Science applications requiring exascale compute and data capabilities

Jack Wells Director of Science Oak Ridge Leadership Computing Facility Oak Ridge National Laboratory SIAM EX14 Workshop Chicago 6 July 2014

2

Outline

• U.S. DOE Leadership Computing Program

– Breakthrough Science Across a Broad Range of Disciplines

• Science opportunities over next decade

– Fusion Energy, Biomass to Biofuels, Solar Energy, Nuclear Energy

• Industry also has big problems and demanding

requirements

• CORAL Procurement: Mission need for pre-

exascale capability system in 2018

• Exascale challenges remain with us

3

Mission need for Leadership Computing

Leadership computing capability is required for scientists to tackle the high-resolution, multi-scale/multi-physics simulations of greatest interest and impact to both science and the nation. Leadership Computing capability is typically 10-100X greater than other computational centers. Leadership Computing research is mission critical to inform policy decisions and advance innovation in far reaching topics such as:

• energy assurance
• ecological sustainability
• scientific discovery
• global security

“We will respond to the threat of climate change, knowing that the failure to do so would betray our children and future generations.” – President Obama 1/21/2013

4

What is the Leadership Computing Facility (LCF)?

• Collaborative DOE Office of Science

program at ORNL and ANL

• Mission: Provide the computational

and data resources required to solve the most challenging problems.

• 2-centers/2-architectures to address

diverse and growing computational needs of the scientific community

• Highly competitive user allocation

programs (INCITE, ALCC).

• Projects receive 10x to 100x more

resource than at other generally available centers.

• LCF centers partner with users to

enable science & engineering breakthroughs (Liaisons, Catalysts).

5

Hardware scaled from single- core through dual-core to quad-core and dual-socket , 12-core SMP nodes Scaling applications and system software was the biggest challenge

Cray XT4 Dual-Core 119 TF

2006 2007 2008

Cray XT3 Dual-Core 54 TF Cray XT4 Quad-Core 263 TF

ORNL has increased system performance by 1,000 times 2004-2010

2005

Cray X1 3 TF Cray XT3 Single-core 26 TF

2009

Cray XT5 Systems 12-core, dual-socket SMP 2.3 PF

6

Science breakthroughs at the OLCF:

Biomass as a viable, sustainable feedstock for hydrogen production for fuel cells, Nano Letters (2011)

• J. Phys. Chem. Lett. (2010)

71 & 74 citations, respectively World’s first continuous simulation of 21,000 years of Earth’s climate history, Science (2009) 116 citations Largest simulation of a galaxy’s worth of dark matter, showed for the first time the fractal-like appearance of dark matter substructures, Nature (2008) 326 citations, 3/2014 MD simulations show selectivity filter of a trans-membrane ion channel is sterically locked

• pen by hidden water

molecules, Nature (2013) Global Warming preceded by increasing carbon dioxide concentrations during the last deglaciation, Nature (2012). 64 citations, 3/2014 Researchers solved the 2D Hubbard model and presented evidence that it predicts HTSC behavior, Phys. Rev. Lett (2005) 105 citations, 3/2014 First-Principles Flame Simulation Provides Crucial Information to Guide Design of Fuel-Efficient Clean Engines, Proc. Combust. Insti. (2007) 78 citations, 3/2014 Calculation of the number of bound nuclei in nature, Nature (2012), 36 citations, 3/2014 , 36 citations, 3/2014

SELECTED science and engineering advances over the period 2003 - 2013

Astrophysicists discover supernova shock-wave instability,

• Astrophys. J. (2003)

254 citations, 3/2014 Demonstrated that three-body forces are necessary to describe the long lifetime of 14C

• Phys. Rev. Lett. (2011)

28 citations, 3/2014

2007 2008 2009 2010 2011 2013 2012 2004 2005 2006 2014 2003

7

High-impact science across a broad range

• f disciplines

Superconductivity “Doping dependence of spin excitations and correlations with high-temperature super- conductivity in iron pnictides,“ Meng Wang(IOP CAS Beijing), Nature Communications. December (2013) Paleoclimate Science “Northern Hemisphere forcing

• f Southern Hemisphere

climate during the last deglaciation,” Feng He (UW Madison), et al., Nature, February (2013) Molecular Biology “Recovery from slow inactivation in K1 channels is controlled by water molecules” Jared Ostmeyer, et al. (U. Chicago) Nature, Sept. (2013) Polymer Science “Self-Organized and Cu- Coordinated Surface Linear Polymerization” Qing Li, B. Sumpter (ORNL), Nature Scientific Reports. July (2013) Molecular Biology “A phenylalanine rotameric switch for signal-state control in bacterial chemoreceptors”

• D. Ortega (UTK),

Nature Communications December (2013) Complex Oxide Materials “Atomically resolved spectroscopic studyof Sr2IrO4: Experiment and theory,” Qing Li (ORNL), E.G. Eguiluz (UTK) Nature Scientific Reports. October (2013)

For example in 2013:

8

Science opportunities over the next decade

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.

• Science benefits and impact of future systems are

examined on an ongoing basis.

• Baseline plans are developed in consultation with

leading domain scientists.

• Detailed performance analyses are conducted

for a subset of applications to understand architectural bottlenecks.

• Leadership Computing Facility has been actively

engaged in community assessments of future computational needs and solutions.

Application requirements process has been guiding paths forward

9

Our Science requires that we advance computational capability 1000x over the next decade.

Mission: Providing world-class computational resources and specialized services for the most computationally intensive global challenges Vision: Deliver transforming discoveries in climate, materials, biology, energy technologies, etc

Jaguar 2.3 PF 362 TB DRAM Titan 27 PF 600 TB DRAM Hybrid GPU/CPU

2010 2012 2017 2022

OLCF-5: 1 EF 20 MW OLCF-4: 100-250 PF 4000 TB memory > 20MW 6 day resilience

Roadmap to Exascale

What are the Challenges?

10

Science challenges for LCF in next decade

Combustion Science

Increase efficiency by 25%-50% and lower emissions from internal combustion engines using advanced fuels and low- temperature combustion.

Biomass to Biofuels

Enhance the understanding and production of biofuels for transportation and other bio- products from biomass.

Fusion Energy

Develop predictive understanding of plasma properties, dynamics, and interactions with surrounding materials.

Climate Change Science

Understand the dynamic ecological and chemical evolution of the climate system with uncertainty quantification of impacts.

Solar Energy

Improve photovoltaic efficiency and lower cost for organic and inorganic materials.

Nuclear Energy:

For existing reactors, provide safe, increased fuel utilization, power upgrades, and reactor lifetime extensions. Design new, safe, cost-effective reactors. .

11

Fusion Energy/ITER

2013-2018 2018-2023

• Perform high-fidelity simulation of edge plasma

turbulent transport in tokamak from first- principles to address DIII-D and JET-scale plasmas with a goal of understanding high- confinement physics.

• Increase simulation of tokamak edge plasma to

ITER scale. Coupled simulations of plasma edge with core and chamber wall interactions. Control edge-localized modes and other destructive mechanisms.

• Perform integrated first-principles simulation

including the critical multiscale processes to study fusion-reacting plasmas in realistic magnetic confinement geometries.

• Produce an experimentally validated

simulation capability for ITER to design DEMO, the ITER follow-on facility to solve the engineering issues necessary for electricity production with fusion plasmas.

Key science challenges: Effectively model and control the flow of plasma and energy in a fusion reactor, scaling up to ITER-size. Develop predictive understanding of plasma properties, dynamics, and interactions with surrounding

• materials. Mitigate plasma disruptions.

Science enabled by LCF Capabilities

A global particle-in-cell simulation to show core turbulence in a tokamak. Image S. Ethier, PPPL

12

XGC1 Gyrokinetic simulation of “blobby” edge turbulence in a DIII-D H-mode plasma, together with background and neutral particle dynamics. The resulting heat load footprint from XGC1 on divertor plate, mapped back to outboard midplane.

Achieved clarification of some assumptions/findings from reduced models, together with some new discoveries

XGC1 on Titan simulates turbulent transport in plasma edge for whole tokamak from first-principles

Courtesy: CS Chang

13

Biomass to biofuels Biomass to biofuels

2013-2018 2018-2023

• Atomic-detail dynamical models of biomass

systems of several million atoms, permitting detailed analysis of interactions

• Simulations of pretreatment effects on multi-

component biomass systems to understand the bottlenecks in bioconversion

• Understand the dynamics of enzymatic

reactions on biomass by simulating interactions between microbial systems and cellulosic biomass

• Design superior enzymes for

conversion of biomass Key science challenges: Enhance the understanding and production of biofuels from biomass for transportation and other bio-products. The main challenge to overcome is the recalcitrance of biomass (cellulosic materials) to hydrolysis. Science enabled by increasing LCF Capabilities

Lignin interacting with crystalline cellulose.

14

Science Objectives and Impact

Boosting Bioenergy and Overcoming Recalcitrance

Molecular Dynamics Simulations

• Improve our understanding of lignin-cellulose

interactions at the molecular level in order to

• vercome biomass recalcitrance and improve the

efficiency of biofuel production, thereby reducing the cost of ethanol

• Ethanol, which is carbon-neutral and domestically

produced, is the primary renewable substitute for gasoline

2013 INCITE Program PI: Jeremy Smith University of Tennessee & ORNL Used Hours: 72,167,000

Performance & OLCF Contribution Science Results

A cellulase enzyme (pink) hydrolyzing a cellulose (blue) strand despite the presence of lignin aggregates (green) on the cellulose

• surface. Vizualization by M. Matheson (ORNL)
• GROMACS application has been adapted to

run on the GPU-accelerated Titan system: Project can handle much larger systems—30 million atoms, compared to 3 million atoms

• n Jaguar
• The OLCF’s Mike Matheson provided

visualization services

• Discovered amorphous cellulose is easier to break

down because it associates less with lignin

• This is because the less-organized cellulose

interacts strongly with water, making it less available to interact with lignin

• Biofuel production may potentially become more

efficient by manipulating cellulose crystallinity so as to reduce lignin precipitation onto cellulose

15

Solar ener Solar energy

2013-2018 2018-2023

• Understand growth, interface structure, and

stability of heterogeneous polymer blends necessary for efficient solar conversion.

• Simulations of structure, carrier transport, and

defect states in nanomaterials.

• Describe excited state phenomena in

homogeneous systems.

• Enable computational screening of

materials for desired excited-state and charge transport properties.

• Systems-level, multiphysics simulations
• f practical photovoltaic devices are

enabled.

• Uncertainty quantification enabled for

critical integrated materials properties. Key science challenges: Improve photovoltaic efficiency and lower cost for organic and inorganic materials. A photovoltaic material poses difficult challenges in the prediction of morphology, excited state phenomena, transport, and materials aging. Science enabled by LCF Capabilities

16

Science Objectives and Impact

• Organic photovoltaic (OPV) solar cells

are promising renewable energy sources: – Low costs, high-flexibility, and light weight

• Bulk-heterojunction (BHJ) active layer

morphology and domain size is critical for improving performance

Towar ards Ra ds Rational Design of tional Design of Ef Efficient ficient Or Organic Photo ganic Photovoltaic Ma

• ltaic Materials

terials

LAMMPS Early Science Project J.-M. Carrillo, W.M. Brown, Oak Ridge National Laboratory Hours Used: 72,000,000

Titan Simulation: LAMMPS Preliminary Science Results

Corse-grained MD simulation of phase-separation

• f a 1:1 weight ratio P3HT/PCBM mixture into

donor (white) and acceptor (blue) domains.

P3HT (electron donor) PCBM (electron acceptor)

• OLCF/CAAR team prepared LAMMPS for

use with GPUs on Titan

• Portability: Builds with CUDA or OpenCL
• Speedups on Titan (GPU+CPU vs. CPU:

2X to 15x (mixed precision) depending upon model and simulation

• Speedup of 2.5-3x for OPV simulation

used here

• Titan simulations are 27x larger and 10x longer

– Converged P3HT:PCBM separation in 400ns CGMD time

• Prediction: Increasing polymer chain length will

decrease the size of the electron donor domains

• Prediction: PCBM (fullerene) loading parameter results

in an increasing, then decreasing impact on P3HT domain size

17

Nuc Nuclear Ener lear Energy advances will be y advances will be ena enabled by L bled by LCF o CF over the ne er the next decade xt decade

2013-2016 2016-2020

• Coupled-physics simulation of fluid flow,

heat transfer, neutron transport, and fuel behavior for fuel assemblies.

• Single-physics and low-fidelity coupled-

physics analysis of full cores.

• Predict behavior of nominal reactor
• peration and existing nuclear fuels with

limited quantification of uncertainties.

• Coupled-physics simulation of fluid

flow, heat transfer, neutron transport, and fuel behavior for multiple fuel assemblies and limited full-core analysis of nominal reactor operation.

• Initial capability for analysis of reactor

transients, including some accident

• scenarios. Improved quantification of

uncertainties. Key science challenges: For existing reactors provide safe, increased fuel utilization, power upgrades, and reactor lifetime extensions. Design new, safe, cost- effective reactors. Science enabled by LCF Capabilities

18

Execution Goals

• Compare fidelity and performance of Shift against Keno, SPN,

and SN (Denovo)

• Generate high-fidelity neutronics solution for code comparison
• f solutions for predicting reactor startup and physics testing

Westinghouse-CASL Simulation of Reactor Start Up – Quarter-Core Zero Power Physics Test

• AP1000 model created and results generated for reactor

criticality, rod worth, and reactivity coefficients

• Identical VERA Input models used for Shift, SPN, and SN

– dramatically simpler than KENO-VI input model

Results

• Some of the largest Monte Carlo calculations ever performed

(1 trillion particles) have been completed

– runs use 230,000 cores of Titan or more

• Excellent agreement with KENO-VI
• Extremely fine-mesh SN calculations, which leverage Titan’s

GPU accelerators, are under way

AP1000 pin powers

19

Number of Number of Industr Industry Pr y Projects Underw

• jects Underway

ay at OL t OLCF by Calendar Y CF by Calendar Year ear

3 5 5 7 12 19 21 29 28 5 10 15 20 25 30 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014

Current as of June 2014

*

* Year in progress

20

Human skin barrier Global flood maps Engine cycle-to- cycle variation Fuel efficient ¡ jet engines ¡ Wind turbine resilience Welding Software Demonstrated small molecules can have large and varying impact on skin permeability depending on their molecular characteristics— important for product efficacy and safety Developed fluvial and pluvial high resolution global flood maps to enable insurance firms to better price risk and reduce loss of life and property Developing novel approach to using massively parallel, multiple simultaneous combustion cycle simulations to address cycle-to- cycle variations in spark ignition engine Conducting first-

• f-a-kind high-

fidelity LES computations

• f flow in

turbomachinery components for more fuel efficient, next- generation jet engines ¡ First time simulation of ice formation within million-molecule water droplets is expanding understanding of freezing at the molecular level to enhance wind turbine resilience in cold climates Evaluating large- scale HPC and GPU capability of critical welding simulation software and further developing & testing weld

• ptimization

algorithm

Innovation through Industrial Partnerships

21

Aircraft design

Consumer product stability

Gasoline engine injector Jet engine efficiency Li-ion batteries Underhood cooling Unexpected discovery of multiple solutions for steady RANS equations with separated flow helps explain why numerical modeling sometimes fails to capture maximum lift Developed method to measure impact

• f additives,

such as dyes and perfumes,

• n properties of

lipid systems such as fabric enhancer and

• ther formulated

products Optimizing multihole gasoline spray injector nozzle designs for better in-cylinder fuel-air mixture distributions, greater fuel efficiency and reduced physical prototypes Accurate predictions

• f atomization
• f liquid fuel

by aerodynamic forces enhance combustion stability, improve efficiency, and reduce emissions New classes

• f solid inorganic

Li-ion electrolytes could deliver high ionic and low electronic conductivity and good electrochemical stability Developed a new, efficient and automatic analytical cooling package

• ptimization

process leading to one of a kind design

• ptimization of

cooling systems

Innovation through Industrial Partnerships

22

Catalysis Design innovation Aircraft design Industrial fire suppression Turbo machinery efficiency Long-haul truck fuel efficiency Demonstrated biomass as a viable, sustainable feedstock for hydrogen production for fuel cells; showed nickel is a feasible catalytic alternative to platinum Accelerating design of shock wave turbo compressors for carbon capture and sequestration Simulated takeoff and landing scenarios improved a critical code for estimating characteristics

• f commercial

aircraft, including lift, drag, and controllability Developing high-fidelity modeling capability for fire growth and suppression; fire losses account for 30%

• f U.S. property

loss costs Simulated unsteady flow in turbo machinery,

• pening new
• pportunities for

design innovation and efficiency improvements. Simulations reduced by 50% the time to develop a unique system of add-on parts that increases fuel efficiency by 7−12% for long-haul (18- wheeler) trucks

Innovation through Industrial Partnerships

23

Science Objectives and Impact

• Ramgen Power Systems is developing shock wave

compression technology to meet DOE goals for reducing Carbon Capture and Sequestration costs.

• NASA transonic test case: Conduct high-resolution

simulations of “Stage 67” tip injection flow control (originally designed and experimentally tested by NASA Glenn Research Center in 2004) to observe new details

• f fundamental aerodynamic phenomenon.

Ramping Up Turbomachine Performance

Simulating novel tip injection flow control shown to delay stall in shock wave compression technology Application Performance Science Results

• Validated accuracy of CFD models driving
• ptimization of Ramgen turbomachine

designs.

• Simulated secondary structures observed

for the first time and never detected experimentally.

• Gained insight into how injected jets

manipulate viscous shear flow and vortex structures to delay stall.

Project PI: A. Grosvenor, Ramgen Power Systems Allocation Program: Discretionary, ALCC

• ADIOS integrated into FINE/Turbo, enabling 100x

increase in I/O speed.

• Efficient parallel performance of commercial code

FINE/Turbo to 1.5 billion grid cells (148 million per rotor passage) running up to 5,000 cores.

Simulation demonstrating tip injection influence on vortices at tip clearance gap between rotor tip and casing. Grosvenor, et al. Proceedings of ASME Turbo Expo (2014).

OLCF contributions: Mike Matheson guided Ramgen and Numeca to improve scalability, I/O performance, memory utilization and workflow design.

24

Leadership Computing Mission Need for 150 PF to 400 PF Capability System in 2017-2018

DOE Mission Need Statement was approved 12/2012 and revised in 7/2013:

• 150-400 PF Capability System with delivery in

2017-2018

– Capability will be divided between two Oak Ridge and Argonne Leadership Computing Facilities – Architectural Diversity among the LCF systems is required

25

CORAL Joint NNSA & SC Leadership Computing Acquisition Project

Leadership Computers run the most demanding DOE mission applications and advance HPC technologies to assure continued US/DOE leadership Objective - Procure 3 leadership computers to be sited at ANL, ORNL and LLNL in CY17 Approach Competitive process - one RFP (issued by LLNL) leading to 2 R&D contracts and 3 computer procurement contracts For risk reduction and to meet a broad set of requirements, 2 architectural paths will be selected Once Selected, Multi-year Lab-Awardee relationship to co-design computers Both R&D contracts jointly managed by the 3 Labs Each lab manages and negotiates its own computer procurement contract, and may exercise options to meet their specific needs Understanding that long procurement lead-time may impact architectural characteristics and designs of procured computers

Sequoia (LLNL) 2012 - 2017 Mira (ANL) 2012 - 2017 Titan (ORNL) 2012 - 2017

Current DOE Leadership Computers

26

CORAL Procurement Model

RFP R&D contract SC Lab #1 computer contract (2017 delivery) R&D contract SC Lab #2 computer contract (2017 delivery) LLNL computer contract (2017 delivery)

Two Diverse Architecture Paths

27

OL OLCF-4 Acceler CF-4 Accelerated A ted Applica pplication tion Readiness eadiness

Center for Accelerated Application Readiness (CAAR)

• Performance analysis of community applications
• Technical plan for code restructuring and optimization
• Deployment on OLCF-4

OLCF-4 will issue a call for proposals in FY2015 for application development partnerships between community developers, OLCF staff and the OLCF Vendor Center of Excellence.

28

Are we seeing the real exascale challenges?

Advanced simulation and modeling apps Exascale Challenges

Scale Power Resilience Memory wall

Conquering Petascale problems of today Beware being eaten alive by the Exascale problems of tomorrow.

29

Conclusions

• Leadership computing is for the critically important

problems that need the most powerful compute and data infrastructure

• Broad-based science requirements for exascale

computing are well established

• Accelerated, hybrid-multicore computing solutions are

performing well on real, complex scientific applications.

– But you must work to expose the parallelism in your codes. – This refactoring of codes is largely common to all massively parallel architectures

• OLCF resources are available to industry, academia, and

labs, through open, peer-reviewed allocation mechanisms.

30

Acknowledgements

OLCF-3 Vendor Partners: Cray, AMD, NVIDIA, CAPS, Allinea OLCF Users: CS Chang (PPPL), Jeremy Smith(UT/ORNL), Jan- Michael Carrillo (ORNL), Tom Evans/John Turner (ORNL), Allan Grosvenor (Ramgen/Masten) Mike Matheson and Dave Pugmire (ORNL) for visualizations DOE ASCR Leadership Computing Program, ALCF, OLCF

This research used resources of the Oak Ridge Leadership Computing Facility at the Oak Ridge National Laboratory, which is supported by the Office of Science of the U.S. Department of Energy under Contract No. DE-AC05-00OR22725.

31

Questions? WellsJC@ornl.gov

31

Contact us at http://olcf.ornl.gov http://jobs.ornl.gov
