Università degli Studi di Roma “Tor Vergata” Dipartimento di Ingegneria Civile e Ingegneria Informatica

Search and Time Series Databases

Corso di Sistemi e Architetture per Big Data A.A. 2016/17 Valeria Cardellini

The reference Big Data stack

Valeria Cardellini - SABD 2016/17 1

Resource Management Data Storage Data Processing High-level Interfaces Support / Integration

Why search platforms?

• How to find documents that match queries?

– With text search faster than RDBMs

• How to obtain specific features?

– Such as highlighting, spatial search, suggestions, guided navigation, …

Valeria Cardellini - SABD 2016/17 2

Search engines

• Most popular search platforms:

– Apache Solr – ElasticSearch

• ETL process

Valeria Cardellini - SABD 2016/17 3

Apache Solr

• Scalable, highly reliable and open-source framework

for searching data

• Built on Apache Lucene

– Open-source library for indexing and search – Used by Solr for full-text search

• Can index documents written in:
• XML, JSON, CSV and binary formats
• Runs as Java Web application
• Provides a REST-like web service that exposes

services to manage the lifecycle of documents in the index (indexing, querying, …)

• Used by most popular Web apps (Apple, Instagram,

LinkedIn, …)

Valeria Cardellini - SABD 2016/17 4

Solr: key features

• Faceting

– To group the results based on specific field or defined criteria, providing the count of each subset – Example: shopping site can provide facets to narrow search results by manufacturer or price

• Auto-suggest

– To present list of possible query terms

• Spell check

– To suggest corrected spelling of query terms

• Highlighting
• Document clustering

– To group related documents in the search results

• Spatial search

– To filter search results based on location

Valeria Cardellini - SABD 2016/17 5

Solr: key features

• Pagination and ranking of search results
• Results grouping

– To group the results based on a grouping field and return the top documents in each group

• Near real-time search

– To search documents immediately after they have been indexed; useful for apps with dynamic changing content (e.g., news)

• More Like This

– identifies other documents that are similar to one in a result set

Valeria Cardellini - SABD 2016/17 6

Solr feature example

Valeria Cardellini - SABD 2016/17 7

Solr components

Valeria Cardellini - SABD 2016/17 8

Solr components

• Request Handlers: handle a request at a URL

– E.g.: /select

• Search Components: part of a Search Handler, a

componentized request handler

– Includes: Query, Faceting, Highlighting, Debug, … – Distributed Search capable

• Update Handlers: handle an indexing request
• Update Processors chain: per-handler componentized

chain that handles updates

• Query Parser plugins

– Mix and match query types in a single request – Function plugins for Function Query

• Text Analysis plugins: Analyzers, Tokenizers,

TokenFilters

• Response Writers: serialize and stream response to

client

Valeria Cardellini - SABD 2016/17 9

Scaling Solr: SolrCloud

• How to provide distributed indexing and search

capabilities?

– Up to millions of users and millions of indexed documents

• SolrCloud: deployment functionality of Solr which

allows to setup clusters of Solr servers

– Enables and simplifies horizontal scaling of a search index through replication and sharding – Sharding: incoming queries are distributed to to shards in the collection, which respond with merged results – Replication: to handle higher concurrent query load by spreading the requests to multiple servers

• No master node to allocate nodes, shards and

replicas

• SolrCloud uses ZooKeeper for storing shared

configuration files and for coordination

Valeria Cardellini - SABD 2016/17 10

Solr distributed architecture

Valeria Cardellini - SABD 2016/17 11

Elasticsearch

• Distributed, multitenant-capable and scalable

full-text search engine with REST-based interface and schema-free JSON documents

• Search engine based on Apache Lucene
• Developed in Java
• Distributed

– Indices can be divided into shards and each shard can have zero or more replicas – Each server hosts one or more shards, and acts as a coordinator to delegate operations to the correct shard(s) – Rebalancing and routing are done automatically

Valeria Cardellini - SABD 2016/17 12

Elastic (ELK) Stack

• Elasticsearch is closely integrated with

Logstash and Kibana (Elastic Stack, previously known as ELK)

• Logstash

– Server-side data processing pipeline that ingests data from a multitude of sources simultaneously, transforms it, and then sends it to Elasticsearch

• Kibana

– Data visualization platform

Valeria Cardellini - SABD 2016/17 13

Solr vs. Elasticsearch

• Solr

– Mature, widely deployed product – Active and large developer community – Provides highly detailed functional environment wide range

• f plug-ins are available
• Elasticsearch

– Newer, but already very widely used – Focus on extracting value from data generally, and not just

• n search

– Part of ELK stack – Schema-free and document-oriented

Valeria Cardellini - SABD 2016/17 14

• Elasticsearch vs Solr on Google Trends

Time series data base (TSDB)

• How to analyze DevOps monitoring, application

metrics, IoT sensor data?

– Time series databases (TSDBs) provides an effective and lightweight solution

• Optimized for handling high-volume time series data

– Time series: a sequence of data points (arrays of numbers) indexed by time (a date time or a date time range), e.g.:

• Time series of stock prices (price curve)
• Time series of energy consumption (load profile)
• Log of temperature values (temperature trace)
• Optimized for providing complex logic to analyze time

series data

– Queries for historical data, replete with time ranges and roll ups and arbitrary time zone conversions are difficult in DBMS

Valeria Cardellini - SABD 2016/17 15

TSDB: overview

• Create, enumerate, update and destroy

various time series and organize them in some fashion

– Series may be organized hierarchically and have companion metadata – Provide basic calculations on a series as a whole , (e.g., multiplying, adding, or combining various time series into a new time series) – Filter on arbitrary patterns (e.g., day of the week, low value, high value) – Provide additional statistical functions that are targeted to time series data

Valeria Cardellini - SABD 2016/17 16

TSDB: some products

• Some open-source products

– CrateDB https://crate.io – Chronix http://www.chronix.io – Graphite https://graphiteapp.org

• Stores numeric time-series data and render graphs of

this data on demand

– InfluxDB https://www.influxdata.com – KairosDB https://kairosdb.github.io

• Stores its time series in Cassandra

– OpenTSDB http://opentsdb.net

• Stores its time series in HBase

– Riak-TS http://basho.com/products/riak-ts/

Valeria Cardellini - SABD 2016/17 17

InfluxDB

• Written in Go
• Supports high write loads and large data set storage
• Conserves space through downsampling

– By automatically expiring and deleting unwanted data as well as backup and restore

• Provides easy-to-use SQL-like query language for

interacting with data

• Provides simple, high performing write and query

HTTP(S) APIs, e.g.:

– To create a database

url -i -XPOST http://localhost:8086/query --data- urlencode "q=CREATE DATABASE mydb”

– To write data

curl -i -XPOST 'http://localhost:8086/write? db=mydb' --data-binary 'cpu_load_short,host=server01,region=us-west value=0.64 1434055562000000000'

Valeria Cardellini - SABD 2016/17 18

InfluxDB datastore

• Data organized by time series, which contain a

measured value, like “cpu_load” or “temperature”

• Time series have zero to many points, one for each

discrete sample of the metric

• Points consist of:

– time (a timestamp) – a measurement (e.g., “cpu_load”) – at least one key-value field (the measured value itself, e.g. “value=0.64”, or “temperature=21.2”) – and zero to many key-value tags containing any metadata about the value (e.g. “host=server01”, “region=EMEA”, “dc=Frankfurt”)

Valeria Cardellini - SABD 2016/17 19

InfluxDB datastore

• General format of points:

<measurement>[,<tag-key>=<tag-value>...] <field- key>=<field-value>[,<field2-key>=<field2- value>...] [unix-nano-timestamp]

• Examples of points:

– cpu,host=serverA,region=us_west value=0.64 – payment,device=mobile,product=Notepad,method=credit

• billed=33,licenses=3i 1434067467100293230

– stock,symbol=AAPL bid=127.46,ask=127.48 – temperature,machine=unit42,type=assembly external=25,internal=37 1434067467000000000

• Valeria Cardellini - SABD 2016/17

20

InfluxDB datastore

• A measurement is like a SQL table, where the

primary index is time

• With respect to DBMS:

– No need to define schemas up-front – Null values are not stored

Valeria Cardellini - SABD 2016/17 21

InfluxDB stack

• Integrated with Telegraph, Chronograf and Kapacitor

(TICK stack)

Valeria Cardellini - SABD 2016/17 22

References

• Apache Solr Reference Guide, http://bit.ly/2scksQF
• InfluxDB Version 1.2 Documentation,

http://bit.ly/2ryagFT

• Dunning and Friedman, “Time Series Databases”,

O’Reilly, 2015.

Valeria Cardellini - SABD 2016/17 23
