SpaceWire Standard Evolution Martin Suess European Space Agency, E-mail: martin.suess at esa.int, 2 nd International SpaceWire Conference 2-4 November 2008 Slide : 1 in Nara, Japan SpaceWire Standard Evolution Overview Introduction


slide-1
SLIDE 1

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 1

SpaceWire Standard Evolution

Martin Suess European Space Agency, E-mail: martin.suess at esa.int,

slide-2
SLIDE 2

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 2

SpaceWire Standard Evolution

Overview

  • Introduction
  • Proposed updates to the SpaceWire Standard on:

– Physical Level, – Character Level, – Exchange Level, – Network Level.

  • Conclusion
slide-3
SLIDE 3

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 3

SpaceWire Standard Evolution

Introduction

  • The SpaceWire standard ECSS-E-50-12A was first published in

2003.

  • Since then many groups all over the world worked on the

development of SpaceWire links, nodes, routers and networks and on the application of this technology in space systems.

  • In the past years the standardization effort aimed at higher level

communication protocols such as RMAP.

  • In parallel the SpaceWire Working Group is discussing new

concepts and additional protocols like SpW-PnP and SpW-RT.

  • Through the experience gained with real systems and through

the development of new concepts several issues have been identified to be considered for the update of the standard.

  • This presentation summarizes updates to the SpaceWire

standard which have been proposed during the past years in the SpaceWire Working Group.

slide-4
SLIDE 4

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 4

SpaceWire Standard Evolution

Cable Specification

  • The standard provides a

detailed specification of the construction of the cable.

  • The disadvantage is that the

standard does not provide freedom to optimise the cable for specific applications.

  • The update should only

specify some physical and electrical parameters like:

– Differential Impedance, – Signal Skew, – Return Loss, – Insertion Loss, – Near-end Crosstalk (NEXT) – Far-end Crosstalk (FEXT)

Conductor 28 AWG (7 x 36 AWG) Insulating layer Twisted pair Inner shield around twisted pair (40AWG) Outer shield (38AWG) Outer Jacket Filler Filler Jacket Binder

Section though a SpaceWire cable as defined in the standard

slide-5
SLIDE 5

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 5

SpaceWire Standard Evolution

Connectors

  • The SpaceWire connector is a

nine-pin micro-miniature D-type.

  • It is compact and available for space

use.

  • D-type connectors do not match the

100 Ω differential impedance.

  • Distortion introduced by connectors

is acceptable in most cases.

  • Other connectors have been

proposed and investigated: – Circular 13 pin 38999 Series II connector, – 4-way twinax connector.

38999-series connector 4-way Twinax connector micro-miniature D-type connector

slide-6
SLIDE 6

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 6

SpaceWire Standard Evolution

Cable Assembly

  • The micro-miniature D-type connector has nine signal contacts.
  • Eight contacts are used for the 4 twisted pair cables and one is

used to terminate the inner shields at end of the cable from which the signals are being driven.

  • The inner shields are isolated from one another.
  • This prevents a direct ground connection via the SpaceWire link

and provides a symmetrical cable.

  • A problem occurs when the cable is broken into several parts

due to bulkhead connectors.

  • In this case the inner shields on both sides of the bulkhead are

not connected to the ground of either side.

  • A connection of the inner shield on both sides with the

possibility to implement a controlled capacitive decoupling on

  • ne side behind the plug could be investigated.
slide-7
SLIDE 7

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 7

SpaceWire Standard Evolution

Distributed Interrupts

  • Two control flags of the time-codes are reserved for

future use.

  • It has been proposed to use one of the reserved

states to distribute interrupts through the network.

  • They will propagate on the same side channel as

time-codes independent of the normal traffic.

  • This mechanism will allow to define 32 Interrupts

Codes and 32 Interrupt-Acknowledge Codes.

  • Routers and nodes propagate the interrupts only
  • nce unless:

– a timeout has expired – they have received the corresponding Interrupt- Acknowledge Code

slide-8
SLIDE 8

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 8

SpaceWire Standard Evolution

Distributed Interrupts

  • Interrupt-code: interrupt request, IRQ vector I=16h

Node 82 Master Router 1 Router 2 Router 3 Node 74 Master Node 64 Slave Node 60 Slave

  • Interrupt Acknowledge: interrupt acknowledgment

I=16h I=16h

slide-9
SLIDE 9

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 9

SpaceWire Standard Evolution

Multi-Time-Code Master Mechanism

  • Only one node in network is allowed to act as time-

code master.

  • It is the only to should provide the active TICK_IN

signal which triggers the broadcast of the Time- Codes.

  • This is required to avoid collisions of Time-Codes

within the network.

  • For fail safety and redundancy reasons it could be

useful to have simultaneous Time-Codes from different time-code masters in a system.

  • Up to two additional time signals could be

implemented by using the two remaining reserved states of the control flag.

slide-10
SLIDE 10

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 10

SpaceWire Standard Evolution

Simplex Link Operation

  • Many high speed payload data applications require only a

simplex connection.

  • This could be for example a direct connection from a high rate

instrument to the memory.

  • For these simple applications the back of SpaceWire is

sometimes regarded as complex and of cable mass.

  • A proposal has been made to modify the SpaceWire codec and

the state machine to support simplex operation.

  • Also the possibility of a half-duplex SpaceWire implementation

has been suggested.

  • The details and consequences of these proposals remains to be

investigated.

slide-11
SLIDE 11

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 11

SpaceWire Standard Evolution

2 Mbit/s Link Speed at Start-up

  • The standard currently requires a link speed of

10 Mbit/s at start-up.

  • In some applications data rates of less than 2 Mbit/s

are required.

  • For power saving and simplicity reasons the start-up

at 2 Mbit/s is desirable for these systems.

slide-12
SLIDE 12

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 12

SpaceWire Standard Evolution

Configuration Port 0 in Nodes

  • SpaceWire routing switches have an internal

configuration port with address zero.

  • It is used to configure the routing switch and to

access status information.

  • This is an important feature for network discovery

and PnP.

  • Currently this port zero is only required in routing

switches and not in nodes.

  • It is intended that in the update the definition of

SpaceWire Node addressing will be aligned with the SpaceWire Routing Switch.

slide-13
SLIDE 13

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 13

SpaceWire Standard Evolution

Configuration Port 0 in Nodes

1st Byte

Configuration Engine, PnP

1st Byte = 0 1st Byte = 32-254 => LA 1st Byte = 1 - 31 Application Level Software PID analysis, Transport protocol identification.

Reserved

Payload PID LA Path Address E O P

slide-14
SLIDE 14

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 14

SpaceWire Standard Evolution

Router Function in Nodes

  • What has been described before corresponds to a

very simple router with: – one external port, – one internal configuration port and – one node internal port.

  • This concept can be extended to several external

ports by introducing path addressing and a routing table.

  • This would fulfil the needs of network discovery
  • Could provide an elegant method for cross strapping

and redundancy switching

  • Enable easy packet routing through nodes.
slide-15
SLIDE 15

2-4 November 2008 2nd International SpaceWire Conference in Nara, Japan Slide : 15

SpaceWire Standard Evolution

Conclusion

  • A non exhaustive list of the modifications proposed to the

SpaceWire standard has been presented.

  • Additional proposals are welcome and can still be submitted to

the author.

  • The different options will be discussed and consolidated within

the SpaceWire working group starting next year.

  • In many cases breadboard implementations of the modifications

already exist.

  • Results of the discussions on modifications will be included in

the next update of the SpaceWire standard.

  • The review and update of the SpaceWire standard is planned to

be started in 2010.
