By: Dr. Foadoddini Department of Physiology & Pharmacology Birjand University of Medical Sciences Body fluids and Renal physiology 25 Volume and Osmolality of Extracellular and Intracellular Fluids in Abnormal States Pc Edema C Kf

slide-1
SLIDE 1

Body fluids and

Renal physiology

By: Dr. Foadoddini

Department of Physiology & Pharmacology Birjand University of Medical Sciences

slide-2
SLIDE 2

25

slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10

Volume and Osmolality of Extracellular and Intracellular Fluids in Abnormal States

slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13

Fluids in the "Potential Spaces" of the Body

Edema

Pc Kf πC

slide-14
SLIDE 14
slide-15
SLIDE 15

Safety factor

Low compliance in IF 3 mmHg "Washdown“

  • f IF Protein

7mmHg Lymph Flow 7mmHg Safety Factors That Normally Prevent Edema

slide-16
SLIDE 16

26

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20

Blood Supply to the Kidneys

  • Blood travels from afferent arteriole to capillaries in the nephron called glomerulus
  • Blood leaves the nephron via the efferent arteriole
  • Blood travels from efferent arteriole to peritubular capillaries and vasa recta
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25

Internal Anatomy

slide-26
SLIDE 26
  • Blood is filtered in

the nephrons

  • The cortex of each

kidney contains ± 1,2 million nephrons

  • The nephron

consists of a renal corpuscle and a renal tubule

  • The renal tubule

consists of the convoluted tubule and the loop of Henle

  • The main filter of the

nephron is glomerulus which is located within the Bowman's capsule

Function of the Kidney

  • Terminology
slide-27
SLIDE 27

Micturation

slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

Bowman’s capsules - with glomerulus

slide-32
SLIDE 32

The filtration barrier - podocytes

fenestrated endothelium fenestrated endothelium primary process podocyte cell body secondary process (pedicel) filtration slit basal lamina podocyte pedicel filtration slit basal lamina

slide-33
SLIDE 33

Detailed structure of the filtration system

Capillary Capillary Basement membrane Basement membrane Fenestrations Fenestrations Podocyte process Capillary BM Endoth cell nucleus Endoth cell nucleus E F

slide-34
SLIDE 34

The filtration barrier - pedicels Bowman’s space capillary

pedicel filtration slit

slide-35
SLIDE 35

Control of Kf

  • Mesangial cells have contractile properties, influence capillary

filtration by closing some of the capillaries – effects surface area

  • Podocytes change size of filtration slits
slide-36
SLIDE 36

GLOMERULAR FILTRATION

The first step in the formation of urine is the production of a plasma ultrafiltrate. The ultrafiltrate is cell and protein-free and the concentration of small solutes are

the same as in plasma.

The filtration barrier restricts movement of solutes on a basis of size and charge.

Molecules < 1.8 nm freely filtered; >3.6 nm not filtered Cations are more readily filtered than anions for the same molecular radius. Serum albumin has a radius if about 3.5 nm but its negative charge prevents its filtration In many disease processes the negative charge on the filtration barrier is lost so that proteins are more readily filtered - a condition called proteinuria The glomerular filtration rate (GFR) is about 125 ml/min in a normal adult

slide-37
SLIDE 37
slide-38
SLIDE 38

10mmHg

slide-39
SLIDE 39

Glomerular hydrostatic pressure, PGC, is high and relatively constant ≈45 mmHg. This is offset by a pressure in Bowman’s capsule PBC ≈10 mm Hg Net filtrative force is: ≈ 35 mm Hg PGC-PBC

40 30 20 10 mm Hg

  • aff. art eff. art.

THE GLOMERULUS - THE STARLING EQUILIBRIUM The glomerulus is unusual with respect to most capillary beds.

slide-40
SLIDE 40

Glomerular hydrostatic pressure, PGC, is high and constant ≈45 mmHg. This is offset by a pressure in Bowman’s capsule PBC ≈10mmHg Net filtrative force is:≈ 35 mm Hg

Osmotic pressure, ΠGS, ≈25 mm Hg. Due to the large net filtration of fluid ΠGS increases along the capillary to 35 mm Hg to achieve a balance of forces. PGC-PBC

40 30 20 10 mm Hg

Net filtration force ΠGS THE GLOMERULUS - THE STARLING EQUILIBRIUM

  • aff. art eff. art.
slide-41
SLIDE 41

FILTRATION FRACTION Filtration fraction is an important expression of the extent of glomerular filtration. It is the ratio: Filtration fraction = Glomerular filtration rate Renal plasma flow It is the fraction of renal plasma flow that is filtered at the glomerulus

RPF 750 ml/min GFR 125 ml/min Renal blood flow 1250 ml/min

Efferent Arteriole 625 ml/min

Urine 1 ml/min

124 ml/min

renal vein glomerulus tubule

slide-42
SLIDE 42

Thus, in this example filtration fraction is: 125 750 ≈ 0.17 GFR and RPF can be measured separately using clearance methods Glomerular filtration rate (GFR) is about: 125 ml/min Renal blood flow is about: 1250 ml/min Renal plasma flow (RPF) is about: 750 ml/min FILTRATION FRACTION an example Remember: plasma volume is about 60% of total blood volume

slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48

RENAL BLOOD FLOW (RBF) Renal blood flow is ≈1.25 l/min -i.e. about 25% of the cardiac output This is a very large flow relative to the weight of the kidneys (≈350 g) Renal blood flow GFR 0 100 200 Arterial blood pressure, mm Hg 1.5 1.0 0.5 Flow, l/min

RBF determines GFR RBF also modifies solute and water

reabsorption and delivers nutrients to nephron cells.

Renal blood flow is autoregulated

between 90 and 180 mm Hg by varying renal vascular resistance (RVR)

i.e. the resistances of the interlobular

artery, afferent arteriole and efferent arteriole

slide-49
SLIDE 49
slide-50
SLIDE 50

RENAL BLOOD FLOW - AUTOREGULATION Two hypotheses have been proposed to explain autoregulation 1. Myogenic hypothesis When arterial pressure increases the renal afferent arteriole is stretched Autoregulation effectively uncouples renal function from arterial blood pressure and ensures that fluid and solute excretion is constant. Increase of arterial pressure Flow increases Remember: Flow α 1 r4

slide-51
SLIDE 51

RENAL BLOOD FLOW - AUTOREGULATION

  • 1. Myogenic hypothesis

When arterial pressure increases the renal afferent arteriole is stretched Vascular smooth muscle responds by contracting thus increasing resistance Increase of arterial pressure Increase of vascular tone Flow increases Flow returns to normal

slide-52
SLIDE 52

RENAL BLOOD FLOW - AUTOREGULATION

  • 2. Tubuloglomerular feedback

Alteration of tubular flow (or a factor in the filtrate) is sensed by the macula densa of the juxtaglomerular apparatus (JGA) and produces a signal that alters GFR. It is unclear what is the factor (NaCl reabsorption?) or the nature of the signal (renin?).

  • 4. ↑Ra

↓GFR

  • 1. ↑GFR
  • 2. ↑filtrate

3.signal from JGA

slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55

27: Tubular Processing of the Glomerular Filtrate

slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62
slide-63
SLIDE 63
slide-64
SLIDE 64
slide-65
SLIDE 65
slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68
slide-69
SLIDE 69
slide-70
SLIDE 70
slide-71
SLIDE 71

10mmHg

slide-72
SLIDE 72
slide-73
SLIDE 73
slide-74
SLIDE 74
slide-75
SLIDE 75

First Defense line: TGF GFR regulation Second Defanse line: GTB Reabsorption regulation

ΔP ΔUO

AgII

slide-76
SLIDE 76

Use of Clearance Methods to Quantify Kidney Function

slide-77
SLIDE 77
slide-78
SLIDE 78
slide-79
SLIDE 79
slide-80
SLIDE 80

C = U * V/ P

GFR = Cinulin FF= GFR / RPF RPF= CPAH
