Performance and capability
3 Gbps throughput 8 GB RAM, 16GB Flash IOS-XE & SD-WAN
Form factor and scalability
3RU and 19” depth 2x10G / 2 x 1G PoE 4xSM slots (3SW, 2DW, 2SW + 1DW) 3xNIM slots Power supply options: 1000W, 650W and 450W DC Support for redundant power supply
Front panel connectivity
USB storage, RJ45 console, Aux PoE support, MACSec support
USE CASE 1
BRANCH IN A BOX with Network, UC, Security, Compute and Storage all in
USE CASE 2
ENTERPRISE NFV Running 10+ VNFs
E-Series and NFVIS
USE CASE 3
EDGE COMPUTING With Cisco Kinetic IoT Gateway Modules
4
CONFIDENTIAL
5
CONFIDENTIAL
Up to 128 GB DRAM (4 DIMMs) DDR4-2400 Intel Xeon Broadwell D-1500 8 Core: 2.0 Ghz, 12 MB cache 12 Core: 1.5 GHz, 18 MB cache LSI MegaRAID SAS 3316 Supports RAID 0, 1, 5, 10, 128 MB cache & Supercap
Onboard eMMC 2 * 16 GB eMMC onboard storage in RAID 1, 8GB for CIMC and HIM & 8 GB for local OS installation
KVM dongle Dedicated CIMC Management port 2 x USB 3.0 port for external device connectivity Dual External 1/10G 4 Hard Drive Slots Up to 16TB SSD Storage
SITE 1 SITE 2 SITE 3 SITE n
HQ LOCATION DEPLOY MANAGE WITNESS
6
CONFIDENTIAL
7
CONFIDENTIAL
SvSAN License 2, 6, 12 and unlimited TBs License entitlement 2 mirrored servers Maintenance and support Platinum (24x7) and Gold (9x5)
8
