Shielding & Atomic Radius, Ions & Ionic Radius Chemistry AP Periodic Table Periodic Table Elements in same column have similar properties Column # (IA-VIIIA) gives # valence electrons All elements in column end in same ns x np y
SLIDE 2
SLIDE 3
Periodic Table
Elements in same column have similar properties Column # (IA-VIIIA) gives # valence electrons All elements in column end in same nsx npy configuration
SLIDE 4
Periodic Table
Elements in same column have similar properties Column # (IA-VIIIA) gives # valence electrons All elements in column end in same nsx npy configuration Ion Formation Metals lose electrons to form noble gas core: Na → Na+ + e–: [Ne]3s1 → [Ne] Al → Al3+ + 3e–: [Ne]3s23p1 → [Ne]
SLIDE 5
Periodic Table
Elements in same column have similar properties Column # (IA-VIIIA) gives # valence electrons All elements in column end in same nsx npy configuration Ion Formation Metals lose electrons to form noble gas core: Na → Na+ + e–: [Ne]3s1 → [Ne] Al → Al3+ + 3e–: [Ne]3s23p1 → [Ne] Nonmetals gain electrons to form next noble gas: F + e– → F: 1s22s22p5 → 1s22s22p6 or [Ne] Se + 2e– → Se2–: [Ar]4s23d104p4 → [Ar]4s23d104p6 or [Kr]
SLIDE 6
SLIDE 7
Special Ion Formation Transition metals lose ns2 electrons before (n–1)dx: Fe → Fe3+ + 3e–: [Ar]4s23d6 → [Ar]3d5 Ni → Ni2+ + 2e–: [Ar]4s23d8 → [Ar]3d8 Populated (n–1)d orbitals shield ns electrons, ns higher in energy, easier to remove Will see evidence in 2nd lesson from now
SLIDE 8
Special Ion Formation Transition metals lose ns2 electrons before (n–1)dx: Fe → Fe3+ + 3e–: [Ar]4s23d6 → [Ar]3d5 Ni → Ni2+ + 2e–: [Ar]4s23d8 → [Ar]3d8 Populated (n–1)d orbitals shield ns electrons, ns higher in energy, easier to remove Will see evidence in 2nd lesson from now Post-transition metals can lose ns2 npx or just npx electrons: Sn → Sn2+ + 2e–: [Kr]5s24d105p2 → [Kr]5s24d10 Sn → Sn4+ + 4e–: [Kr]5s24d105p2 → [Kr]4d10 Full (n–1)d10 called “pseudo-noble gas” configuration
SLIDE 9
Effective Nuclear Charge
SLIDE 10
Effective Nuclear Charge
Outermost (valence) electrons shielded from full nuclear charge (Z) by inner core electrons: Trade-off between coulombic attraction to nucleus and repulsion by core electrons
SLIDE 11
Effective Nuclear Charge
Outermost (valence) electrons shielded from full nuclear charge (Z) by inner core electrons: Trade-off between coulombic attraction to nucleus and repulsion by core electrons In all elements in energy levels n≥2, the effective nuclear charge, Zeff, is approximated by: Zeff = Z – σ σ is the shielding factor, repulsion by core electrons σ = number of core electrons Not exact; qualitative understanding of the phenomenon
SLIDE 12
Trends in Zeff
SLIDE 13
Within a period, Zeff increases as Z increases across and σ remains constant:
Trends in Zeff
SLIDE 14
Within a period, Zeff increases as Z increases across and σ remains constant:
Trends in Zeff
σ = 0 σ = 2 σ = 10
Z = 1+ Z = 2+ Z = 3+ Z = 4+ Z = 5+ Z = 6+ Z = 7+ Z = 8+ Z = 9+ Z = 10+ Z = 11+ Z = 12+ Z = 13+ Z = 14+ Z = 15+ Z = 16+ Z = 17+ Z = 18+
SLIDE 15
Within a period, Zeff increases as Z increases across and σ remains constant:
Trends in Zeff
Zeff=1+ Zeff=2+ Zeff=3+ Zeff=4+ Zeff=5+ Zeff=6+ Zeff=7+ Zeff=8+ Zeff=2 σ = 0 σ = 2 σ = 10
Z = 1+ Z = 2+ Z = 3+ Z = 4+ Z = 5+ Z = 6+ Z = 7+ Z = 8+ Z = 9+ Z = 10+ Z = 11+ Z = 12+ Z = 13+ Z = 14+ Z = 15+ Z = 16+ Z = 17+ Z = 18+
SLIDE 16
Within a period, Zeff increases as Z increases across and σ remains constant: Within a group, Zeff remains constant as Z and σ both increase as n increases
Trends in Zeff
Zeff=1+ Zeff=2+ Zeff=3+ Zeff=4+ Zeff=5+ Zeff=6+ Zeff=7+ Zeff=8+ Zeff=2 σ = 0 σ = 2 σ = 10
Z = 1+ Z = 2+ Z = 3+ Z = 4+ Z = 5+ Z = 6+ Z = 7+ Z = 8+ Z = 9+ Z = 10+ Z = 11+ Z = 12+ Z = 13+ Z = 14+ Z = 15+ Z = 16+ Z = 17+ Z = 18+
SLIDE 17
Within a period, Zeff increases as Z increases across and σ remains constant: Within a group, Zeff remains constant as Z and σ both increase as n increases Zeff = #Valence Electrons (outermost electrons with greatest n)
Trends in Zeff
Zeff=1+ Zeff=2+ Zeff=3+ Zeff=4+ Zeff=5+ Zeff=6+ Zeff=7+ Zeff=8+ Zeff=2 σ = 0 σ = 2 σ = 10
Z = 1+ Z = 2+ Z = 3+ Z = 4+ Z = 5+ Z = 6+ Z = 7+ Z = 8+ Z = 9+ Z = 10+ Z = 11+ Z = 12+ Z = 13+ Z = 14+ Z = 15+ Z = 16+ Z = 17+ Z = 18+
SLIDE 18
Atomic Radius
SLIDE 19
Radius is smallest where Zeff is largest, increases to left as Zeff decreases Electron attraction depends on Zeff Stronger attraction pulls electrons closer to nucleus Electron cloud, radius smaller
Atomic Radius
Radius Increases
SLIDE 20
Radius is smallest where Zeff is largest, increases to left as Zeff decreases Electron attraction depends on Zeff Stronger attraction pulls electrons closer to nucleus Electron cloud, radius smaller Radius increases as n increases Electrons in higher energy levels more shielded, farther from nucleus Electron orbitals larger, radius larger
Atomic Radius
Radius Increases Radius Increases
SLIDE 21
Periodic Variation in Radius
SLIDE 22
Periodic Variation in Radius
Atoms exhibit trends in radius from period to period:
SLIDE 23
Ionic Radius
SLIDE 24
Ionic Radius
Metals lose electrons: Na → Na+ + e– positive ion smaller than atom: less electron-electron repulsion, remaining electrons experience more electrostatic attraction to nucleus
SLIDE 25
Ionic Radius
Metals lose electrons: Na → Na+ + e– positive ion smaller than atom: less electron-electron repulsion, remaining electrons experience more electrostatic attraction to nucleus Nonmetals gain electrons: Cl + e– → Cl– negative ion larger than atom: more electron-electron repulsion, electrons experience less electrostatic attraction to nucleus
SLIDE 26
Ionic Radius
SLIDE 27
Ionic Radius
Ionic radius increases down group same trend as atomic radius
- uter electrons more shielded,
less attracted to nucleus
SLIDE 28
Ionic Radius
Negative Ions Positive Ions
Ionic radius increases down group same trend as atomic radius
- uter electrons more shielded,
less attracted to nucleus Ionic radius increases right-to-left Split at anion/cation boundary Anions filling higher energy level than cations
SLIDE 29
Isoelectronic Ions
SLIDE 30
Isoelectronic Ions
In isoelectronic series, all ions have same electron configuration
SLIDE 31
Isoelectronic Ions
In isoelectronic series, all ions have same electron configuration
[Ne] [Ar] [Xe]
SLIDE 32
Isoelectronic Ions
In isoelectronic series, all ions have same electron configuration radius decreases as Z (hence Zeff) increases Stronger electrostatic attraction with same number of electrons
[Ne] [Ar] [Xe]
