Self Control Protector (SCP)

Surface mounted type fuse for Li-ion rechargeable battery

Agenda

• Dexerials
• What is SCP?
• Product Line-up
• Technology Roadmap
• Solutions

Overview Main products Headquarters : Tokyo, Japan Marketing offices : 8 Manufacturing sites : 8 Employees : 2,366(Consolidated)

Optical materials Adhesive materials Electronic components

Optical elasticity resin Coating materials for

• ptical disks

Antireflection film Hard coated film Anisotropic Conductive Film (ACF) UV curable adhesives Adhesive tapes Thermal conductive sheets

Self Control Protector (SCP)

NFC antenna Touch Panel Inorganic polarizer Receiving Coil for Wireless Charging

Our name Over view Main products Display material specialists with advanced solutions

Dexterous + Materials

Headquarters : Tokyo, Japan Marketing offices : 8 Manufacturing sites : 8 Employees : 2,693 (Consolidated)

Optical materials Adhesive materials Electronic components New energy materials

Optical elasticity resin Coating materials for

• ptical disks

Antireflection film Hard coated film Anisotropic Conductive Film (ACF) UV curable adhesives Adhesive tapes Thermal conductive sheets

Self Control Protector (SCP)

Inorganic polarizer Solar cell Conductive Film

What is SCP?

(Photo) 5A rated series

Features

It protects a Li-ion battery from the overcurrent and the overvoltage. It has been shipped over 1.5 billion pcs. since its launch in 1993 the beginning of the Li-ion battery commercialization. It is a standard product of the secondary protection device.

• Small, Thin and Surface mountable package
• Overcurrent and Overvoltage protection

SCP : Self Control Protector

Structure Equivalent circuit

Small, thin and surface mountable

(Photo) SFR 12A rated series Ceramic board Electrode Heater Insulator Fuse element Cap

Front view Side view

T1 T2 T3

0.75mm

Liquid Crystal Polymer Ceramic

12A

x x x x x x x x

2.7mm

T1 T3 T2

R1A

1.8mm

Application examples

SCP Smartphone Tablet PC

Battery management system

Notebook PC Power Tool E-Bike Energy Storage System Outdoor Power Equipment E-Scooter e-call

Small Large Application

Medical

Medical Applications

Powerknee Electric tooth brush Medical carts Blood pump Eye disease detection Blood and infusion warmer

SCP

Battery Pack FET 2nd Protection IC

Cell Cell

Cell Cell Cell Cell Cell Cell

Charger 1st Protection IC FET FET

An example of a circuit diagram for a Li-ion secondary battery protection of notebook PC

How does it work?

<Current>

SCP

Battery Pack FET 2nd Protection IC

Cell Cell

Cell Cell Cell Cell Cell Cell

Charger 1st Protection IC FET FET

An example of a circuit diagram for a Li-ion secondary battery protection of notebook PC

How does it work?

<Over Current> Cut

Heater Fuse ① ③ ②

×

SCP

SCP

Battery Pack FET 2nd Protection IC

Cell Cell

Cell Cell Cell Cell Cell Cell

Charger 1st Protection IC FET FET

An example of a circuit diagram for a Li-ion secondary battery protection of notebook PC

How does it work?

Cut <Over Charge>

FET : ON SCP

Heater Fuse ① ③ ②

× ×

SCP operation

Normal state

Example of overcurrent protection Example of overvoltage protection

(Photo) SFH-12A series

SCP Technology roadmap

SFJ-A （2013） SFJ-U （2014）

SFR （2016） SFS （2018）

Thinner Smaller

4.0 x 3.0 x 1.05 4.0 x 3.0 x 0.85 2.7 x 1.8 x 0.75

12.6 ｍｍ3 10.2 ｍｍ3

3.6 ｍｍ3

2 x 1.5 x 0.75 Under Consideration

2.25 ｍｍ3

▲70% ▲82% ▲20%

Technology roadmap : Smaller and Thinner

Super High Rate Type Screw Connected

*Caution: There are possibilities that the specification may be revised without notice in the future. Unit : mm

17.8 6

T-1 T-3 T-2

30 10 16.8 0.5

Terminal Case

29.4 10 15.1 40

120A M

External View

SFM Series

20 x 17 x 6mm (Screwed)

30A 45A 60A 90A-120A

5.4 x 3.2 x 1.25mm

SFH-30A

9.5 x 5.0 x 2.0mm

SFK-30A

15 x 8 x 3mm Under Consideration

SFH-60A SFK-45A

~ 2016

SFK-60A Launch

2018-19

Current SCP

Technology roadmap : Higher rate

2017

Underdevelopment

SFL-90A

120A 145A

40 x 29.4 x 6 mm (Screwed)

Underdevelopment

Current SCP

SFM-120A SFM-145A

Rated Voltage

Cells in series

1cell 2cells 3cells 4cells 5cells 6-7cells 9-10cells 12-14cells

Rated current

120A 50V 60A 62V 45A 30A 22A 36V 15A 12A 5A

SFR

Product line-up

：Under Development SFK

High Rate With standard size Small and Thin High Rate With wider operation Voltage

SFJ series SFH series SFK series

SFJ SFK SFH SFJ SFK

SFR series

SFR SFM

Super High Rate Screwed connection type

SFM series

Super Small size

SFR

1.8×2.7×0.75mm 4.0×3.0×0.85mm 5.4×3.2×1.35mm 9.5×5.0×2.0mm 40×30×6.0mm

SFJ SFJ

PSx series:

PSH-35A PSK-65A Features:

Specialized Over Current Fuse: PSx series

0.001 0.01 0.1 1 10 100 100 200 300

Cut Time(s) Current(A)

Current vs Cut Time (at 25℃)

PSH-35A PSK-65A

Thinner

Surface mountable

Smaller

For customers who need;

4 8 12 16 20 30 50 100 200 300 150 100 50 30 15 10 5 Operating voltage [V] Rated current [A]

LIB application Trend

SFK-series

High Rate

SFJ series

Smaller and Thinner

SFR series

Super Small size

SFM-series

Super High Rate

What if our SCP will not fit in your application?

Lower current solution

In case you would like to use our SCP. However it has to cut under the double rated current In this case you can add a current detection circuit and a resistor. The current detection circuit will detect the lower current and turns the FET

• n. The SCP can cut at any time you want.

High voltage solution (VDR)

Voltage Divide Resistance

High voltage solution (SVS)

2nd-IC will check all the cells SCP model for 5 cells

Suitable Voltage Supply

FET line for 5 cells. In case of overvoltage: FET turns ON and the suitable voltage will be suplied through the heather

High current solution (Parallel)

Parallel Solution

Thank you

For more information or samples, please contact: Dexerials Europe B.V. Jan-Willem Dubru |jan-willem.dubru@dexerials.com |+31 20 44 99 703

Small SCP : 12A rated SFJ series

12A J1x 12A J2x 12A J3x 12A J4x Applicable Cells in series

1 cell 2 cells 3 cells 4 cells

Product (“x” is Any Letter(*))

SFJ-0412x SFJ-0812x SFJ-1212x SFJ-1412x

Rated current 12A Size 4.0 x 3.0 x 0.85 mm Fuse resistance (Typical) 2.4 m-ohm Operating voltage 3.0 - 4.5 V 4.0 - 9.0 V 7.4 - 13.8 V 10.5 - 19.6 V Heater resistance 0.6 - 1.5 ohm 2.0 - 3.2 ohm 5.7 - 9.9 ohm 11.2 - 20.0 ohm Marking (x and # = Any letter or digit) Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 36 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity

50 A

Re-flow temp.（MAX） 260 deg.C

• Products Lineup

(*)”x” is defined according to the version of the product. The latest letter is “U”

Applicable Cells in series 1 cell 2 cells 3 cells 4 cells 5cells Product (“x” is Any Letter(*)) － SFJ-0815x SFJ-1215x SFJ-1415x SFJ-2015x Rated current － 15A Size － 4.0 x 3.0 x 0.85 mm Fuse resistance (Typical) － 1.5 m-ohm Operating voltage － 5.0 – 9.0 V 7.4 - 13.8 V 10.5 - 19.6 V 14.4-23.5 V Heater resistance － 2.2 – 3.3 ohm 5.5 – 8.4 ohm 10.4 – 15.8ohm 17.9 -29.1 ohm Marking (x and # = Any letter or digit) Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Antimony Free 700ppm or less Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 36 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 50 A Re-flow temp.（MAX） 260 deg.C

• Products Lineup

Small SCP : 15A rated SFJ series

15A J3x 15A J4x 15A J5x 15A J2x

(*)”x” is defined according to the version of the product. The latest letter is “U”

Small SCP : 22A rated SFJ series

Applicable Cells in series 1 cell 2 cells 3 cells 4 cells 5 cells Product SFJ-0422U SFJ-0822U SFJ-1222U SFJ-1422U SFJ-2022U Rated current 22A Size 4.0 x 3.0 x 0.85 mm Fuse resistance (Typical) 0.9 m-ohm Operating voltage 3.5 - 4.7V 6-9.2V 9-13.8V 12.0-18.5V 15.9-23.1V Heater resistance 0.68 – 1.0 ohm 2.3-3.4ohm 5.3-7.5ohm 9.75-13.25ohm 16.1-23.1mohm Marking (x and # = Any letter or digit) Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Antimony Free 700ppm or less Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 36 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 50 A Re-flow temp.（MAX） 260 deg.C 22A J1U

• Products Lineup

22A J4U 22A J5U

Under development

22A J2U 22A J3U

Applicable Cells in series 1 cell 2 cells 3 cells 4 cells Product (“x” is Any Letter(*)) SFR-0405x SFR-0805x SFR-1205x SFR-1405x Rated current 5A Size 2.7 x 1.8 x 0.75 mm Fuse resistance (Typical) 5.3 m-ohm Operating voltage 2.5 – 5.5 V 4.0 - 10.0 V 7.4 - 15.0 V 10.5 - 20.0 V Heater resistance 1.25– 2.05 ohm 3.85 - 5.35 ohm 10.8 - 18.2 ohm 21.7 – 36.3 ohm Marking (x and # = Any letter or digit) Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 36 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 50 A Re-flow temp.（MAX） 260 deg.C

• Products Lineup

Super Small SCP : 5A rated SFR series

5A R1x 5A R2x 5A R3x 5A R4x

(*)”x” is defined according to the version of the product. The latest letter is “A”

Applicable Cells in series 1 cell 2 cells 3 cells 4 cells Product (“x” is Any Letter(*)) SFR-0412x SFR-0812x SFR-1212x SFR-1412x Rated current 12A Size 2.7 x 1.8 x 0.75 mm Fuse resistance (Typical) 3.9 m-ohm Operating voltage 3.0 – 5.0 V 6.0 – 9.4 V 9.0 – 14.0 V 12.0 – 18.6 V Heater resistance 0.84 - 1.26 ohm 3.4 - 4.9 ohm 7.8 - 10.9 ohm 14.1 – 19.3 ohm Marking (x and # = Any letter or digit)

• Products Lineup

Super Small SCP : 12A rated SFR series

12A R1x 12A R2x 12A R3x 12A R4x Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Antimony Free 700ppm or less Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) ) Rated voltage 36VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 50A Re-flow temp.（MAX） 260deg.C

Under development

(*)”x” is defined according to the version of the product. The latest letter is “A”

30A rated SCP : SFH series

Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 62VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 80A Re-flow temp.（MAX） 260deg.C Applicable Cells in series 3cells 4cells 5cells 7 cells 9-10 cells 13-14 cells Product (“x” is Any Letter(*)) SFH-1230x SFH-1430x SFH-2030x SFH-3030x SFH-4030x SFH-5030x Rated current 30A Size 5.4 x 3.2 x 1.15 mm Fuse resistance (Typical) 1.3 m-ohm Operating voltage 9.9 – 13.5 V 13.4 – 18.4 V 17.1 – 23.5 V 23.0 – 31.5 V 34.2 – 46.9 V 49.0 – 62.0 V Heater resistance 4.2 – 7.0

• hm

7.7 – 12.9

• hm

12.6 – 21.0

• hm

22.6 – 37.7

• hm

63.75 – 86.25

• hm

130.05 – 175.95

• hm

Marking 30A H3x 30A H10x 30A H7x 30A H14x

• Products Lineup

30A H5x 30A H4x

(*)”x” is defined according to the version of the product. The latest letter is “A”

30A rated SCP : SFK series

30A K01x SC SF 30A K07x SC SF 30A K45x SC SF 30A K10x SC SF 30A K03x SC SF Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 62 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 80 A Re-flow temp.（MAX） 260 deg.C

• Products Lineup

(*)”x” is defined according to the version of the product. The latest letter is “A”

Applicable Cells in series 1-2 cells 3 cells 4-5cells 6-9 cells 10-14 cells Product (“x” is Any Letter(*)) SFK-0630x SFK-1230x SFK-1830x SFK-3030x SFK-4030x Rated current 30A Size 9.5x5.0x2.0 mm Fuse resistance (Typical) 1.3 m-ohm Operating voltage 4.0 – 9.6 V 8.4 – 19.1 V 10.5 – 23.5 V 20.2 – 46.3 V 28.0 – 62.0 V Heater resistance 0.8 – 1.2 ohm 3.2 – 5.2 ohm 4.8 – 8.0 ohm 18.8 – 31.2 ohm 40.0 – 60.0 ohm Marking

45A K04x SC SF 45A K10x SC SF 45A K07x SC SF 45A K14x SC SF 45A K05x SC SF 45A K03x SC SF

45A rated SCP : SFK series

Items General Specification Environmental compliance Compliance with RoHS Halogen Free Bromine (Br)=900ppm or less, Chlorine (Cl)=900ppm or less, Br+Cl=1500ppm or less (By weight) Qualification UL248-14 (File No. E167588)，TUV (Certificate No. J9650637) Rated voltage 62 VDC (*)It is the maximum voltage can be cut off by fuse. It is not the operational voltage of the heater. Rated breaking capacity 120 A Re-flow temp.（MAX） 260 deg.C Applicable Cells in series 3cells 4cells 5cells 6-7 cells 9-10 cells 12-14 cells Product (“x” is Any Letter(*)) SFK-1245x SFK-1445x SFK-2045x SFK-3045x SFK-4045x SFK-5045x Rated current 45A Size 9.5 x 5.0 x 2.0 mm Fuse resistance (Typical) 1.1 m-ohm Operating voltage 9.8 – 13.5 V 13.0 – 18.4 V 16.7 – 23.5 V 22.3 – 31.5 V 33.0 – 46.9 V 43.7 – 62.0 V Heater resistance 1.9 – 2.9 ohm 3.4 – 5.1 ohm 5.6 – 8.4 ohm 10.0 – 15.0 ohm 22.0 – 33.0 ohm 38.5 – 57.8 ohm Marking

• Products Lineup

(*)”x” is defined according to the version of the product. The latest letter is “A”

120A rated SCP : SFM series

• Products Lineup

*Caution: There are possibilities that the specification may be revised without notice in the future.

Applicable Cells in series 3 cells 4 cells 5 cells 6 - 7 cells 8 - 11 cells 12 - 14 cells Product (“x” is Any Letter(*1)) SFM-12120x SFM-14120x SFM-20120x SFM-30120x SFM-40120x SFM-50120x Rated current 120A Size 40.0 x 29.4 x 6.0 mm Fuse resistance (Typical) 0.5 m-ohm Operating voltage 8.2 - 13.5 V 10.8 - 18.0 V 14.2 - 23.5 V 18.9 – 31.5 V 29.7 – 49.5 V 37.7 – 62.0 V Heater resistance 1.0 – 1.6 ohm 1.8 – 2.7 ohm 3.0 – 4.7 ohm 5.5 – 8.3 ohm 13.6 – 20.5 ohm 22.0 – 33.0 ohm Marking Environmental compliance Compliance with RoHS Qualification UL248-14 (File No. E489967) 120A M05x 120A M07x 120A M10x 120A M14x 120A M04x 120A M03x

*1 x” is defined according to the version of the product. The latest letter is “A”
