Samsung- GLOBALFOUNDRIES 14nm Collaboration

April 2014

Introducing : Samsung and GLOBALFOUNDRIES Collaboration

A new strategic collaboration between Samsung and GLOBALFOUNDRIES Provides unprecedented global capacity for leadership 14nm FinFET technology Gives customers choice and assurance of supply that can only come from true design compatibility at multiple sources across the globe Addressing industry needs with a necessary advancement of the foundry supply chain model Covers both 14LPE and 14LPP, the leading choice for high-volume, power-efficient SoC designs

Mobile and Wireless

Applications Extend Battery Life

Computer, Network, Storage

Applications Reduce Energy OPEX

Meet Thermal Constraints Improve Reliability Reduce Carbon Footprint

Power Efficiency Driving FinFET Technology Adoption All while increasing performance!

Lg

20 % ¡

20nm 14LPE

▼35 % ¡

Performance Power

Intrinsically operates at a lower supply voltage Lowest off-state leakage Faster switching speed

14nm FinFET Offers Breakthrough Power/ Performance

Gate length shrink enables performance scaling FET is turned

• n its

edge Double-gate reduces off- current

20nm ¡Planar FinFET

S i m i l a r

Other foundries

Delivering Maximum Value with Leadership 14nm

• Aggressive gate pitch
• Smallest memory solution
• Innovative layout

schemes for compact logic

Smallest Area

Meeting the Growing Market Demand

LOWER WATTS PER GHz

Smartphone Tablet Mobile PC

MORE PERFORMANC E PER WATT

Ethernet Switch Fiber Access Base Station Wireless Access Data Center

Mobility and Wireless Computer, Network and Storage

~$25B

2017 Advanced Node Projected TAM

Source: Gartner Foundry Supply & Demand 4Q13 Update

Mobile data traffic Increasing exponentially Pressure of increased bandwidth through the infrastructure Increasing need to efficiently scale out of the infrastructure

S2 Fab

Austin, Texas, USA

S1 Fab

GiHeung, South Korea

S3 Fab

HwaSeong, South Korea

Fab 8

Saratoga, NY, USA

Satisfying FinFET Demand with Global Capacity

4 leading-edge fabs

• n two continents

For mass production For mass production For mass production For prototyping

New model – Single design, Flexible sourcing

Technology information shared Fab synchronized Concurrent source(s) bring up Risk mitigated production ramp

We are Advancing the Supply Chain Model

PDK

Design with common PDK

Single design

to multiple technology- matched foundries

All fabs are in sync involving materials, process recipes, integration, and tools

Fabless

Ready for Design In, Ramping by end 2014

Early TTM version, fully enabled Enhanced - More performance, less power

Fully Qualified

Common Design Rules for fast migration

14LPE qualified in Feb2014 14LPE & 14LPP PDK Released MPW shuttles available Libraries and IPs Design Kits Ready Prototyping now, Mass production by end 2014

Recap of Today’s Announcement

A new strategic collaboration between Samsung and GLOBALFOUNDRIES Provides unprecedented global capacity for leadership 14nm FinFET technology Gives customers choice and assurance of supply that can only come from true design compatibility at multiple sources across the globe Addressing industry needs with a necessary advancement of the foundry supply chain model Covers both 14LPE and 14LPP, the leading choice for high-volume, power-efficient SoC designs
