Robert L. Swaim

Systems Engineering National Resource Specialist

Robert L. Swaim

Systems Engineering National Resource Specialist FAA Workshop November 5, 2002

National Transportation Safety Board

TWA 800 & SW111 brought focus to electrical problems & vulnerabilities…

BACKGROUND

National Transportation Safety Board

B-747 Fuel Tank Arrangement

B-747 Fire/Explosions

• f 5/9/76

TWA 800 Explosions

• NO. 1 & 4 Reserve 500 US gallons
• NO. 1 & 4 Main

4,420 US gallons

• NO. 2 & 3 Main

12,240 US gallons Center Wing Tank 12,890 US gallons

Surge Tanks (2) Dry Bay Area (3)

National Transportation Safety Board

TWA800 ELECTRICAL INDICATIONS TWA800 ELECTRICAL INDICATIONS

CVR background noise drop-outs before explosion Fluctuating fuel flow indicator Cabin light write-ups (co-routed bundles) Fuel quantity write-ups (co-routed bundles)

Wiring continues from bundles into fuel tanks

National Transportation Safety Board

From the TWA 800 airplane: From the TWA 800 airplane:

• Damaged Wire Insulation

(Mechanical Damage & Cracks)

• Repairs & Metal Shavings Along Wire

Routes

• Repetitive Maintenance Write-ups

(Refueling, Cabin Lights, Galley Leaks)

National Transportation Safety Board

From TWA 800 maintenance, NTSB found: From TWA 800 maintenance, NTSB found:

• Improper hardware and practices used for a

wing tank compensator

• Open-ended Splices in Wet Areas
• Concentrations of Splices
• Totalizer Repair Bridged Connector Pins
• Tape-wrapped Splice From Wing Tank

National Transportation Safety Board

Teflon W rap Fiberglass Lacing B raid

Example of improper wire repair, as found in TWA 800 fuel tank.

National Transportation Safety Board

Structure from beneath floor of TWA800 had repairs over wire routes Structure from beneath floor of Structure from beneath floor of TWA800 had repairs over wire routes TWA800 had repairs over wire routes

Structural metal repair

National Transportation Safety Board

Drill shavings were found along wire routes in TWA800 wreckage Drill shavings were found along wire routes in TWA800 wreckage

National Transportation Safety Board

Which led to NTSB (then FAA & ATSRAC) inspections that found contamination & drill shavings in other airplanes Which led to NTSB (then FAA & ATSRAC) inspections that found contamination & drill shavings in other airplanes

Drill shavings and dirt in A300

National Transportation Safety Board

Shavings On Top Of Wires And Coming Through Bundle (747) Shavings On Top Of Wires And Coming Through Bundle (747)

National Transportation Safety Board

• Shavings Cut through some Wire Insulation
• Other Shavings were Shed by Insulation
• Shavings Could Transfer Energy

SHAVING IN WIRE BUNDLE

Problems that drill shavings can lead to: (NTSB Short Circuit Test results) Problems that drill shavings can lead to: (NTSB Short Circuit Test results)

National Transportation Safety Board

Such short circuits have caused:

• System Interuptions
• Misleading Displays
• Unintended Operations
• In-Flight Fires

767 Wire Damage at London 767 Wire Damage at London January 9, 1998 January 9, 1998

National Transportation Safety Board

…NTSB inspections also found..

Chafe between fuel gauge and galley power wires (747)

…NTSB inspections also found..

Chafe between fuel gauge and galley power wires (747)

National Transportation Safety Board

…NTSB inspections also found..

Lack of Production Illustration configuration control

…NTSB inspections also found..

Lack of Production Illustration configuration control

Wires Loose in Tray (747), rather than tied into separate bundles

National Transportation Safety Board

…NTSB inspections also found..

Lint in Circuit Breaker Panel (A300)

…NTSB inspections also found..

Lint in Circuit Breaker Panel (A300)

National Transportation Safety Board

Contamination may represent two sides

• f a fire triangle

Contamination may represent two sides

• f a fire triangle

Fuel Ignition Oxygen

National Transportation Safety Board

…NTSB inspections also found..

Non-Aircraft Hardware Near Wiring

…NTSB inspections also found..

Non-Aircraft Hardware Near Wiring

Dinner Knife Hardware

National Transportation Safety Board

…NTSB inspections also found..

Damaged wires that can not be visibly inspected

…NTSB inspections also found..

Damaged wires that can not be visibly inspected

HOLE WORN THROUGH PROTECTION (747)

National Transportation Safety Board

…NTSB inspections also found..

Fluid Contamination (747)

…NTSB inspections also found..

Fluid Contamination (747)

National Transportation Safety Board

Hydraulic Fluid In Connector (747) Hydraulic Fluid In Connector (747)

BOEING SERVICE LETTER 747-SL-20-048, DATED JANUARY 25, 1995 Damage To Rubber Grommet

National Transportation Safety Board

Lavatory Fluid Stains (737) Lavatory Fluid Stains (737)

Damaged Wire Sleeves

Blue Lavatory Fluid Stains

National Transportation Safety Board

NTSB sponsored wet-arc tests NTSB sponsored wet-arc tests

DRIP

Cut Wires In Bundle

LECTROMEC COMPANY PHOTOGRAPH

National Transportation Safety Board

Wet wires could arc without tripping circuit breakers for more than 20 minutes. Wet wires could arc without tripping circuit breakers for more than 20 minutes.

National Transportation Safety Board

PHOTO OF POLY-X WIRES AFTER 5 MINUTES OF WET-SHORT (WIRES FROM 1970-ERA 747)

Evidence of a Wet-short Evidence of a Wet-short

National Transportation Safety Board

…NTSB inspections also found..

Overheated Connector Pins (747)

…NTSB inspections also found..

Overheated Connector Pins (747)

National Transportation Safety Board

…NTSB inspections also found..

Degraded foam hanging from clamps (747)

…NTSB inspections also found..

Degraded foam hanging from clamps (747)

National Transportation Safety Board

…NTSB inspections also found..

That while most wires in a bundle might appear to be new, some insulation materials would crack and be difficult to find.

…NTSB inspections also found..

That while most wires in a bundle might appear to be new, some insulation materials would crack and be difficult to find.

Crack in aromatic polyimide insulation,

• REL. HUMIDITY

TEMPERATURE

60,000 HOURS

DATA FROM LECTROMECHANICAL DESIGN CO SHOWN FOR MIL-W-81381 (AROMATIC POLYIMIDE)

LIFE (HOURS)

Wire insulation may degrade with atmospheric exposure

National Transportation Safety Board

MIL-W-81381 (KAPTON) WIRE DEGRADATION DATA BY LECTROMECHANICAL DESIGN CO.

The rate of degradation will be different in various areas of the same airplane

National Transportation Safety Board

…NTSB inspections also found.. …NTSB inspections also found..

While most wires in a bundle might appear to be in new condition… …knicks, cuts, and other mechanical damage were found in almost every airplane inspected, regardless of age.

National Transportation Safety Board

Principal Causes of Wire Degradation,

per Boeing Service Letter 747-SL-20-048, January 25, 1995

Principal Causes of Wire Degradation,

per Boeing Service Letter 747-SL-20-048, January 25, 1995

• Vibration
• Maintenance (proper and improper)
• Indirect damage (damage resulting from events

not directly related to wiring, such as pneumatic duct ruptures)

• Chemical contamination
• Heat.

National Transportation Safety Board

…NTSB inspections also found..

In General

• No guidance on degradation beyond

physical damage criteria

• No requirements for periodically retesting

materials

• Wire insulation (Poly-X) aging problems

were documented in 1975, but the material is still acceptable for use.

National Transportation Safety Board

…NTSB inspections also found..

The Standard Wiring Practices Manual

…NTSB inspections also found..

The Standard Wiring Practices Manual

• Should contain acceptable materials and

practices,

• FAA stated that the guidance is too general,
• Bulky and difficult to extract data.

National Transportation Safety Board

NTSB stated that the FAA inadequately responded to NTSB recommendations

1998 Debris found

in NTSB-surveyed 747

1967

Debris in C/B panel

1991 Debris

in Delta L-1011

August 2000, TWA800 Board Meeting

National Transportation Safety Board

NTSB TWA 800 Finding #23

• f August 23, 2000, stated that:

NTSB TWA 800 Finding #23

• f August 23, 2000, stated that:

The condition of the wiring system in the accident airplane was not atypical for an airplane of its age, and the airplane was maintained in accordance with prevailing industry practices.

National Transportation Safety Board

Safety Recommendation A-00-108 Safety Recommendation A-00-108

Regardless of the scope of the ATSRAC’s eventual recommendations, address all of the issues identified in the Aging Transport Non-Structural Systems Plan...

August 2000, TWA800 Board Meeting

National Transportation Safety Board

The FAA issues (not initiatives) in ATNSSP to be addressed were: The FAA issues (not initiatives) in ATNSSP to be addressed were: Physical conditions, such as…

…deterioration of wiring components… …contamination… …metal shavings… …excessive dust and various fluids… …cracking of…insulation in some wire types… …ground terminal resistance… …corrosion on connector pins…

National Transportation Safety Board

…& Systemic Problems:

“Current maintenance practices do not adequately address wiring components” “…criteria is too general…details pertaining to unacceptable conditions are lacking…” “Airlines report shortcomings in manufacturer’s maintenance and repair manual on wire” “…Wire replacement criteria may be inadequate” “…improper installation and repair of wiring”

The FAA issues (not initiatives) to be addressed were: The FAA issues (not initiatives) to be addressed were:

National Transportation Safety Board

Industry (as the ATSRAC) inspected airplanes older than 20 years, documented similar conditions, then stated that: Industry (as the ATSRAC) inspected airplanes older than 20 years, documented similar conditions, then stated that:

“None were airworthiness concerns…”

National Transportation Safety Board

More than 30 AD’s did result, in which the FAA stated that “safety of flight” was affected and… Some items documented by NTSB & FAA inspections were not noted in the ATSRAC report, such as: More than 30 AD’s did result, in which the FAA stated that “safety of flight” was affected and… Some items documented by NTSB & FAA inspections were not noted in the ATSRAC report, such as:

Example: Chafe between fuel gauge and galley power wires (747)

National Transportation Safety Board

ATSRAC generally inspected airplanes older than 20

• years. Why inspect airplanes newer than 20 years?

ATSRAC generally inspected airplanes older than 20

• years. Why inspect airplanes newer than 20 years?

Thai 737 fuel tank explosion/fire at Bangkok, March 3, 2001

Photo from Reuters

National Transportation Safety Board

While 20 years was selected as a starting point by ATSRAC, wire samples from the <11 year-old Thai 737 exhibited: While 20 years was selected as a starting point by ATSRAC, wire samples from the <11 year-old Thai 737 exhibited:

Numerous sites of mechanical damage. Displaced insulation & possible wire-wire abrasion. Cracks in aromatic polyimide insulation, Intact portions of non-polyimides generally passed tests.

National Transportation Safety Board

ATSRAC is developing recommendations for FAA: ATSRAC is developing recommendations for FAA:

As an exemplar issue, the FAA ATNSSP cited “…improper installation and repair of wiring.” The FAA established the ATSRAC, which created WG 8 to address training. A sample syllabus was developed. ATSRAC recommended that training be left to operators. Currently, FAA considering what and how to implement.

National Transportation Safety Board

The FAA EAPAS plan has six topics: The FAA EAPAS plan has six topics:

• Training
• Maintenance
• Design
• Research and Development
• Wire Reporting
• Information Sharing and Outreach

National Transportation Safety Board

Through EAPAS, the FAA does have… Through EAPAS, the FAA does have…

Established research in issue areas, Plans for inspection of airplanes newer than 20 years of age. Rulemaking in progress,but no action to-date

National Transportation Safety Board

Through incidents and sister-ships, investigations inspect a

cross-section of the fleet:

As-is, In-service, Various operators, Various types, Various countries

Through incidents and sister-ships, investigations inspect a

cross-section of the fleet:

As-is, In-service, Various operators, Various types, Various countries

Bashkirian TU-154M sister-ship, Freiderichshafen, Germany, July 2002

National Transportation Safety Board

Providing NTSB with regular wire exams.

Example: Aft lav harness from Dalian, China, MD-82, May 7, 2002

LABORATORIES USED INCLUDE: NTSB Materials Lab, AFRL, NASA Huntsville, Raytheon Indianapolis, Manufacturer labs, Contract labs

• 1. Find, recover,

& identify wreckage

• 2. Examine at site
• 3. Submit samples

National Transportation Safety Board

December 2001, and 10 days out of C-check: February 2002

Over 66 months (~5½ years) since TWA800 64 months since TWA800

Photos show lint & dirt at 737 rudder pedals seen in two airplanes since NTSB TWA800 Finding #25 Photos show lint & dirt at 737 rudder pedals seen in two airplanes since NTSB TWA800 Finding #25

The bottom line is that

no changes have been seen in recent investigations…

National Transportation Safety Board

Nov 2000, turn-back at ATL when fire from area of wire bundle burned through

• skin. Evidence of lavatory fluid found in bundle and connectors.

…and final FAA action is not complete. Rulemaking will need implemention time... …and final FAA action is not complete. Rulemaking will need implemention time... …while in-flight problems continue.

National Transportation Safety Board

The initiatives called for by the 1998 FAA ATNSSP plan were to be in place by October 2000 (with one exception). Current EAPAS end-dates discussed are in 2017.

Estimated Completion: Estimated Completion:

National Transportation Safety Board

The FAA already has regulations, AC’s, and Handbook items that apply to cracked insulation, wear, contamination, and similar issues. The FAA already has regulations, AC’s, and Handbook items that apply to cracked insulation, wear, contamination, and similar issues. The FAA can take action NOW

National Transportation Safety Board

You don’t have to wait You don’t have to wait

Most operators already have cleanliness (motherhood) statements to refer to. The airplanes are designed and built to standards that have an approval. Wire insulation cracks and other damage typically do not meet manufacturer or FAA approved standards that already can be cited (refer to SWPM).

National Transportation Safety Board

THREE SUMMARY POINTS THREE SUMMARY POINTS

• 1. Conditions found to create previous

electrical problems continue to exist.

• FAA has plans to address the issues.
• FAA research has had positive results.
• FAA rulemaking & implementation yet unseen.
• 2. Basic assumptions need to be

continually revisited.

• Example: Electrical systems damage exists in

airplanes of less than 20 years age.

3.Action can be taken NOW.
