CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Secrecy Security Policy

CSE497b - Spring 2007 Introduction Computer and Network Security Professor Jaeger

www.cse.psu.edu/~tjaeger/cse497b-s07/

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Secrecy Problem

• Does the following protection state ensure the secrecy
• f J’s private key in O1?

2

O1 O2 O3 J R R W R W S2 N R R W S3 N R R W

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Protection vs Security

• Protection

– Security goals met under trusted processes – Protects against an error by a non-malicious entity

• Security

– Security goals met under potentially malicious processes – Protects against any malicious entity

• For J:

– Non-malicious process shouldn’t leak the private key by writing it to O3 – A malicious process may write the private key to O3

3

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Why Doesn’t DAC Work?

• Goal: User has a file O1 she wants to keep secret
• Threat: A malicious process she runs wants to leak O1

– To some other subject (user) or system (via network)

• Problems:

– Permission Assignment: Malicious process maximizes permissions

• Any way that data can be read by or written to another user is

enabled

– Complete Mediation: DAC systems do not mediate network

• Can be sent to anyone or requires firewall rules to control access

– Complexity: How does she know that all these permissions prevent the leak

• Good luck

4

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Governmental Secrecy

• Military

– When will ship sail? – Where are troops? – What is the next troop movement?

• Military is hierarchical

– Decisions made at a higher level of authority are enacted

• Thus, security is top-down

– Secrets flow up – Decisions flow down

• Release is manual

– Also, “need to know”

5

CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger Page

Multilevel Security

• A multi-level security (MLS) system tags all object and

subject with security tags classifying them in terms of sensitivity/access level.

– We formulate an access control policy based on these levels – We can also add other dimensions, called categories which horizontally partition the rights space (in a way similar to that as was done by roles) security levels categories

CSE497b Introduction to Computer (and Network) Security - Spring 2007 - Professor Jaeger Page

Lattice Model

• Used by the US military (and many others), the Lattice

model uses MLS to define policy

• Levels:

unclassified < confidential < secret < top secret

• Categories (actually unbounded set)

NUC(lear), INTEL(igence), CRYPTO(graphy)

• Note that these levels are used for physical documents

in the US government as well.

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Lattice

• Levels form a lattice

– Vertices form a partial order – Every pair of vertices has a LUB, GLB

8

Very Secret Mostly Secret Pretty Secret Secret ?

CSE497b Introduction to Computer (and Network) Security - Spring 2007 - Professor Jaeger Page

Assigning Security Levels

• All subjects are assigned clearance levels and

compartments

– Alice: (SECRET, {CRYTPO, NUC}) – Bob: (CONFIDENTIAL, {INTEL}) – Charlie: (TOP SECRET, {CRYPTO, NUC, INTEL})

• All objects are assigned an access class

– DocA: (CONFIDENTIAL, {INTEL}) – DocB: (SECRET, {CRYPTO}) – DocC: (UNCLASSIFIED, {NUC})

CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger Page

Example

Access is allowed if

subject clearance level >= object sensitivity level and

• bject categories subset-of subject categories (read down)

Q: What would write-up be?

Hence,

Bob: CONF., {INTEL}) Trent: TS, {CRYPTO, NUC, INTEL}) Alice: (SEC., {CRYTPO, NUC}) DocA: (CONFIDENTIAL, {INTEL}) DocB: (SECRET, {CRYPTO}) DocC: (UNCLASSIFIED , {NUC})

CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger Page

Secrecy Properties

• Simple-Security Property (Read-Down)

– A subject s can only read from an object o if the subject’s clearance dominates or is same as the access class of the

• bject
• *-Security Property (Write-Up)

– A subject s can only write to an object o if the subject’s clearance is dominated by or is the same as the access class of the object

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Trojan Horses

• Trojan horse: A program with a malicious function that

masquerades as a benign application

• Claim: MLS prevents a Trojan horse from leaking data
• Proof

– Complete mediation

• All operations are mediated

– MLS *-security property

• Trojan horse cannot write data down

– Mandatory policy

• Trojan horse cannot change policy
• Policy defines legal info flows

12

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Covert Channels

• Use access to shared resources as a means of

communication – Rather than an overt channel

• Storage Channel

– Uses an attribute of a shared resource – E.g., Fill up shared disk

• Timing Channel

– Uses temporal relationships in access to a shared resource – E.g., Driver timing behavior

• Not prevented by MLS alone!

13

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Trojan Horse Paradox

• MLS enables the OS to guarantee

– that a process at a higher secrecy clearance cannot – leak to a process at a lower secrecy level

• But, lots of applications handle data of multiple access

classes!

• Examples:

– Server process (Mail server): Many mails of different access classes are possible

• One server per combination of level and category set is not practical

– Client process (Email client): A single email client may receive and respond to emails at different access classes

• And, think about the integrity impact of a Trojan horse

– Discuss next time

14

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Program-Level Secrecy

• Situation: A program reads data at a higher access

class than it writes

– Program can leak secret that it reads by writing it to the lower access class

• Challenge: Write a program where you can prove that

no illegal information flows (i.e., violating MLS properties) can occur

15

Program Secret Public

Read Write

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Denning Lattice Model

• Information flow within a program

– Can a secret variable leak to a public variable?

• Model covers all programs

– Statement S – Sequence S1, S2 – Conditional c: S1, …, Sm

16

Stmt Cond Stmt Stmt Stmt Stmt

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Implicit and Explicit Flows

• Explicit

– Direct transfer to b from a (e.g., b = a)

• Implicit

– Where value of b may depend on value of a indirectly (e.g., if a = 0, then b = c)

• Implicit flows only occur in conditionals

17

Stmt

b = a

Cond

if (b < 1)

Stmt

c = d

Stmt

e = c

Stmt Stmt

c = b

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Denning Semantics

• Program is secure if:

– Explicit flow from S is secure – Explicit flow of all statements in a sequence are secure (e.g., S1; S2) – Conditional c:S1, …, Sm is secure if:

• The explicit flows of all statements S1, …, Sm are secure
• The implicit flows between c and the objects in Si are secure

18

Stmt

b = a

Cond

if (b < 1)

Stmt

c = d

Stmt

e = c

Stmt Stmt

c = f

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Information Flow

• Explicit and implicit flows form a graph
• Resulting flow graph

19

Stmt

b = a

Cond

if (b < 1)

Stmt

c = d

Stmt

e = c

Stmt Stmt

c = f a

c

b d f e

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Secure When...

• Suppose e is public

– What variables can be secret?

• Suppose d is public

– What variables can be secret?

• Suppose b is secret

– What variables can be public?

20

Stmt

b = a

Cond

if (b < 1)

Stmt

c = d

Stmt

e = c

Stmt Stmt

c = f

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Chinese Wall

• Keep different parts of a firm isolated

– Accounts with Ford and GM

• Access is not controlled by attribute of data alone

– Also, data that the subject holds – Conflict sets

21

t0 t1

Hold: None Conflict: {Ford, GM}

t2

Op: Access GM Hold: None Access: Allowed

t3 t4

Op: Access Ford Hold: GM Access: Denied

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Chinese Wall

• More formally,

– Objects may belong to a company dataset – Companies may compete, so

• Conflict of interest sets consist of competing company dataset labels

– Cannot access objects in two datasets in a COI set

• CW Simple Security Property

– Read O,

• if accessed CD(O) already, can access again
• for all datasets accessed previously, CD(O) not-in COI(previous)
• CW *-Security Property

– Write O,

• if CW-Simple permits read
• And we have only read data from CD(O)

22

Page CSE497b Introduction to Computer and Network Security - Spring 2007 - Professor Jaeger

Take Away

• MLS policy provides a guarantee that a secret will not

be leaked to a lower access class

– Even if you are running malicious code (e.g., Trojan horse) – But, does not include covert channels

• Know how to apply this
• However, we may also need to obtain secrecy

guarantees for more privileged programs

– Ones that could violate MLS – Use Denning’s model to prove compliance

• Information flows: Explicit and implicit

23
