Riverview Heights Darren K. Howard Structural Option Architectural Engineering Spring Thesis 2005 Advisor: Dr. Ali Memari Riverview Heights Darren K. Howard Structural Option Table of Contents: 1.0 Project Background 2.0 Problem

slide-1
SLIDE 1

Riverview Heights

Darren K. Howard Structural Option Architectural Engineering Spring Thesis 2005 Advisor: Dr. Ali Memari

slide-2
SLIDE 2

Riverview Heights

Darren K. Howard Structural Option

1.0 Project Background 2.0 Problem Statement 3.0 Solution Overview 4.0 Structural Redesign 5.0 Mechanical Issues 6.0 Acoustical Issues 7.0 Cost Estimates 8.0 Conclusions and Recommendations Acknowledgements Questions

Table of Contents:

slide-3
SLIDE 3

Riverview Heights

Darren K. Howard Structural Option

1.0 PROJECT BACKGROUND

slide-4
SLIDE 4

Riverview Heights

Darren K. Howard Structural Option 1.0 Project Background:

  • Conshohocken, Pennsylvania
  • 4 apartment levels
  • 2 levels of partially underground parking
slide-5
SLIDE 5

Riverview Heights

Darren K. Howard Structural Option 1.1 Apartment Structural Systems:

  • Bearing Walls: Wood stud walls
  • Floor: 20” deep, floor trusses
  • Lateral System: Wood Panel Shear Walls
slide-6
SLIDE 6

Riverview Heights

Darren K. Howard Structural Option 1.1 Parking Structural Systems:

  • Elevated Two-Way concrete slab with drop panels
  • Top slab is a 11” thick “transfer slab”
  • “Transfer slab” picks up random bearing wall loads
  • Concrete columns send loads to spread footings
slide-7
SLIDE 7

Riverview Heights

Darren K. Howard Structural Option

2.0 PROBLEM STATEMENT

slide-8
SLIDE 8

Riverview Heights

Darren K. Howard Structural Option 2.0 Problem Statement

  • Lumber is a renewable, but not unlimited resource
  • New building materials will eventually become necessary
  • Alternative materials and methods must be found
slide-9
SLIDE 9

Riverview Heights

Darren K. Howard Structural Option

3.0 SOLUTION OVERVIEW

slide-10
SLIDE 10

Riverview Heights

Darren K. Howard Structural Option 3.0 Solution Overview

  • Cold-formed steel buildings are growing in popularity
  • Recyclable material
  • Not susceptible to termite damage
  • Will not burn or harbor mold
  • Will not rot, shrink, warp or split
  • Prices for cold-formed steel have been more stable than

lumber

  • Construction methods are very similar to wood framing
slide-11
SLIDE 11

Riverview Heights

Darren K. Howard Structural Option

4.0 STRUCTURAL REDESIGN

slide-12
SLIDE 12

Riverview Heights

Darren K. Howard Structural Option 4.0 Structural Redesign

  • Replace existing bearing walls with cold-formed studs
  • Replace wood floor trusses with cold-formed joists
  • Investigate the use of possible lateral systems:

Wood panel shear walls over cold-formed studs Lateral strap bracing

slide-13
SLIDE 13

Riverview Heights

Darren K. Howard Structural Option

4.1 BEARING WALLS

slide-14
SLIDE 14

Riverview Heights

Darren K. Howard Structural Option 4.1 Bearing Wall Redesign

  • Existing bearing walls and unit separation walls:
slide-15
SLIDE 15

Riverview Heights

Darren K. Howard Structural Option 4.1 Bearing Wall Redesign

  • Design Considerations:

Replace existing unit separation walls with a single cold-formed stud wall Set studs at a spacing of 24” o.c. rather than 16” o.c.

slide-16
SLIDE 16

Riverview Heights

Darren K. Howard Structural Option 4.1 Bearing Wall Redesign

  • Redesigned Walls:

Unit separation walls: 6” wide studs @ 24” o.c. Interior bearing walls: 3-5/8” studs @ 24” o.c. Gauge of stud varies from floor to floor

slide-17
SLIDE 17

Riverview Heights

Darren K. Howard Structural Option 4.1 Bearing Wall Redesign 11.51 8-11 6SW-12@24” 1 11.51 6-8 6SW-12@24” 2 7.56 5.3-6.6 6SW-14@24” 3 5.73 3.2-4.4 6SW-16 @24” 4 Allowable (kips) Load (kips) Stud Floor Unit Separation Walls

slide-18
SLIDE 18

Riverview Heights

Darren K. Howard Structural Option 4.1 Bearing Wall Redesign

7.32 5-6 358SW-12@24” 1 5.12 4-4.48 358SW-14@24” 2 4.05 3-3.6 358SW-16@24” 3 2.75 2-2.4 358SW-18 @24” 4

Allowable (kips) Load (kips) Stud Floor Interior Unit Bearing Walls

slide-19
SLIDE 19

Riverview Heights

Darren K. Howard Structural Option

4.2 FLOOR SYSTEM

slide-20
SLIDE 20

Riverview Heights

Darren K. Howard Structural Option 4.2 Floor System Redesign

  • Existing Floor: 16’ to 25’ interior spans
slide-21
SLIDE 21

Riverview Heights

Darren K. Howard Structural Option 4.2 Floor System Redesign

  • Design considerations:

Cold-formed steel joists should require less depth This will add additional floor-to-floor height in units

slide-22
SLIDE 22

Riverview Heights

Darren K. Howard Structural Option 4.2 Floor System Redesign

  • Redesigned Joists: 14j10 Marino/Ware Joists

14” deep, 10 gauge joists @ 24” o.c. Allowable p.l.f. = 130 p.l.f. ( δ < L/360) An additional 6” of floor-to-floor height is achieved

slide-23
SLIDE 23

Riverview Heights

Darren K. Howard Structural Option

4.3 LATERAL RESISTANCE

slide-24
SLIDE 24

Riverview Heights

Darren K. Howard Structural Option 4.3 Lateral System Redesign

  • Existing Lateral System: Wood Shear Panel Walls
slide-25
SLIDE 25

Riverview Heights

Darren K. Howard Structural Option 4.3 Lateral System Redesign

  • Design Considerations:
slide-26
SLIDE 26

Riverview Heights

Darren K. Howard Structural Option 4.3.1 Lateral System Redesign

  • Alternative #1: Wood shear panels over cold-formed studs

Greater strength = fewer shear walls required

36 36 1 33 36 2 25 36 3 22 36 4 CF Steel Wood Floor # of Shear Walls Required

slide-27
SLIDE 27

Riverview Heights

Darren K. Howard Structural Option 4.3.2 Lateral System Redesign

  • Alternative #2: Lateral Strap Bracing
slide-28
SLIDE 28

Riverview Heights

Darren K. Howard Structural Option 4.3.2 Lateral System Redesign

  • Alternative #2: Lateral Strap Bracing
  • STAAD frame model of tension braces
slide-29
SLIDE 29

Riverview Heights

Darren K. Howard Structural Option 4.3.2 Lateral System Redesign 7.14 4” x 18ga (both sides) 1 7.14 4” x 18ga (both sides) 2 3.56 2” x 18ga (both sides) 3 3.56 2” x 18ga (both sides) 4 Allowable Load (kips) Lateral Strap Sizes Floor

slide-30
SLIDE 30

Riverview Heights

Darren K. Howard Structural Option

5.0 MECHANICAL

slide-31
SLIDE 31

Riverview Heights

Darren K. Howard Structural Option 5.0 Mechanical Issue

  • Major disadvantage of cold-formed steel

Thermal conductivity

HOT COLD

slide-32
SLIDE 32

Riverview Heights

Darren K. Howard Structural Option 5.0 Mechanical Issue

  • Add a thermal break between the exterior and interior space
  • An additional layer of 1” rigid insulation must be installed
slide-33
SLIDE 33

Riverview Heights

Darren K. Howard Structural Option 5.0 Mechanical Issue

10.2 13.3

CF Wall (thermal break)

3 ½” steel studs, 24” o.c., R-11 batts, ½” ext. plywood, ½” int. gypsum, 1” rigid insulation over ext. plywood

7.1 9.4

CF Wall (no thermal break)

3 ½” steel studs, 24” o.c., R-11 batts, ½” ext. plywood, ½” int. gypsum

9.6 10.6

Existing Wall:

2x4 Studs, 16” o.c., R-11 batts, ½”

  • ext. plywood, ½” int. gypsum

Whole-Wall R-Value Clear-Wall R-Value Wall Assembly

slide-34
SLIDE 34

Riverview Heights

Darren K. Howard Structural Option

6.0 ACOUSTICS

slide-35
SLIDE 35

Riverview Heights

Darren K. Howard Structural Option 6.0 Acoustics

  • Cold-formed studs have lower acoustical properties
  • Riverview Heights was designed as an “average” site
  • Unit separation walls and floors need to meet an STC

rating of 52

slide-36
SLIDE 36

Riverview Heights

Darren K. Howard Structural Option 6.0 Acoustics

  • An additional 5/8” of gypsum is required on both sides
  • f walls to meet acoustical requirements
  • Existing wood floor trusses and the redesigned joists

required resilient channels on the ceiling side

slide-37
SLIDE 37

Riverview Heights

Darren K. Howard Structural Option 6.0 Acoustics 57 Existing Floor 56 CF Floor Assembly 53 Existing Walls 57 CF Unit Separation Walls and Corridor Walls STC rating System

slide-38
SLIDE 38

Riverview Heights

Darren K. Howard Structural Option

7.0 COST ESTIMATES

slide-39
SLIDE 39

Riverview Heights

Darren K. Howard Structural Option 7.0 Cost Estimates Estimate of Wood Framing $780,340.20 Total Cost $241, 647.00 Floor Trusses $553, 316.40 2x4 Stud Walls $70,502.40 Wood Panel Shear Walls Cost System

slide-40
SLIDE 40

Riverview Heights

Darren K. Howard Structural Option 7.0 Cost Estimates Estimate of Cold-Formed Framing $1,146,830.20 Total with Either Lateral System $383,875.92 Cold-formed Stud Walls $710,955 Cold-formed Joists $51,984.00 Lateral Strap Bracing $52,387.20 Wood Panel Shear Walls Cost System

slide-41
SLIDE 41

Riverview Heights

Darren K. Howard Structural Option 7.0 Cost Estimates Cold-Formed Framing Additional Costs $1,227,538.60 Total Cold-Formed Cost $80,707.68 Total $53.707.68 Additional layer of 5/8” drywall on walls $27,000 1” rigid insulation Cost System

slide-42
SLIDE 42

Riverview Heights

Darren K. Howard Structural Option 7.0 Cost Estimates Total Costs

  • $447,198.40

Difference in cost $1,227,538.60 Cold-Formed Framing $780,340.20 Wood Framing Cost System CF joists are more than twice the cost of wood floor trusses!!

slide-43
SLIDE 43

Riverview Heights

Darren K. Howard Structural Option 7.0 Cost Estimates Total Costs without Floor Systems + $22,109.60 Difference in Cost $516,583.60 Cold-Formed Framing minus Floor System $538,693.20 Wood Framing minus Floor System Cost System

slide-44
SLIDE 44

Riverview Heights

Darren K. Howard Structural Option

CONCLUSIONS AND RECOMMENDATIONS

slide-45
SLIDE 45

Riverview Heights

Darren K. Howard Structural Option 8.0 Conclusions and Recommendations

  • Cold-formed framing is a viable solution if the redesigned

floor framing is not included

  • Cost of the cold-formed floor framing was more than twice

the cost of wood trusses

  • Cold-formed framing used less material in walls and in

lateral systems

  • Using less material translated into lower costs
  • Promising conclusion as the need for alternative building

materials becomes greater in the next century

slide-46
SLIDE 46

Riverview Heights

Darren K. Howard Structural Option Acknowledgements

  • My family and friends
  • A.E. faculty
  • Staff of Cates Engineering
  • Trammel Crow Residential
  • Minno & Wasko Architects
  • Marino/Ware
  • Images courtesy of Marino/Ware, Cates Engineering, and

Minno & Wasko Architects

slide-47
SLIDE 47

Riverview Heights

Darren K. Howard Structural Option Questions?
