Shawn Hall

Hybrid RDMA

RDMA/SR mix for data, SR otherwise Client side events

Completion of sending request messages – polling Completion of incoming reply and control messages – interrupts

Server side events

Since it’s dedicated - polling

For small messages, memory (de)registration cost > zero-copy benefit

Data-piggybacked SR w/ pre-registered buffers

Client caches location of preallocated/ preregistered Fast RDMA buffers on I/O server RDMA Write with Immediate data Large transfers split into smaller ones Client/server communication and disk I/O pipelined

Internal Buffer Credit-Based Flow Control

Preallocated/prepinned buffers per connection

Server RDMA Buffer Management

Most I/O server memory allocated as RDMA buffers Buffers are grouped by size into “zones”

Try to fit into contiguous buffer, otherwise split transfer

Client RDMA Buffer Management

Dynamic (de)registration required for clients Pin-down cache delays deregistration, caches info

Pin-down not useful for I/O intensive applications

Fast Memory Registration and Deregistration

Uses pin-down cache and batched deregistration

% of pin-down cache hits

Chunk List – Multidimensional lists that store the locations of multiple buffers RPC Long Call – Long RPCs are broken into chunks

First message contains chunk list of other messages

NFS Write

Client Server

NFS Readdir and Readlink – similar to NFS Read NFS Read

Client Server Read-Read Design Client Server Read-Write Design

Server buffers exposed to client RDMA Server resources not freed until client sends RDMA_DONE Synchronous RDMA read causes latency Number of concurrent RDMA reads is limited

RPC long replies and NFS READ can come directly from server

Client cannot initiate RDMA and try to access other buffers, so more secure

Mellanox HCA can issue many RDMA write

• perations in parallel

No waiting for RDMA_DONE

Fewer server interrupts

Fast Memory Registration – registration steps that involve communication with the HCA are done at initialization rather than dynamically Buffer Registration Cache

No information about server buffers exposed

Physical Memory Registration – avoids virtual to physical address translation

Translation also does not need to be sent to HCA

RDMA_DONE elimination RDMA Write parallelism

No local scatter/gather, so more RDMA reads. Simultaneous reads are capped though, so decreased parallelism.

Server memory saturates.

Applies only to MPI implementation. Not portable. Portable and transparent to MPI stacks and applications

FUSE – software that allows to create a user level virtual file system. Berkeley Lab Checkpoint/Restart (BLCR) – writes a process image to a file for later restart. MPI Checkpointing Mechanisms – offered by MVAPICH2, MPICH2, OpenMPI.

MPI library flushes communication channel BLCR library used to dump memory snapshot BLCR library used to restart job if needed

VFS Cache Efficient Sequential Writes Needs Work

File Open – caught by FUSE, CRFS inserts/increments value in hash table, passes call to underlying file system File Close – buffer pool flushed into work queue, blocked until operations complete File Sync – complete all writes on file, pass fsync() to underlying file system Other File Operations – passed to file system

File Write

Data copied from file into chunk in buffer pool until chunk is full Chunk enqueued into work queue This triggers an I/O thread to wake up and write chunk

Number of I/O threads limited to prevent contention
