Seismic Modeling, Migration, and Velocity Inversion

Available Data and Migration Bee Bednar

Panorama Technologies, Inc. 14811 St Marys Lane, Suite 150 Houston TX 77079

May 18, 2014

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 1 / 32

slide-2
SLIDE 2

Outline

1

A Preliminary Workflow Isotropic Workflow Anisotropic Workflow

2

Available Data Reflection Seismic

Land Marine

Borehole Seismic

Well Logs Dipole Sonics VSP’s and Checkshots

3

Migration Kirchhoff Wave Equation

4

Aliasing

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 2 / 32

slide-3
SLIDE 3

A Preliminary Workflow

Outline

1

A Preliminary Workflow Isotropic Workflow Anisotropic Workflow

2

Available Data Reflection Seismic

Land Marine

Borehole Seismic

Well Logs Dipole Sonics VSP’s and Checkshots

3

Migration Kirchhoff Wave Equation

4

Aliasing

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 3 / 32

slide-4
SLIDE 4

A Preliminary Workflow Isotropic Workflow

Isotropic Workflow

Find vnmo

Best isotropic imaging velocity Done with available data

If no anisotropy, DRILL

Acquire Sonics, Dipole Sonics, VSP , 3D VSP , Walkways, check shots Determine just how bad your depth estimates really were If depths an fault positioning is off — ANISOTROPY

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 4 / 32

slide-5
SLIDE 5

A Preliminary Workflow Anisotropic Workflow

Anisotropic Workflow

Given vnmo find δ

Miss tie analysis

Assumes one has a well and can determine the miss ties δ scans to make markers tie image

Local inversion of Walkaway or 3D VSP (see FWI) Guess based on experience Extrapolation of sparse well bore data

Find ǫ

Scans Residual depth analysis

Determine the two symmetry angles

Some fraction of the dip normal Automatic dip determination

Iteratively migrate until you’re blue in the face

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 5 / 32

slide-6
SLIDE 6

Available Data

Outline

1

A Preliminary Workflow Isotropic Workflow Anisotropic Workflow

2

Available Data Reflection Seismic

Land Marine

Borehole Seismic

Well Logs Dipole Sonics VSP’s and Checkshots

3

Migration Kirchhoff Wave Equation

4

Aliasing

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 6 / 32

slide-7
SLIDE 7

Available Data Reflection Seismic

Reflection Seismic

For imaging the subsurface, seismic (sonics) is the most important and useful data we acquire. It provides us with the redundancy necessary to estimate background subsurface sound speeds (velocities). While frequently acquired using schemes designed to optimize fold, the shot array is mathematically the most important ingredient for achieving optimum seismic acquisition. To avoid aliasing and enhance migration dip responses sampling increments must be chosen carefully.

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 7 / 32

slide-8
SLIDE 8

Available Data Reflection Seismic

Sources and Receivers

(a) Source Arrays (b) Receiver Arrays (c) Receiver Takeouts

Seismic acquisition usually uses source arrays, receiver arrays, and receiver takeouts

The underlying mathematical physics assumes point sources and point receivers Arrays are not encompassed within the theory

Data are redundant and digital Organized by shot profile and surface offset

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 8 / 32

slide-9
SLIDE 9

Available Data Reflection Seismic

Sources and Receivers

(a) Gunboats for OBC and NODES (b) Gunboat and Surface Cable(s)

Marine acquisition uses surface cables, subsurface cables, or fixed nodes Data are highly redundant and digital Organized by shot profile, receiver profile, and surface offset OBC and NODAL data are essentially land acquisition schemes

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 9 / 32

slide-10
SLIDE 10

Available Data Borehole Seismic

Sonics

Single source/receiver pair

Up borehole Records dt

Uses

Time-depth miss ties Vertical sound speed Guess at δ

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 10 / 32

slide-11
SLIDE 11

Available Data Borehole Seismic

Dipole Sonics

Source and receiver array

Moves up (down) borehole Borehole reflection method

Determination of

Time-depth ties Depth migration miss ties Vertical P & S velocities Estimation of δ Estimation of γ

With vsnmo

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 11 / 32

slide-12
SLIDE 12

Available Data Borehole Seismic

VSP’s and Checkshots

Surface sources borehole receivers

4-8 sources per receiver string

Best for determination of

Time-depth ties Vertical P and S velocities Estimation of δ Estimation of γ

With a shear image vsnmo required

Revising the current Earth Model Checkshot is poor man’s VSP

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 12 / 32

slide-13
SLIDE 13

Available Data Borehole Seismic

Walkaway Synthetic VSP

(c) Model and Borehole (d) Example VSP’s

Velocity model and with borehole (a) Sample VSP’s (b) Source at water bottom Borehole receivers

Small number for each shot

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 13 / 32

slide-14
SLIDE 14

Available Data Borehole Seismic

VSP and RTM Image

(e) RTM Image (f) Walkaway VSP Image

Full RTM image of prestack data using exact model Full RTM image of prestack VSP data using exact model

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 14 / 32

slide-15
SLIDE 15

Available Data Borehole Seismic

3D VSP’s and Walkaways

Provide

Estimates of δ and ǫ over a wide range.

Walkways provide data over a line. 3D VSPs provide data over a conical volume

Significant impact on estimation of full Earth model

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 15 / 32

slide-16
SLIDE 16

Available Data Borehole Seismic

Well Bore Data Issues

Borehole measurements are sparse Estimating Thomsen parameters requires mathematical extrapolation

The accuracy of such processes is not clear Sometimes done statistically using surface seismic as a guide

Borehole measurements coupled with surface data

Provide good local estimates of δ Provide good local estimates of ǫ

With additional sonic type measurements – VSP , walkways, checkshots, · · ·

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 16 / 32

slide-17
SLIDE 17

Migration

Outline

1

A Preliminary Workflow Isotropic Workflow Anisotropic Workflow

2

Available Data Reflection Seismic

Land Marine

Borehole Seismic

Well Logs Dipole Sonics VSP’s and Checkshots

3

Migration Kirchhoff Wave Equation

4

Aliasing

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 17 / 32

slide-18
SLIDE 18

Migration

What does seismic migration do?

Seismic migration recovers approximate reflection amplitude responses at each subsurface by spraying calculated amplitudes over equal-traveltime (green curve) locations. Equal-traveltime curves need not be smooth. They can be multi-valued.

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 18 / 32

slide-19
SLIDE 19

Migration Kirchhoff

What does Krichhoff isotropic time migration do?

Computes ts and tr using t =

  • t0 +

h2 v2

rms

Corrects the trace amplitude at ts + tr for energy loss Sums the result into the image point (single valued)

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 19 / 32

slide-20
SLIDE 20

Migration Kirchhoff

What does Krichhoff VTI time migration do?

Computes ts and tr using t2(h) = t2

0 + h2 v2

nmo −

(v2

hor −v2 nmo)h4

v2

nmo(t2 0 v4 nmo+1.2v2 hor h2) or

t2(h) = t2

0 + h2 v2

nmo −

2ηh4 v2

nmo(t2 0 v2 nmo+(1+2η)h2)

Sums corrected amplitude at ts + tr into image point (single valued)

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 20 / 32

slide-21
SLIDE 21

Migration Kirchhoff

What does Krichhoff depth migration do?

Raytraces in full 3D Earth Model to compute ts and tr Corrects the trace amplitude at ts + tr for energy loss Sums the result into the image point. Can be single or multi-valued

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 21 / 32

slide-22
SLIDE 22

Migration Wave Equation

What do wave equation migrations do?

(a) Forward propagated source at image point (b) Trace recorded at receiver

Forward propagates the source with amplitude E (top) to the image point Amplitude at image point is EAs where As is path loss The decay from the image point to the receiver is denoted Ar

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 22 / 32

slide-23
SLIDE 23

Migration Wave Equation

Imaging a Point — Frequency by frequency

(a) Trace recorded at receiver (b) Back Propagated Receiver

Back propagates recorded trace to image point removes the Ar decay Amplitude of the back propagated trace is thus ρvEAs Here ρv is the reflectivity at the image point

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 23 / 32

slide-24
SLIDE 24

Migration Wave Equation

Imaging a Point — Frequency by frequency

(a) Back propagated receiver at image point (b) Forward propagated source at image point

Frequency domain divide of forward by backward traces at image point Amplitude at image point ≈ ρvEAs

EAs

Amplitude at image point is proportional to ρv

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 24 / 32

slide-25
SLIDE 25

Migration Wave Equation

So wave-equation migrations

Forward propagates the source to a trace at the image point Back propagates receiver trace to image point Cross-correlates (frequency domain divide) the two traces Sums the zero-lag cross-correlation into the image point

Multiple arrivals

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 25 / 32

slide-26
SLIDE 26

Migration Wave Equation

Actually they both work the same way

(a) Back propagated receiver at image point (b) Forward propagated source at image point

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 26 / 32

slide-27
SLIDE 27

Aliasing

Outline

1

A Preliminary Workflow Isotropic Workflow Anisotropic Workflow

2

Available Data Reflection Seismic

Land Marine

Borehole Seismic

Well Logs Dipole Sonics VSP’s and Checkshots

3

Migration Kirchhoff Wave Equation

4

Aliasing

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 27 / 32

slide-28
SLIDE 28

Aliasing

What is Aliasing

Aliasing is what happens when the digital sampling interval is too large. Because movie images are sampled at 30 frames/sec, automobile or wagon wheels may appear to rotate slower or in reverse direction of the rate of revolution is greater then 30.

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 28 / 32

slide-29
SLIDE 29

Aliasing

Aliasing during Acquisition

Array effects

Left

Little

Middle

Strong Mixed Low frequency

Right

Severe Severe mixing Lower frequency

Suppression

Left - Easy Middle - Difficult Right - Impossible

Ground roll here is traveling at approximately 160 m/s.

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 29 / 32

slide-30
SLIDE 30

Aliasing

Aliasing during processing

(a) Stacked Sections (b) Migration

Aliasing in seismic data can take many forms. Offset (pre-stack) Aliasing in time (pre- and post-stack) Aliasing in depth (after migration)

(c) Offsets

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 30 / 32

slide-31
SLIDE 31

Aliasing

Rules of Thumb

To avoid aliasing tan β ≥ 2v∆x ∆t With fmax = .5

∆t and sin α = tan β

∆x ≤ v 4fmax tan β = v 4fmax sin α = v 4fmax cos θ fmax ≤ v 4∆x tan β = v 4∆x sin α = v 4∆x cos θ

Bee Bednar (Panorama Technologies) Seismic Modeling, Migration, and Velocity Inversion May 18, 2014 31 / 32

slide-32
SLIDE 32

Aliasing

Questions?
