SEER

Nuno Diegues, Paolo Romano and Stoyan Garbatov 27th Symposium on Parallel Architectures and Algorithms

PROBABILISTIC SCHEDULING FOR COMMODITY HARDWARE TRANSACTIONAL MEMORY

Seer: Scheduling for Commodity HTM SPAA 2015

2

Multi-cores are now ubiquitous

The multi-core (r)evolution

Shared Memory

CPU 1 CPU 2 CPU 3 CPU 4

Concurrent programming is complex

Hard to get right:

• fine-grained locks
• deadlocks
• correctness

Classic approach: Locking

atomic { withdraw(acc1,val); deposit(acc2,val); }

Transactional Memory abstraction Programmer identifies atomic blocks Runtime implements synchronization

Transactional Memory System

Seer: Scheduling for Commodity HTM SPAA 2015

3

Too much optimism

• Problem: CPU time is wasted
• run other computations instead
• inhibit parallelism
• improve cache usage
• increase core frequency
• reduce power consumption

y = x x++

I d e n t i f y l i k e l y c

• n

f l i c t s b e f

• r

e t h e y h a p p e n

Seer: Scheduling for Commodity HTM SPAA 2015

4

Scheduler

• Software TM (STM): library has full concurrency control
• can point precisely the culprit for the conflict

H T M a v a i l a b l e i n c

• m

m

• d

i t y p r

• c

e s s

• r

s

• Hardware TM (HTM): feedback is quite limited
• rough categorization for the type of conflict

Objective: Scheduling for Commodity HTM

Seer: Scheduling for Commodity HTM SPAA 2015

5

Avoid running T1 and T2 concurrently How to find the root cause for the data conflict?

In an ideal world for HTMs…

xbegin widthdraw(acc1,val) deposit(acc2,val) xend

Seer: Scheduling for Commodity HTM SPAA 2015

6

Transactions may abort:

• because of contention on

same memory locations

…and every transaction shall eventually succeed

Transactions restart

…in practice: HTMS are Best-Effort

Seer: Scheduling for Commodity HTM SPAA 2015

7

No progress guarantees:

• A transaction may always abort

…due to a number of reasons:

• Forbidden instructions
• Capacity of caches (for reads and writes)
• Faults and signals
• Contending transactions, aborting each other

Single Global Lock SGL fall-back path for HTM

Seer: Scheduling for Commodity HTM SPAA 2015

8

• Hardware transaction executes if SGL is free
• Acquire SGL depending on retry policy
• SGL is a very simple scheduler
• Ignores the root cause
• Takes a global decision --- the SGL
• Adaptive Transaction Scheduling [SPAA08]

W e n e e d b e t t e r S c h e d u l i n g f

• r

C

• m

m

• d

i t y H T M s

Seer: Scheduling for Commodity HTM SPAA 2015

9

Related Work

Scheduler

Support for HTM? Support for Imprecise Information? Schedules Transactions in a Fine-Grained Fashion?

ATS [SPAA08] Yes Yes No CAR-STM [PODC08] No No Yes Shrink [PODC09] No No Yes ProPS [Euro-Par14] No No Yes SER [PPoPP10] No No Yes TxLinux [SOSP07] Yes No Yes SOA [HiPEAC09/10] Yes No Yes Seer Yes Yes Yes

Seer: Scheduling for Commodity HTM SPAA 2015

10

Key Idea

• Transactions to be executed are announced
• Many observations are collected
• upon transaction commit and abort
• which transactions were active at the same time?
• Over time, the outliers will be identifiable w.h.p.
• A dynamic, fine-grained, locking scheme is devised

Seer: Scheduling for Commodity HTM SPAA 2015

11

Seer: overview

Transaction = source code transaction active transactions

Seer: Scheduling for Commodity HTM SPAA 2015

12

Seer: details

• Threads collect lightweight events independently --- low overhead
• Locking scheme (re-)calculated periodically
• Calculate conditional probabilities of commit/abort
• Relevance threshold based on mean/stdev
• One lock per transaction (atomic block in the application)
• T1 lock (L1) taken by T2 if they are deemed to conflict
• T1 waits for L1 to be free before executing

Seer: Scheduling for Commodity HTM SPAA 2015

13

Seer: details

For each pair of transactions (x,y) acquire lock of each other if: Are abort events of x common enough with y running concurrently? Is y one of the main causes for x to abort? Hill climbing based adaptive loop for optimal Threshold search.

Seer: Scheduling for Commodity HTM SPAA 2015

14

Seer: optimizations

• Capacity Aborts: another limitation from best-effort nature
• Per-core lock
• Taken when capacity aborts occur
• Tailored for hyper-thread usage

Only one thread (re-)calculates the locking scheme:

• Whenever it is waiting for the SGL (some thread is on the fallback path)
• If the SGL is rarely taken, then scheduling will not improve
• Lock acquisition
• Hardware transaction used as multi-CAS for 2+ locks

Seer: Scheduling for Commodity HTM SPAA 2015

15

Evaluation

• HLE: Intel Hardware Lock Elision, i.e., no scheduling
• RTM: Intel Commodity HTM with a SGL
• SCM: Software-assisted Contention Management
• [PODC14] --- schedule with a (single) auxiliary lock
• aux lock is not read speculatively (in hw tx)
• Seer: our Probabilistic Scheduler on top of Intel RTM

Intel Haswell 4 cores (8 hyper-threads)

Seer: Scheduling for Commodity HTM SPAA 2015

16

How much can we gain with Seer?

Threads Threads

Geometric Mean Speedup in STAMP 50%

Speedup Speedup

Genome Intruder

Seer: Scheduling for Commodity HTM SPAA 2015

17

What motivates these gains?

• HLE: 77% with fall-back lock

Geometric Mean over STAMP w/ 8 threads Fine-grained locks

• RTM: 37% with SGL
• SCM: 5% with SGL, 29% with (single) auxiliary lock
• Seer:
• 3% with at least one tx lock
• 4% with core lock
• 12% with tx + core locks
• 1% with SGL

Seer: Scheduling for Commodity HTM SPAA 2015

18

Relevance of each mechanism?

Baseline: Seer with all mechanisms enabled (i.e., their overhead) but without any lock acquisitions.

HTM lock acquisition: Small improvement --- benchmark dependent the more locks, the better

Transaction locks: Detect conflicts inherent to benchmarks Core locks: Only relevant for >4t (hyper-threading)

Threshold tuning for probabilities Consistent/small improvement

Seer: Scheduling for Commodity HTM SPAA 2015

19

Summary

First scheduler tailored for Commodity HTMs:

• Copes with imprecise information
• Schedules transactions in a fine-grained manner
• 50% performance improvement with 8 threads
• 0-8% overhead from monitoring/calculation
• Taken by measuring Seer, but without acquiring locks

Seer: Scheduling for Commodity HTM SPAA 2015

20

Thank you

Questions?

• Nuno Diegues, Paolo Romano and Stoyan Garbatov

Seer: Scheduling for Commodity HTM SPAA 2015

21

Backup slides

Seer: Scheduling for Commodity HTM SPAA 2015

22

HTM with a fall-back path

start: int status = htm_begin code: application logic htm_end // fast-path

Seer: Scheduling for Commodity HTM SPAA 2015

23

HTM with a fall-back path

start: int status = htm_begin if (status == ok) // != ok when aborted if (fallback-in-use()) htm_abort // fall-back in use else goto code // fast-path ?? code: application logic if (inFastPath) htm_end // fast-path else ??

Seer: Scheduling for Commodity HTM SPAA 2015

24

HTM with a fall-back path

start: int status = htm_begin if (status == ok) // != ok when aborted if (fallback-in-use()) htm_abort // fall-back in use else goto code // fast-path if (shouldRetry()) // retry policy goto start else use-fallback() // use fall-back code: application logic if (inFastPath) htm_end // fast-path else quit-fallback() // fall-back

Seer: Scheduling for Commodity HTM SPAA 2015

25

HTM with a fall-back: a single lock

start: int status = htm_begin if (status == ok) // != ok when aborted if (isTaken(lock)) htm_abort // fall-back in use else goto code // fast-path if (shouldRetry()) // retry policy: e.g., limit retries to 10 goto start else acquire(lock) // use fall-back code: application logic if (inFastPath) // fast-path htm_end else // fall-back release(lock) Still simple enough.
