Selecting a High Pressure Impingement Mix Spray Gun

John H. Bender Diamond Spray Coating 9507 Santa Fe Springs Road Santa Fe Springs, CA. 90670 562-781-1045 jhbender@diamondliners.com www.diamondspraycoatings.com

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013 Fusion AP Probler P2 Probler P2 Elite Probler P2 Elite Chopper Fusion AP Auto Spray Gusmer GAP Pro Probler P2 Auto Spray PMC AP2

Air Purge Spray Guns Used in Polyurea Applications Today

Air Purge Round Pattern Mix Chambers

Fusion AP Probler P2 & P2 Elite Gusmer GAP Probler

**Note: Gusmer GAP and Probler may look similar but they are different sizes.

PMC AP2 Mix Chamber & Cap 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Internal Mixing Impingement of ISO & Poly inside of an Air Purge Round Mix Chamber Fusion AP Cyclone-Mix Chamber

See all the mixing going

• n inside of the nozzle?

ISO - Red Poly - Blue 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013 This is why you must

keep the nozzle clean!!

Cleaning of Mix Chambers

Fusion AP AR2929 Mix Chamber uses three different drill sizes: nozzle, counter bore & impingement ports Probler P2 03 Mix Chamber uses two different drill sizes: nozzle insert & impingement ports 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013 *Using the Proper Size Drill is a Must!

Tools To Check Drill Sizes

You need to know your Drill Size. Learn to read a Micrometer or Use a Drill Gauge. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mix Chamber Conversion Chart

Fusion AP, P2, Probler, Gap PMC AP2 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Air Purge Spray Guns Flow Rates in Gallons Per Min.

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Air Purge Flat Pattern Adaptors

Fusion Flat Cap, Tip, Chamber Fusion Adaptor for use with Fusion MP Tips Fusion Adaptor for use with Gusmer PCD Tips Adaptor that can be used with round or flat Fusion AP mix chambers Probler P2 Adaptor for use with Tungsten Carbide Tips PMC AP2 Adaptor for use With Tungsten Carbide Tips Gusmer GAP Adaptor for Tungsten Carbide Tips Probler P1 Adaptor for Tungsten Carbide Tips

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Flat Tip Cleaning Tool

One tool can clean ID of Tip / PCD Pattern Control Disc. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Air Purge Static Mix Adaptors with Flat Tips

P2 Static Mix Adaptor for use with Tungsten Carbide Tips Probler Static Mix Adaptor for use with Tungsten Carbide Tips Gusmer GAP Static Mix Adaptor for use with Tungsten Carbide Tips

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

AP-2 Air Purge Gun

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Graco Fusion AP

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Probler P2

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Liquid Purge/Air Purge Guns

Fusion Clear Shot 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Liquid Purge Mix Chambers

Fusion Clear Shot Round Mix Chamber Fusion Clear Shot Flat Mix Chamber 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Liquid Purge Flat Spray Adaptors

Fusion CS Flat Tip and Retainer Fusion CS Flat Tip Adaptor Allows you to use any Gusmer GX7-DI Flat Tip 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Fusion Clear Shot

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Fusion MP Gusmer GX7-400 Gusmer GX-7 DI Gusmer GX-8 Pentech BD Gun Pentech MG Gun Pentech Palm Gun 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mechanical Purge Guns

Mechanical Purge Mix Modules

Fusion MP Direct Impingement Module 1 ISO & 1 Poly Fusion MP Round Module 2 ISO & 2 Poly Higher Output Gusmer GX-7-400 2 ISO & 2 Poly Gusmer GX-7-400 2 ISO & 2 Poly Gusmer GX-7-400 1 ISO & 1 Poly Gusmer GX-7-DI Direct Impingement Module 1 ISO & 1 Poly

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mechanical Purge Low Output Modules

Gusmer GX-8 Flat Module .013 Orifice Gusmer GX-8 Flat Direct Impingement Gusmer GX-8 Round Module .013 Orifice see the groove it lets you know it’s a Round Module Gusmer GX-8 Round Module notice the ISO and Poly enter the module offset which helps with mixing.

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Internal Mixing Mechanical Purge Modules

In this picture there is four fluid streams two ISO and two Poly impingement taking place. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mechanical Purge Spray Guns Flow Rates in gallons per min.

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mechanical Purge Flat Tips

Fusion MP Flat or Round Tips Gusmer GX-7-400 Flat or Round Tip GX-7 DI Tip Flat or Round Gusmer GX-8 Round Tip Gusmer GX- 8 Flat Tip Pentech MG Round Tip 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Mechanical Purge, Static Mixer Adaptor with Flat Tips and Solvent Flush

Fusion MP Solvent Flush Static Mix

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Graco Fusion MP

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

FUSION MP Operation

Fluid Tip Cleaning Air

De-Triggered Triggered

Polycarballoy™ Mix module Rear Rod seal CeramTip™ 27

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Gusmer GX-7 DI Operation

GX-7 DI Direct Impingement Red is ISO and Blue is Poly 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Physical Properties Test Spray

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Set-Up Of Proportioner Used in the PDA Class and Test Spray

Proportioner:

• Graco EXP-2 Electric Reactor, 50’ x 3/8” Diameter Heated Hose, Fluid Temperature

Sensor (FTS), 10’ x ¼” Heated Whip Hose, Complete Recirculation System. Transfer Pumps:

• Graco T1

(Both A – ISO & B – Poly) Spray Guns:

• Graco Fusion Air Purge
• Graco Fusion Mechanical Purge

Material:

• Pre-warmed with Power Blankets to 80˚F.

**All of this material was sprayed out of the same batch and sprayed on the same day, one after the other. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Viscosity Profile

Viscosity Profile of Polyurea System

Manufacturer ETECO Inc. Material T6011

Temperature Component A ISO (cps) Component B Poly (cps) 75˚F 1340 cps 400 cps 85˚F 1000 cps 290 cps 95˚F 740 cps 200 cps 105˚F 580 cps 140 cps 115˚F 480 cps 90 cps 125˚F 360 cps 70 cps 135˚F 290 cps 60 cps 145˚F 240 cps 50 cps 150˚F 200 cps 50 cps 155˚F 180 cps 45 cps

Knowing the viscosity of A (ISO) & B (POLY) material before spraying will help you stay balanced (within 200-300psi) when spraying. First, select the temperature closest to where both materials are equal in viscosity then set the temperature set points on your Proportioner for the A (ISO) & B (Poly). Ask your material supplier for a viscosity profile.

2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Physical Property Testing Definitions

Tensile Strength The ability of a material to withstand a load under tension, i.e. when being pulled apart. It is expressed in pounds per square inch (psi). Elongation The amount a product will stretch under tension before it breaks. Expressed in percent of its original length, i.e. a tensile elongation of 10% means the product stretched 10% more than its original length before breaking. Modulus of Elasticity A value that is the ratio of the breaking strength to the deformation at break of a given

• material. It indicates the relative rigidity and strength of a material. The ratio of normal

stress to corresponding strain of a material. The ratio of normal stress to corresponding strain for tensile or compressive stresses below the proportional limit of the material; referred to as elastic modulus or Young's modulus. Die "C" Tear, pli The amount of force required till break of the "pre-notched" sample. Hardness The relative resistance of a material to scratching. Hardness, Shore A A measure of elastomer hardness. Hardness, Shore D A measure of elastomer hardness.

**Everyone should have this Glossary from PDA, it’s Very Helpful. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Test Results of Polyurea Sprayed With Air Purge and Mechanical Purge Guns

Test Results of ETECO T6011 Polyurea

Gun Information Proportioner Set Points Test Results

Spray Gun Model Mix Chamber / Module A "ISO" Impingement Orifice Size Thousands of inch B "Poly" Impingement Orifice Size Thousands of inch Air Purge Nozzle Orifice Size Thousand of inch Air Purge & Mechanical Purge Tip Orifice Size Thousand of inch Hose Temperature Set Point (˚F) A "ISO" Primary Heater Set Point (˚F) B "Poly" Primary Heater Set Point (˚F) Spray Pressure Set Point (PSI) Tensile Strength (PSI) Elongation % Hardness (Shore A) Hardness (Shore D) Graco Fusion AP AW2828 Wide Round 0.028 0.028 0.062 NA 160˚ 160˚ 150˚ 3000 psi 2020 psi 570% 90A n/a Graco Fusion AP AF2929 Flat 0.029 0.029 0.094 0.024 FT0424 160˚ 160˚ 150˚ 3000 psi 1540 psi 550% 90A n/a Graco Fusion MP XR3535 Round Two ISO .024 Two Poly .024 NA .040 RTM040 round pattern 160˚ 160˚ 150˚ 3000 psi 2190 psi 590% 90A n/a Graco Fusion MP XF2323 Flat 0.023 0.023 NA 0.024 FTM624 low flow, 12"-14" wide flat pattern 160˚ 160˚ 150˚ 3000 psi 2010 psi 610% 90A n/a

Thanks to ETECO for Supplying the Polyurea Material for the PDA Class and Doing the Testing for this Presentation. They are a New Member of PDA (March 2013.) 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013

Review of Findings

• When will the Physical Property be different?
• Different Spray Guns (Air Purge VS. Mechanical Purge)
• Different Mix Chambers (Round VS. Flat)
• Different if using Static Mixer Air Purged VS. Static Mixer Solvent Flushed
• Polyurea Manufactures should have their Polyurea Systems tested using

different Guns, Mix Chambers (round VS. flat) and then compare the Physical Properties. Now they will know the best process parameters for their systems. This information should be in the Technical Data Sheet.

• Last thing Polyurea Manufactures make Part A (ISO) and Part B (POLY).

You the applicator make Polyurea. Using the right Equipment, Gun and Process will allow you to make a Quality Polyurea Coating. 2013 PDA Annual Conference Flamingo Las Vegas Hotel and Casino April 15 – 17, 2013
