What will the future bring for signalling systems in Thalys

Peter ZIJDEMANS Senior Consultant, Ricardo Rail, The Netherlands July 9, Parallel Session 7, Technology B, Signalling

Content

• Thalys connecting European capitals
• Signalling systems in Thalys trains
• Continuous development
• Drivers of future developments
• Consequences for Thalys trains

2 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Thalys operation

• Thalys connects Paris, Brussels, Cologne and Amsterdam
• 26 train sets
• Four networks
• Five high speed sections
• 50 % conventional speeds
• Travel times up to 3 hours
• Paris Brussels 1h 20min

France TVM 430, KVB Germany PZB, LZB Netherlands ATB

Belgium Memor, TBL1, TBL2

HSL ERTMS L1, L2 France TVM 430, KVB Germany PZB, LZB Netherlands ATB

Belgium Memor, TBL1, TBL2

HSL ERTMS L1, L2

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 3

2005: Decision to develop and integrate ERTMS

• Scope of the decision:
• ERTMS version – Corridor 2007 (Baseline 2.3.0 D did not exist)
• System architecture – reuse of existing ATP equipment
• Definition of work packages
• Cost estimate and cost distribution
• Planning
• Management structure
• The first highspeed cross border ERTMS train

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 4

ERTMS Corridor 2007 Baseline version 2A

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 5

System architecture

EVC DMI GSM-R BTM STM France STM Belgium STM Germany STM NL JRU Odometry EVC DMI GSM-R BTM STM France STM Belgium STM Germany STM NL JRU Odometry

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 6

System architecture

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 7

Driving cabin Thalys PBKA

Class A ERTMS Class B TVM LZB ATB KVB TBL PZB

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B 8

Start of ERTMS operation in December 2009

Reaching the top right end of the EN50126 V-diagram

• NL: HSL-Zuid (Amsterdam-

Rotterdam and Rotterdam- Belgium border)

• B: L4 (Antwerp - Dutch border)
• B: L3 (Liège – German border)
• ETCS level 1 and level 2

9 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Continuous development

• During five year of operation
• Dual signalling ERTMS + ATB on deviation route
• Dual signalling ERTMS + TVM on incidental route
• ERTMS on routes in Belgium in various configurations
• Compatible with Thalys
• Compatible after adaptation of infrastructure design
• Compatible after adaptation of onboard software
• ERTMS on routes not used by Thalys
• Modification of class B systems

10 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Baselines: Compatibility onboard - infrastructure

11 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

  

Baseline 2 Baseline 3 BL2 BL3

Pre-Baseline 2

Infra Infra

Baseline 4 and higher



Compatible No compatibility



Future developments in the Netherlands

ERTMS BL 3 level 2

• Equip all trains with ERTMS +

ATB

• TEN lines with ERTMS only
• Other main lines with ERTMS
• nly

12 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Future developments in Belgium

ERTMS BL 2 level 1

• Freight corridors

ERTMS BL 2 level 2

• Core network

ERTMS BL 3 level 1 Limited Supervision

• All other lines

13 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Future developments in France

14 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

Roll-out ERTMS scheduled at European level only

• Freight corridors
• L1 and L2 on Paris-Lyon and new

lines

• Rhin - Rhône
• Est
• Nîmes - Montpellier

Future developments in Germany

15 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

• ERTMS BL 3 level 2
• Freight corridors
• Individual connections
• Rostock – Berlin
• Berlin – Halle – Leipzig
• POS Paris – Süddeutchland
• Various new and upgraded lines

LZB will remain up to 2026-2030 25% will be ETCS only

(http://fahrweg.dbnetze.com)

Drivers of future developments for Thalys trains

Infrastructure developments drive onboard developments

• ERTMS BL2 must be developed
• ERTMS BL3 must be developed
• Synchronise onboard development with upgrades

infrastructure No planning to make class B systems superfluous

16 Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

What will the future bring for signalling systems in Thalys

• ERTMS alone does not bring efficiency for Thalys
• ERTMS increases complexity of onboard systems and their
• peration
• ERTMS developments need to be carried on to maintain

interoperability Challenge: to improve ERTMS masterplans made by Infrastructure Managers to render Class B systems in High Speed trains superfluous

17

ERTMS masterplans should render Class B systems in High Speed trains superfluous

Peter ZIJDEMANS - Senior Consultant, Ricardo Rail, The Netherlands - July 7 - Session: 7 Technology B

...Thank you

for your kind attention
