New Hydro-Fluoro-Olefins have been developed:

• HFO-1234yf has been identified as replacement for R134a by

the automotive industry.

• It has an atmospheric life of only 11 days (12 years for HFC-134a)

and an extremely low GWP of only 4 (1430 for R-134a).

• ASHRAE std 34 has classified HFO-1234yf as low toxicity class A.
• HFO-1234ze, is currently replacing R-134a for one-component

foam applications and looks promising for centrifugal chillers.

• This molecule also has a very short atmospheric lifetime with a GWP
• f 6.
• ASHRAE std 34 has classified HFO-1234ze as low toxicity class A.
• Another molecule is currently under development and is code

named N12.

• Intended refrigerant application is low pressure centrifugal chillers.

High temperature Heat Pumps and ORC.

• It has a GWP of 7 and is non-flammable.

HFO-1234ze(E) HFO-1234yf

500 1000 1500 2000 2500 3000 3500 4000 500 1000 1500 2000 2500 3000 3500 4000

Cooling Capacity

Reduced GWP

GWP

Non-Flammable Refrigerants GWP<150 Ultra Low GWP Mildly Flammable “2L” Plug-ins & Large Chillers L13 L-YF R134a N-13 R404A R22 L-20 N-40 N-20 L-40 Performax LT R410A L-41 Commercial Refrigeration Unitary Air Conditioning

Overview of Fluorocarbon Refrigerant Options

Water Dispenser

Developed by Celli (italy) Presented at Mostra .. Milan (March2012) Previous machine operates on R134a (GWP: 1400) New Design operates on HFO1234ze (GWP: 6)

HFO Success Story

Vending Machine

HFO12 HFO1234yf yf performa mance is is simi similar lar to R1 R134a.

Air dryer applications

Production Ready HFO1234yf and HFO1234ze Air Dryers

 Frascold validation of its reciprocating compressor with Solstice L13.  Better COP versus R134a across a wide range of operation.  Frascold announced investing in next generation HFO optimised compressors..

Compressor Development

HFO 1234ze Water Chiller

First HFO Chiller operational at Waitrose supermarket (South London).

 Important reduction in energy consumption versus identical R290 chiller reported.. Frascold /Geoclima tests show a 3.5% higher COP versus R134a Chiller.

HFO-1234ze in Commercial Refrigeration

• Limited prototype availability to OEMs in April 2012 for

development testing

• Significant energy efficiency increase over equivalent

HCFC 134a compressors

• Designed with environmentally friendly, ultra-low GWP

refrigerant HFO-1234ze

• Optimal solution for outdoor applications (air-cooled)

Compressor Development

Various Compressor technologies HFO ready.

HFO1234ze Chillers

Geoclima Chiller using Turbocor compressor presented at the Mostra

HFO1234ze Chillers

R-404A R-404A R-404A R-407A R-407A R-407F

Energy Consumption Time

Energy usage with time

15% lower Energy consumption for the MT R407F Pack.

ASDA Case Study

4% lower Energy consumption for the LT R407F Pack.

Supermarket Freezer Cases (LT) Supermarket/Deli Cases (MT)

> 50% GWP Reduction From R-404A >65% >90%

All opti tions offer significantl tly imp mproved efficiency & GWP GWP reducti tion comp mpared to to R-404A 404A

R-404A Replacement

2000000 4000000 6000000

R-404A Performax N40 L40

Direct Indirect

CO2 eq. kg

50% Lower GWP 65 % Lower GWP 90% Lower GWP

All opti tions offer significantl tly imp mproved efficiency & GWP GWP reducti tion comp mpared to to R-404A 404A

Options for the environment

R407F prediction

R407F 82608 92%

* Atmosphere 2011

Refrigeration Technologies Comparison

Cascade systems in commercial Refrigeration

CO2 R404A

R407F N40 L40

GWP =3922

GWP Reduction > 50% > 65% > 90%

Low Temp. Medium Temp.

GWP = 1 CO2 R134a

N13 L13

GWP =1430

GWP < 600 6

Low Temp. Medium Temp.

GWP = 1

Concluding Remarks

• Revised F-Gas regulation to take effect 2015.

 Business As Usual Not an option.

• Honeywell Leading HFO technology

 3 new molecules developed (2 Commercial / 1 pilot scale)  HFO and Blends identified  Validation with Partners in progress.  Solstice L13 identified as potential replacement to R134a in

medium Pressure Chillers.
