FASTER FROM ZERO TO

SOLUTION

FULL-SERVICE-PROJECTS

THE C O MPA N Y SMA

• Foundation of the company SMA 2019
• Company succession of the company SASIT
• Legal form GmbH
• Over 70 employees
• Place of business: Zwickau
• worldwide active
• Administrative area: 1600 m²
• Manufacturing area: 2.500 m²

Conveyor technology Industrial handling Automation technology Welding technology Special-purpose machines Maintenance work



Our specials

F ie ld s o f Bu si n ess

Automation technology / Robot technology Assembly automation, equipment of complete assembly lines, peripheral devices for assembly automation, linear system for distribution, robot technology with 7-axes, gripper systems for handling / joining processes / conservation Transport / Conveyor technology / Modular assembly and joining technology Conveyor systems for linking production processes and material flow systems, such as: overhead monorail conveyors, Power & Free, storage chains, accumulation conveyors, belt conveyors, transport roller, conveyor technology (skid transport), gravity conveyors, position changers, equipment of trailers for material flow systems in JIT deliveries , joining devices working on the welding and riveting principle, welding gun production

F ie ld s o f Bu si n ess

Special plants/ special solutions Impregnation plants, gelling dryers, SMA ALU-range of profiles, safety devices / protective devices, recurrent testing, safety officer/ safety coordination Customer service Scheduled maintenance work, service work, major and general repairs, module repair Engineering according to customer specifications Development of special plants according to specific customer requirements In-house services WIG, MAG, resistance welding, manual arc welding

Se r v i ces

Design Design engineering with CATIA V5 E-PLAN & pneumatic-plan / HLS plant planning & management Robotics 3D process simulation Offline programming Online programming KUKA | FANUC | ABB | +++ Safety and certificates ISO 9001 Safety concept and consulting BGV A3 measuring PROFIBUS / -NET-measurement Welding technology WIG / MAG Resistance welding Manual arc welding Job order production Milling Turning Welding Painting Maintenance and repair Recurrent mandatory tests Major and general repairs Accident repairs

Ma c h in e s h op

Machining centers Traversing ranges up to 1,2 m Drilling and milling machines Travels up to 4.0 m Vertical machining centres Clamping areas up to 1.4 x 0.7 m Lathes Travels up to 2 m 3D coordinate measuring machine Travel up to 4 m Clamping area 5 m x 2.5 m Welding stations Bending technology

Pla n t , r o b o t- a n d a u t om a tio n t e c h n olog y

Welding robot Handling Application robot

Pla n t , r o b o t- a n d a u t om a tio n t e c h n olog y

Setting expanding nuts

Intended purpose: Installation of expanding nuts with automatic feed and placement by robot in various areas of vehicles

Ma t er ia ls h an d lin g an d a sse m b ly tec hn o log y

Roller conveyor technology

• stable roller conveyor profile up to 6 m

long

• Modular construction system compatible

with aluminum profiles with a 10 mm slot width

• Equally spaced hole punching for roller

mounting according to customer request

• available as arch, various roller drives can

be implemented

• high load capacity up to 2400 N / roller

with low empty weight (4.96 kg / m)

• Fast, inexpensive construction and

conversion with modular construction system

• expandable with additional profiles and

accessories for complex systems

Accessories:

• Stopper modules,

transverse indexing machine,

• Transverse ejectors

Tr a n sp ort a n d c o nv ey or s y s te m s

Automatic transport system for vehicle seats and ergonomic hoist for manual removal Body hoist and position changer to transfer vehicle bodies from

• verhead monorail conveyor

hangers to transport skids

O v er h ea d m on or a il c o n v ey or te c h n olog y

Transport systems for vehicle bodies including steelwork and manual workstations

Sy st em so lu tio n f o r J I T / J I S s u p pl ier s

Automatic cockpit supply

• Unloading: via upper level
• Loading: via lower level
• Connection between levels: Hoist at the front of the trailer
• Capacity of the trailer: max. 24 workpiece holders

(with or without cockpit)

• 0, 2, 4, ..., 22, 24 are possible for the travel
• Buffer principle: accumulating conveyor
• Positioning of the trailer: by special docking station (positioning

in X, Y and Z by raising the trailer)

Ro b ot Te c h n olog y

Robot systems for the application of sprayable insulating mats in vehicle interiors, and for application to door sills, including drying units

W e ld in g t ec h nol og y

Welding equipment Rejected part Welding apparatus for hydraulic cylinders

Sp ec ia l-p u rp os e m a c h in es

AGM battery manufacturing plants Automatic heating and bonding unit for side armrests

Sp ec ia l-p u rp os e m a c h in es

Cavity preservation systems Trimming station

SM A S ä c h sis c h e Ma sc h i n en - u nd An lag en b au G m bH Ko p ern iku ss tr a ße 5 8 0 8 0 56 Zw ic k au G E RMAN Y

P h o n e 0 3 5 7 – 2 7 1 5 - 0 Fa x 0 3 5 7 – 2 9 5 2 3 4 E - M a i l i n fo @ s m a - z . d e We b w w w. s m a - z . d e

YO UR CO N TAC T PE RSO N

M r. J u r r a n M r. M e i e r M r. U l l m a n n M r s . G ü n z e l Fa x E - M a i l

D i s t r i b u t i o n S e c r e t a r y

0 3 7 5 – 2 7 1 5 1 1 3 0 3 7 5 – 2 7 1 5 1 5 7 0 3 7 5 – 2 7 1 5 1 6 5 0 3 7 5 – 2 7 1 5 0 0 3 7 5 – 2 9 5 2 3 4 i n f o @ s m a - z . d e
