Security Engineering Based on Atomically Thin Layered Transition Metal Dichalcogenides Davood Shahrjerdi Electrical and Computer Engineering Department , New York University Our team at NYU Nano Lab Abdullah Alharbi Ting Wu PhD student PhD

slide-1
SLIDE 1

Security Engineering Based on Atomically Thin Layered Transition Metal Dichalcogenides

Davood Shahrjerdi

Electrical and Computer Engineering Department , New York University

slide-2
SLIDE 2

2

Abdullah Alharbi PhD student Ting Wu PhD student Sirius You PhD student Zhujun Huang PhD student

Our team at NYU Nano Lab

slide-3
SLIDE 3

3

Laboratory for Nano-engineered Integrated System

Materials security Nanoelectronics (Bio-)Sensing Flexible Electronics Material & Device Innovations

slide-4
SLIDE 4

4 DS, et al. Nano Lett 2013

22 nm ETSOI CMOS on plastic 28% efficient flexible III-V solar cells

DS, et al., J. Advanced Energy Materials, 2013

Heterogeneous graphene+CMOS for bio-sensing

BN, TW, DS et al. ISSCC, 2017 BN, TW, DS et al. IEEE TBioCAS 2017

Nanoscale devices for bio-sensing

TW, DS et al. ACS Nano, 2017

slide-5
SLIDE 5

Transition metal dichalchogenides (TMD)

5

Hexagonal lattice structure with chemical formula of MX2 M= Transition metal (Mo, W, etc) X = Chalcogen atom (S, Se, or Te)

  • Strong spin-orbit coupling
  • Valley degeneracy at k and k’ points
slide-6
SLIDE 6

Negative quantum capacitance

6

  • S. Larentis, et al., Nano Lett., 2014
slide-7
SLIDE 7

Proximity effects: Inducing spin-orbit in graphene

7

  • Z. Wang, et al., Nat. Comm., 2015
slide-8
SLIDE 8

RF-switches from 2D TMDs

8

  • M. Kim, et al., Nat. Comm., 2018
slide-9
SLIDE 9

2-D Van der Waals heterostructures

9

  • Substrate agnostic
  • Stacking a wide range of materials (insulators, semiconductors, etc)
  • Rotational alignment
  • No need for epitaxy

Ajayan, Kim, Physics Today, 2016

slide-10
SLIDE 10

Mechanical exfoliation: Isolation of monolayer 2-D materials

10

Nobel prize in Physics, 2010 Andre Geim, and Konstantin Novoselov

slide-11
SLIDE 11

CVD growth of WS2 and MoS2

Large-area synthesis of TMDs

  • Structural heterogeneity revealed by PL and Raman studies

11 Alharbi, DS, Appl. Phys. Lett. 2016 Alharbi, DS, Appl. Phys. Lett., 2017

slide-12
SLIDE 12

Understanding inherent properties of TMDs

12

  • Highest mobility reported for CVD MoS2 and WS2
  • Mobility is limited by disorders

Alharbi, DS, Appl. Phys. Lett. 2016 Alharbi, DS, Appl. Phys. Lett., 2017 Alharbi, et al. IEEE TED, 2018 Alharbi, et al. IEEE EDL, in press

slide-13
SLIDE 13

Healing defects using superacids

13

  • M. Amani, et al. Science, 2015
slide-14
SLIDE 14

Healing S-vacancy defects using superacids

14

Alharbi, DS, Appl. Phys. Lett., 2017

slide-15
SLIDE 15

15

1 in 10 medical products in developing countries is substandard or falsified

World Health Organization Report, 2017

slide-16
SLIDE 16

16

Our Goal: Creating Optical tags for securing pharmaceutical supply chain

1- Unique nano-tags 2- Physically transient 3- Easy readout

  • A. Alharbi, DS, US Patent pending
slide-17
SLIDE 17

Atomically thin optical nano-tags

17

Leverage two fundamental materials properties:

1- Dependence of TMD bandgap size and type on number of layers 2- Possibility to tune growth mode and achieve layer-plus-island growth (Spatial Poisson’s distribution)

  • A. Alharbi, DS, US Patent pending
slide-18
SLIDE 18

Atomically thin optical nano-tags

18

slide-19
SLIDE 19

Thin-film growth modes

19

  • Depends on deposition rate and growth temperature
  • Beyond critical growth condition, the growth mode is layer-plus-island
slide-20
SLIDE 20

Atomically thin optical nano-tags

20

Alharbi, DS, ACS Nano, 2017 (Research highlight by Nature Nano)

slide-21
SLIDE 21

Understanding dynamics of the growth

21

slide-22
SLIDE 22

22

Large-area synthesis of nano-tags

  • Clark-Evans test suggests complete spatial randomness
  • Avarami equation suggests a 2D disk-shaped growth governed by the

surface diffusion 10 um

slide-23
SLIDE 23

23

Physical implementation of nano-tags (Nanofabrication)

20 um Raman fingerprint of 1L, 2L, and >2L MoS2

slide-24
SLIDE 24

24

Edge recombination in 2-D TMDs

  • P. Zhao, et al. Nano Lett., 2017
slide-25
SLIDE 25

25

Optical properties of MoS2 layers

slide-26
SLIDE 26

26

Conversion of the analog response to a binary response

Integrated photoemission of a pixel covered by 50% monolayer

slide-27
SLIDE 27

27

Security metrics of nano-tags

4x1017 worst-case number of attempts to guess an unknown (64-bit) key from another known key.

slide-28
SLIDE 28

28

Physical unclonability of nano-tags

slide-29
SLIDE 29

Conclusions

Unique physical properties

  • f

2-D layered materials together with fundamental properties of thin-film growth can create new paradigms for securing supply chain

  • f

valuable goods (electronics or otherwise).
