Sequencing technology and assembly Sanger sequencing Sanger sequencing with radioactivity High throughput Sanger sequencing with fmuorescence Roche/454 sequencing Yield: 500,000,000 bp Cost: $5,000 Time: ~1 min per bp

slide-1
SLIDE 1

Sequencing technology and assembly

slide-2
SLIDE 2

 Sanger sequencing with radioactivity  High throughput Sanger sequencing

with fmuorescence

Sanger sequencing

slide-3
SLIDE 3

Roche/454 sequencing

  • Yield: 500,000,000 bp
  • Cost: $5,000
  • Time: ~1 min per bp
  • Read length: 450 bp - > 1kb
slide-4
SLIDE 4

Pyrosequencing

slide-5
SLIDE 5

 Yield: 8,000,000,000 – 80,000,000,000 bp  Time: ~1 hour per bp  Read length: ~150 bp  Cost:

– Sample Extraction, $14.00/sample – Automated Sample Library, $90.00/sample – MiSeq (2x250), 1 lane 8-10Gb/lane, $1,700.00/sample – MiSeq (2x300), 1 lane, 10-12Gb/lane, $2,100.00/sample – HiSeq2500 (2x150), 1 lane, ~40Gb/lane, $2,500.00/lane – HiSeq2500 (2x250), 1 lane, ~65Gb/lane, $3,500.00/lane

Illumina sequencing

slide-6
SLIDE 6

Illumina sequencing

slide-7
SLIDE 7

 Yield: 50,000,000 bp  Time: 2 hours  Read length: 500bp  <1 min per bp  Cost: $500

Ion Torrent

slide-8
SLIDE 8

Ion Torrent

slide-9
SLIDE 9

PacBio

  • Long reads (5-10kb)
  • High error, but read 150x coverage
  • Library prep: $600
  • Sequencing: $300
slide-10
SLIDE 10

PacBio

slide-11
SLIDE 11

Minion

  • Quick sample prep
  • Long reads (~50kb)
  • High error
  • $150 per run
slide-12
SLIDE 12

Minion

slide-13
SLIDE 13

Errors

Difgerent technologies have difgerent error rates:

slide-14
SLIDE 14

 Need to be sure which base you have identifjed  Depends on the technology  Each machine includes software  Phred is an historical package developed by at U.

Washington

 Phred scores are probability that the base is

correct

Base calling

slide-15
SLIDE 15

 Phred 10: 1 x 101 chance that the base is wrong  Phred 20: 1 x 102 chance that the base is wrong  Phred 30: 1 x 103 chance that the base is wrong  Phred 40: 1 x 104 chance that the base is wrong  Phred 99: the base is correct!  Fastq scores are the score + 33 then converted to ascii text

Quality values

slide-16
SLIDE 16

Homopolymeric errors

Homopolymeric runs: Signal is not linear Not clear if 5 or 6 bases

slide-17
SLIDE 17

Errors

  • Difgerent technologies have difgerent error rates:
  • Pyrosequencing/Ion Torrent – homopolymeric

tracts

  • Illumina – substitution errors
  • PacBio – Machines can not keep up with biology
  • Minion – noise coming through the membrane
