Remote Timing Attacks are Practical by David Brumley and Dan Boneh Presented by Seny Kamara in Advanced Topics in Network Security (600/650.624) Outline Traditional threat model in cryptography Side-channel attacks Kochers

slide-1
SLIDE 1

Remote Timing Attacks are Practical

by David Brumley and Dan Boneh Presented by Seny Kamara in Advanced Topics in Network Security (600/650.624)

slide-2
SLIDE 2

02/10/05

  • S. Kamara (600/650.624)

Outline

  • Traditional threat model in cryptography
  • Side-channel attacks
  • Kocher’s timing attack
  • Boneh & Brumley timing attack
  • Experiments
  • Countermeasures
slide-3
SLIDE 3

02/10/05

  • S. Kamara (600/650.624)

Traditional Crypto

  • Brute force attacks
  • large key
  • Mathematical attacks
  • reduction to hard problem
  • RSAP:
  • DHP:

(me mod n) → m (gx, gy) → gxy

slide-4
SLIDE 4

02/10/05

  • S. Kamara (600/650.624)
  • Attacker has access to:
  • Ciphertext
  • Algorithm

Traditional Crypto

slide-5
SLIDE 5

02/10/05

  • S. Kamara (600/650.624)
  • Attacker has access to:
  • Ciphertext
  • Algorithm
  • Physical observables from the device

Real-Life Crypto

slide-6
SLIDE 6

02/10/05

  • S. Kamara (600/650.624)

Side Channel Attacks

  • Paul Kocher in 1996
  • Recovers RSA and DSS signing key
  • Not taken seriously by cryptographers
  • Lot of attention from the press
slide-7
SLIDE 7

02/10/05

  • S. Kamara (600/650.624)
  • Timing analysis
  • Fault analysis
  • Differential fault analysis
  • Simple power analysis
  • Differential power analysis
  • EM analysis

Side Channel Attacks

slide-8
SLIDE 8

02/10/05

  • S. Kamara (600/650.624)

Side Channel Attacks

k

m

EM radiation c time

Power consumption

slide-9
SLIDE 9

02/10/05

  • S. Kamara (600/650.624)

Side Channel Attacks

e

m

Side channel

me mod n

Encryption

slide-10
SLIDE 10

02/10/05

  • S. Kamara (600/650.624)

Side Channel Attacks

d

m

Side channel

md mod n

Decryption/ Signing

slide-11
SLIDE 11

02/10/05

  • S. Kamara (600/650.624)
  • RSA signatures:
  • Modular exponentiation is computed using

square and multiply algorithm

  • Time of modular exponentiation is a

function of the bits of the exponent

  • Use time to recover exponent (signing key)

Kocher Timing Attack

sig(m) = md mod n

slide-12
SLIDE 12

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

  • Recovers key bit by bit
  • Guesses key bit then verifies
  • Uses statistical analysis
  • Needs many samples of signing time
slide-13
SLIDE 13

02/10/05

  • S. Kamara (600/650.624)

Kocher Attack Target

sig(m) = md mod n

slide-14
SLIDE 14

02/10/05

  • S. Kamara (600/650.624)

Square and Multiply

1: INPUT: m, n, d 2: OUTPUT: x = md mod n 3: x := m 4: for i = n − 1 downto 0 do 5:

x := x2

6:

if di = 1 then

7:

x := x · m mod n

8:

end if

9: end for 10: return x

slide-15
SLIDE 15

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

Bob

m1 s1 m2 s2

... ... Eve ... d

T(m1) T(m2)

slide-16
SLIDE 16

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

Eve

m1 s1 m2 s2

... ... Eve ... 0?

T0(m2) T0(m1)

slide-17
SLIDE 17

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

Eve

m1 s1 m2 s2

... ... Eve ... 1?

T1(m1) T1(m2)

slide-18
SLIDE 18

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

  • Compare
  • vs
  • vs
  • will be correlated with correct guess

T0(mi) T(mi) T1(mi) T(mi) T(mi)

slide-19
SLIDE 19

02/10/05

  • S. Kamara (600/650.624)

Kocher Timing Attack

  • 1998 UCL experimental results:

Key size sample size 64 1 500-6 500 128 12 000-20 000 256 70 000-80 000 512 350 000

slide-20
SLIDE 20

02/10/05

  • S. Kamara (600/650.624)

Limit of Kocher Attack

  • Does not work when mod exp is optimized
slide-21
SLIDE 21

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • Sun Ze Th. aka CRT
  • m, d and n are order of 1024 bits
  • exponentiation of 1024 bit number by

another 1024 bit number taken modulo a third 1024 bit number

sig(m) = md mod n

slide-22
SLIDE 22

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • exponentiate mod q (512 bits)
  • exponentiate mod p (512 bits)
  • combine using SZT to get mod n (= pq)
slide-23
SLIDE 23

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • where
  • sig(m) = md mod n

n = pq m1 = m mod p m2 = m mod q d1 = d mod (p − 1) d2 = d mod (q − 1)

slide-24
SLIDE 24

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • s1 = md1

1 mod p

s2 = md2

2 mod q

CRT(s1, s2) = md mod n

slide-25
SLIDE 25

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • Modular exponentiation:
  • pre-processing
  • exponentiation mod p
  • exponentiation mod q
  • CRT
slide-26
SLIDE 26

02/10/05

  • S. Kamara (600/650.624)

RSA with Sun Ze Th.

  • Kocher’s attack does not work
  • Cannot get precise timings
  • Cannot repeat pre-processing without

factors

  • Most implementations use CRT
  • OpenSSL
slide-27
SLIDE 27

02/10/05

  • S. Kamara (600/650.624)

OpenSSL

  • SSL establishes encrypted and authenticated

channel between client and server

  • 1994
  • SSL v1 completed but never released
  • SSL v2 released with Navigator 1.1
  • SSL v2 PRNG broken
slide-28
SLIDE 28

02/10/05

  • S. Kamara (600/650.624)

OpenSSL

  • 1995
  • SSL v3 released (designed by Kocher)
  • SSL is ubiquitous
  • 1996
  • IETF standardizes SSL
slide-29
SLIDE 29

02/10/05

  • S. Kamara (600/650.624)

OpenSSL

  • 1998
  • OpenSSL 0.9.1c is released (based on

SSLeay)

  • mod_ssl for Apache is released
slide-30
SLIDE 30

02/10/05

  • S. Kamara (600/650.624)

OpenSSL

  • Most popular open source SSL

implementation

  • Most popular crypto library
  • 18% of all Apache servers use mod_ssl
  • stunnel
  • sNFS
slide-31
SLIDE 31

02/10/05

  • S. Kamara (600/650.624)

RSA in OpenSSL

  • Sun Ze Theorem
  • Modular exponentiation: sliding window
  • Modular reduction: Montgomery
  • Multi-precision multiplication: Karatsuba

sig(m) = md mod n

slide-32
SLIDE 32

02/10/05

  • S. Kamara (600/650.624)

Sliding Window

  • Extension of square and multiply
  • uses multiple bits of the exponent at once
  • makes attack more difficult
slide-33
SLIDE 33

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

  • Introduced in 1985 by Peter Montgomery
  • Performs modular multiplication efficiently
  • Transforms multiplication mod n to

multiplication mod R

slide-34
SLIDE 34

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

extra reduction

Algorithm 1 Montgomery Reduction

1: INPUT: x, y and q 2: OUTPUT: x · y mod q 3: RR−1 − qq∗ = 1 4: Ψ(x) := xR mod q 5: Ψ(y) := yR mod q 6: z := Ψ(x) × Ψ(y) = abR2 mod q 7: r := z × q∗ mod R 8: s := z+rq

R

9: if s > q then 10:

s := s − q

11: end if 12: return s

slide-35
SLIDE 35

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

  • Pr[extra reduction] = m mod q

2R m → q ⇒ Pr[reduction] m → q+ ⇒ Pr[reduction] m = q ⇒ Pr[reduction] = 0

slide-36
SLIDE 36

02/10/05

  • S. Kamara (600/650.624)

Karatsuba

  • Multi-precision multiplication
  • where and
  • Runs in
  • As opposed to
  • worst case

O(nlog2 3) O(n2) O(n · m) x · y |x| = n |y| = n

slide-37
SLIDE 37

02/10/05

  • S. Kamara (600/650.624)

Karatsuba

  • Used only if inputs have same length
  • OpenSSL:
  • if |x| = |y| then Karatsuba
  • if |x| != |y| then normal

O(nlog2 3) O(n2)

slide-38
SLIDE 38

02/10/05

  • S. Kamara (600/650.624)

Biases

  • What is the effect of these optimizations on

the exponentiation time?

slide-39
SLIDE 39

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

  • if m approaches q from below then slow
  • if m approaches q from above then fast
slide-40
SLIDE 40

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

Decryption time

q 2q 3q g Figure 1

slide-41
SLIDE 41

02/10/05

  • S. Kamara (600/650.624)

Multiplication

  • if |x| = |y| then fast
  • if |x| != |y| then slow
slide-42
SLIDE 42

02/10/05

  • S. Kamara (600/650.624)

Multiplication

g g < q g > q

Decryption time

Karatsuba Normal

slide-43
SLIDE 43

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

hello e g or ghi error Eve Server

slide-44
SLIDE 44

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

  • Kocher attack recovers signing key
  • Boneh-Brumley attack recovers factor
slide-45
SLIDE 45

02/10/05

  • S. Kamara (600/650.624)

Kocher Attack Target

sig(m) = md mod n

slide-46
SLIDE 46

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Target

sig(m) = md mod p · q

slide-47
SLIDE 47

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Target

  • n = pq
  • Knowing q we recover p

d = e−1 mod (p − 1)(q − 1)

slide-48
SLIDE 48

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

CRT Square and multiply Montgomery Multiplication

m modq md mod q md mod R I · m

slide-49
SLIDE 49

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

  • Recover bit of q
  • when we already have the top bits

sig(m) = md mod pq ith i − 1

slide-50
SLIDE 50

02/10/05

  • S. Kamara (600/650.624)

Timing Attack

  • q: smallest factor
  • g: same top bits as q (rest is all 0)
  • : g with bit set to
  • : decryption(g) - decryption( )

i − 1 ghi ith 1 ghi ∆

slide-51
SLIDE 51

02/10/05

  • S. Kamara (600/650.624)

Timing Attack

  • i = 4
  • q = 101 ?
  • g = 101 0...
  • g = 101 10...

hi

slide-52
SLIDE 52

02/10/05

  • S. Kamara (600/650.624)

Timing Attack

  • i = 4
  • q = 101 1 ?
  • g = 101 0...
  • g = 101 10...

hi

if then

q4 = 1 g < ghi < q

slide-53
SLIDE 53

02/10/05

  • S. Kamara (600/650.624)

Timing Attack

  • i = 4
  • q = 101 0 ?
  • g = 101 0...
  • g = 101 10...

hi

if then

g < q < ghi q4 = 0

slide-54
SLIDE 54

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

Montgomery Multiplication T(g) slow (xtra reds) fast (kara)

ghi

T( ) fast slow (normal)

|∆|

large large

qi = 0 → g < q < ghi

slide-55
SLIDE 55

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

Montgomery Multiplication T(g) slow (xtra reds) fast (kara)

ghi

T( ) fast slow (normal)

|∆|

large large

g < q < ghi

slide-56
SLIDE 56

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

Montgomery Multiplication T(g) slow fast

ghi

T( ) slow fast

|∆|

small small

qi = 1 → g < ghi < q

slide-57
SLIDE 57

02/10/05

  • S. Kamara (600/650.624)

Boneh-Brumley Attack

Montgomery Multiplication T(g) slow fast

ghi

T( ) slow fast

|∆|

small small

g < ghi < q

slide-58
SLIDE 58

02/10/05

  • S. Kamara (600/650.624)

Timing Attack

  • if then and
  • is small
  • if then and
  • is large

q4 = 1 |∆| g < ghi < q q4 = 0 g < q < ghi |∆|

slide-59
SLIDE 59

02/10/05

  • S. Kamara (600/650.624)

Experimental Setup

  • RedHat Linux 7.3
  • 2.4 GHz Pentium 4
  • 1 GB of RAM
  • gcc 2.96
  • OpenSSL 0.9.7
slide-60
SLIDE 60

02/10/05

  • S. Kamara (600/650.624)

Number of Queries

  • Interprocess using TCP
  • Neighborhood size: for each bit measure

decryption time of many guesses (sliding window)

  • Sample size: for each guess measure multiple

times

slide-61
SLIDE 61

02/10/05

  • S. Kamara (600/650.624)

Number of Queries

slide-62
SLIDE 62

02/10/05

  • S. Kamara (600/650.624)

Number of Queries

  • Delta increases as neighborhood size

increases

  • Variance decreases as sample size increases
slide-63
SLIDE 63

02/10/05

  • S. Kamara (600/650.624)

Other Experiments

  • Tested using 3 different keys
  • Deltas are very sensitive to
  • execution environment (cache misses,

code offsets etc...)

  • compilation flags
slide-64
SLIDE 64

02/10/05

  • S. Kamara (600/650.624)

Network Experiments

  • Works against Apache+mod_ssl when

seperated by:

  • 1 switch
  • 3 routers and a number of switches
slide-65
SLIDE 65

02/10/05

  • S. Kamara (600/650.624)

Network

slide-66
SLIDE 66

02/10/05

  • S. Kamara (600/650.624)

Attack Results

  • Interprocess attack
  • 1024 bit key
  • Unoptimized: 350 000 queries
  • Optimized: 1.4 million queries
  • 2 hours
slide-67
SLIDE 67

02/10/05

  • S. Kamara (600/650.624)

More Details

  • Lucas will talk more about the experiments
slide-68
SLIDE 68

02/10/05

  • S. Kamara (600/650.624)

Countermeasures

  • Make running time independent of input
  • Montgomery: perform dummy reductions
  • Multiplication: always use Karatsuba

(shifts)

  • Make all operations take the same time
slide-69
SLIDE 69

02/10/05

  • S. Kamara (600/650.624)
  • Blinding

Countermeasures

Eve

(rem) (rem)d

rmd

r ∈R Zn

slide-70
SLIDE 70

02/10/05

  • S. Kamara (600/650.624)

Countermeasures

slide-71
SLIDE 71

02/10/05

  • S. Kamara (600/650.624)

Blinding

  • How do we know it prevents other attacks?
  • Blinding is not provably secure
  • What about template attacks?
slide-72
SLIDE 72

02/10/05

  • S. Kamara (600/650.624)

Impact

  • CERT advisory
  • At least 37 products vulnerable
  • 23 not vulnerable
  • 56 unknown
slide-73
SLIDE 73

02/10/05

  • S. Kamara (600/650.624)

Questions?

slide-74
SLIDE 74

02/10/05

  • S. Kamara (600/650.624)

Montgomery Reduction

  • and
  • Multiplication and division by powers of 2 is

efficient

x · y mod q → x · y mod 2k 2k > q gcd(2k, q) = 1

slide-75
SLIDE 75

02/10/05

  • S. Kamara (600/650.624)

Karatsuba

  • A × B = AHAL × BHBL

A × B = (2

n 2 AH + AL) × (2 n 2 BH + BL)

A × B = 2nAHBH + 2

n 2 (AHBL + ALBH) + ALBL

slide-76
SLIDE 76

02/10/05

  • S. Kamara (600/650.624)

Karatsuba

AHBL + ALBH = (AH + AL) × (BH + BL) − AHBH − ALBL

A × B = 2nAHBH + 2

n 2 (AHBL + ALBH) + ALBL

A × B = 2nAHBH + 2

n 2 [(AH + AL) × (BH + BL) − AHBH − ALBL] + ALBL

slide-77
SLIDE 77

02/10/05

  • S. Kamara (600/650.624)

Karatsuba

  • 3 multiplications and 2 shift and 7 additions
  • multiplications fit in registers (no overflows)
