Remarks on the Data Complexity of Zero-Correlation Linear Attacks

C´ eline Blondeau

Aalto University ESC, Luxembourg 2015

Complexity of Statistical Attacks 2/22

Outline

Zero-Correlation Linear Attacks Data Complexity of Zero-Correlation Attacks Repetition of Plaintexts Data Complexity of Key-Invariant Bias Attacks

Complexity of Statistical Attacks 3/22

Outline

Zero-Correlation Linear Attacks Data Complexity of Zero-Correlation Attacks Repetition of Plaintexts Data Complexity of Key-Invariant Bias Attacks

Complexity of Statistical Attacks 4/22

Zero-Correlation (ZC) Linear Cryptanalysis

[Bogdanov et al 12, 13,14], [Soleimany, Nyberg 13] The distinguisher takes advantage of linear approximation(s) with no bias.

◮ Single approximation (u, v) with cor(u, v) = 0 ◮ Multiple approximations:

C =

• u∈U,v∈V,u=0

cor 2(u, v) = 0,

◮ multiple ZC: U and V without structure. ◮ multidimensional ZC: U and V linear (affine) spaces.

Complexity of Statistical Attacks 5/22

Outline

Zero-Correlation Linear Attacks Data Complexity of Zero-Correlation Attacks Repetition of Plaintexts Data Complexity of Key-Invariant Bias Attacks

Complexity of Statistical Attacks 6/22

Notation

◮ [Selc

¸uk 08]

◮ XR ∼ N(µR, σR) and XW ∼ N(µW, σW) ◮ Φ: CDF of the central normal distribution ◮ a: advantage of the attack

PS ≈ Φ   µR − µa

• σ2

a + σ2 R

  , where µa = µW + σW · Φ−1(1 − 2−a) and σa is often negligible.

◮ ϕa = Φ−1(1 − 2−a) and ϕPS = Φ−1(PS) ◮ n: number of bits of the permutation (block cipher)

Complexity of Statistical Attacks 7/22

Data Complexity of Multiple/Multidimensional ZC Attacks

[SAC 13]:

◮ ℓ: Number of linear approximations ◮ Multiple ZC Attack (m)

Nm ≈ 2n(ϕPS + ϕa)

• ℓ/2 − ϕa

◮ Multidimensional ZC Attack (M)

NM ≈ (2n − 1)(ϕPS + ϕa)

• (ℓ − 1)/2 + ϕPS

◮ In [Soleimany, Nyberg 13], experiments have been conducted for

a distinguisher

◮ The general behaviour: N = O(

2n

• ℓ/2

) is correct.

Complexity of Statistical Attacks 8/22

Success Probability

◮ Are these formulas correct for a key-recovery attack? ◮ Why is there a difference ? (In particular, when the set of masks

is close to a linear space) Success probability: Pm

S

≈ Φ Nm 2n

• ℓ/2 − ϕa · (Nm

2n + 1)

• (m)

PM

S

≈ Φ

• NM

(ℓ − 1)/2 (2n − 1) − NM − ϕa 2n − 1 (2n − 1) − NM

• (M)

Complexity of Statistical Attacks 9/22

Setting for the Experiments

◮ 16-bit cipher ◮ Type-II GFN with 4 branches ◮ Zero-correlation approximations:

(0, 0, u, 0) → (0, u, 0, 0) over 9 rounds (u = 0)

◮ Key-recovery: 1 round before, 2 rounds after ◮ Maximal advantage: 12 bits ◮ Similar structure as for instance CLEFIA

F F s ✲ ❡ s ✲ ❡ PPPPPPPPPPPPPPP

• F

F s ✲ ❡ s ✲ ❡ PPPPPPPPPPPPPPP

• F

F s ✲ ❡ s ✲ ❡ PPPPPPPPPPPPPPP

• u

u K 1

2

K 11

1

K 12

2

X 1 X 2 X 11 X 12 X 13

ZC on 9 rounds

Complexity of Statistical Attacks 10/22

Multidimensional ZC Attacks

a = 1

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 10/22

Multidimensional ZC Attacks

a = 2

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 10/22

Multidimensional ZC Attacks

a = 4

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 10/22

Multidimensional ZC Attacks

a = 6

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 11/22

Observations

NM ≈ (2n − 1)(ϕPS + ϕa)

• (ℓ − 1)/2 + ϕPS

For a multidimensional ZC linear attack,

◮ NM is accurate for small advantages ◮ NM gives an overestimate of the data complexity for larger

advantages

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

8 approximations and a = 1

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

8 approximations and a = 2

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

8 approximations and a = 4

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

5 approximations and a = 1

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

5 approximations and a = 2

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

5 approximations and a = 4

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

2 approximations and a = 1

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 12/22

Multiple ZC Attack

2 approximations and a = 2

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Exp (1) (1)

Complexity of Statistical Attacks 13/22

Data Complexity of Multiple ZC Attacks

Based on these experiments, we confirmed that

◮ we do not need a particular formula to compute the data

complexity/success probability of multiple zero-correlation attacks (comparatively to the complexity of multidimensional ZC attacks)

Complexity of Statistical Attacks 14/22

Outline

Zero-Correlation Linear Attacks Data Complexity of Zero-Correlation Attacks Repetition of Plaintexts Data Complexity of Key-Invariant Bias Attacks

Complexity of Statistical Attacks 15/22

Repetition of Plaintexts

◮ In the presented attacks, distinct known plaintexts are used. ◮ Indeed the formulas for NM and PM S in the multidimensional

linear context have been derived under this assumption.

◮ What happens if there is some repetition (assuming for instance

that the plaintexts are generated/obtained randomly)?

Complexity of Statistical Attacks 16/22

Repetition of Plaintexts in a Multidimensional ZC Attack

a=2

0.2 0.4 0.6 0.8 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

Distinct Random (1) (1)

Complexity of Statistical Attacks 16/22

Repetition of Plaintexts in a Multidimensional ZC Attack

a=4

0.2 0.4 0.6 0.8 1 12 12.5 13 13.5 14 14.5 15 15.5 16

PS log2(N)

No repertion Repetition (1) (1)

Complexity of Statistical Attacks 17/22

Theoretical Conclusion

We can show that

◮

Nm ≈ 2n(ϕPS + ϕa)

• ℓ/2 − ϕa

, corresponds to the case where the plaintexts can be repeated.

◮

NM ≈ (2n − 1)(ϕPS + ϕa)

• (ℓ − 1)/2 + ϕPS

, corresponds to the case of distinct known plaintexts.

Complexity of Statistical Attacks 17/22

Theoretical Conclusion

We can show that

◮

Nm ≈ 2n(ϕPS + ϕa)

• ℓ/2 − ϕa

, corresponds to the case where the plaintexts can be repeated.

◮

NM ≈ (2n − 1)(ϕPS + ϕa)

• (ℓ − 1)/2 + ϕPS

, corresponds to the case of distinct known plaintexts.

◮ In the known plaintext model how can we select distinct

messages?

Complexity of Statistical Attacks 18/22

Idea behind the proofs

◮ The proofs have already been presented in [Bogdanov et al 12,

13].

◮ For distinct known plaintexts, we use hypergeometric

distributions (no replacement).

◮ The other model assume a normal distribution of the capacity for

the wrong keys.

Complexity of Statistical Attacks 18/22

Idea behind the proofs

◮ The proofs have already been presented in [Bogdanov et al 12,

13].

◮ For distinct known plaintexts, we use hypergeometric

distributions (no replacement).

◮ The other model assume a normal distribution of the capacity for

the wrong keys.

◮ In both proofs, there is no assumption on the linear masks.

Complexity of Statistical Attacks 19/22

In Practice

If we consider distinct known plaintexts we can improve the complexities of some ZC attacks. For instance:

◮ on CAST-256 presented at INDOCRYPT 2014

◮ from 2123.74 KP (2123.2?) to 2123.67 DKP (29 rounds)

◮ on Camellia presented at SAC 2013

◮ Camellia-128 : from 2125.3 KP to 2125.1 DKP (11 rounds) ◮ Camellia-192 : from 2125.7 KP to 2125.5 DKP (12 rounds)

Complexity of Statistical Attacks 20/22

Outline

Zero-Correlation Linear Attacks Data Complexity of Zero-Correlation Attacks Repetition of Plaintexts Data Complexity of Key-Invariant Bias Attacks

Complexity of Statistical Attacks 21/22

Key-Invariant Bias Attacks

◮ Related-key attack introduced at ASIACRYPT 2013 ◮ We can make the same observation on the data complexity ◮ Improvement of the attack on LBlock (Twine) considering distinct

plaintexts:

◮ Data: from 262.95 KP to 262.52 DKP (considering the same

advantage and the same success probability)

◮ Improvement of the time complexity is also possible depending

• n the data/time trade-off

Complexity of Statistical Attacks 22/22

Conclusion

◮ We made the distinction between known plaintext and distinct

known plaintext models.

◮ We improved the complexity of some zero-correlation linear

attacks.

◮ We improved the complexity of the key invariant bias attacks. ◮ This reasoning can probably be generalized to other attacks

such as for instance multidimensional linear attacks.
