Sparse Proteomics Analysis (SPA) Toward a Mathematical Theory for - - PowerPoint PPT Presentation
Sparse Proteomics Analysis (SPA) Toward a Mathematical Theory for Feature Selection from Forward Models Martin Genzel Technische Universit at Berlin Winter School on Compressed Sensing December 5, 2015 Outline Biological Background 1
Toward a Mathematical Theory for Feature Selection from Forward Models Martin Genzel
Technische Universit¨ at Berlin
Winter School on Compressed Sensing December 5, 2015
1
Biological Background
2
Sparse Proteomics Analysis (SPA)
3
Theoretical Foundation by High-dimensional Estimation Theory
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 2 / 19
1
Biological Background
2
Sparse Proteomics Analysis (SPA)
3
Theoretical Foundation by High-dimensional Estimation Theory
The pathological mechanisms of many diseases, such as cancer, are manifested on the level of protein activities.
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 3 / 19
The pathological mechanisms of many diseases, such as cancer, are manifested on the level of protein activities. To improve clinical treatment options and early diagnostics, we need to understand protein structures and their interactions! Proteins are long chains of amino acids, controlling many biological and chemical processes in the human body.
http://www.topsan.org/Proteins/JCSG/3qxb Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 3 / 19
The pathological mechanisms of many diseases, such as cancer, are manifested on the level of protein activities. To improve clinical treatment options and early diagnostics, we need to understand protein structures and their interactions! Proteins are long chains of amino acids, controlling many biological and chemical processes in the human body. The entire set of proteins at a certain point of time is called a proteome. Proteomics is the large-scale study of the human proteome.
http://www.topsan.org/Proteins/JCSG/3qxb Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 3 / 19
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 4 / 19
Mass spectrometry (MS) is a popular technique to detect the abundance
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 4 / 19
Mass spectrometry (MS) is a popular technique to detect the abundance
Detector
Laser
Intensity (cts) Mass (m/z)
Sample
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 4 / 19
Mass (m/z) Intensity (cts)
MS-vector: x = (x1, . . . , xd) ∈ Rd, d ≈ 104 . . . 106 Index ˆ = Mass/Feature, Entry ˆ = Intensity/Amplitude
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 5 / 19
Mass (m/z) Intensity (cts)
MS-vector: x = (x1, . . . , xd) ∈ Rd, d ≈ 104 . . . 106 Index ˆ = Mass/Feature, Entry ˆ = Intensity/Amplitude
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 5 / 19
Mass (m/z) Intensity (cts)
MS-vector: x = (x1, . . . , xd) ∈ Rd, d ≈ 104 . . . 106 Index ˆ = Mass/Feature, Entry ˆ = Intensity/Amplitude
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 5 / 19
Goal: Detect a small set of features (disease fingerprint) that allows for an appropriate distinction between the diseased and healthy group.
Blood from healthy individual Blood from diseased individual Samples
Mass (m/z)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 6 / 19
Goal: Detect a small set of features (disease fingerprint) that allows for an appropriate distinction between the diseased and healthy group.
Mass (m/z)
MS ¡
Mass (m/z)
Blood from healthy individual Blood from diseased individual
MS ¡
Intensity (cts) Intensity (cts)
Samples Mass Spectra Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 6 / 19
Goal: Detect a small set of features (disease fingerprint) that allows for an appropriate distinction between the diseased and healthy group.
Mass (m/z)
MS ¡
Mass (m/z)
Blood from healthy individual Blood from diseased individual Disease Fingerprint
Comparing ¡ MS ¡
Intensity (cts) Intensity (cts)
Samples Mass Spectra Feature Selection Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 6 / 19
Supervised Learning: We are given n samples (x1, y1), . . . , (xn, yn). xk ∈ Rd: Mass spectrum of the k-th patient yk ∈ {−1, +1}: Health status of the k-th patient (healthy = +1, diseased = −1)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 7 / 19
Supervised Learning: We are given n samples (x1, y1), . . . , (xn, yn). xk ∈ Rd: Mass spectrum of the k-th patient yk ∈ {−1, +1}: Health status of the k-th patient (healthy = +1, diseased = −1)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 7 / 19
Supervised Learning: We are given n samples (x1, y1), . . . , (xn, yn). xk ∈ Rd: Mass spectrum of the k-th patient yk ∈ {−1, +1}: Health status of the k-th patient (healthy = +1, diseased = −1)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 7 / 19
Supervised Learning: We are given n samples (x1, y1), . . . , (xn, yn). xk ∈ Rd: Mass spectrum of the k-th patient yk ∈ {−1, +1}: Health status of the k-th patient (healthy = +1, diseased = −1) Goal: Learn a feature vector ω ∈ Rd which is sparse, i.e., few non-zero entries, (⇒ stability, avoid overfitting) and its entries correspond to peaks that are highly correlated with the disease. (⇒ interpretability, biological relevance)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 7 / 19
Supervised Learning: We are given n samples (x1, y1), . . . , (xn, yn). xk ∈ Rd: Mass spectrum of the k-th patient yk ∈ {−1, +1}: Health status of the k-th patient (healthy = +1, diseased = −1) Goal: Learn a feature vector ω ∈ Rd which is sparse, i.e., few non-zero entries, (⇒ stability, avoid overfitting) and its entries correspond to peaks that are highly correlated with the disease. (⇒ interpretability, biological relevance)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 7 / 19
1
Biological Background
2
Sparse Proteomics Analysis (SPA)
3
Theoretical Foundation by High-dimensional Estimation Theory
Sparse Proteomics Analysis is a generic framework to meet this challenge.
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 8 / 19
Sparse Proteomics Analysis is a generic framework to meet this challenge. Input: Sample pairs (x1, y1), . . . , (xn, yn) ∈ Rd × {−1, +1} Compute:
1 Preprocessing (Smoothing, Standardization) 2 Feature Selection (LASSO, ℓ1-SVM, Robust 1-Bit CS) 3 Postprocessing (Sparsification)
Output: Sparse feature vector ω ∈ Rd
Mass (m/z)
Blood ¡Sample
Biomarker Identification
Intensity (cts)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 8 / 19
Sparse Proteomics Analysis is a generic framework to meet this challenge. Input: Sample pairs (x1, y1), . . . , (xn, yn) ∈ Rd × {−1, +1} Compute:
1 Preprocessing (Smoothing, Standardization) 2 Feature Selection (LASSO, ℓ1-SVM, Robust 1-Bit CS) 3 Postprocessing (Sparsification)
Output: Sparse feature vector ω ∈ Rd
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 8 / 19
Linear Separation Model: Find a feature vector ω ∈ Rd such that yk = sign(xk, ω) for “many” k ∈ {1, . . . , n}. Moreover, ω should be sparse and interpretable.
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 9 / 19
The LASSO (Tibshirani ’96)
min
ω∈Rd n
(yk − xk, ω)2 subject to ω1 ≤ R Multivariate approach, originally designed for linear regression models: yk ≈ xk, ω, k = 1, . . . , n. But also applicable to non-linear models → Next part Later: R ≈ √s to allow for s-sparse solutions (with unit norm).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 10 / 19
The LASSO (Tibshirani ’96)
min
ω∈Rd n
(yk − xk, ω)2 subject to ω1 ≤ R Multivariate approach, originally designed for linear regression models: yk ≈ xk, ω, k = 1, . . . , n. But also applicable to non-linear models → Next part Later: R ≈ √s to allow for s-sparse solutions (with unit norm).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 10 / 19
5-fold cross-validation for real-world pancreas data (156 samples):
1 Learn feature vector ω
by SPA, using 80% of the samples.
2 Classify the remaining
20% of the sample by an
projecting onto supp(ω).
3 Iterate this procedure
12-times for random partitions.
Classification accuracy for different sparsity levels s = # supp(ω)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 11 / 19
1
Biological Background
2
Sparse Proteomics Analysis (SPA)
3
Theoretical Foundation by High-dimensional Estimation Theory
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n am: Deterministic feature atom, sampled Gaussian peak (∈ Rd) sm,k: Random latent factor specifying the peak amplitude (∈ R) nk: Random baseline noise (∈ Rd)
𝑡",$ % exp −(% −𝑑")- 𝛾"
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n am: Deterministic feature atom, sampled Gaussian peak (∈ Rd) sm,k: Random latent factor specifying the peak amplitude (∈ R) nk: Random baseline noise (∈ Rd)
𝑡",$ % exp −(% −𝑑")- 𝛾"
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n am: Deterministic feature atom, sampled Gaussian peak (∈ Rd) sm,k: Random latent factor specifying the peak amplitude (∈ R) nk: Random baseline noise (∈ Rd)
𝑡",$ % exp −(% −𝑑")- 𝛾"
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n
Supposed that sufficiently many samples are given, can we learn the sparse fingerprint ω0?
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n
Supposed that sufficiently many samples are given, can we learn the sparse fingerprint ω0?
Problem: The vector ω0 is not unique because some features are perfectly correlated ⇒ No hope for support recovery or approximation
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
Linear Separation Model: Explains the observations/labels: yk = sign(xk, ω0), k = 1, . . . , n Forward Model: Explains the random distribution of the data: xk = M
m=1 sm,kam + nk,
k = 1, . . . , n
Supposed that sufficiently many samples are given, can we learn the sparse fingerprint ω0?
Problem: The vector ω0 is not unique because some features are perfectly correlated ⇒ No hope for support recovery or approximation
Idea: Separate the fingerprint from its data representation!
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 12 / 19
xk = M
m=1 sm,kam + nk,
k = 1, . . . , n Assumptions: sk := (s1,k, . . . , sM,k) ∼ N(0, IM) – peak amplitudes nk ∼ N(0, σ2Id) – noise vector a1, . . . , aM ∈ Rd – arbitrary (peak) atoms, D := a⊤
1
. . . a⊤
M
∈ RM×d
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 13 / 19
xk = M
m=1 sm,kam + nk,
k = 1, . . . , n Assumptions: sk := (s1,k, . . . , sM,k) ∼ N(0, IM) – peak amplitudes nk ∼ N(0, σ2Id) – noise vector a1, . . . , aM ∈ Rd – arbitrary (peak) atoms, D := a⊤
1
. . . a⊤
M
∈ RM×d Put this into the classification model: yk = sign(xk, ω0) = sign( M
m=1 sm,kam + nk, ω0)
= sign(D⊤sk + nk, ω0)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 13 / 19
xk = M
m=1 sm,kam + nk,
k = 1, . . . , n Assumptions: sk := (s1,k, . . . , sM,k) ∼ N(0, IM) – peak amplitudes nk ∼ N(0, σ2Id) – noise vector a1, . . . , aM ∈ Rd – arbitrary (peak) atoms, D := a⊤
1
. . . a⊤
M
∈ RM×d Put this into the classification model: yk = sign(xk, ω0) = sign( M
m=1 sm,kam + nk, ω0)
= sign(D⊤sk + nk, ω0) = sign(sk, Dω0
+ nk, ω0) = sign(sk, z0 + nk, ω0)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 13 / 19
xk = M
m=1 sm,kam + nk = D⊤sk + nk
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 14 / 19
xk = M
m=1 sm,kam = D⊤sk
Let us first assume that nk = 0 (no baseline noise).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 14 / 19
xk = M
m=1 sm,kam = D⊤sk
Let us first assume that nk = 0 (no baseline noise). Then yk = sign(xk, ω0) = sign(sk, z0), where z0 = Dω0.
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 14 / 19
xk = M
m=1 sm,kam = D⊤sk
Let us first assume that nk = 0 (no baseline noise). Then yk = sign(xk, ω0) = sign(sk, z0), where z0 = Dω0. z0 has a (non-unique) representation in the dictionary D with sparse coefficients ω0. z0 “lives” in the signal space RM (independent of specific data type). ω0 “lives” in the coefficient space Rd (data dependent).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 14 / 19
xk = M
m=1 sm,kam = D⊤sk
Let us first assume that nk = 0 (no baseline noise). Then yk = sign(xk, ω0) = sign(sk, z0), where z0 = Dω0. z0 has a (non-unique) representation in the dictionary D with sparse coefficients ω0. z0 “lives” in the signal space RM (independent of specific data type). ω0 “lives” in the coefficient space Rd (data dependent).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 14 / 19
yk = sign(xk, ω0) = sign(sk, z0) with z0 = Dω0
SPA via the LASSO
min
ω∈Rd n
(yk − xk, ω)2 subject to ω1 ≤ R
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 15 / 19
yk = sign(xk, ω0) = sign(sk, z0) with z0 = Dω0
SPA via the LASSO
min
ω∈R·Bd
1
n
(yk − xk, ω )2
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 15 / 19
yk = sign(xk, ω0) = sign(sk, z0) with z0 = Dω0
SPA via the LASSO
min
ω∈R·Bd
1
n
(yk − xk, ω
=sk,z
)2
z:=Dω ↓
= min
z∈R·DBd
1
n
(yk − sk, z)2
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 15 / 19
yk = sign(xk, ω0) = sign(sk, z0) with z0 = Dω0
SPA via the LASSO
min
ω∈R·Bd
1
n
(yk − xk, ω )2
z:=Dω ↓
= min
z∈R·DBd
1
n
(yk − sk, z)2
Warning: The minimizers “live” in different spaces! Warning: We neither know D nor sk, but just their product.
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 15 / 19
yk = sign(xk, ω0) = sign(sk, z0) with z0 = Dω0
SPA via the LASSO
min
ω∈R·Bd
1
n
(yk − xk, ω )2
z:=Dω ↓
= min
z∈R·DBd
1
n
(yk − sk, z)2
Warning: The minimizers “live” in different spaces! Warning: We neither know D nor sk, but just their product.
Idea: Apply results for the K-LASSO with K = R · DBd
1 !
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 15 / 19
Theorem (Plan, Vershynin ’15)
Suppose that sk ∼ N(0, IM), z0 ∈ SM−1, and the observations follow yk = sign(sk, z0), k = 1, . . . , n. Put µ =
π and assume that µz0 ∈ K, where K is convex, and
n w(K)2. Then, with high probability, the solution ˆ z of the K-LASSO satisfies ˆ z − µz02
√n .
The (global) mean width for bounded K ⊂ RM is given by w(K) = sup
u∈K
g, u, where g ∼ N(0, IM).
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 16 / 19
Theorem (Plan, Vershynin ’15)
Suppose that sk ∼ N(0, IM), z0 ∈ SM−1, and the observations follow yk = sign(sk, z0), k = 1, . . . , n. Put µ =
π and assume that µz0 ∈ K, where K is convex, and
n w(K)2. Then, with high probability, the solution ˆ z of the K-LASSO satisfies ˆ z − µz02
√n .
Assume that K = µR · DBd
1
⇒ z0 = Dω0 for some ω0 ∈ R · Bd
1 .
Assume that the columns of D are normalized. Then w(K) R ·
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 16 / 19
Theorem (G. ’15)
Suppose that sk ∼ N(0, IM). Let z0 ∈ SM−1 and assume that there exists R > 0 such that z0 = Dω0 for some ω0 ∈ R · Bd
1 . The observations follow
yk = sign(sk, z0) = sign(xk, ω0), k = 1, . . . , n. and the number of samples satisfies n R2 · log(d). Then, with high probability, the solution of the LASSO ˆ z = argmin
z∈R·DBd
1
n
(yk − sk, z)2 satisfies ˆ z −
πz02
n
1/4 .
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 17 / 19
Theorem (G. ’15)
Suppose that sk ∼ N(0, IM). Let z0 ∈ SM−1 and assume that there exists R > 0 such that z0 = Dω0 for some ω0 ∈ R · Bd
1 . The observations follow
yk = sign(sk, z0) = sign(xk, ω0), k = 1, . . . , n. and the number of samples satisfies n R2 · log(d). Then, with high probability, the solution of the LASSO ˆ z = argmin
z∈R·DBd
1
n
(yk − sk, z)2 satisfies ˆ z −
πz02
n
1/4 .
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 17 / 19
Theorem (G. ’15)
Suppose that sk ∼ N(0, IM). Let z0 ∈ SM−1 and assume that there exists R > 0 such that z0 = Dω0 for some ω0 ∈ R · Bd
1 . The observations follow
yk = sign(sk, z0) = sign(xk, ω0), k = 1, . . . , n. and the number of samples satisfies n R2 · log(d). Then, with high probability, the solution of the LASSO ˆ z = D · ˆ ω = D · argmin
ω∈R·Bd
1
n
(yk − xk, ω)2 satisfies D ˆ ω −
πDω02 = ˆ
z −
πz02
n
1/4 .
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 17 / 19
Extensions:
◮ Baseline noise nk ∼ N(0, σ2Id) ◮ Non-trivial covariance matrix, i.e., sk ∼ N(0, Σ) ◮ Adversarial bit-flips in the model yk = sign(xk, ω0)
How to achieve normalized columns in D? How to guarantee that R ≈ √s, i.e., s-sparse vectors are allowed? → Standardize the data (centering + normalizing) Given ˆ ω, how to switch over to the signal space? (D is unknown) → Identify supp(ˆ ω) with peaks (manual approach)
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 18 / 19
Extensions:
◮ Baseline noise nk ∼ N(0, σ2Id) ◮ Non-trivial covariance matrix, i.e., sk ∼ N(0, Σ) ◮ Adversarial bit-flips in the model yk = sign(xk, ω0)
How to achieve normalized columns in D? How to guarantee that R ≈ √s, i.e., s-sparse vectors are allowed? → Standardize the data (centering + normalizing) Given ˆ ω, how to switch over to the signal space? (D is unknown) → Identify supp(ˆ ω) with peaks (manual approach) Message of this talk
An s-sparse disease fingerprint can be accurately recovered from only O(s log(d)) samples!
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 18 / 19
Further Reading
Sparse Proteomics Analysis: Toward a Mathematical Foundation of Feature Selection and Disease Classification. Master’s Thesis, 2015.
The generalized Lasso with non-linear observations. arXiv:1502.04071, 2015.
Development of an abstract framework → What kind of properties should the dictionary D have? Extension/generalization of the results → More complicated models and algorithms Numerical verification of the theory Other examples from real-world applications → Bio-informatics, neuro-imaging, astronomy, chemistry, . . . Dictionary learning / Factor analysis → What can we learn about D?
Martin Genzel Sparse Proteomics Analysis (SPA) WiCoS 2015 19 / 19
