SFMTA | Municipal Transportation Agency Image: a bus in front of the Palace of the Legion of honor SAN FRANCISCO BICYCLE SHARING PILOT 03 | 06| 2012 | SAN FRANCISCO, CALIFORNIA Pilot Service Area 500 bikes 50 stations 1.78 sq mi.

slide-1
SLIDE 1

SAN FRANCISCO BICYCLE SHARING PILOT

03 | 06| 2012 | SAN FRANCISCO, CALIFORNIA SFMTA | Municipal Transportation Agency Image: a bus in front of the Palace of the Legion of honor

slide-2
SLIDE 2

2

Pilot Service Area

  • 500 bikes
  • 50 stations
  • 1.78 sq mi.
  • Dense
  • Mixed Use
  • Transit Rich
  • Flat
  • Bikable
slide-3
SLIDE 3

3

Bicycle Sharing Suitability Analysis

  • 1. Retail Job Density
  • 2. Population Density
  • 3. Employment Density
  • 4. Zoning
  • 5. Slope
  • 6. Pedestrian Commuters

per Square Mile

  • 7. Bicycle Commuters/

Square Mile

  • 8. Bicycle Infrastructure
  • 9. Transit

10.Tourist Sites 11.Per Capita Income Raster-based GIS overlay using 11 factors:

slide-4
SLIDE 4

4

Citywide Bicycle Sharing Suitability

slide-5
SLIDE 5

5

Citywide Bicycle Sharing Suitability

slide-6
SLIDE 6

6

Transit

slide-7
SLIDE 7

7

slide-8
SLIDE 8

8

Slope

slide-9
SLIDE 9

9

Guiding Principle:

Bike Sharing Station Density is Key to Success “The number one indicator of success is density of stations.”

Alison Cohen, President, Alta Bike Share

slide-10
SLIDE 10

10

Station Spacing

  • Paris Benchmark: 300 meter grid
  • 1 station every 2-3.5 blocks
  • 28 stations per square mile
  • 50 stations = 1.75 square mile service area
slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

Placing Stations

Toronto Madison

slide-13
SLIDE 13

13

slide-14
SLIDE 14

14

Station Setup

slide-15
SLIDE 15

15

Initial Site Review Placement Guidelines

  • Stations should be visible
  • For sidewalk locations, preserve 6 feet of through space
  • Stations should be placed at least:
  • 2 feet from any standpipe, parking meter, mailbox,

light post, utility vault, garbage can, news rack

  • 3 feet from any driveway or wheelchair ramp
  • 5 feet from any low pressure fire hydrant, MUNI

shelter, advertising kiosk, or crosswalk

  • 8 feet from fire escape/exit
slide-16
SLIDE 16

16

Inter- and Intra-Agency Coordination

slide-17
SLIDE 17

17

Station Approval Flow

slide-18
SLIDE 18

18

Field Review

slide-19
SLIDE 19

19

Station Plan View

slide-20
SLIDE 20

20

Photo Simulation

slide-21
SLIDE 21

21

Public Notice for Public Hearing

slide-22
SLIDE 22

22

Heath Maddox

Heath.maddox@sfmta.com

415.701.4605

http://www.sfmta.com/bikesharing
