SDN Solution Overview

Ericsson SDN Solution

Market Opportunity Solution Overview Applications Customer Benefits and Value Summary

Agenda

Why operators deploy SDN

› Need for programmable connectivity infrastructure to realize the full potential of NFV › New market verticals that can be addressed by bundling programmable connectivity with cloud based productivity applications › Addressing OPEX reductions through automation › New Features without changing underlying hardware

Market Opportunity Solution Overview Applications Customer Benefits and Value Summary

Agenda

DC Fabric

Servers

Video IPTV VNF SF DC GW Media App

Telco Operator Data-Center

MPLS/VXLAN tunnel MPLS/VXLAN tunnel MPLS/VXLAN tunnel MPLS/VXLAN tunnel

Mobile BB VNF SF OpenStack Virtualization Environment

vSwitch

MPLS/VXLAN tunnel

Cloud SDN

Ericsson SDN Controller

REST API REST API

Opensource – Multi-vendor solution, any DC gateway or underlay End to end data center automation Virtualised Service Chaining for personalized services Optimised and tested for high performance VNFs

REST API REST API

Ericsson Cloud Manager Ericsson Cloud Manager

REST API REST API

Ericsson SDN

SDN con

• ntroller

roller

Neutron

NFV Automation

CSC Controller CSC Controller CSC Controller

DC VIM (CEE)

Ericsson Cloud Manager (NFVO)

DC Network

DC GW

ToR

1

BBSC

2

CSS

3 4

• 1. 1. Multiple exterior network types

supported

• 2. 2. Granular Service Chains API’s
• 3. 3. Service Exposure to Openstack
• 4. 4. Layer 2 gateway for SR-IOV support
• 5. 5. IPv4 and IPv6 Networks

5

• 1. Cloud SDN Switch (CSS)

Optimized for throughput

• 2. Full flexible networking with OpenFlow

software programmability

• 3. L2/L3 networking IP flows, MPLSoGRE,

VXLAN

• 4. Physical DC underlay Switches (ToR), DC

GW interoperates with CSC

SDN Dat atap apla lane ne

Neutron

NFV Automation

CSC Controller CSC Controller CSC Controller

DC VIM (CEE)

Ericsson Cloud Manager (NFVO)

DC Network

DC GW

ToR BBSC

CSS

3 4 1 2

Market Opportunity Solution Overview Applications Customer Benefits and Value Summary

Agenda

Virtualized Service Chaining Benefits

CSC CSC BBSC BBSC vSF vSF

Data Center

vSF vSF vSF vSF vSF vSF vEPC vEPC

vCGNAT vCGNAT

VPN VPN

Business Benefits

• Deployed on existing controller
• Policy interface for per subscriber control
• Carrier grade – includes load balancing and failure

bypass features

• Does not require CGNAT at every DC – centralized

model supported Business Benefits

• Deployed on existing controller
• Policy interface for per subscriber control
• Carrier grade – includes load balancing and failure

bypass features

• Does not require CGNAT at every DC – centralized

model supported Key Features

• Quickly deploy service functions
• Ability to mirror traffic between service functions

for troubleshooting / monitoring

• Able to load balance across multiple SF
• Traffic injection allows assurance of Service Chains

Key Features

• Quickly deploy service functions
• Ability to mirror traffic between service functions

for troubleshooting / monitoring

• Able to load balance across multiple SF
• Traffic injection allows assurance of Service Chains

Load Balancing Load Balancing Failure bypass Failure bypass

PCRF PCRF

Mirroring Mirroring Traffic Injection Traffic Injection

Built for NFV

› Open solution, tested with Ericsson’s leading core applications › Realises the benefits of network automation for NFVi deployments for any size operator › Automates NFVi for telco core across multiple data centers, with multi- vendor DC gateway support for Juniper and Cisco routers

DC Fabric

Servers

Video IPTV VNF Ent DC GW Voice VNF

Telco Operator Data-Center

MPLS/GRE tunnel MPLS/GRE tunnel MPLS/GRE tunnel MPLS/GRE tunnel

Mobile BB VNF Ent OpenStack Virtualization Environment

vSwitch

MPLS/GRE tunnel

Ericsson SDN Controller

Market Opportunity Solution Overview Applications Customer Benefits and Value Summary

Agenda

Service Provider Value

Allows operators to modulate their investment in SF’s by offering dynamic steering of traffic within the Datacenter Allows operators to modulate their investment in SF’s by offering dynamic steering of traffic within the Datacenter SDN principles of programming the networking and automating the network operations SDN principles of programming the networking and automating the network operations Cloud SDN base for Dynamic Service Chaining, VHGW, VEGW Cloud SDN base for Dynamic Service Chaining, VHGW, VEGW Seamless creation and management of services across WAN and Datacenter is essential to stay relevant Seamless creation and management of services across WAN and Datacenter is essential to stay relevant Based on Open Daylight, leverages open source development strengths Based on Open Daylight, leverages open source development strengths

1

Optimize investment in virtual service functions

2

Automation and programmability

3

Pre-integrated with Ericsson end-to-end Solutions

4

Open, future-proof solution

5

Aligned with Telco business needs

• End to end solution lowers
• perator integration risk

compared with multi-vendor solutions

• Ability to leverage existing core

assets with SDN/NFV is attractive

• Experienced telecoms services
• rganization key to successful

deployment

market SDN/NFV perception
