34
SLIDE 34

40

1

Adjustable table

1 2

L Shape banquette

2 3 3

Storage units

Deep storage for a clear and functional living room.

slide-35
SLIDE 35

41

1

Adjustable table

1 2

Additional seat

2

A real dinner table for all guests

slide-36
SLIDE 36

42

slide-37
SLIDE 37

43

1

Large bed

2

Finishing & design

Elegant Dufour design & cushions

1

160 x 200 owner bed Accessible from each side

2 2 3

Lights

Individual and adjustable lights

3

slide-38
SLIDE 38

44

1

Storage

2

Sofa

Confortable and large sofa in the front cabin. Real and deep storage in the front cabin to welcome the owner.

1 1 2 3 3

Longitudinal head : head + separate shower.

Spacious head

slide-39
SLIDE 39

45

1

TV screen

Optional

2

Pathway

Very large pathway

1 2 3

Bright cabin with natural light from the top and each side.

Natural light

3 3

slide-40
SLIDE 40

46

1

Natural lights

2

Storage

Several storage for the best welcome

1 1 2 2 2 2 3

Modular beds

2 single beds convertible in one double bed. 70 x 200 ( single bed) 160x 200 ( double)

3 4

Access

Exterior access

4

slide-41
SLIDE 41

47

slide-42
SLIDE 42

48

slide-43
SLIDE 43

49

KEY POINTS : INTERIOR – Aft head

1

Toilet

Manual sea toilet

2

Sink

Polyester bowl with Corian, synthetic resin Discharge : direct with electric pump

1 2 3 3 3

Storage and mirror

Several storage units and large mirror

4

Floor

Floor: teak Ventilation via deck panel or opening port

4 5 5

Separate space

Separate shower – for a better confort Washing machine – option in the aft portside head

Optional

slide-44
SLIDE 44

50

Key points

Interior - Aft galley layout

slide-45
SLIDE 45

51

CREW CABIN AFT GALLEY SALOON GUEST CABIN OWNER CABIN WITH EXTRA LARGE LOCKER + OFFICE TABLE SKIPPER CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

KEY POINTS : INTERIOR – Aft galley layout

HEAD WITH SEPARATE SHOWER LOUNGE SOFA

slide-46
SLIDE 46

52

CREW CABIN AFT GALLEY SALOON GUEST CABIN OWNER CABIN WITH EXTRA LARGE LOCKER + OFFICE TABLE SKIPPER CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Configuration : U SHAPE + CONVERTIBLE TABLE

KEY POINTS : INTERIOR – Aft galley layout

HEAD WITH SEPARATE SHOWER TABLE + BENCH CONVERTIBLE INTO BED

slide-47
SLIDE 47

53

CREW CABIN AFT GALLEY SALOON GUEST CABIN OWNER CABIN WITH EXTRA LARGE LOCKER + OFFICE TABLE SKIPPER CABIN / SAIL LOCKER OWNER HEAD & SHOWER NAVIGATION AREA HEAD GUEST CABIN TENDER GARAGE

Version 2 : U SHAPE + CONVERTIBLE TABLE

KEY POINTS : INTERIOR – Aft galley layout

HEAD WITH SEPARATE SHOWER TABLE + U SHAPE BANQUETTE + CONVERTIBLE INTO BED

70x200 160x200 80x200 80x200 80x200 160x200 2,45 m 1,65m 2 m

slide-48
SLIDE 48

54

2

Optional TV

3

Cabin access

Large access to the owner cabin, Guest cabins, and 2 heads

2 3 1 4

Pathway

Very lage parthway in this saloon : more confort when several people.

4 1

U Shape sofa

U shape Convertible sofa Bench part can be placed next to the table for dinner configuration

slide-49
SLIDE 49

55

slide-50
SLIDE 50

56

2 3

slide-51
SLIDE 51

57

slide-52
SLIDE 52

58

slide-53
SLIDE 53

59

Aft galley

Classic approach Living space for the owner and family Specific space for the skipper ( aft galley, aft skiper cabin and head).

1

Complete aft kitchen

Same equipment as for the forward galley layout. Stylish and smart design.

1 2

Natural light

Natural light even in this aft galley from the top and side.

2 2 3

Design

To enhance the space : integrated storage with slinding closets made with mirrors

3 4

Direct Access to the Captain cabin

4

slide-54
SLIDE 54

60

slide-55
SLIDE 55

61

Aft galley ( Captain cabin)

Large and qualitative space : more confort for the skipper/crew in this new « skipper quarters» of the yacht.

1

Storages

Several storage for better confort

2

Toilet

Manual toilet

3

Sink

Polyester bowl with Corian, synthetic resin Discharge : direct with electric pump

1 1 2 4 3 4

Shower

slide-56
SLIDE 56

62

slide-57
SLIDE 57

63

FABRICS

slide-58
SLIDE 58

64

FABRICS

INTERIOR

Taek interior Oak interior Rabbani grey Wenge floorboard Rabbani beige Rabbani light grey Bonanza beige Sahara beige Sahara Brown Soft Beige Noyer floorboard

slide-59
SLIDE 59

65

slide-60
SLIDE 60

Contact : marketing@dufour-yachts.com
