Retrofitting SuDS

Virginia Stovin Department of Civil and Structural Engineering Pennine Water Group University of Sheffield

Outline

• Urban stormwater management

– Conventional approach, problems and costs

• Sustainable (urban) Drainage Systems (SuDS)
• Retrofit SuDS – theory and practice
• Green roofs – an underutilised source control
• Conclusions

2

Urban Stormwater Management

UK Sewer System – increased urbanisation

System capacity

Sewer flow Time Surface runoff Industrial discharges Sanitary sewage Treatment works River

Combined Sewer System

Rainfall

Combined sewer overflow (CSO)

3 Combined Sewer Overflows (CSOs)

‘Traditional’ Engineering Solution

Sanitary sewage Surface runoff Industrial discharges Treatment works River Storage tank

4 Indicative Investment in Conventional CSO Rehabilitation

• 5 year investment programme

worth nearly £1.5 billion.

• £39 million to resolve sewer

flooding at 386 properties and to resolve outdoor flooding at 88 locations.

• Around 95 of Sheffield's CSOs

upgraded at a cost of £30 million.

• Concrete storage chambers in

four of Sheffield’s public parks, each probably costing in the

• rder of £1 million.

Thames Tideway Strategic Study

• 7.2 m diameter storage and transfer tunnel, new STW
• 34.5 km long, £1.5 billion

5

Limitations of conventional approach

• Financial costs
• Hard engineering
• Increased volumes of (diluted) sewage passed on to

treatment works – waste of resources treating rainwater

• Storage tanks and screens require maintenance
• Treats stormwater as a nuisance rather than a resource
• Not future proof

Sustainable (urban) Drainage Systems (SuDS)

6

SuDS = Sustainable (urban) Drainage Systems

• SuDS (or source control)

technologies attempt to ‘solve’ the problem by mimicking nature

– Infiltrate stormwater into ground – Store water for gradual release, evaporation or use

• Toolbox of technologies
• Quantity, quality, amenity
• Developers ‘strongly

encouraged’ to use SuDS on new developments

Retrofit SuDS

• Retrofit → when SuDS approaches are intended to

replace and/or augment an existing drainage system in a developed catchment.

• Examples of retrofit SuDS:

– the diversion of roof drainage from a combined sewer system into a garden soakaway – the conveyance of road runoff via roadside swales into a pond sited in an area of open space – Installation of green roofs

7

Augustenborg, Malmö, Sweden

• Inner-city suburb in Malmö, CSO and flooding problems
• In 2001 Augustenborg was disconnected from the existing

combined sewer and drained by means of an open stormwater

• system. Stormwater is now led through a complex arrangement of

green roofs, swales, channels, ponds and small wetlands.

8

Gipton, Leeds (1 of 4 sub-catchments)

• Contributory surface area: 80

ha

• Residential area (largely

semi-detached housing and some institutional buildings)

• North of catchment underlain

by millstone grit (high permeability)

• South of catchment underlain

by mudstone (low permeability)

• CSO discharges in very

accessible public area

Which (retrofit) SuDS technology?

• Infiltration-based components are designed primarily to dispose
• f the water into the ground

– complete removal from the stormwater drainage system – require permeable substrate (not clay)

• Storage-based components retain a portion of the flow, but

have a finite capacity; once capacity is reached they will pass flows into the stormwater drainage system

• Some SuDS components (e.g. swales incorporating

checkdams) may provide both; many SuDS systems offer a combination of both by integrating a range of structures into an

• verall scheme.
• Water quality – The use of a range of structures, forming a

treatment train, has significant advantages for water quality.

9

Surface Water Management Train

Source control Regional control Site control Conveyance Conveyance Discharge to watercourse

• r groundwater

Discharge to watercourse

• r groundwater

Discharge to watercourse

• r groundwater

UK Examples – Gipton, Leeds

To land drains Soakaway/Infiltrati

• n

Swales

10

Cost/Performance comparison

20000 40000 60000 80000 100000 120000 500 1000 1500 2000 2500 3000 Construction costs (£1,000s) Predicted annual CSO spill Volume (m 3) Existing New CSO SUDS 100/100 SUDS 100/50 SUDS 80/100 SUDS 80/50 SUDS 60/100 SUDS 60/50 SUDS 40/100 SUDS 40/50 SUDS 20/100 SUDS 20/50

Designing retrofit SuDS

• What should I disconnect (houses, roads, hospitals)?
• How will that affect my system hydraulics?
• Should I infiltrate or dispose or store or re-use?
• Which technology best suits my situation?
• What catchment data should I collect?
• Shall I develop a regional scheme with conveyance or is

it always best to deal with rainfall at source?

• Will property owners accept my suggestions?
• Who will maintain the scheme (adoption issues)?
• How much will is cost?

11

Conceptual Basis

Urban surface type Surface water management train Mode of

• peration

Cost Institutional roofs Car parks Residential roofs Highways Source control Conveyance and

• ffsite control

Infiltration Disposal Storage Re-use Cheapest Most expensive Increasing complexity (in terms of detailed design work required) Decreasing

• rder of

preference

Are INSTITUTIONAL ROOFS connected to combined system?

1. Suitable soil percolation rate (>4.63 x 10-6 m/s) 2. Groundwater contamination risk 3. Water table level 4. Space for construction 5. Building regulations 6. Responsibility/maintenance/safety 1. Adjacent watercourse 2. Discharge consents 1. Space for construction 2. Water table level 3. Overflow

Denotes £0-500 per device, based on a 200m2 contributory surface Details of relevant design guidance Basins

• Soakaways
• Ponds

+

• Infilt. Trenches
• Porous Pavements

+ Redirect to watercourse Basins

• Ponds

+ Porous Pavements + Reuse +

Infiltration SuDS Disposal SuDS Storage SuDS Reuse SuDS

Do these measures resolve the catchment’s hydraulic problems? STOP yes Continue through framework: (Conveyance, Site/Regional controls, Car-parks, residential roofs, roads) no

Explore viability of SOURCE CONTROL SuDS

yes

12

The Meanwood Catchment

• 4 km NW of Leeds City Centre
• 55.8 ha

Parkside Road Tongue Lane West Lea King Alfred’s Parklands Meanwood Road Stonegate Road Trunk sewer Location of flooding

13

Application of the framework

Urban surface type Surface water management train Mode of

• peration

Cost Increasing complexity (in terms of detailed design work required) Decreasing

• rder of

preference Institutional roofs Car parks Residential roofs Highways Source control Conveyance and

• ffsite control

Infiltration Disposal Storage Re-use Cheapest Most expensive Viable region for infiltration-based retrofit source control SuDS (3.022 ha of residential roofs) Region initially allocated to storage- based retrofit source control SuDS (4.348 ha of residential roofs)

14

Application of the framework

Urban surface type Surface water management train Mode of

• peration

Cost Increasing complexity (in terms of detailed design work required) Decreasing

• rder of

preference Institutional roofs Car parks Residential roofs Highways Source control Conveyance and

• ffsite control

Infiltration Disposal Storage Re-use Cheapest Most expensive Potential swale and off-site infiltration basin network 0.375 ha residential roof area to off-site infiltration in preference to source-based storage

15

Proposal

• Disconnect 3.022 ha of residential roofs using

soakaways

• Disconnect 0.375 ha of residential roofs and 2.886 ha of

paved area using swales-based off-site controls (infiltration basins)

• (46% of roofed area; 31% of paved area)
• Retrofit water butts to remaining 3.973 ha roofed area
• 68% reduction in the ten year design storm flood volume;

need to be coupled with reduced level of conventional sewer rehabilitation (hybrid solution)

UK Retrofit SuDS Implementation Case Studies

• Cromer, North Norfolk
• Storm sewer flooding
• Water-stressed area
• Good infiltration

characteristics

• Obvious retrofit
• pportunities
• Not supported by

current water industry funding structures or legislation

16

SNIFFER Project – Caw Burn

Culvert drains to Burn, Adverse impacts on water quality

SNIFFER – Phase I: Feasibility Assessment

17

SNIFFER – Phase II: Detailed Design

Large roofs* Car parks Residential roofs Privately

• owned

Source control Conveyance and

• ffsite control

Large roofs* Car parks Highways* Publicly-

• wned

Retention at source: green roofs and porous car parks Infiltration Disposal Storage Reuse Site/regional controls Separately sewered system or branch Decreasing practicality of implementation

Mode of

• peration

Surface water management train Urban Surface Type

*Water quality improvements may be maximised by disconnecting industrial/commercial roofs and/or highways; however adequate protection against local contamination needs to be ensured in the design of SUDS options

But how would this type of retrofit be funded?

18

Barriers to SuDS retrofitting

• Practical problems

– Existing site layouts and infrastructure, particularly in high density urban environments – Multiple ownership

• Legislation and the way the water industry is structured

in the UK acts against water utilities, environmental regulators and local authorities working collaboratively with this type of approach

– Driver/incentive/funding mechanism

• DEFRA pilot projects starting to tackle this

– Salford/Lower Irwell IUD Pilot

• Single-owner roof space

19

Green Roofs Green Roofs

20

Green roof hydrology

21

22

23 UK Example of Retrofit Green Roof – Ethelred Housing Estate, Lambeth

• Estate considered for demolition in the early 1990s
• Tenant Management Organisation opposed demolition
• Various refurbishment works required – including

roofing repairs

• Tenants proposed green roof
• 6000 m2 – largest green roof retrofit in Europe

24

Impact of Green Roof Legislation in Linz International Indicators of Performance

• How should I design my green roof to retain the first 12 mm of a 1

in 10 year rainfall event?

• What costs saving in sewer storage implementation would be

achieved if 50% of office buildings in Sheffield were retrofitted with green roofs?

• Test facilities – roof configuration variables and planting
• Instrumented full scale roofs
• Annual retention of 45-70% rainfall volume
• Peak runoff reduction of up to 100%
• Variations between storm events and between locations
• How relevant are these indicators in a UK climatic context?

Modelling/design questions

25

Quantifying Performance

• Roof configuration variables

– Slope – Drainage layer characteristics – Substrate type and depth – Plant type

• Climatic variation

– Annual rainfall – Predominant rainfall characteristics

• Links between the two –

plant growth and health

• Need for local data and for

appropriate engineering modelling and design tools

Green Roof test rig

26

0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 14-02-06 22-00 14-02-06 23-00 15-02-06 00-00 15-02-06 01-00 15-02-06 02-00 15-02-06 03-00 15-02-06 04-00 15-02-06 05-00 15-02-06 06-00 15-02-06 07-00 15-02-06 08-00 15-02-06 09-00 15-02-06 10-00 Rainfall (mm) 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 0.20 Runoff (mm)

• 9.2 mm rainfall
• 3.55 mm runoff
• 61% retention
• 61% peak reduction
• Significant attenuation

Monitored data for Spring 2006

• Average volume

retention 34%

• Average peak

reduction 56.9%

Scientific data Engineering models and design tools Implementation?

Conclusions

• Retrofit SuDS may offer a practical option for addressing

current problems associated with stormwater quantity and quality in urban areas

• Range of design options potentially there to be matched

to constraints of existing land uses and layouts

• Decision-support framework assists with identifying most

appropriate options

• Green Roofs merit further consideration and research
• Usefulness of modelling tools – integrated models

required for urban flooding problems

• Implementation/adoption issues
