SLIDE 1

1

Information security policies

Security in Organizations 2011 Eric Verheul

SLIDE 2

2

Literature

Main literature for this lecture: 1. ISO 27001 and ISO 27002 2. Besluit voorschrift informatiebeveiliging rijksdienst 2007 (www.wetten.nl) 3. Beveiligingsvoorschrift Rijksdienst 2005 (www.wetten.nl)

Variants on ISO 2700*

SLIDE 3

3

Outline

Introduction
Requirements on IS policies from ISO 2700x and VIR-2007
Organization of information security
IS policy layout
Some first feed-back from assignment #1

SLIDE 4

4

Introduction

Every organization needs an “IS policy”
Most organization have an IS policy but in many cases it is

just a paper tiger:

not sufficiently concrete
not in line what is actual done operational
and most of all … not implemented
I am giving you my perspective on IS policy based

experience and on ISO 2700x and Voorschrift Informatiebeveiliging Rijksdienst 2007

SLIDE 5

5

Introduction

Tactical IS Operational IS Strategic IS

Senior management Line management Operations (administrators, employees, external parties)

The IS policy is a means of communication IS requirements

to organization

The organization communicates back through (progress)

reports

Requirements Reporting

IS policy IS guidelines, parameters IS procedures settings

SLIDE 6

6

Requirements from ISO 2700x and VIR

ISO 2700x

Recall ISO 27001 describes an ISMS that refers to ISO

27002 for security controls

Both ISO 27001 and ISO 27002 have requirements on IS

policy

ISO 27002: Chapter 5 „Security Policy‟
ISO 27001: Clause 4.2.1 b)

SLIDE 7

7

Requirements from ISO 27002 Section 5.1.1

Control An information security policy document should be approved by management, and published and communicated to all employees and relevant external parties. Guidance

Definition of information security
Management intent and support
Framework for implementing IS
General principles to follow (e.g., legal, awareness, BCP,

security incidents)

Definitions of roles and responsibilities
References to documentation

SLIDE 8

8

Requirements from ISO 27002 Section 5.1.2

Control The information security policy should be reviewed at planned intervals or if significant changes occur to ensure its continuing suitability, adequacy, and effectiveness. Guidance on input

Feedback from interested parties
Results from (independent) reviews
Status of preventive and corrective actions
Results of previous management reviews
Changes that could affect the organization‟s IS approach
Trends related to threats and vulnerabilities
Reported information security incidents
Recommendations provided by relevant authorities

SLIDE 9

9

Requirements from ISO 27002 Section 5.1.2

Control The information security policy should be reviewed at planned intervals or if significant changes occur to ensure its continuing suitability, adequacy, and effectiveness. Guidance on output

Improvement of the organization‟s approach to managing

information security and its processes;

Improvement of control objectives and controls
Improvement in the allocation of resources and

responsibilities. Note: the ISO 27002 Chapter 5 requirements resemble the ISO 27001 PDCA cycle.

SLIDE 10

10

Requirements from ISO 27001 Clause 4.2.1 b)

SLIDE 11

11

Requirements from ISO 2700x and VIR

Voorschrift informatiebeveiliging rijksdienst 2007 (VIR)

Applicable to the „Rijksdienst‟ (central government) most

notably the departments („ministeries‟)

Applicable to all information regardless of its form
Stipulates that information security is the responsibility of line

management

Article 3 sets requirements on an information security policy
Article 4 describes responsibilities of line management

SLIDE 12

12

Requirements from VIR article 3

An information security policy document includes:

Strategic principles and conditions on IS
Description of the IS organization including responsibilities
IS baselines
Frequency of IS policy review
Descriptions on how security awareness is increased

The IS policy is approved by the Secretary General (=highest civil servant within department) and is end responsible for its implementation.

SLIDE 13

13

Requirements from VIR article 4

Line management

is end responsible for information security of his/her

information systems

sets security controls based on a risk assessment
is end responsible for the implementation of these security

controls

Periodically evaluates information security and adjusts

information accordingly

SLIDE 14

14

Outline

Introduction
Requirements on IS policies from ISO 2700x and VIR-2007
Organization of information security
IS policy layout
Some first feed-back from assignment #1

SLIDE 15

Information Security & Risk Management

The IS process in helicopter view

Setting the IS policy
Allocation of IS roles and responsibilities
Setting security baselines
ISMS implementation (inc. setting risk assessment methodology)

Plan

Implementing security baselines
Conducting risk assessments
Implementation of additional controls

Do

Reviewing compliance with policy
Reviewing IS effectiveness

Check

Periodic review of IS by management
Planning of corrective actions

Act

SLIDE 16

Information Security & Risk Management

Distinguished IS parties within organization

Senior Management
Security office
Line management (system owners)
Internal / external auditors
Supporting internal / external services
IS projects
Employees of the organization

SLIDE 17

Information Security & Risk Management

Senior Management

What:

Giving commitment on information security
Approval of IS policy
Bootstrapping the ISMS (security officer)
Providing resources and budget
Management of serious security incidents
Periodic review of IS („Act‟), including adjusting the IS policy
Sponsoring of IS projects

Reports to:

Stakeholders
Supervisory board

SLIDE 18

Information Security & Risk Management

Security Officer

What:

IS center point; sits between senior management and the
rganization
Drafting / revising information security including security

baselines (but not approval!)

Providing specific guidelines on information security
Daily supervision on information security
Security incident handling
Progress control on IS including IS projects
Initiation of IS projects
Arranging the periodic management review

Reports to: Senior management

SLIDE 19

Security Office

„Headquarters‟ Business Unit Business Unit Business Unit Business Unit

Locatie Locatie Locatie Location Locatie Locatie Locatie Location Locatie Locatie Locatie Location Locatie Locatie Locatie Location

CISO BISO ISO

SLIDE 20

Information Security & Risk Management

Line management („system owners‟)

What:

Conducting risk assessments on their systems
Implementing security (baselines, additional controls)
Agreements with internal / external parties on security, e.g. as

arising from risk assessments

Supervision on information security, e.g. talking to non-

compliant employees Reports to: Security Office

SLIDE 21

Information Security & Risk Management

Line management („system owners‟)

Risk Criteria related to Integrity

Low Incorrectness of information can result in:

fraud of less than Euro 2.500 no bad publicity no damage to the operational management due to incorrect management decisions no risk for liability or non-compliance with rules and regulations

Medium Incorrectness of information can result in:

fraud of less than Euro 25.000 bad publicity in local news media limited damage to the operational management due to incorrect management decisions limited risk for liability or non-compliance with rules and regulations

High Incorrectness of information can result in:

fraud of substantially more than Euro 25.000 bad publicity in national news media unacceptable damage to the operational management due to incorrect management decisions high risk for liability or non-compliance with rules and regulations

Risk Criteria related to Confidentiality Risk Criteria related to Availability

SLIDE 22

Information Security & Risk Management

Internal / external audit

What:

Conducting audits on compliance with IS policy
Conducting audits on ISMS:
are all parties doing the things they should do?
is the ISMS effective?
Conducting specific audits, e.g., compliance with baselines
Should be independent

Reports to: Senior Management

SLIDE 23

Information Security & Risk Management

Supporting internal / external services

SLIDE 24

Information Security & Risk Management

Supporting internal / external services

What:

IT department (!), facility department, HR, legal department etc.
employment agencies, contractors, couriers, security guards
Compare ISO 27002 chapters
Implementing security baselines
Implementing specific additional security controls arising from

risk assessments Reports to: Security office „Clients‟ (line management)

SLIDE 25

Information Security & Risk Management

IS projects

What:

Implementation of specific security (e.g. PKI, IPS, IAM)

Reports to:

Project leaders
Security office

SLIDE 26

Information Security & Risk Management

Employees of the organization

What:

Adhering to security baselines and specific controls arising from

risk assessments

Reporting security incidents

Reports to:

Security office
Line management

SLIDE 27

Information Security & Risk Management

Relation with PDCA

P D C A X X X X X X X X X X X X X X

Senior Management
Security office
Line management (system owners)
Internal / external auditors
Supporting internal / external services
IS projects
Employees of the organization

There is on „‟X‟ wrong here; which one?

SLIDE 28

Information Security & Risk Management

Relation with PDCA

P D C A X X X X X X X X X X X X X X

Senior Management
Security office
Line management (system owners)
Internal / external auditors
Supporting internal / external services
IS projects
Employees of the organization

SLIDE 29

29

Outline

Introduction
Requirements on IS policies from ISO 2700x and VIR-2007
Organization of information security
IS policy layout
Some first feed-back from assignment #1

SLIDE 30

Information Security & Risk Management

IS policy layout

Chapter Introduction Background on organization (what it does/ produces, clients etc.) Management approval Senior management approval (and commitment) Definition of information security What is CIA, what is IS? Basic principles to follow Important IS aspects within the

rganization.

Objective and scope Minimal requirements to be met What falls under the policy (scope) Organization of information security Who is responsible for what? Relation with PDCA Approach How do you implement PDCA Baselines Make a choice of controls that are important for all systems/processes.

SLIDE 31

Information Security & Risk Management

Introduction

http://www.ru.nl/fnwi/:

Education
Research

(http://www.ru.nl/science/research/research_facilities/ )

Paid research (e.g., LaQuSo,

http://www.ru.nl/publish/pages/566471/rujv2006opmaak.pdf )

Service departments

(http://www.ru.nl/science/about_the_faculty/service_departments/)

SLIDE 32

Information Security & Risk Management

Management approval

SLIDE 33

Information Security & Risk Management

Management approval

Education institutes Research institutes Service departments

SLIDE 34

Information Security & Risk Management

Management approval

Education institutes

Onderwijsinstituut voor Biowetenschappen
Onderwijsinstituut voor Informatica en Informatiekunde
Onderwijsinstituut voor Moleculaire Wetenschappen
Onderwijsinstituut voor Wiskunde, Natuur- en Sterrenkunde (WiNSt)

Research institutes

Donders Centre for Neuroscience (DCN)
Institute for Computing and Information Sciences (ICIS)
Institute for Mathematics, Astrophysics and Particle Physics (IMAPP)
Institute for Molecules and Materials (IMM)
Institute for Science, Innovation and Society (ISIS)
Institute for Water and Wetland Research (IWWR

Service departments next slide

SLIDE 35

Information Security & Risk Management

Management approval

Service departments

Faculteitsbureau
C&CZ, Computer- and Communications Department
FEZ, Financiën en Economische Zaken
IHZ, Interne- en Huisvestingszaken
OWC, Onderwijscentrum
(o.a. Facultaire Studenten Administratie/Examenbureau)
P&O, Personeel en Organisatie
TeCe, TechnoCentrum (Technical Department)
Library of Science
EXO steunpunt
GI, General Instruments (IWWR)
Experimental Garden and Genebank (IWWR)
OC, Onderdeelcommissie

SLIDE 36

Information Security & Risk Management

Definition of information security

Just cite ISO 2700x

SLIDE 37

Information Security & Risk Management

Basic principles to follow

Minimal requirements to be met
What falls under the policy (scope)

Which laws do you think are applicable?

SLIDE 38

Information Security & Risk Management

Objective and scope

What are important IS aspects within FNWI?

Service departments

Faculteitsbureau
C&CZ, Computer- and Communications Department
FEZ, Financiën en Economische Zaken
IHZ, Interne- en Huisvestingszaken
OWC, Onderwijscentrum
(o.a. Facultaire Studenten Administratie/Examenbureau)
P&O, Personeel en Organisatie
TeCe, TechnoCentrum (Technical Department)
Library of Science
EXO steunpunt
GI, General Instruments (IWWR)
Experimental Garden and Genebank (IWWR)
OC, Onderdeelcommissie

SLIDE 39

Information Security & Risk Management

Organization of information security / Approach

Who is responsible for what? Relation with PDCA

Education institutes Research institutes Service departments

SLIDE 40

Information Security & Risk Management

Baselines

Make a choice of controls that are important for all systems/processes.

H ISO 27002 NEN Vertaling 5 Security Policy Beveiligingsbeleid 6 Organization of Information Security Beveiligingsorganisatie 7 Asset Management Classificatie en beheer van bedrijfsmiddelen 8 Human resources security Beveiligingseisen ten aanzien van personeel 9 Physical and Environmental Security Fysieke beveiliging en beveiliging van de omgeving 10 Communications and Operations Management Beheer van communicatie- en bedieningsprocessen 11 Access Control Toegangsbeveiliging 12 Information Systems Acquisition, Development and Maintenance Ontwikkeling en onderhoud van systemen 13 Information Security Incident Management Incidentmanagement 14 Business Continuity Management Continuïteitsmanagement 15 Compliance Naleving
