FAUSTO MILLETARI SEGMENTATION OF MEDICAL VOLUMES USING CONVOLUTIONAL NEURAL NETWORKS MEDICAL IMAGE SEGMENTATION Computer assisted diagnosis Computer assisted intervention Treatment Planning Enhanced visualisation MEDICAL IMAGING

slide-1
SLIDE 1

SEGMENTATION OF MEDICAL VOLUMES USING CONVOLUTIONAL NEURAL NETWORKS

FAUSTO MILLETARI

slide-2
SLIDE 2

MEDICAL IMAGE SEGMENTATION

▸ Treatment Planning ▸ Computer assisted diagnosis ▸ Computer assisted intervention ▸ Enhanced visualisation

slide-3
SLIDE 3

MEDICAL IMAGING

▸ Magnetic Resonance Imaging (MRI)

  • De-facto standard in neuroimaging
  • Complex and expensive
  • Good soft tissue contrast, limited artefacts, high SNR
slide-4
SLIDE 4

▸ Ultrasound

  • Non-invasive, mobile, inexpensive, real-time, safe
  • Emits high frequency sound, forms images from tissue echoes
  • Noisy signal, artefacts, shadows and poor contrast
  • Early Parkinson’s diagnosis

MEDICAL IMAGING

slide-5
SLIDE 5

A LEARNING BASED APPROACH TO SEGMENTATION

▸ Automatic segmentation

▸ Anatomy localisation ▸ Prior shape knowledge

▸ Time efficiency ▸ Limited training data

slide-6
SLIDE 6

SEGMENTATION WITH CONVOLUTIONAL NEURAL NETWORKS

▸ CNNs for image segmentation

  • How to use CNNs for segmentation?
  • How to include shape priors?
  • What is a good network architecture choice?
  • Can we process 3D data?
  • How to be robust to limited amount of

training data?

slide-7
SLIDE 7

SEGMENTATION WITH CONVOLUTIONAL NEURAL NETWORKS

▸ Voxel-wise classification

…

CNN

▸ Segmentation mask prediction for whole volume

CNN

▸ Voting strategy for localisation and segmentation

…

CNN

x Localisation Accurate segmentation

slide-8
SLIDE 8

TRAINING HOUGH-CNN

Training set of (overlapping) patches and votes CNN

Softmax FG BG

▸ Train CNN classification ▸ Extract descriptors foreground patches

CNN

Features (128-d) f1 f2 f3 f4 f5 f6

▸ Build database features/votes/segmentation patches

f4 f5 f6 f3 f1 f2

slide-9
SLIDE 9

TESTING HOUGH-CNN

Collect overlapping patches CNN

Softmax (class) Features (128-d)

▸ CNN classification & Feature Extraction

slide-10
SLIDE 10

TESTING HOUGH-CNN

Binary classification result CNN

Softmax (class) Features (128-d)

▸ CNN classification & Feature Extraction

slide-11
SLIDE 11

TESTING HOUGH-CNN

Binary classification result CNN

Softmax (class) Features (128-d)

▸ CNN classification & Feature Extraction ▸ Use features to retrieve votes from database

Find K-NN
 within range r Features (128-d)


  • nly foreground patches (circles)

Example neighbours

slide-12
SLIDE 12

TESTING HOUGH-CNN

Votes towards object centroid CNN

Softmax (class) Features (128-d)

▸ CNN classification & Feature Extraction ▸ Cast votes and find peak in vote map ▸ Use features to retrieve votes from database

Find K-NN
 within range r Features (128-d)


  • nly foreground patches (circles)

Example neighbours

slide-13
SLIDE 13

TESTING HOUGH-CNN

Collect overlapping patches CNN

Softmax (class) Features (128-d)

▸ CNN classification & Feature Extraction ▸ Cast votes and find peak in vote map

▸ ▸

▸ Trace back correct votes.


Project associated segmentation patches (from database)

▸ Use features to retrieve votes from database

Find K-NN
 within range r Features (128-d)


  • nly foreground patches (circles)

Example neighbours

slide-14
SLIDE 14

EXPERIMENTAL EVALUATION

▸ Ultrasound and MRI volumes ▸ Training dataset size ▸ Data dimensionality

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

▸ Network Architecture

slide-15
SLIDE 15

EXPERIMENTAL EVALUATION

▸ Hough-CNN vs. voxel-wise classification

VOXEL-WISE CLASSIFICATION

0,25 0,5 0,75 1

0,55 0,33

VOXEL-WISE CLASSIFICATION

0,25 0,5 0,75 1

0,47 0,29

MRI US

slide-16
SLIDE 16

EXPERIMENTAL EVALUATION

▸ Hough-CNN vs. voxel-wise classification

Biggest Training set Smallest Training Set

slide-17
SLIDE 17

EXPERIMENTAL EVALUATION

▸ Hough-CNN vs. voxel-wise classification

slide-18
SLIDE 18

EXPERIMENTAL EVALUATION

▸ Patch dimensionality (2D, 2.5D, 3D)

2D

0,25 0,5 0,75 1 MRI US

0,82 0,77 0,83 0,68 0,85 0,68

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

2D 2.5D 3D

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

Experiments

  • Variation of

– network architecture

  • different depth (3, 5 and 8 convolutional layers)
  • different convolution filter sizes (side length of 3,5,7,9,11 voxels)

– Patch size

  • quadratic/cubic patches with side length of 31 or 51 voxels

– Patch dimensionality 2D 2.5D 3D – training set size

  • MRI: 100,1.000 or 10.000 patches/region/volume ~ 116.000, 765.000 or 3.100.000 patches
  • US: 1.000 or 5.000 patches/region/volume

~ 80.000 or 400.000 patches

Segmentation of MRI and Ultrasound Scans Using Deep Convolutional Neural Networks 10

2D 2.5D 3D

slide-19
SLIDE 19

EXPERIMENTAL EVALUATION

▸ Network architectures

2D

0,25 0,5 0,75 1

3-3-3-3-3 3-3-3-3-3-3-3-3 5-5-5-5-5 7-5-3 9-7-5-3-3 SMALL ALEX

0,72 0,68 0,77 0,71 0,7 0,72

MRI

0,25 0,5 0,75 1

3-3-3-3-3 3-3-3-3-3-3-3-3 5-5-5-5-5 7-5-3 9-7-5-3-3 SMALL ALEX

0,83 0,82 0,83 0,83 0,85 0,84

US

0,77 0,85

Architecture Architecture

slide-20
SLIDE 20

CONCLUSION

▸ Need precision and robustness in medical domain
 ▸ Volumetric CNNs via CuDNN and powerful GPUs
 ▸ Localisation strategy minimises impact of outliers
 ▸ Segmentation makes use of previous shape knowledge
 ▸ Results show excellent results in challenging situations

slide-21
SLIDE 21

ADDITIONAL RESOURCES

▸ Our Hough-CNN paper

http://arxiv.org/abs/1601.07014

  • Dr. Seyed-Ahmad Ahmadi

Fausto Milletari

  • Prof. Nassir Navab

▸ Our team at

Christine Kroll

  • Prof. Kai Bötzel
slide-22
SLIDE 22

THANK YOU!

contact: fausto.milletari@gmail.com
