Screenshot CC BY-NC 3.0

Before: the mess CC BY-NC 3.0

Before: the mess CC BY-NC 3.0

Before: the mess Akka & Spray RabbitMQ C++ & CUDA Cassandra CC BY-NC 3.0

Before: the mess scene topic (Map[String, String], Array[Byte]) (Map[String, String], Array[Byte]) identity topic CC BY-NC 3.0

Before: the mess scene topic _tmp_ x topics (Map[String, String], Array[Byte]) JSON (Map[String, String], Array[Byte]) identity topic CC BY-NC 3.0

Before: the mess fire-and-forget at-most-once at-most-once fire-and-forget non-durable CC BY-NC 3.0

Asynchronous request–response orchestration class Orchestrator extends Actor with ActorFSM[Orchestrator.State, Orchestrator.Data] { startWith(Idle, UninitializedData) when(Idle, idleTimeout)(idleSF) when(ImageProcessing, stepTimeout)(imageProcessingSF) when(WaitingForProcessingResult, stepTimeout)(waitingForProcessingSF) whenUnhandled(timeoutSF) onTransition { case _ -> Aborted => ??? ... } def idleSF: StateFunction = ??? def imageProcessingSF: StateFunction = ??? def waitingForProcessingSF: StateFunction = ??? def timeoutSF: StateFunction = { case Event(StateTimeout, data: RunningTransactionData) => goto(Aborted) } } CC BY-NC 3.0

After: proper microservices text scene dashboard ingest identity CC BY-NC 3.0

After: proper microservices text scene dashboard ingest identity CC BY-NC 3.0

After: proper microservices Lagom Cassandra Akka text scene dashboard ingest identity Kafka CC BY-NC 3.0

After: proper microservices text group text topic scene topic text scene dashboard ingest identity tweet-image topic scene group identity topic identity group CC BY-NC 3.0

After: proper microservices message Text { … } text topic message Envelope { scene topic int32 version = 1; string handle = 2; message Scene { … } int64 processingTimestamp = 3; int64 ingestionTimestamp = 4; text string correlationId = 5; string messageId = 6; string messageType = 7; bytes payload = 8; } scene dashboard ingest identity tweet-image topic bytes image; identity topic message Identity { … } CC BY-NC 3.0

After: proper microservices at-least-once fire-and-forget at-most-once text scene dashboard ingest identity at-least-once at-least-once CC BY-NC 3.0

Persistence and formats message Envelope {
 int32 version = 1;
 string handle = 2;
 int64 processingTimestamp = 3;
 int64 ingestionTimestamp = 4;
 string correlationId = 5;
 string messageId = 6;
 string messageType = 7;
 bytes payload = 8;
 } CC BY-NC 3.0

Persistence and formats message Text { repeated string areas = 1;
 } CC BY-NC 3.0


 Persistence and formats message Scene { message Label {
 string label = 1;
 double score = 2;
 } repeated Label labels = 3;
 } CC BY-NC 3.0



 Persistence and formats message Identity {
 oneof face {
 IdentifiedFace identifiedFace = 1;
 UnknownFace unknownFace = 2;
 }
 message IdentifiedFace {
 string name = 1;
 double score = 2;
 }
 message UnknownFace { }
 } CC BY-NC 3.0



 Persistence and formats message IdentifyFace {
 int64 ingestionTimestamp = 2;
 string correlationId = 3;
 string handle = 4;
 bytes image = 5;
 }
 message IdentifyFaces {
 repeated IdentifyFace identifyFaces = 1;
 }
 message FaceImage {
 double confidence = 1;
 int32 x = 2;
 int32 y = 3;
 int32 w = 4;
 int32 h = 5;
 bytes rgbBitmap = 6;
 } CC BY-NC 3.0

Fire–and–forget send object Act { def props(config: Config): Props = { val producerConf = KafkaProducer.Conf (config.getConfig("..."), new StringSerializer, KafkaSerializer[Envelope](_.toByteArray)) Props( classOf [Act], producerConf) } } class Act(producerConf: KafkaProducer.Conf[String, Envelope]) extends Actor { private [ this ] val producer = KafkaProducer(conf = producerConf) override def receive: Receive = { case TweetImage (handle, content) => producer.send(KafkaProducerRecord("tweet-image", handle, Envelope (version = 100, handle = handle, ingestionTimestamp = System. nanoTime() , processingTimestamp = System. nanoTime() , messageId = UUID. randomUUID() .toString, correlationId = UUID. randomUUID() .toString, payload = content))) } } CC BY-NC 3.0

At least once delivery I class SceneClassifierActor(…) extends Actor { private[this] val kafkaConsumerActor = context.actorOf(…) private[this] val producer = KafkaProducer(…) override def receive: Receive = { case extractor(consumerRecords) => val futures = consumerRecords.pairs.flatMap { case (_, envelope) => val outEnvelope = … Some(producer.send(KafkaProducerRecord("scene", envelope.handle, outEnvelope))) } import context.dispatcher Future. sequence (futures).onSuccess { case _ => kafkaConsumerActor ! Confirm(consumerRecords.offsets, commit = true ) } } } CC BY-NC 3.0

At least once delivery II class IdentityMatcherActor(...) extends PersistentActor with AtLeastOnceDelivery { override val persistenceId: String = "identity-matcher-actor" def identifyFacesAndSend(identifyFaces: Seq[IdentifyFace])( implicit executor: ExecutionContext): Future[Unit] = { // Future.sequence(producer.send(...)) } def handleIdentifyFace: Receive = { case (deliveryId: Long, identifyFaces: IdentifyFaces) => import context.dispatcher identifyFacesAndSend(identifyFaces.identifyFaces).onSuccess { case _ => confirmDelivery(deliveryId) } case IdentifyFaces (faces) => import context.dispatcher identifyFacesAndSend(faces).onFailure { case _ => self ! Kill } } override def receiveRecover: Receive = handleIdentifyFace override def receiveCommand: Receive = handleIdentifyFace orElse { case extractor(consumerRecords) => val identifyFaces = consumerRecords.pairs.map { case ( _ , envelope) => IdentifyFace(envelope.ingestionTimestamp, envelope.correlationId, envelope.handle, envelope.payload)) } persist(IdentifyFaces(identifyFaces = identifyFaces)) { result => deliver(self.path)(deliveryId => (deliveryId, result)) sender() ! Confirm(consumerRecords.offsets, commit = true ) } } } CC BY-NC 3.0





 At least once delivery III public interface TweetImageService extends Service {
 Topic<Envelope> tweetImageTopic();
 …
 }
 public class TextServiceImpl implements TextService {
 private final PersistentEntityRegistry persistentEntityRegistry;
 public Topic<Envelope> textTopic() {
 return TopicProducer.singleStreamWithOffset(offset -> persistentEntityRegistry
 .eventStream(TextEntityEvent.OcredTag. INSTANC E, offset)
 .map(p -> new Pair<>(p.first().envelope(), offset))
 );
 }
 @Inject
 public TextServiceImpl(PersistentEntityRegistry persistentEntityRegistry, TweetImageService tweetImageService) {
 this .persistentEntityRegistry = persistentEntityRegistry;
 persistentEntityRegistry.register(TextEntity. class );
 tweetImageService.tweetImageTopic().subscribe().withGroupId("text").atLeastOnce(Flow.fromFunction( this ::extractText));
 }
 private Done extractText(Envelope envelope) {
 TextEntityCommand.Ocr command = new TextEntityCommand.Ocr(…);
 PersistentEntityRef<TextEntityCommand> ref = persistentEntityRegistry.refFor(TextEntity. class , envelope.handle());
 ref.ask(command);
 return Done.getInstance();
 }
 } CC BY-NC 3.0

At most once delivery class DashboardSinkActor(...) extends Actor { private[this] val kafkaConsumerActor = context.actorOf(...) override def receive: Receive = { case extractor(consumerRecords) => consumerRecords.pairs.foreach { case (_, envelope) => context.system.eventStream.publish(envelope); } kafkaConsumerActor ! Confirm(consumerRecords.offsets, commit = true ) } } CC BY-NC 3.0

ENOUGH SLIDES! CC BY-NC 3.0

After: proper microservices text scene dashboard ingest identity CC BY-NC 3.0
