Reliability Modeling and Optimization of New Product Development - - PowerPoint PPT Presentation

Reliability Modeling and Optimization of New Product Development Process Mohammad Sadegh Mobin PhD Candidate in Engineering Management Department of Industrial Engineering and Engineering Management Western New England University Springfield,


slide-1
SLIDE 1

Mohammad Sadegh Mobin PhD Candidate in Engineering Management Department of Industrial Engineering and Engineering Management Western New England University Springfield, MA PhD advisor: Dr. Zhaojun (Steven) Li 2017

Reliability Modeling and Optimization

  • f New Product Development Process

mobin.sadegh@gmail.com

slide-2
SLIDE 2

1

Reliability Modeling and Optimization

  • f New Product Development Process

 Part 1: Reliability Growth Planning (RGP) Modeling and Optimization  Part 2: Verification and Validation (V&V) Activities Planning and Optimization

Overview

mobin.sadegh@gmail.com

slide-3
SLIDE 3

Continuous Product Development

High % of total revenue Consumer needs changes Marketing environment changes To stay ahead of Competition Changing technology Not to lose market share

2

New Product Development (NPD)

mobin.sadegh@gmail.com

slide-4
SLIDE 4

3

Prototype/pilot

(Build components/ system)

Prototype test

(Test components/ System)

Production phase Field performance Verification &Validation

(System and process V&V)

Business case

(new idea)

Concept design

(System requirement identification)

Detail design

(Component requirement identification)

New Product Development (NPD)

Planning Product/Process design & development Product/Process V&V Production mobin.sadegh@gmail.com

slide-5
SLIDE 5

NPD Challenges

NPD programs are often plagued with:

Cost overruns, Schedule delays, and Quality issues.

Product Company Issues Year Source

787 Dreamliner Boeing Co Delay due to a structural flaw 2009 The Wall Street Journal Chevy Volt General Motors Cost overrun during design 2009 CNN Money The Honda/GE HF120 turbofan engine Honda Design issues: An unanticipated test program glitch. A part of the gearbox failed during the test. Rebuild the engine and begin the test again. 2013 Flying F-35 United Technologies Corp.’s Pratt and Whitney unit Delays in delivering engines. Quality flaws and technical issues. Systemic issues and manufacturing quality escapes. 2014 Defence- aerospace.com Bloomberg Business Sikorsky US Marine Corps' (USMC's) A failure in the main gear box and need for redesign of the component. Problems with wiring and hydraulics

  • systems. Budget constraints.

2015 HIS Jane’s 360

4

mobin.sadegh@gmail.com

slide-6
SLIDE 6

5

NASA’s main projects that faced cost and time overrun:

  • The International Space Station.

Prime contract had grown: 25%

(from $783M to $986M, the 3rd increase in 2 years).

  • The NASA Ares-I launch system.

Cost overrun: 43%

(from $28 billion original estimate to $40 billion)

The Department of Defense (DoD)

The set of 96 major new weapon system development programs (2000-2010) have:  an average development cost growth of 42%,  an average delay of 22 months.

“50% of the DOD’s NPD programs faced cost

  • verrun”.

“80% experienced an increase in unit costs from initial estimates”.

NPD Challenges

mobin.sadegh@gmail.com

slide-7
SLIDE 7

Reliability Management Process

6

mobin.sadegh@gmail.com

slide-8
SLIDE 8

Objective

Improve the NPD process by reducing:

  • Time to market delay (Scheduling)
  • Cost overrun (Budgeting)
  • Quality flaws (Reliable product)

Model and optimize the NPD reliability process in terms of cost, time, and product reliability

  • Proposing a model to improve the reliability growth planning (RGP).
  • Providing a quantitative model to improve product V&V activities planning.

7

mobin.sadegh@gmail.com

slide-9
SLIDE 9

Part1: RGP Multi-Objective and Multi-Stage Reliability Growth Planning (MO-MS-RGP)

mobin.sadegh@gmail.com

slide-10
SLIDE 10

Test Time MTBF (Days)

1.000 10.00 100.0 1000

Initial MTBF: 3 days Achieved MTBF: 70.0 days

Reliability goal = 73 390 Days

A single stage Reliability Growth Plan

One RG plan can be:  390 Days,  Required test units  Required test time  Total cost: $50k

Objective of RGP:

To determine the number of test units, test time, and cost to maximize the reliability growth.

Another RGP can be:  490 Days,  Test units and test time  Total cost $70k 490 Days

8

Reliability Growth Planning (RGP)

mobin.sadegh@gmail.com

slide-11
SLIDE 11
  • Duane Model (1964)
  • An empirical model, based on the learning curve,
  • Also known as power law model
  • Duane model in terms of cumulative failure rate:

𝒎𝒐 𝑫 𝒖 = 𝜺 − 𝜷 𝒎𝒐 𝒖

𝐷 𝑢 : The average failure rate 𝐷 𝑢 = 𝑂(𝑢)/𝑢 𝑂 𝑢 : The cumulative number of failures up to time 𝑢 during the reliability growth testing. 𝜀, 𝛽 > 0 , 𝛽 is known as growth rate

Duane Reliability Growth Model

9

mobin.sadegh@gmail.com

slide-12
SLIDE 12

Motivation for Multi-Stage RGP

An example of multi-stage NPD plan

10

mobin.sadegh@gmail.com

slide-13
SLIDE 13
  • Challenges for multi-stage RGP in early product development stage:

1. How to allocate test units and time to individual stage. 2. How to determine the proportion of new technology introduction in each stage

The schematic of multi-stage reliability growth planning

11

Multi-Stage Reliability Growth Planning

mobin.sadegh@gmail.com

slide-14
SLIDE 14

RGP Literature Review

Significant contribution: Multi-objective & Multi-stage RGP

Author Duane (1964) [1] Crow (1974) [2] Lloyd (1986) [3] Robinson and Dietrich (1987) [4] Coit (1998) [5] Walls & Quigley (1999) [6] Walls & Quigley (2001) [7] Quigley and Walls (2003) [8] Krasich et al. (2004) [9] Johnston et al. (2006) [10] Jin and Wang. (2009) [11] Jin et al. (2010) [12] Jin et al. (2013) [13] Jin and Li (2016) [14] Jackson (2016) [15] Li et al (2016) [16] Single

  • bjective

Multi

  • bjective

Single - stage Multi- stage Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No No Yes Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No No Yes No Yes

12

mobin.sadegh@gmail.com

slide-15
SLIDE 15

Proposed MO-MS-RGP Model

Objectives :

  • 1. Minimize failure rate at the final stage
  • 2. Minimize total development time
  • 3. Minimize total test cost

Decision variables: 1- Number of test units for each subsystem in each stage 2- Test time for each subsystem in each stage 1- Total product test time 2- Number of available test units in each development stage Constraints:

Stage 1 Stage 2 Stage 3

Initial MTBF (stage 1) Initial MTBF (stage 2) Initial MTBF (stage 3) MTBF at the end of stage 1 MTBF at the end of stage 2 MTBF at the end of stage 3

Test time for stage 1 Test time for stage 2 Total time

Reliability Goal

MTBF

13

mobin.sadegh@gmail.com

slide-16
SLIDE 16

MS-MO-RGP Mathematical Modeling

mobin.sadegh@gmail.com

slide-17
SLIDE 17

Proposed MO-MS-RGP Model

Min: 𝜇𝑜 = 𝑔 𝜇 𝑗−1, 𝜇 𝑜(𝑗), 𝛽𝑗 , 𝑈𝑗 Min: 𝜐 = 𝑗=1

𝑜

𝜐𝑗 , 𝑗 = 1, … , 𝑜 Min: 𝐷 = 𝑗=1

𝑜

𝐷𝑗 , 𝑗 = 1, … , 𝑜 s.t. 0 ≤ 𝜐 ≤ 𝜐𝑣 𝑂𝑚(𝑗) ≤ 𝑂𝑗 ≤ 𝑂𝑣(𝑗) , 𝑗 = 1, … , 𝑜 Decision variables:

  • 𝑜𝑗𝑘
  • 𝑢𝑗𝑘

𝒈𝟐 𝒈𝟑 𝒈𝟒

An optimal solution (RGP) * Time (Yrs.) * Cost ($) * Reliability (MTBF (YRS.)) * Number of test units for each sub-system in each stage * Planned testing time for each sub-system in stage

15

mobin.sadegh@gmail.com

slide-18
SLIDE 18

Method 1: Creating a weighted composite objective function

Shortcomings:

  • 1. Difficulties in determining appropriate utility functions (weights).
  • 2. Objectives have different scale and cannot easily be added up.

Method 2: Consider one as main objective function and others as constraints

Shortcomings:

  • 1. Difficulties in determining boundary values.
  • 2. Defining boundaries may reduce the solution space.

Method 3: Multi-Objective Evolutionary Algorithms (MOEAs)

e.g., MOPSO, NSGA, etc.

  • 1. Simultaneously optimizing two or three (or more) conflicting objectives.
  • 2. Effective methods in exploring feasible solutions and providing a population of approximately
  • ptimal solutions (Pareto-optimal frontier).
  • 3. Apply evolutionary operators, e.g., crossover and mutation to generate variety of new solutions.

Solution Methodologies

16

mobin.sadegh@gmail.com

slide-19
SLIDE 19

Overview of the proposed solution methodology

Mathematical model:

  • Objective functions
  • Constraints
  • Decision variables

A set of Pareto-

  • ptimal solutions

Inputs (Minimization objective functions) Outputs (Maximization objective functions)

Data Envelopment Analysis (DEA) Multiple Objectives Evolutionary Algorithm

Optimal efficient solutions

17

Proposed Solution Methodology

mobin.sadegh@gmail.com

slide-20
SLIDE 20

Case Study

  • Application of MS MO RGP for next generation dual engine development process

i stage Group description λij θ1 (%) θ2 (%) θ3 (%) cij ($1000) mi αi Nl(i) Nu i 1 Engine Block 1.38 100 600 2 0.4 4 8 Turbocharger 0.03 100 45 2 Engine control 0.24 80 50 4 0.3 8 16 Cooling System 0.02 100 30 Fuel System 0.20 80 40 Lubricating system 0.05 80 20 3 Engine control 0.24 20 12.5 3 0.2 6 20 Fuel system 0.20 20 10 Lubricating system 0.05 20 5

Min: 𝜇𝑗=3 = 𝑔 𝜇 𝐽(𝑗−1), 𝜇 𝑜(𝑗), 𝛽𝑗 , 𝑈𝑗 Min: 𝑗=1

𝑜

𝐷𝑗 = 𝐷1 + 𝐷2 + 𝐷3 Min: 𝜐 = 𝑗=1

𝑜

𝜐𝑗 = 𝜐1 + 𝜐2 + 𝜐3 s.t. 0 ≤ 𝜐 ≤ 𝜐𝑣 ⟹ 0 ≤ 𝜐1 + 𝜐2 + 𝜐3 ≤ 3.5 4 ≤ 𝑜11 + 𝑜12 ≤ 8 8 ≤ 𝑜21 + 𝑜22 + 𝑜23 + 𝑜24 ≤ 16 6 ≤ 𝑜31 + 𝑜32 + 𝑜33 ≤ 20

𝜐𝑣: 3.5 years The effective work hours in each year: 2000 hours The variable cost per hour: $2000

18 decision variables:

  • 𝑜𝑗𝑘 (discrete)
  • 𝑢𝑗𝑘 (continuous)

18

mobin.sadegh@gmail.com

slide-21
SLIDE 21
  • Obtaining Pareto optimal frontier for RGP using NSGA-II

0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 0.5 1 1.5 2 2.5 3 3.5 3000 6000 9000 12000 15000

f1(x): Failure rate of stage 3 f2(x): Projected total test time f3(x): Projected total test cost

1 = 0.4 2 = 0.3 3 = 0.2 n(1) = 1.41 n(2) = 0.51 n(3) = 0.49

19

Optimal Solutions

mobin.sadegh@gmail.com

slide-22
SLIDE 22
  • DEA applications

0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 0.5 1 1.5 2 2.5 3 3.5 3000 6000 9000 12000 15000

f1(x): Failure rate of stage 3 f2(x): Projected total test time f3(x): Projected total test cost

CCR solutions NSGA-II solutions

Inputs Output DMUs Time Cost Reliability (Yrs.) ($) MTBF (Yrs.) DMU 01 3.45 15.38 2.13 DMU 02 0.79 4.56 0.79 DMU 04 3.28 14.72 2.13 DMU 07 0.82 4.67 0.83 DMU 10 2.30 10.87 1.88 DMU 15 0.88 4.91 0.89 DMU 19 0.80 4.60 0.81 DMU 26 3.23 14.53 2.10 DMU 31 2.66 12.31 1.96 DMU 34 1.76 8.57 1.58 DMU 36 2.57 11.96 1.94 DMU 38 2.25 10.68 1.86 DMU 48 0.79 4.56 0.79 DMU 51 2.22 10.56 1.86 DMU 56 1.83 8.84 1.62 DMU 58 2.29 10.84 1.87 DMU 67 1.86 8.95 1.64 DMU 69 1.78 8.65 1.60 DMU 70 2.55 11.88 1.94 DMU 86 1.20 6.20 1.18 DMU 87 1.86 8.94 1.63 DMU 96 1.22 6.27 1.20 DMU 98 1.21 6.23 1.19

20

Optimal Efficient Solutions

mobin.sadegh@gmail.com

slide-23
SLIDE 23

21

Conclusions and Future Research

 Uncertainties in the variables of the RGP model:

e.g. uncertainty in the failure rate, reliability growth, etc.

 Component-level approach in RGP:

e.g. provide number of test units and test time for each component in different sub-systems.

 Application and comparison of other evolutionary algorithms:

e.g. Multi-objective Particle Swarm Optimization (MOPSO).

Ongoing and Future Research: Conclusion:  A new approach in reliability growth planning (RGP)

  • Correlates multiple stages of developing a new product.
  • Considers multiple objectives of NPD process.
  • Determines test time and test units for each subsystem in each stage
  • Provides efficient and optimal RGP for implementation

mobin.sadegh@gmail.com

slide-24
SLIDE 24

[1] Duane J., Learning curve approach to reliability monitoring, IEEE Transactions on Aerospace, 2(2), 563-6, 1964. [2] Crow L.H.. Reliability analysis for complex, repairable systems. In Reliability and Biometry, ed. By F. Proschan and R. J. Serfing, Eds: SIAM, 379-410,1974. [3] Lloyd D.K., Forecasting reliability growth. Quality and Reliability Engineering International, 2(1),19-23. 1986 [4] Robinson D.G. and Dietrich D., A new nonparametric growth model. IEEE Transactions on Reliability, 36(4),411-8, 1987. [5] Coit D.W., Economic allocation of test times for subsystem-level reliability growth testing. IIE transactions, 30(12), 1143-51, 1998. [6] Walls L, Quigley J. Learning to improve reliability during system development. European Journal of Operation Research, 119(2), 495-509, 1999. [7] Walls L, Quigley J. Building prior distributions to support bayesian reliability growth modelling using expert

  • judgement. Reliability Engineering and System Safety, 74(2), 117-28. 2001.

[8] Quigley J. and Walls L., Confidence intervals for reliability-growth models with small sample-sizes, IEEE Transactions on Reliability, 52(2), 257-62, 2003. [9] Krasich M., Quigley J., Walls L., Modeling reliability growth in the product design process, Proceedings of the Annual Reliability and Maintainability Symposium (RAMS), 424-30, 2004. [10] Johnston W., Quigley J., and Walls L., Optimal allocation of reliability tasks to mitigate faults during system development, IMA Journal of Management Mathematics, 17(2), 159-69, 2006. [11] Jin T, Wang H., A multi-objective decision making on reliability growth planning for in-service systems, Proceedings of the IEEE International Conference on Systems, Man, and Cybernetics (SMC), 4677-83, 2009. [12] Jin T., Liao H., and Kilari M., Reliability growth modeling for in-service electronic systems considering latent failure modes, Microelectronics Reliability, 50(3), 324-31, 2010. [13] Jin T., Yu Y., Huang H. Z., A multiphase decision model for system reliability growth with latent failures, IEEE Transactions on Systems, Man and Cybernetics, 43(4), 958-966, 2013. [14] Jin T., Li Z., Reliability growth planning for product-service integration, Proceedings of the Annual Reliability and Maintainability Symposium (RAMS), 2016. [15] Jackson C., Reliability growth and demonstration: the multi-phase reliability growth model (MPRGM), Proceedings of the Annual Reliability and Maintainability Symposium (RAMS), 2016.

References

mobin.sadegh@gmail.com

slide-25
SLIDE 25

22

Journal Publications

  • Mobin M., Li Z., Komaki M., A Multi-Objective Approach for Multi-Stage Reliability

Growth Planning by Considering the Timing of New Technologies Introduction, IEEE Transaction on Reliability, 66 (1), 97-110, 2017

  • Li Z., Mobin M., Keyser T., Multi-objective and Multi-Stage Reliability Growth

Planning in Early Product Development Stage, IEEE Transaction on Reliability, 65(2), 769-781, 2016.

Conference Presentations

  • Mobin M. and Li. Z., An Integrated Reliability Growth Planning in the New Complex

Engineering Product Development, Accelerated Stress Testing and Reliability Conference (ASTR 2016), Florida, USA.

  • Mobin M. and Li Z., Multi-stage Reliability Growth Planning Using Dynamic

Programming, The Institute for Operations Research and the Management Sciences Annual Conference (INFORMS 2014), California, USA.

  • Li Z., Mobin M., Pervaiz M., Keyser T., Multi-Objective and Multi-Stage Reliability

Growth Planning in Early Product Development Stage, Industrial and Systems Engineering Research Conference (ISERC 2014), Montreal, Canada.

Related Publications and Presentations

mobin.sadegh@gmail.com

slide-26
SLIDE 26

Section 2: V&V Planning An Approach for Design Verification and Validation Planning and Optimization for New Product Reliability Improvement

mobin.sadegh@gmail.com

slide-27
SLIDE 27

Scheduling

Challenges

Cost optimization Reliability improvement Failures prioritization V&V effectiveness Process iteration

A schematic summary of V&V process during NPD for reliability improvement

Failure modes (𝑔

𝑗, 𝑗 = 1, … , 𝑜)

Criticality (𝐸𝑗, 𝑇𝑗, 𝑃𝑗), V&V activities (𝑤𝑘, 𝑘 = 1, … , 𝑛) Duration (𝑢𝑘) Effectiveness (𝜄𝑗𝑘 , 𝛿𝑗𝑘) Design Failure Modes and Effects Analysis (DFMEA) V&V Execution V&V planning NO

23

V&V Process in NPD

Final product design Product Reliability Estimation Meets reliability goal? YES

mobin.sadegh@gmail.com

slide-28
SLIDE 28

Literature Review

24

Models that

  • nly focus on

product requirements and configurations

  • Quality Function Deployment (QFD) [19]
  • Key Characteristics (KCs) [20]
  • Design for X (DFX) [21]

Models that

  • nly focus
  • n

scheduling and budgeting

  • Project evaluation and review technique (PERT) [16]
  • The general evaluation and review technique (GERT) [17]
  • The dependency structure matrix (DSM) [18]

Scheduling Cost optimization Reliability improvement Failures prioritization Process effectiveness Process iteration mobin.sadegh@gmail.com

slide-29
SLIDE 29
  • Objective function and constraints:

Objective: Maximize the product reliability improvement. Constraints: 1: Limited budget; 2: Limited time; 3: Cover all failure modes; 4: Precedence constraints

25

Objective of V&V activities planning:

To determine an optimal set of V&V activities to be implemented in the limited time and cost, and optimizing reliability.

V&V Activities Plan

A schematic view of the V&V planning

mobin.sadegh@gmail.com

slide-30
SLIDE 30

Proposed Model for the V&V Planning

Objective: Maximize the product reliability improvement Constraint 1: Total cost of performing V&V activities Constraint 2: The critical failure coverage constraint Constraint 3: Total V&V process time (makespan of V&V process ) Constraint 4: Precedence constraints for V&V activities Subject to: 𝑵𝑩𝒀 𝑺𝑱𝑼𝒑𝒖𝒃𝒎 =

𝒋=𝟐 𝒐

𝑺𝑱𝒋 =

𝒋=𝟐 𝒐 𝑺𝑸𝑶𝒋(𝒋𝒐𝒋𝒖𝒋𝒃𝒎)

𝑺𝑸𝑶𝒋(𝒐𝒇𝒙)

(𝒕𝒌 + 𝒖𝒌)𝒘𝒌 ≤ 𝒕𝒌′,∀ 𝒌 immediately preceding 𝒌′ 𝑵𝒃𝒚

𝒌=𝟐,..,𝒏; 𝒋=𝟐,…,𝒐{(𝒕𝒌 + 𝒖𝒌) 𝒘𝒌 , ∀ 𝒋 = 𝟐, … , 𝒐} ≤ 𝑼 𝒌=𝟐 𝒏

𝒃𝒋𝒌 𝒘𝒌 ≥ 𝟐 , ∀ 𝒋 = 𝟐, … , 𝒐

𝒌=𝟐 𝒏

𝒅𝒌 𝒘𝒌 ≤ 𝑫

26

𝑆𝑄𝑂𝑗 (𝑗𝑜𝑗𝑢𝑗𝑏𝑚) = 𝐸𝑗 (𝑗𝑜𝑗𝑢𝑗𝑏𝑚) ∗ 𝑃𝑗 𝑗𝑜𝑗𝑢𝑗𝑏𝑚 ∗ 𝑇𝑗 (𝑗𝑜𝑗𝑢𝑗𝑏𝑚) 𝐸𝑗 (𝑜𝑓𝑥) = 𝐸𝑗 (𝑗𝑜𝑗𝑢𝑗𝑏𝑚) ∗

𝑘=1 𝑛

(1 − (𝜄𝑗𝑘 ∗ 𝑤𝑘))

  • 𝑛 V&V activities 𝑤𝑘 (𝑘 = 1, … , 𝑛) and (𝑤𝑘 ∈ {0,1})
  • 𝑜 failures (𝑗 = 1, … , 𝑜).

mobin.sadegh@gmail.com

slide-31
SLIDE 31

Numerical Example

 A modified case study of power assembly design when developing a new next generation engine.

27

  • Total budget (𝐷) for performing the V&V activities is $470K.
  • Total time of implementing V&V process is 480 days.

The incidence matrix Cost and duration of each V&V activity Initial detectability, occurrence, and severity for each failure mode (𝜄𝑗𝑘 , 𝛿𝑗𝑘): Risk reduction percentage in 𝐸𝑗 𝑗𝑜𝑗𝑢𝑗𝑏𝑚 and 𝑃𝑗(𝑗𝑜𝑗𝑢𝑗𝑏𝑚) after conducting the V&V activity 𝑤𝑘 on the failure mode 𝑔

𝑗

mobin.sadegh@gmail.com

slide-32
SLIDE 32

Numerical Results

Decision variables (𝑤𝑘) and the starting time of each V&V activity

  • The objective function value is obtained as: 𝑆𝐽𝑈𝑝𝑢𝑏𝑚 = 𝑗=1

25 𝐽𝐽𝑗 = 850.132.

  • The reduction in total RPN is calculated as: 𝑇𝑣𝑛 𝑆𝑄𝑂 𝑗𝑜𝑗𝑢𝑗𝑏𝑚 – 𝑇𝑣𝑛 𝑆𝑄𝑂 𝑜𝑓𝑥 = 3635.907.
  • Total cost of implementing the selected six V&V activities is $454,000.
  • Total implementation time is obtained as 405 days.

28

Summary of results

mobin.sadegh@gmail.com

slide-33
SLIDE 33

29

Conclusions and Future Research

 Uncertainties in the variables of the V&V planning model:

e.g. uncertainty in the DFMEA results, such as failure detectability and occurrence, time and cost of V&V activities, effectiveness, etc.

 Possible iteration of V&V activities:

e.g. V&V activities can be iterated with different effectiveness levels.

 Multi-objective optimization applications:

e.g. considering time and cost minimization as objective functions.

Ongoing and Future Research: Conclusion:  A new mathematical approach to plan V&V activities

  • Reliability improvement optimization
  • Time and cost constraints
  • Failure coverage
  • Effectiveness of V&V activities
  • Sequencing of V&V activities

mobin.sadegh@gmail.com

slide-34
SLIDE 34

[16] A.K. Bhattacharjee, S.D. Dhodapkar, and R.K. Shyamasundar, “PERTS: an environment for specification and verification of reactive systems,” Reliability Engineering & System Safety, vol. 71, no.3, pp.299-310, 2001. [17] W. Bernard, III. Taylor, and J. L. Moore, “R&D project planning with Q-GERT network modeling and simulation,” Management Science, vol. 26, no. 1, pp. 44-59, 1980. [18] S. D. Eppinger, D. E. Whitney, R. P. Smith, and D. A. Gebala, “A model-based method for organizing tasks in product development,” Research in Engineering Design, vol. 6, no. 1, pp.1-13, 1994. [19] D. Y. Kim, and P. Xirouchakis, “CO 2 DE: a decision support system for collaborative design,” Journal of Engineering Design, vol. 21, no. 1, pp. 31-48, 2010. [20] Y. M. Deng, G. A. Britton, and S. B. Tor, “Constraint-based functional design verification for conceptual design,” Computer-Aided Design, vol. 32, no. 14, pp. 889-899, 2000. [21] T.C. Kuo, S. H. Huang, and H.-C. Zhang, “Design for manufacture and design for ‘X’: concepts, applications, and perspectives,” Computers & Industrial Engineering, vol. 41, no. 3, pp. 241-260, 2001.

References

29

mobin.sadegh@gmail.com

slide-35
SLIDE 35

30

Journal Publications

  • Mobin M., Li Z., V&V Activity Planning Modeling and Optimization During New

Product Development Stages, Reliability Engineering and System Safety, (Under Review).

Conference Presentations

  • Mobin M., Li. Z. An Integrated Approach to Plan the Design Verification and

Validation (V&V) Activities for the New Product Reliability Improvement, 2017 IEEE Symposium on Product Compliance Engineering, California, USA.

  • Mobin M., Li Z., A Simulation-Optimization Approach to Optimize the Design

Verification and Validation Activities Planning for the New Product Reliability

  • Improvement. INFORMS 2016.

Related Publications and Presentations

mobin.sadegh@gmail.com

slide-36
SLIDE 36

Mohammad Sadegh Mobin (PhD Candidate),

Western New England University, Springfield, MA
