SHEPHERD UNIVERSITY WELLNESS CENTER Lisha A Brown| Lighting + Electrical AE Senior Thesis | April 13, 2011 PROJECT OVERVIEW OUTLINE INTRODUCTION LOCATION SHEPHERDSTOWN, WEST VIRGINIA PROJECT OVERVIEW SCOPE OF RE-DESIGN OCCUPANT FITNESS

slide-1
SLIDE 1

SHEPHERD UNIVERSITY WELLNESS CENTER

Lisha A Brown| Lighting + Electrical AE Senior Thesis | April 13, 2011

slide-2
SLIDE 2

LOCATION OCCUPANT SIZE LEVELS ARCHITECT LIGHTING AND MEP ENGINEER SHEPHERDSTOWN, WEST VIRGINIA FITNESS AND EDUCATION CENTER 73,400 SQUARE FEET TWO HUGHES GROUP ARCHITECTS BRINJAC ENGINEERS PROJECT OVERVIEW

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-3
SLIDE 3

LIGHTING ELECTRICAL ARCHITECTURAL ACOUSTICAL OUTDOOR ENTRY ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM FOUR SPACES PHOTOVOLTAIC ARRAY STUDY GENERATOR VS. DISTRIBUTED BATTERIES MULTI-PURPOSE ROOM MULTI-PURPOSE ROOM SCOPE OF RE-DESIGN

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-4
SLIDE 4

LIGHTING ELECTRICAL ARCHITECTURAL ACOUSTICAL OUTDOOR ENTRY ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM FOUR SPACES PHOTOVOLTAIC ARRAY STUDY GENERATOR VS. DISTRIBUTED BATTERIES MULTI-PURPOSE ROOM MULTI-PURPOSE ROOM PRESENTED TODAY

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-5
SLIDE 5

OBJECTIVE

TO INCORPORATE SOLAR POWER AND REDUCE THE BUILDING’S ENERGY COSTS

CONSIDERATIONS

LOCATION | SHEPHERDSTOWN, WEST VIRGINIA USABLE SUNLIGHT | 4.4 KW-HRS

PHOTOVOLTAIC ARRAY STUDY

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

CONSIDERATIONS

LOCATION | SHEPHERDSTOWN, WEST VIRGINIA USABLE SUNLIGHT | 4.4 KW-HRS

slide-6
SLIDE 6

SOLUTION

MOUNTING SYSTEM | UNIRAC SOLAR MODULE TYPE | SHARP, MONOCRYSTALLINE SIZE | 39.1” X 64.4” INVERTER | SHARP

PHOTOVOLTAIC ARRAY STUDY

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-7
SLIDE 7

RESULTS

KEY FIGURES

PHOTOVOLTAIC ARRAY STUDY

OUTLINE YEARLY PAYBACK INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-8
SLIDE 8

LIGHTING CONCEPT

OUTLINE

“THREE KEY ELEMENTS PROVIDE A BALANCED RECREATION PROGRAM: FITNESS ZONE, NEW POOL, AND A MULTI-FUNCTION GYMNASIUM.” HUGHES GROUP ARCHITECTS

INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-9
SLIDE 9

LIGHTING CONCEPT

OUTLINE

“THREE KEY ELEMENTS PROVIDE A BALANCED RECREATION PROGRAM: FITNESS ZONE, NEW POOL, AND A MULTI-FUNCTION GYMNASIUM.” HUGHES GROUP ARCHITECTS MOVEMENT | NAVIGATION | SAFETY

INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-10
SLIDE 10

ROTUNDA

slide-11
SLIDE 11

ROTUNDA

  • ACCENTUATE THE GRAND ENTRANCE
  • ENHANCE THE ARCHITECTURE AND MATERIALS
  • PROVIDE A PATHWAY OF LIGHT
  • LIGHTING POWER DENSITY OF 1.3 WATTS/ SQ. FT.

DESIGN CRITERIA AND CONSIDERATIONS

slide-12
SLIDE 12

ROTUNDA

slide-13
SLIDE 13

ROTUNDA (1) 32W CFL RECESSED DOWNLIGHT

slide-14
SLIDE 14

ROTUNDA (1) 32W CFL RECESSED DOWNLIGHT (1) 42W CFL SEMI-RECESSED WALLWASHER

slide-15
SLIDE 15

ROTUNDA

slide-16
SLIDE 16

ROTUNDA (1) 32W CFL RECESSED DOWNLIGHT

slide-17
SLIDE 17

ROTUNDA (1) 32W CFL RECESSED DOWNLIGHT (1) 35W MH T6 SEMI-RECESSED WALLWASHER

slide-18
SLIDE 18

ROTUNDA

slide-19
SLIDE 19

ROTUNDA

  • DEFINES BOUNDARIES USING PERIMETER LIGHTING
  • HIGHLIGHT WALKWAYS

DESIGN SUMMARY

Area Size Power Density Allowable Power Density Designed Rotunda 3780 sq. ft. 1.3 W/sq. ft. 1.256 W/sq. ft.

Area Average Illuminance Maximum Illuminance Minimum Illuminance Rotunda 1st level 7.98 fc 17 fc 2 fc Rotunda 2nd level 8.93 fc 19 fc 4 fc

slide-20
SLIDE 20

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-21
SLIDE 21

FITNESS ROOM

slide-22
SLIDE 22

FITNESS ROOM

  • DIRECT AND REFLECTED GLARE
  • UNIFORM LIGHT DISTRIBUTION ON TASK PLANE
  • VISUAL CLARITY
  • MOVEMENT THROUGHOUT SPACE
  • RECREATIONAL SPORTS ILLUMINATION OF 30 FC
  • LIGHTING POWER DENSITY OF 0.9 WATTS/ SQ. FT.

DESIGN CRITERIA AND CONSIDERATIONS

slide-23
SLIDE 23

FITNESS ROOM

slide-24
SLIDE 24

FITNESS ROOM (1) 80W T5HO LENSED DOWNLIGHT

slide-25
SLIDE 25

FITNESS ROOM (1) 80W T5HO LENSED DOWNLIGHT (1) 32W CFL RECESSED DOWNLIGHT

slide-26
SLIDE 26

FITNESS ROOM (1) 80W T5HO LENSED DOWNLIGHT (1) 32W CFL RECESSED DOWNLIGHT (1) 5W LED SUSPENDED PENDANT

slide-27
SLIDE 27

FITNESS ROOM

slide-28
SLIDE 28

FITNESS ROOM

  • CLARITY AND MOVEMENT USING THREE LIGHT LEVELS
  • ADEQUATE AND UNIFORM LIGHT LEVELS MET

DESIGN SUMMARY

Area Size Power Density Allowable Power Density Designed Exercise 4278 sq. ft. 0.9 W/sq. ft. 0.88 W/sq. ft.

Area Average Illuminance Maximum Illuminance Minimum Illuminance Exercise 31.7 fc 46.9 fc 5.3 fc

slide-29
SLIDE 29

OUTLINE INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-30
SLIDE 30

MULTI-PURPOSE ROOM

slide-31
SLIDE 31
  • MIRROR THE HIGH INTENSITY OF ACTIVITIES
  • ENHANCE THE PLAYFULNESS OF THE SPACE
  • WORK WITH THE LIGHTING SCHEME

MULTI-PURPOSE ROOM DESIGN GOALS ARCHITECTURAL BREADTH

slide-32
SLIDE 32
  • 4 PERFORATED METAL PANELS
  • SUSPENDED 2 FEET FROM CABLE CORDS
  • METAL L-SHAPED ANGLES FOR SUPPORT

MULTI-PURPOSE ROOM SOLUTION ARCHITECTURAL BREADTH

slide-33
SLIDE 33

MULTI-PURPOSE ROOM

  • FESTIVE IMPRESSION
  • SPARKLE AND REFLECTED HIGHLIGHTS
  • COLOR APPEARANCE
  • LIGHTING POWER DENSITY OF 1.3 WATTS/ SQ. FT.

DESIGN CRITERIA AND CONSIDERATIONS

slide-34
SLIDE 34

MULTI-PURPOSE ROOM

slide-35
SLIDE 35

MULTI-PURPOSE ROOM (1) 32W CFL RECESSED DOWNLIGHT

slide-36
SLIDE 36

MULTI-PURPOSE ROOM

slide-37
SLIDE 37

MULTI-PURPOSE ROOM

  • RANDOM PATTERNS OF LIGHT
  • WARM COLOR TEMPERATURE

DESIGN SUMMARY

Area Size Power Density Allowable Power Density Designed Multi-Purpose 1512 sq. ft. 1.3 W/sq. ft. 0.938 W/sq. ft.

Area Average Illuminance Maximum Illuminance Minimum Illuminance Multi-Purpose 14.61 fc 25.5 fc 9.2 fc

slide-38
SLIDE 38

OUTLINE

ELECTRICAL LIGHTING ARCHITECTURAL PHOTOVOLTAIC ARRAYS PAYBACK AFTER 20 YEARS RE-DESIGN PROMOTES MOVEMENT, NAVIGATION, AND SAFETY COMPLY WITH IESNA AND ASHRAE MULTI-PURPOSE ROOM IS AESTHETICALLY PLEASING SUMMARY OUTCOME

INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-39
SLIDE 39

OUTLINE

AE FACULTY BRINJAC ENGINEERS PROFESSOR DANNERTH PROFESSOR HOUSER PROFESSOR MISTRICK PROFESSOR HOLLAND SHAWN GOOD ACKNOWLEDGEMENTS FAMILY, FRIENDS, AND FELLOW AE

INTRODUCTION PROJECT OVERVIEW SCOPE OF RE-DESIGN ELECTRICAL DEPTH PHOTOVOLTAIC ARRAY STUDY LIGHTING DEPTH CONCEPT ROTUNDA FITNESS ROOM MULTI-PURPOSE ROOM ARCHITECTURAL BREADTH CONCLUSION SUMMARY OUTCOME ACKNOWLEDGEMENTS

slide-40
SLIDE 40

QUESTIONS | COMMENTS

Lisha A Brown| Lighting + Electrical AE Senior Thesis | April 13, 2011
