Outline:

• A £198 million track & signalling scheme
• The signalling equipment around Derby Station is

nearing the end of its operational life

• The track layout is nearly 50 years old
• Since track & signalling work in unison and so are

being replaced together

• Preparatory work has already begun and as much

work as possible will be done prior to disrupting station users & passengers

• This includes installing 3.5km of track, new signal

bases, drainage, signals & telecoms cabling and construction of a new station platform

Derby project

/

Schedule of work:

• August 2017: Piling for new signal bases begins
• Christmas 2017:
• Removal of sidings & goods lines in the station area
• Some reduction in public car parking for materials

storage

• January - June 2018:
• Installation of signalling continues
• New 320 metre platform constructed - new stairs & lift

from existing pedestrian footbridge installed

• 22 July to 7 Oct 2018:
• Main works

Derby project

/

Main works (22 July to 7 Oct 2018) :

• The volume of work to be completed will take 79

days

• During this time:
• 14km of track will be replaced & re-laid in a new

configuration

• 55 new straight post signals, 9 new signal gantries & 79

sets of points will be installed

• 150,000 tonnes of new ballast will be laid
• 240 engineering trains will bring in material & remove

waste from the site

The station will remain operational for the majority

• f this period

Derby project

/

Benefits:

• The new layout will:
• Reduce bottlenecks
• Increased line speed
• Enable more efficient management of rail traffic &

quicker passage through station

• Deliver new signalling with remote condition

monitoring for improved reliability & ease of maintenance

• Provide greater operational flexibility & reliability
• Deliver a layout to help meet future growth

Derby project

/

Impact on station users/passengers:

• Derby Station will remain open & operational for

majority of 79 days in summer 2018

• We are still a year away from any disruption
• A train & replacement bus plan is being developed
• Network Rail and Train Operators are working together to

ensure key links, such as Derby to London, are maintained wherever possible

• There will be significant communications activity

during the project to keep you informed

• Including an online tool passengers can use to plan around

the disruption
