Responsible sourcing: Views from Mars and the chalk face. Mike - - PowerPoint PPT Presentation

Sep 15, 2022 289 likes •689 views

Responsible sourcing: Views from Mars and the chalk face. Mike Berners-Lee An Associate Company of Lancaster University Very quick background Books A sustainability consultancy largely focussed largely on supply chains BT, Booths, Taylor

slide-1
SLIDE 1

Responsible sourcing:

Views from Mars and the chalk face.

Mike Berners-Lee

An Associate Company of Lancaster University

slide-2
SLIDE 2

Very quick background

A sustainability consultancy largely focussed largely on supply chains BT, Booths, Taylor Wimpey, lots of SMEs in many industries, public sector, Lancaster University, Eden Project, Science Museum, Guardian, community projects ... Books Research

slide-3
SLIDE 3

Types of impact

Direct Indirect

slide-4
SLIDE 4

If those products could talk ….

We’ve got a history We want a long lives We want to be looked after We want to be ‘net good’

We don’t want to be buried alive

We want an after life

slide-5
SLIDE 5

Most supply chains are complex and

  • paque

Our understanding can never be exact but it can be ‘good enough’

slide-6
SLIDE 6

Bringing transparency to supply chains

Meat sales up 30% during the horsemeat scandal

slide-7
SLIDE 7

UK government increasingly understands embedded impacts

slide-8
SLIDE 8

We need an up to date understanding of what ‘responsible’ looks like

slide-9
SLIDE 9
slide-10
SLIDE 10

An Exponential curve

slide-11
SLIDE 11

Carbon emissions since 1850

slide-12
SLIDE 12

Carbon emissions since 1850

slide-13
SLIDE 13

No encouraging signs from the last few years

slide-14
SLIDE 14

Efficiency is part of the growth dynamic

slide-15
SLIDE 15

50% chance of <2oC – peaking in 2020

slide-16
SLIDE 16

Responsibility entails mapping the issues and priorities

slide-17
SLIDE 17

We need a carbon instinct like we have a money instinct

slide-18
SLIDE 18

Mapping the Greenhouse gas impacts

  • f supermarket products
  • The Mapa Mundi for Booths
  • Covers the whole range
  • Enables GHG emissions to be

factored into marketing and sourcing decisions

  • Full reports are

publically available.

  • Results and models are now used by

universities and think tanks for research.

  • Affordable

0.000 0.500 1.000 1.500 2.000 2.500 3.000 3.500 (2) BEER AND CIDER Potatoes Tomatoes Green salads Prepared Veg., fruit & salad Exotic veg and mushrooms Apples & Pears Bananas Citrus and melons Exotic fruit and berries (including soft,… (67) FLORISTRY (84) CABINETS COOKED MEATS Cabinets Milk Ready meals, pizza & pasta Sandwiches (52) BREAD (70) FROZEN FOODS kgCO2e Source ingredients to farm / factory gate Food processing Total consumer packaging footprint Transit packaging Transport Emissions to DC Transport emissions from all DCs to Stores Storage and processing at DC Overhead (exc. refrigeration) Refrigeration

slide-19
SLIDE 19

Typical UK Person: 15 tonnes per year

slide-20
SLIDE 20

Hong Kong return: 4.6 tonnes

Low 3.4 tonnes High 13.4 tonnes Average 4.6 tonnes Economy First class

slide-21
SLIDE 21

Drying your hands: 10g

Low 0 g 20g typical hand drier Average 10 g Let them drip Paper towels

slide-22
SLIDE 22

Laptop: 400Kg embodied

Low ~100Kg High ~1 tonne Average 400 Kg 2010 21.5 inch iMac A simple low cost laptop

slide-23
SLIDE 23

Laptop: ~50g / hour operational

12g 150g 63 Kg Old desktop Energy efficient laptop Power hungry iMac or similar

slide-24
SLIDE 24

Data Centres

2010: 130 million tonnes CO2e Prediction for 2020: 250 – 340 million tonnes CO2e

slide-25
SLIDE 25
slide-26
SLIDE 26

Mapping supply chain impacts

slide-27
SLIDE 27

Process Based Life Cycle Analysis

slide-28
SLIDE 28

0.0% 10.0% 20.0% 30.0% 40.0% 50.0% 60.0% 70.0% 80.0% 90.0% 100.0% Direct Tier 1 Tier 2 Tier 3 Tier 4

Percentage of emissions captured with cumulative tiers of the supply chain.

Agriculture Metal ores extraction Plastic products Non-ferrous metals Motor vehicles Telecommunications

slide-29
SLIDE 29

PAS 2050 – Review of methods

“Experts highlighted particularly two weaknesses of PLCA: cost and labour intensity of carrying out a PLCA and the system boundary problem … “system cut-off” is unavoidable in PLCA …The cut-off criteria suggested by ISO can be misleading and do not provide a satisfactory basis for a transparent system boundary selection…. The (resulting) truncation error is potentially very large. …” “…This is further aggravated when restrictions are imposed on the budget as typical in simplified PLCA approaches. Such simplified approaches usually fail to reliably reproduce results from detailed PLCA . However, only simplified PLCAs work under tight budget constraints required for the PAS to be applicable to organisations of all sizes. This seriously limits the usefulness of PLCA for the PAS development.”

slide-30
SLIDE 30

Input Output Analysis

Looks at the whole economy divided into industry sectors.

slide-31
SLIDE 31

Input Output Analysis

Demand for products stimulates output across the economy….

slide-32
SLIDE 32

Input Output Analysis

…. causing both direct and indirect emissions…

slide-33
SLIDE 33

Input Output Analysis

…. the ripple effects are endless…

slide-34
SLIDE 34

Input Output Analysis

…without systematic underestimation …. the ripple effects are endless… but can be modelled as a complete system…

slide-35
SLIDE 35

A hybrid methodology is usually the most practical way to get a reasonable understanding

+

slide-36
SLIDE 36

Summary questions

  • What does responsible look like in 2013?
  • How can standards ensure the real priorities

are addressed – within a finite resource?

  • How can standards work for small players?
  • How can supply chains become transparent
  • How can standards be greenwash proof?
slide-37
SLIDE 37

Thank you for listening

Any questions?

Mike Berners-Lee

mike@sw-consulting.co.uk

An Associate Company of Lancaster University
