Solid State Power (Pty) Ltd

All in One Solar Street Light

1.Company Profile 2.Product Display 3.Product Introduction

• a. Principles
• b. Structure
• c. Features

4.Product Parameters 5.Installation Case

Content

Solid State Power (Pty) Ltd was established in 2008. It is a professional manufacturer of Solar Water Heaters, LED lights, Energy Controllers, UPS online and offline systems, all in one solar street light and customized products. We focus on research, development and innovation. We do not supply only products to customers, but also provide solutions to their specific needs. Reasonable prices, efficient production time and good after-sale service” are our strengths. We hope to cooperate with more customers for mutual development and benefits.

Company Profile

Product Display

Product Display

Product Display

a.Principles All in one solar street lights are integrated with solar panels that convert the sun's energy into DC power, and then through the intelligent micro controller to charge the lithium battery. During the day and even in cloudy days the solar panels can collect solar energy which is converted into DC power and stored in the lithium iron battery. At night LED lights are automatically switched on with PIR motion sensor when movement is detected within range; The light will switch off when no movement is detected within range. Light intensity is 100%within 7m distance from the light, changing to 1/3 brightness after 35 seconds when no movement is detected, saving energy intelligently.

Product Introduction

b.Structure All in one solar street light is composed of two parts - integrated LED light and pole. Integrated LED light built-in high efficient solar module, high-capacity lithium iron batteries, micro MPPT intelligent controller, high brightness LED light source, PIR motion sensor, mounting bracket.

Product Introduction

Product Introduction

b.Structure

Product Introduction

• c. Features

Solar LED light can be positioned where you want it *Easy installation, no wiring necessary. Brighter light when you need it *Built-in infra-red motion sensor regulates light output automatically. *Changes from dim mode (30%) to bright mode (100%) upon motion

• detection. (Option)

*Light sensor restricts operation during daylight to save battery power. Rustproof, dustproof and waterproof *Rated IP65 for all outdoor applications. Zero running cost *Fully solar powered. *Lithium battery prolongs life & protects the environment.

Product Parameter（8－20W）

Model YBSS0815 YBSS1218 YBSS1525 YBSS1840 YBSS2045 LED light source 8W 12W 15W 18W 20W Solar Module 15W 18W 25W 40W 45W PIR motion sensor Yes Yes Yes Yes Yes Charge/discharge protection Yes Yes Yes Yes Yes Dimension（mm） 439*325*43 689*325*43 829*325*140 1079*325*14 N.W 5.0kg 5.0kg 9.2kg 10.8kg 14.6kg Lumen(LM) 780lm 1250lm 1530lm 2160lm 2546lm Luminous angle 120° 120° 120° 120° 120° Color temperature 6000k- 6500k 6000k- 6500k 6000k- 6500k 6000k-6500k 6000k-6500k Discharge time Full power 12hours 12hours 12hours 12hours 12hours Half power 24hours 24hours 24hours 24hours 24hours Working temp.

• 20℃-+60℃(charge temp.0℃-+60℃;discharge temp.-20℃-

+60℃) IP grade IP65 Mounting height 3-4m 3-4m 4-5m 5-6m 5-6m Space between light 8-10m 8-10m 10-15m 18-20m 18-20m

Product Parameter（25－60W）

Model YBSS2550 YBSS3060 YBSS4060 YBSS5080 YBSS6090 LED light source 25W 30W 40W 50W 60W Solar Module 50W 60W 60W 80W 90W PIR motion sensor Yes Yes Yes Option Option Charge/discharge protection Yes Yes Yes Yes Yes Dimension（mm） 1189*325*140 1189*450*140 N.W 16.2kg 16.2kg 16.2kg 19.8kg 19.8kg Lumen(LM) 2925lm 3800lm 4400lm 5515lm 6600lm Luminous angle 120° 120° 120° 120° 120° Color temperature 6000k- 6500k 6000k- 6500k 6000k- 6500k 6000k-7300k 6000k-7300k Discharge time Full power 12hours 12hours 12hours 12hours 12hours Half power 24hours 24hours 24hours 24hours 24hours Working temperature

• 20℃-+60℃(charge temp.0℃-+60℃;discharge temp.-20℃-

+60℃) IP grade IP65 Mounting height 5-6m 6-7m 6-7m 7-8m 7-8m Space between light 18-20m 20-25m 20-25m 25-30m 25-30m

Product Parameter（100－120W）

Model

YBSS25100 YBSS30120

LED light source 100W 120W Solar Module 120W 140W PIR motion sensor Yes Yes Charge/discharg e protection Yes Yes Dimension（mm） 1325*543*54 N.W 22.2kg 25.2kg Lumen(LM) 13,000l m 15,600lm Luminous angle 120° 120° Color temperature 6000k- 6500k 6000k- 6500k Discharg e time Full power 12hours 12hours Half power 24hours 24hours Working temperature -20℃-+60℃(charge temp.0℃-+60℃;discharge temp.-20℃- +60℃) IP grade IP65 Mounting height 9-10m 10-12m Space between light 25-30m 25-30m

Product Parameter（100W） Special Addition

Reference Pictures Description FLAT SERIES Main Parameters

• 1. Materials: High quality Aluminum Alloy
• 2. Solar panel: 120W DC36V (High-efficiency Monocrystalline

silicon)

• 3. LED light: 100W DC30V (Bridgelux LED chip from US),

120 pcs LEDs, 45mil, 1W/LED

• 4. CCT (Correlated Color Temperature): 3000- 6500K

(optional)

• 5. Battery: Grade A LiFePO4 battery, 27AH DC25.6V
• 6. Luminous flux: 12000-13000lm
• 7. Work time: Continuously 4-5 rainy days, 12 hours per night

with dimming program

• 8. Control modes: Light / Timing / Microwave / Timing +

Microwave control 4 Timings program, 4 dimmings levels

• 9. Propositional mounting height: 9-10m
• 10. Propositional installation distance: 25-30m
• 11. Full remote control for diagnostic and programming
• 12. Certificates: CE, RoHS, FCC, TUV, SGS,

ISO9001:2015

• 13. Controller: Hybrid Power Supply, 10A, 220V/110V

(Optional)

PH-FL-100 100W Model Light Power

Installation Cases

Installation Cases

Installation Cases

Installation Cases

Product Parameter AC Street Light

SPECIFICATION OF AC STREET LIGHT 80W WITH MEANWELL DRIVER ELG-100-42A

No. Parameter Description 1 Input Voltage

200VAC ~ 305VAC 50/60 Hz

2 Power consumption 80W ± 2W 3 Light Source Phillips SMD LED 4 LED Life > 50,000 Hrs. 5 Color Temperature 5500 to 6500 0 K 6 Led Efficiency ≥ 120 lumens/watt 7 Total Lumen Output 10 000 Lumens 8 CRI ≥ 80 9 Beam Angle and Lens 70 0 (Approx.) 10 Driver Type Meanwell Constant Current Isolated ELG-100-42A. 11 Power Factor ≥ 0.97 12 Protections Short ckt, Open ckt, Over Voltage, Under Voltage, Over Current, Over Temperature, 13 THD ≤ 10% Electronic efficiency ≥ 90 % 14 Surge withstand Minimum 4 kV 15 Working Temp

• 40 0 to + 90 0 C

16 Enclosure Pressure Die Cast Aluminum with efficient heat dissipation design and coating 17 Cover N/A 18 Ingress Protection IP 65/ IP67 19 Mounting pipe dia. 40 – 60 mm. 20 Connecting cable 3 core (minimum 0.5mm2 )ISI marked , Minimum Length 1 Mtr. 21 Warranty Minimum 6 years from the receiving date of material

Product Parameter AC Street Light

SPECIFICATION OF AC STREET LIGHT 100W WITH MEANWELL DRIVER ELG-100-42A

No. Parameter Description 1 Input Voltage

200VAC ~ 305VAC 50/60 Hz

2 Power consumption 100W ± 2W 3 Light Source Phillips SMD LED 4 LED Life > 50,000 Hrs. 5 Color Temperature 5500 to 6500 0 K 6 Led Efficiency ≥ 120 lumens/watt 7 Total Lumen Output 14 000 Lumens 8 CRI ≥ 80 9 Beam Angle and Lens 70 0 (Approx.) 10 Driver Type Meanwell Constant Current Isolated ELG-100-42A. 11 Power Factor ≥ 0.97 12 Protections

Short ckt, Open ckt, Over Voltage, Under Voltage, Over Current, Over Temperature,

13 THD ≤ 10% Electronic efficiency ≥ 90 % 14 Surge withstand Minimum 4 kV 15 Working Temp

• 40 0 to + 90 0 C

16 Enclosure Pressure Die Cast Aluminum with efficient heat dissipation design and coating 17 Cover N/A 18 Ingress Protection IP 65/ IP67 19 Mounting pipe dia. 40 – 60 mm. 20 Connecting cable 3 core (minimum 0.5mm2 )ISI marked , Minimum Length 1 Mtr. 21 Warranty Minimum 6 years from the receiving date of material
