Apicomplexan Genome Sequencing in Sanger Arnab Pain, The Pathogen - - PowerPoint PPT Presentation

SLIDE 1

Apicomplexan Genome Sequencing in Sanger

Arnab Pain, The Pathogen Sequencing Unit (PSU) 2nd November, 2005; ICGEB, New Delhi

SLIDE 2

Overview

• Overview of Apicomplexan genome

sequencing projects in Sanger

• Update on Plasmodium genome projects
• Theileria and Tropical Theileriosis
• Sequencing & annotation strategies
• Genome architecture
• Gene families
• Metabolic reconstruction
• Comparative genomics (eg. dN/dS analysis,

synteny)

• SNPs/ INDELs

SLIDE 3

Apicomplexans and ongoing genome seuencing projects

SLIDE 4

Overview of Eukaryotic Pathogen Sequencing in PSU

SLIDE 5

The World of Apicomplexans!

Intestinal disease in mammals Parasitise brain/ kidney of rodent Malaria Tropical theileriosis Babesiosis

• Periph. eosinophilia (30%)

Brain infection (Chinchila) Parasitises heart muscle/brain Toxoplasmosis parasitic disease of falcolns bowel diease in human Coccidiosis Insect gut parasites Cryptosporidiosis Insect gut parasites Dog parasites Oyster parasite

SLIDE 6

Update on Plasmodium genome projects

• P. falciparum (Gardner et al 2002)
• P. reichenowi (3x shotgun in progress)
• P. knowlesi (3x shotgun)
• P. berghei (3x shotgun complete)
• P. yoelii (5.6x, Carlton et al 2002)
• P. chabaudi (3x shotgun complete)
• P. gallinaceum (3x shotgun in progress)
• P. vivax (complete sequencing)

3D7: 3 gaps Clinical isolate: 8x IT strain: 31,000 reads (0.8x) 8x complete, prefinishing, annotation 8x complete, some finishing 8x complete, prefinish

SLIDE 7

Theileria and Tropical Theileriosis

SLIDE 8

Genus-Theileria

Theileria parva Parasite of cattle: East/Central Africa

‘East-Coast Fever’

Theileria annulata Parasite of cattle: S. Europe, North Africa, Middle East, Asia

‘Tropical Theileriosis’

Theileria hirci Parasite of sheep/goats:

• S. Europe, North Africa,

Middle East & Asia

(B. Shiels)

SLIDE 9

Theileria annulata

Disease; Tropical Theileriosis 250 million cattle are at risk Pathogenic in exotic animals, up to 70% mortality Mild to moderate pathogenicity in indigenous breeds but productivity loss

SLIDE 10

Theileria parva

Disease: East Coast Fever 50 million cattle at risk Highly pathogenic in naïve animals 97-100 % mortality rates

SLIDE 11

Clonal expansion of infected cells

H.nuc

Macroschizont Merozoite production merozoites Piroplasm infected erythrocytes

Theileria Life Cycle

SLIDE 12

Clinical Pathology Tropical Theileriosis (T. annulata) Following lymph node enlargement get fever Marked anaemia - pale mucous membranes which may become jaundiced, diarrhoea/blood stained faeces common Sub acute/chronic cases show intermittent fever, anaemia and Jaundice can be seen Poor condition and convalescence is protracted

SLIDE 13

Sequencing & annotation strategies

SLIDE 14

Shotgun sequencing

DNA Contiguous sequence

STS-1 STS-2 STS-3 STS-4

pUC clone end sequence physical gap sequence gap large clone end sequence “scaffold”

SLIDE 15

Strategy

• Separate chromosomes by PFGE.
• Shotgun sequence individual

chromosomes

• Align Contigs to map and close

gaps using PCR/primer walking.

SLIDE 16

Map Resources

• Mapped STS markers.

– Short sequence markers, mapped genetically.

• Mapped YAC clones.

– reads from mapped YAC clones align with contigs and thus position.

• Optical map

– DNA fragments of partial digestion of genome are sized

• ptically and tiled, providing ordered restriction fragments.
• HAPPY MAP

– Fragmented DNA diluted and replicated. STS markers detected by PCR.

SLIDE 17

Curating gene models in Artemis

Use of multiple lines of evidence

SLIDE 18

• T. annulata Genome

From Karyotype:

• Four chromosomes

– 2.6 Mb (3 gaps) – 2 Mb (Finished) – 1.9 Mb (2 small gaps) – 1.8 Mb (Finished)

From Sequencing:

• Number of bases: 8,351,610
• Gene number: 3792
• Genes with orthologues in T. parva: 3265
• GC percentage: 32.5
• Unique T. annulata genes: 34 (60 in T.

parva)

SLIDE 19

Gene finding & Annotation

SLIDE 20

e.g. Theileria annulata (~ 8.4 Mb)

Total contig length vs No of reads. Contig no. vs No. of reads

4X 8X 6X 3X 4X 8X 6X 3X

SLIDE 21

Genome architecture

SLIDE 22

The Chromosomes of P. falciparum

Rep20

TARE2-5

telomere Subtelomeric repeats

VAR genes

Rifin/stevor genes Other gene families

antigenic variation House-keeping antigenic variation

VAR genes Rifin

SLIDE 23

Chromosome Structure (Theileria)

Other families (0-2) Family_3 (0-3) Family_1 (up to 28), Family_3 (0-3) Repeats Family_5 (1-3)

(T)TTAGGG telomere

Secreted antigens House-keeping genes Secreted antigens Putative centromere

SLIDE 24

Telomeres

• T. parva
• T. parva
• T. annulata
• T. parva

e e

• T. annulata
• T. annulata

A) B) C)

Other fam (0-2) [Fam-1 (up to 28), Fam-3 (0 to 4)] [Fam-3 (0 to 3)]

Subtelomeric repeats (species-specific)

Fam-5 (1-3)

[(T)TTTAGGG]n

m

TaSR3 [TaSrpt2,TaSrpt1] TpSR3 TpSR2 TpSrpt1

SLIDE 25

• P. falciparum & P. vivax: sub-telomeric

species-specific gene families

• P. falciparum
• P. vivax

SLIDE 26

Centromeres

• P. falciparum

Chromosome 3 P falciparum Chromosome 2

• T. annulata

SLIDE 27

Synteny: TA & TP ACT comparison

SLIDE 28

Comparative Genomics: synteny

SLIDE 29

Comparing genomes with Artemis Comparison Tool (ACT): Chr 02

BlastN & TBlastX

• T. annulata
• T. parva

SLIDE 30

Pain et al. Science (2005)

SLIDE 31

• T. parva TPR loci

T PARVA T ANN Chr_02

TPR_related family shown in pink

SLIDE 32

ACT comparison: 3 malaria species

P P

• P. knowlesi

SLIDE 33

“species-specific” genes at interruptuions in synteny

Plasmodium falciparum Plasmodium yoelii Plasmodium knowlesi

SLIDE 34

Plasmodium core proteome and “species- specific” genes

Hall et al. Science (2005)

SLIDE 35

ACT Comparison: 3D7 vs PFCLIN

SLIDE 36

Gene Families

SLIDE 37

Clustering Theileria proteins

• All peptide sets from TA and TP combined
• BLASTed against itself with a cutoff of E=10-5.
• TRIBE-MCL run with an inflation value of 5 (quite stringent).
• Each checked for numbers of peptides from each organism.

To identify which gene families have expanded in which

• rganisms.
• Clusters annotated using predicted products in TA & TP

SLIDE 38

Theileria-specific gene families: Family 1 (SVSP)

Exclusively Sub-telomeric Contain 1 or more DUF529 (now called FAINT) domains Majority contain signal peptides and conserved C-termini Unequally expanded (48 in TA, 85 in TP) Expressed during macroschizont stage (EST evidence)

SLIDE 39

DUF529 domain containing proteins Frequently Appears IN Theileria: FAINT

• Only found in Theileria proteins
• Highly diverged ~70 residue domain
• Majority of FAINT- domain containing proteins have signal peptides
• > 900 copies per genome (in at least 166 Theileria annulata proteins)
• Many are expressed at least at the macroschizont stage

SLIDE 40

Comparative Genomics: protein domains

SLIDE 41

Architecture of Theileria proteins with FAINT domain

[TA03125 / TP01_0608, Tash1] [TA20095 / TP01_0602, TashAT2] [TA20082, TashAT3] [TA17375 / TP03_0861, Polymorphic antigen precursor / P150] [TA20085 / TP01_0604, TashAT1] [TA08425 / TP04_0437, Microneme-rhoptry protein] [TA17505, SfiI-fragment-related hypothetical protein, family 3] [TA20090 / TP01_0603, TashHN]

• FAINT
• AT-hook
• PEST
• PT
• Signal peptide

(332 aa) (416 aa) (465 aa) (994 aa) (1163 aa) (893 aa) (1338 aa) (2732 aa) [TA18865, Subtelomeric hypothetical protein (SVSP), family 1] [TA18950, Subtelomeric hypothetical protein (SVSP), family 1] (502 aa) (605 aa) Domain keys:

SLIDE 42

Whole genome domain

• rganisation of pfEMP1 proteins
• 59 var genes in total.
• Expressed on red

cell surface and involved in sequestration

• 3 types of domain.

– DBL- duffy binding like – CIDR- cystine rich interdomain region – C2 - constant2

SLIDE 43

Comparative Genomics: metabolic reconstruction

SLIDE 44

SLIDE 45

KEGG: Phospholipid metabolism

X8

SLIDE 46

IMP AMP XMP GMP GTP GDP

glutamate N-acetyl-glutamate glutamine

Amino Compounds

aspartate methionine salvage pathway NOVEL INHIBITORS glycine serine cysteine alanine proline asparagine

• rnithine
• rnithine

spermidine putrescine

Purine salvage, Pyrimidine synthesis

PEP

pyruvate

GLYCEROL GLUCOSE

fructose-6P fructose-1,6-bisP dihydroxyacetone-P + glyceraldehyde-3P

Glycolysis Glycolysis

myo-inositol-1P L-LACTATE 6-phospho- gluconate ribulose-5P ribose-5P

Pentose Phosphate Pentose Phosphate Pathway Pathway

PRPP glucosamine-6P glucosamine glucosamine-1P dihydroorotate

• rotate

dUMP Methylene THF DHF THF xylulose-5P + erythrose-4P CDP dCDP DNA RNA chorismate ?

Shikimic Acid Shikimic Acid Pathway Pathway

CoA dephosphoCoA riboflavin FMN FAD CO2 pABA Folate biosynthesis glycosyl phophatidylinositol (GPI anchors)

NOVEL INHIBITORS

Glycerolipid Metabolism Glycerolipid Metabolism

3-deoxyarabino- heptulosanate- 7-phosphate dTMP Pyrimethamine Cycloguanyl

• xaloacetate

glycerol triacylglycerol phosphatidylcholine choline ethanolamine phosphatidylethanolamine Protohaem (FPIX2+) porpho- bilinogen acetoacetyl-ACP + malonyl-ACP

APICOPLAST

isopentenyl-PP 3-oxoacyl-ACP 3-hydroxy- acyl-ACP enoyl-ACP acyl-ACP acetyl-CoA

Haem Haem Biosynthesis Biosynthesis Fatty acid Fatty acid elongation elongation

Glycerolipids Triclosan Thiolactomycin ALA Haem A Haem C Ubiquinone (UQ) acetate glycine NAD+ NADH modified tRNAs ? malonyl-CoA pyruvate glucose-6P malate

NOVEL INHIBITORS

2C-methylerythrose-4P deoxyxylulose-5P

NOVEL INHIBITORS

O2 FPIX2+ Large peptides Small peptides Amino Amino acids acids Haemoglobin FPIX3+ O2- Haemozoin

FOOD VACUOLE

Chloroquine Artemesinin Quinine

PROTEASE INHIBITORS PROTEASE INHIBITORS F, V, & P-type ATPases

ADP ATP

H+

V

ADP ATP P-lipids, Cu2+,

• ther cations?

(16)

P

Na+ H+ Ca2+ H+ Zn2+ H+ Mn2+ H+

water/ glycerol nucleotide

• r nt-sugar?

(2)

nucleo- side/base ADP ATP

H+

F ?

? H+ NOVEL INHIBITORS

Sulfonamides ATP hypoxanthine xanthine guanine

Folate Biosynthesis Folate Biosynthesis

7,8-dihydropteroate dihydrofolate (DHF) tetrahydrofolate (THF) pABA Pyrimethamine Cycloguanyl

Purines and Purines and Pyrimidines Pyrimidines

H2O Cytc Fe3+ Cytc Fe2+ UQ UQH2 O2

• r

Atovaquone CO2 + aspartate

MITOCHONDRION

acetyl-CoA glucose-1P

DOXP Pathway DOXP Pathway

Fosmidomycin aminolevulinic acid (ALA)

• xoglutarate

citrate

Tricarboxylic acid Tricarboxylic acid cycle cycle

• xaloacetate

malate fumarate succinate succinyl-CoA isocitrate cis-aconitate

Fatty Acid Fatty Acid Biosynthesis Biosynthesis

NOVEL INHIBITORS

PPi

H+

(2)

Pi ADP ATP

ABC transporters

(13)

drugs?

NOVEL INHIBITORS NOVEL INHIBITORS

? malate

• xaloacetate
• r

ubiquinone pool

Gardner et al. Nature (2002)

? ++

SLIDE 47

Transcription-Associated Proteins (TAPs)

Ta Pf Sp Sc At Ce Ag Dm Hs Ta Pf

SLIDE 48

Transcription Associated Proteins (TAPs)

SLIDE 49

Comparative Genomics: genes under selection

SLIDE 50

The dN/dS ratio is higher on average in genes with signal peptides

dN/dS ratio of genes with and without signal peptides in T.parva and T. annulata

0.05 0.1 0.15 0.2 0.25 0.3 0.35

• .

4 9 . 1

• .

1 4 9 . 2

• .

2 4 9 . 3

• .

3 4 9 . 4

• .

4 4 9 . 5

• .

5 4 9 . 6

• .

6 4 9 . 7

• .

7 4 9 . 8

• .

8 4 9 dN/dS Proportion of genes sigp non_sigp

The dN/dS distribution is different. Possibly proteins with signal peptide are interacting with the host immune system hence dN/dS may be an indicator of antigenicity

SLIDE 51

Orthologous genes under ‘selection’

Pb vs Py Pb vs Pc Pc vs Py Pb vs Pf Pc vs Pf All rodent All

• Av. Protein

Identity 88 % 83 % 85 % 63 % 62%

• Av Nucleotide

Identity 91 % 87 % 88 % 70 % 70 %

• Median dN

4.2% 7% 6.7% 27% 26.9%

• Median dS

26 % 48% 53% 26% 26.5%

• Mean dN/dS

0.16 0.13 0.11 0.009 0.0092

• Number of
• rthologous gene

pairs detected 3153 4678 3318 3890 3842 2528 2125

Most orthologues are easily identifiable, so where do the differences lie?

SLIDE 52

Comparative Genomics: genes under selection

SLIDE 53

Comparing P. falciparum strains / isolates

• Genes not present in 3D7
• Genes unique to 3D7
• Rapidly evolving genes
• SNP detection
• Indels (insertions, deletions)
• Any other noteworthy differences from

3D7

SLIDE 54

Data

• Plasmodium falciparum (3D7) genome

– Laboratory-adapted isolate, completed 2002 – 23 Mb, 14 chromosomes

• Sanger Pathogen Group projects

–

• P. falciparum Ghanaian Isolate (PFCLIN)

– 266K Plasmodium reads (~8x) – Only just completed – all prelim. analysis to date on 5X

–

• P. falciparum IT strain (IT)

–

• Ex. Brazil, laboratory-adapted

– 36K Plasmodium reads (~1X) –

• P. riechenowi (REICH)

– chimp parasite – 51K Plasmodium reads (~1x)

SLIDE 55

Analysis

• Genome reconstruction by mapping

PFCLIN (X5 assembly) contigs onto 3D7 scaffold (ACT)

• Comparative annotation
• Mapping WGS reads onto 3D7 scaffold

(SSAHA2-Sequence Search and Alignment by Hashing Algorithm )

– SNPs – INDELs

SLIDE 56

Contig ordering & annotation of PFCLIN

PF3D7 (chromosome)

NNNNNNNNNN NNN NNN NNN

PFCLIN (ordered contigs) PFCLIN (annotated contigs)

SLIDE 57

Contig ordering I: Chr 1

SLIDE 58

Mapping reads onto 3D7 assembly using SSAHA

SLIDE 59

SNP detection (SSAHA2): Chr1 & Chr2

(1135) (738, 633) (576, 559) (446) (1140) (963, 789) (809, 601) (464)

SLIDE 60

Acknowledgements
