Asbestos Inspector Refresher Training Course Notice to Viewer: This sample slideshow includes our standard, up to date information that is based on industry standards and current EPA and OSHA requirements. We can customize this material to

slide-1
SLIDE 1

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Asbestos Inspector Refresher

Training Course

Notice to Viewer: This sample slideshow includes our standard, up to date information that is based on industry standards and current EPA and OSHA requirements. We can customize this material to meet state and local requirements in your area. Feel free to contact us for a quote. This sample manual is presented for viewing only and may not be reproduced.

slide-2
SLIDE 2

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 1

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Asbestos Inspector Refresher

Training Course

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Secti tion 1 Pre re-Ins Inspecti tion Acti tivit vities

TSI

Reasons to Conduct an Inspection

  • Liability Reduction & Safe Building

Environment

  • Property Transfer
  • Regulatory Compliance

P.1

TSI

Liability ty Reducti tion & & Safe fe Building Envir vironme ment

  • Conducting a comprehensive survey

– State of art practices – Inspector‟s duty

  • thoroughly identify and assess
  • accurately report the findings
  • recommend methods to control asbestos

P.1

TSI

Liability ty Reducti tion & & Safe fe Building Envir vironme ment

  • Implementing effective management

controls

– Implement controls – Continuously manage

P.1

TSI

Property Transfer

Recognized Environmental Conditions Protocols

– rarely comprehensive – usually identify only limited suspect materials (i.e. friable) – limited assessments (i.e. damaged materials) – few samples in a facility

P.1

slide-3
SLIDE 3

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 2

TSI

Regulatory Inspection Requirements

  • AHERA 40 CFR Part 763 Subpart E
  • OSHA General Industry Standard

29 CFR 1910.1001

  • OSHA Construction Standard

29 CFR 1926.1101

  • NESHAP 40 CFR Part 61 Subpart M
  • States
  • P. 2

TSI

Regulatory Comparison

Scope

AHERA 40 CFR Part 763 OSHA 29 CFR 1910.1001 General Industry OSHA 29 CFR 1926.1101 Construction NESHAP 40 CFR Part 61

Facilities

Schools (K-12) Public & private not-for-profit All buildings w/ employees Exception: construction & off- shore All areas employees are or will perform construction activities All structures excluding residential buildings w/ 4 or fewer dwelling units

Identify

  • Building-wide
  • Interior
  • Accessible
  • Employees’

Areas

  • Accessible
  • Employees’

Areas

  • Accessible &

Inaccessible

  • Affected areas of

facility

  • Accessible &

Inaccessible

Detect

AHERA protocol

  • r assume

AHERA protocol

  • r assume

AHERA protocol

  • r assume

AHERA protocol or assume

Assess

  • Location
  • Condition
  • Potential for

Disturbance

  • Quantity
  • Location
  • Quantity
  • Location
  • Condition
  • Potential for

Disturbance

  • Quantity
  • Location
  • Condition
  • Potential for

Disturbance

  • Quantity

P.3

TSI

ASTM Asbestos Survey

Baseline Survey Project Design Survey Entire facility

  • Indoor & outdoor material
  • Includes miscellaneous items & stored

materials

Long term ACM management Sampling & assuming permitted No destructive testing/ surface damage Generates enough information to support posting signs & labeling for OSHA compliance Limited to abatement areas Supports abatement All suspect ACM sampled Destructive testing often needed No assessment unless abatement decisions have not been made Supports NESHAP requirements to thoroughly inspect prior to renovation/ demolition

  • P. 2

TSI

New Buildings & Materials Need to inspect? Yes

P.4

  • Ban issues
  • PACM
  • AHERA Exemptions
  • MSDS‟s
  • State requirements

TSI

Active U.S. Ban Legislation

Senate passed Ban Asbestos in America Act

– Bans nearly all asbestos uses – Exempts naturally occurring fill material – Other exemptions include DOD, NASA, & chlorine process

P.5

Similar bill in House committee

TSI

Current Asbestos Bans and Restrictions

  • Argentina
  • Austria
  • Chile
  • Czech Republic
  • Estonia*
  • France
  • Germany
  • Honduras
  • Iceland
  • Italy
  • Kuwait
  • Lithuania
  • Malta
  • Norway
  • Portugal
  • Seychelles
  • Slovenia
  • Sweden
  • United Kingdom
  • Australia
  • Belgium
  • Cyprus
  • Denmark
  • Finland
  • Gabon
  • Greece
  • Portugal
  • Hungary
  • Ireland
  • Japan
  • Latvia
  • Luxembourg
  • Netherlands
  • Poland
  • Saudi Arabia
  • Slovakia
  • Spain
  • Switzerland
  • Uruguay
  • P. 5
slide-4
SLIDE 4

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 3

TSI

Selecting an Inspection Firm

  • 1. Scope of Work

Owner Responsibilities Inspector Responsibilities Convey why they are conducting the survey including:  Intended use for survey report  Who will use survey report  Regulatory requirements to be fulfilled  Activities following survey Provide information including:  Drawings & specifications  Previous inspections  Knowledgeable escorts Thoroughly review bid documents Ask questions about:  Reasons for survey  Availability of building records  Escorts and/ or access  Previous surveys

  • P. 6

TSI

  • 2. Site Visits
  • Complexity determines need
  • Individual or group visits
  • Information available
  • Plans & specifications
  • Overview of building processes
  • Finalize scope & purpose of

inspection

  • Schedule inspection, escorts, &

access

  • P. 6

TSI

  • 3. Bidding Format

Lump Sum Unit Cost Document review Pre-inspection meetings Walkthrough & identification Field sampling Report writing Report review PLM analysis Point count analysis TEM analysis Non-typical materials

  • P. 6

TSI

Certifications & Qualifications

MAP Course Inspector Management Planner Requirements  3-day initial course  At least 70% on exam  ½ -day refresher  Completed inspector course  2-day initial course  At least 70% on exam  ½ -day additional refresher Suggested Pre-requisites High school diploma Registered architect, engineer, CIH or related scientific field

  • P. 7

TSI

Certifications & Qualifications

AHERA 40 CFR Part 763 Subpart E

  • Inspector

– 24 hr MAP Course

  • Management Planner

– 16 hr MAP Course

  • P. 7

TSI

Certifications & Qualifications

ASHARA

  • Inspector

– 24 hr MAP Course

  • Management Planner

– 16 hr MAP Course

  • P. 7
slide-5
SLIDE 5

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 4

TSI

Certifications & Qualifications

OSHA Construction & General Industry

  • AHERA inspector or CIH for pre-1980 TSI or

surfacing (PACM)

  • Industrial hygienist for pre-1980 flooring
  • AHERA inspector or CIH is recommended to

fulfill „due diligence‟ requirement

  • P. 7

TSI

Certifications & Qualifications

NESHAP 40 CFR Part 61 Subpart M

  • No requirements identified, however, AHERA

inspector is recommended to fulfill „thoroughly inspect‟ requirement

  • P. 7

TSI

Certifications & Qualifications

State Licenses

  • Inspector

– 24 hr MAP Course

  • Management Planner

– 16 hr MAP Course

  • Application & Fee
  • P. 7

TSI

Notifications

Functions

  • Limits confrontations during inspection
  • Building occupants are informed of potential

hazard

  • Informed occupants less likely to disturb ACM
  • Early and full disclosure may reduce legal

liabilities

  • P. 8

TSI

Notifications Approaches

  • Communicate with all affected parties
  • Bring it up early.
  • Tell the truth.
  • P. 8

TSI

Notifications Methods

  • Notices
  • Signs
  • Meetings
  • P. 8
slide-6
SLIDE 6

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 5

TSI

Notifications

AHERA 40 CFR Part 763 Subpart E

  • Annual

–Occupants & legal guardians

  • P. 8

TSI

Notifications

OSHA 29 CFR 1926.1101

  • Building & facility owners

– Employees, tenants & occupants in adjacent areas

  • Contractor (Inspector)

– Other employers (contractors)

  • P. 8

TSI

Notifications

None to conduct inspections

– OSHA 29 CFR 1910.1001 – NESHAP

State requirements vary

  • P. 8

TSI

Building Records

Drawings

Assists inspector to locate ACM within the building and identify the building systems

  • P. 9
TSI TSI

Improves the quality of the asbestos inspection report Various types of drawings

TSI

Building Records

SYMBOL DRAWING COMPONENTS A Architectural Floor plans Miscellaneous finishes M Mechanical Mechanical thermal system insulation P Plumbing Plumbing thermal system insulation S Structural Building grid plans Structural component insulation (usually fireproofing) E Electrical Wiring, transformers, panel boxes

  • P. 9

TSI

Review of Building Records

Abatement Records Floor Plans Site Plan Plans & Other Construction Documents

  • P. 9
slide-7
SLIDE 7

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 6

TSI

Previous Inspections

  • 1. Provides a starting point
  • 2. Identified ACM should be verified
  • 3. Inadequate parts should be

repeated.

  • 4. Helps to know who did it
  • 5. Should know why it was done
  • P. 9

TSI

Liability Concerns Inspection Report

–Foundation for all asbestos activities –Future actions rely on asbestos inspection

  • P. 10

TSI

Liability Concerns

Regulatory Liability

– Certification & performance issues – Laws & statutes – Enforcement trends – Letters of interpretation

Criminal Liability

– Knowingly & willful – Damages human health & environment

  • P. 10

TSI

Civil Liability

  • Contractual –agreement violation
  • Tort – legal wrong
  • P. 10

TSI

Inspector’s Liability

  • P. 10

Regulations  Identify all regulations applicable to the inspection activity  Review the sections of each regulation that apply  Comply with most stringent requirements Contract  Read & become familiar with if not developed by inspector  Develop proposals/ contracts that are specific for each project  Explain in detail what is to be done  Identify limitations to the survey scope TSI

Inspector’s Liability

  • P. 10

Inspection Report  Explain what was done in detail  Identify limitations to the survey scope  Provide definitions for key terms  List findings clearly  Make sure lab results, reported findings & drawings agree  Have the report carefully reviewed by a qualified individual

slide-8
SLIDE 8

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 7

TSI

Health Effects of Asbestos

  • Primary route of exposure is inhalation
  • Secondary route is ingestion
  • Latency Period of 10-40 years
  • 10,000 deaths/ year
  • Most affected trades
  • Mining
  • Insulating
  • Milling
  • Ship building
  • Manufacturing
  • Construction

P.11 Worker handling amosite asbestos at a pipe insulation manufacturing plant in Tyler, TX in the early 1970's. CDC Photo

TSI

Asbestos Diseases

P.11

Asbestosis – White Lung Scarring of the lung tissue

TSI

Asbestos Diseases

  • Asbestosis –

White Lung

–1,500 deaths/ year –20,000 hospital visits –Shortness of breath common symptom –Dose-response relationship

Time of Exposure Amount

  • f

Exposure Chance of Disease

P.11

TSI

Asbestos Diseases

  • Lung Cancer

Lung Cancer Healthy Lung

P.12

TSI

Asbestos Diseases

P.11

Lung Cancer

– Increased risk from smoking 10x – Increased risk from industrial asbestos exposure 5x – Combined increased risk over 50x

Increases Lung Cancer risk by over 50x Asbestos & Smoking

TSI

Asbestos Diseases

  • Mesothelioma

– Cancer of the lining of the chest cavity or abdomen. – 2,500 deaths/ year – Rare Cancer – No dose-response relationship – Always fatal

P.12

slide-9
SLIDE 9

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 8

TSI

Asbestos Diseases

  • Risks Associated with Low

Level Asbestos Exposure

  • Manufactured Mineral Fibers

P.12

TSI

Other Diseases

  • Pleural plaques
  • Pleural thickening
  • Pleural effusion

Cancers

  • Esophagus
  • Stomach
  • Colon
  • Pancreas

P.12

TSI

Insurance & Bonding

Workers‟ Compensation General Liability Pollution Prevention

– Occurrence – Claims Made

P.13

TSI

Insurance & Bonding

  • Bid Bonds
  • Performance Bonds
  • Payment or Labor & Material

Bonds

P.13

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Sec ection tion 2 Con Condu duct ctin ing g th the e Insp Inspec ection tion

TSI

Conducting the Inspection

Identifying Suspect Material

– Assume or test to determine asbestos content – USEPA & state lists – Commercial & residential buildings

  • P. 14-15
slide-10
SLIDE 10

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 9

TSI

Non-Suspect Materials

  • No testing needed for wood, metal or glass
  • “Usually not, however…” materials

– Cinder block, mortar, brick, house paint

  • AHERA exemptions

– Fiberglass, foam glass, rubber

  • Ultimately inspector‟s decision
  • P. 16

TSI

Identifying Suspect ACM

Homogeneous Areas

Is uniform in:

and appears identical in every other respect

color use or system date of application texture

P.16

TSI

Homogeneous Area

Texture Examine & describe all visible layers Surfacing Materials  loosely bound fireproofing  tighter bound acoustical plaster TSI  corrugated (aircell) paper  wrapped (compressed) paper  block insulation  cementitious (mudded) fittings  batt insulation Ceiling Tile – surface patterns & texture

P.16

TSI

Homogeneous Area

Color Flooring-Different patterns & tile color Does not include painted color of material

P.16

TSI

Homogeneous Area

Date of Application Any indication of differing installation dates including material at: different wings of a building different floors special areas such as cafeterias, machine shops, band rooms

P.16

TSI

Homogeneous Area

Use or System Surfacing/ plasters

  • fireproofing, ceilings, walls

TSI  hot water supply and/or return  cold water supply  chilled water supply  steam supply & return (watch for different pressure/temperature steam lines)  roof or system drain  chemical or waste transport  roofing, and siding

  • P. 16
slide-11
SLIDE 11

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 10

TSI

Identifying Suspect ACM

Friable/ Non-Friable

Homogeneous Area (Extent)

Material Type

Surfacing TSI Miscellaneous

Assessment

Location Condition Quantity Potential for Disturbance

  • P. 17

TSI

Friable vs. Non-Friable Can the material be crumbled, pulverized, or reduced to powder by hand pressure?

P.17

TSI

Categories of ACM

  • Surfacing ACM
  • Thermal System Insulation

ACM (TSI)

  • Miscellaneous ACM

P.17

TSI

Assessing ACM

  • Includes category, condition, quantity,

location, potential for disturbance

  • Timing considerations

Assessing during identifying & sampling  Reduces number of trips to site  Increases number of assessments conducted Assessing after receiving sample analysis  Reduces number of assessments conducted  Increases number of trips to site

  • P. 18

TSI

Functional Space

  • Defined by the

inspector

  • Up to entire

building (no additions)

  • Down to room-by

room

  • P. 18

TSI

Seven AHERA Categories

1. Damaged or significantly damaged thermal system insulation. 2. Damaged friable surfacing ACM 3. Significantly damaged friable surfacing ACM 4. Damaged

  • r

significantly damaged friable miscellaneous ACM. 5. ACBM with potential for damage. 6. ACBM with potential for significant damage. 7. Any remaining friable ACBM or friable suspected ACBM

  • P. 18
slide-12
SLIDE 12

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 11

TSI

Condition

General Damage Category AHERA Damage Category Criteria Good No Damage No Damage

(ASTM allows small amounts)

Fair Damage Up to 10% overall damage Up to 25% localized damage Poor Significant Damage Over 10% overall damage Over 25% localized damage

  • P. 18

TSI

Condition Factors

  • Type of damage
  • Severity of damage
  • Causes of damage
  • Measures to prevent damage
  • P. 19

TSI

Quantity

  • Each HA in each functional space
  • Surfacing material, miscellaneous material, and

boiler, tank, & duct insulation in square feet (SF)

  • Pipe insulation in linear feet (LF)
  • Pipe fittings (elbows, tees, valves) counted (each)
  • Bulk waste & stored materials in cubic feet (CF)
  • P. 19

TSI

Location

  • Identify each functional space

HA is present

  • Ideally locate all materials on

drawings

  • Use location descriptions

familiar to owner/ survey users

  • P. 19

TSI

Potential for Disturbance

EPA Curriculum Model Contact Vibration Air Erosion Overall

  • P. 19

TSI

Potential for Disturbance

ASTM E 2356 - 04 Physical Disturbances

  • Accessibility
  • Activities

Environmental Disturbances

  • Vibration
  • Water damage
  • Air currents
  • Airborne dust
  • Corrosive atmosphere
  • P. 19
slide-13
SLIDE 13

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 12

TSI

Potential for Disturbance

High

Service workers work in the vicinity of the material more than once per week, or The material is in a public area (e.g., hallway, corridor, auditorium) and accessible to building

  • ccupants.

Moderate

Service workers work in the vicinity of the material once per month to once per week, or The materials in a room or office and accessible to the occupants.

Low

Service workers work in the vicinity of the material less than once per month, or The material is visible but not within reach of building occupants.

C

  • n

t a c t

  • P. 20

TSI

Potential for Disturbance

High

Loud motors or engines present (e.g., some fan rooms), or Intrusive noises or easily sensed vibrations (e.g., major airports, a major highway).

Moderate

Motors or engines present but not obtrusive (e.g., ducts vibrating but no fan in the area), or Occasional loud sounds (e.g., a music room).

Low

None of the above

V i b r a t i

  • n
  • P. 20

TSI

Potential for Disturbance

High

High velocity air (e.g., elevator shaft, and fan room).

Moderate

Noticeable movement

  • f

air (e.g., airshaft, ventilator air stream).

Low

None of the above

A i r E r

  • s

i

  • n
  • P. 20

TSI

Potential for Disturbance

High

Any high rating

Moderate

No high ratings At least one moderate

Low

No high or moderate ratings

Overall

  • P. 20

TSI

Bulk Sampling Equipment

  • Ladder and flashlight
  • Barrier tape and signs
  • Airtight sampling containers
  • A plastic spray miser bottle
  • Plastic drop cloths
  • Tools for extracting samples
  • Patching materials, tape, adhesives
  • Cloths or towelettes for cleaning up debris and tools
  • HEPA vac
  • Indelible ink pen for labeling sample containers;
  • Camera for photographic documentation; and
  • Tape measure.

P.20-21

TSI

Bulk Sampling Guidelines

1. Sample after working hours or when the building area is not in use. 2. Random locations consider to safety, occupant & damage issues 3. Intact core samples assure all layers will be included 4. Chemically exposed and water damaged areas – Optical issues

P.21

5. Additional sampling considerations with materials near 1% 6. Rigid sample containers, not plastic bags, sample # on container 7. Steam lines & hot water lines may need to be cooled and de- pressurize. 8. Record sample location and number, use photographs 9. Use wet methods (water & surfactant) for most materials. 10. Clean and decontaminate sampling tools between each sample. 11. Patch sample hole

slide-14
SLIDE 14

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 13

TSI

OSHA Sampling Requirements

  • Notification
  • Regulated area
  • Work practices
  • PPE
  • Disposal
  • Hygiene facilities/ decons
  • Medical exams

P.22

TSI

Sampling Protocols

Surfacing Material

– AHERA requires a minimum number of samples based

  • n square footage

– Square footage based on material in HA throughout building – EPA recommends British „Pink Book‟ used to determine sample locations

P.23

TSI

Sampling Protocols

Size of the Homogeneous Sampling Area AHERA Minimum Number of Samples to be Collected Recommended Number of Samples to be Collected Less than 1,000 ft²

3 9

Between 1,000 & 5,000 ft²

5 9

Greater than 5,000 ft

7 9

P.23

Surfacing Material

TSI

Sampling Protocols

Thermal System Insulation

At least three (3) random samples except:

  • Exception 1 - Patch - 1 sample
  • Exception 2 –Mudded fittings

– determined by the inspector. – rule of thumb is 3 samples.

  • Exception 3 - Non-ACM materials

P.23

TSI

Sampling Protocols

Mixed & applied

  • n-site

 Hard ceiling plaster*  Hard wall plaster*

ACM usually in finish coat

AHERA 3-5-7 rule, Consider 9 per HA

P.23-24

Miscellaneous & Non-Friable

–AHERA states in a manner sufficient –Site mixed vs. manufactured –„bulk samples‟ means at least 2

–*NYDOL requirements TSI

Sampling Protocols

Factory mixed & applied on- site  Drywall joint compound  Mudded fittings  Roofing products  Window caulking & glazing Minimum 3 HA, be aware of additional materials added

  • n-site

Mixed and completely made at the factory  Ceiling tile  Drywall  Floor tile & mastic  Roofing materials  Transite 3 per HA

P.24

Miscellaneous & Non-Friable

slide-15
SLIDE 15

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 14

TSI

Sampling Protocols

Small manufactured items

  • Vibration joint cloth
  • Gaskets
  • Friction products

Minimum 2 per HA

P.24

Miscellaneous & Non-Friable

TSI

Vermiculite Sampling & Analysis

Characteristics

– Bound in matrix of other materials – Loose fill

Loose-Fill Vermiculite Attic Insulation USEPA Photo

Examples of Vermiculite Uses and Characteristics Vermiculite bound in matrix of another material Vermiculite exists as loose fill Gypsum plaster Fireproofing Insulation Acoustic finishes Paints Sealants Lightweight concrete Attic insulation Masonry fill Fertilizer carrier Potting soil Soil conditioners Absorbent packing

P.24

TSI

Vermiculite Sampling & Analysis

Sampling and Analysis Alternatives

P.25

Traditional PLM & TEM Bulk Sampling & Analysis  Obtain all layers of material  Best suited for vermiculite bound into a material  Not designed for applications where asbestos coexists and is not bound to other material  Bound vermiculite materials have same considerations as traditional asbestos materials including fiber size and binder type when considering PLM vs. TEM, gravimetric, and point counting.  Amount of material may not be sufficient for reliable negative determination with loose fill vermiculite  Ranges of fiber size in loose fill vermiculite makes it difficult to choose only PLM or TEM

TSI

Vermiculite Sampling & Analysis

Sampling and Analysis Alternatives

P.25

Cincinnati Method Good portion of sampled material should be taken from bottom of application 1-gallon size samples 3 samples recommended Too much water effects sample drying during analysis Use of surfactant effects analysis of smaller amphiboles Analysis involves both PLM and TEM analysis Reliability of results may be limited to asbestos presence, not % in sample Reliable negative determination for amphibole asbestos, not chrysotile TSI

Vermiculite Sampling & Analysis

Research Method for Sampling and Analysis of Fibrous Amphibole in Vermiculite Attic Insulation

EPA/600/R-04/004 “The Cincinnati Method”

P.25

TSI

Vermiculite Sampling & Analysis

The Cincinnati Method - Tools

  • Scoop, metal (approx. 12 x 5 cm) with a

flat edge

  • One gallon reusable plastic bags
  • Sample labels & makers
  • Chain-of-custody forms

P.25

slide-16
SLIDE 16

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 15

TSI

Vermiculite Sampling & Analysis

The Cincinnati Method - Sampling

  • Do not use amended water
  • Thrust metal scoop into vermiculite until scoop

reaches bottom (substrate)

  • Move along bottom
  • Raise through material
  • Place into 1-gallon bag
  • Repeat at location until full
  • Take minimum of 3 samples

P.25

TSI

Vermiculite Sampling & Analysis The Cincinnati Method – Sample Prep

  • Dry sample for 2 hours @ 100º C
  • Weigh before and after drying

TSI

Vermiculite Sampling & Analysis The Cincinnati Method - Analysis

  • Prepare sub-sample 5-50 grams
  • Introduce into aqueous solution

– Vermiculite floats – Large amphiboles sinks (PLM) – Small amphiboles suspended (TEM/SEM)

  • % weight results 0.01%-100%

TSI

Vermiculite Sampling & Analysis

Sampling and Analysis Alternatives

P.25

Other Loose- Fill Methods Size and number

  • f samples

required Make sure areas

  • f material most

likely to contain asbestos are included in sample Make sure sampling techniques support analytical methods Is PLM or TEM involved

  • r both?

Is sample prepared with loose fill characteristics considered? Is a reliable negative determination possible? Which type of asbestos is analyzed (amphiboles and/ or chrysotile)? TSI

Non-friable Organically Bound Materials

  • NOB‟s

– tar, roofing materials, mastic, glue, and floor tile

  • ASTM Recommendations

– PLM w/ <1% or NAD not reliable – Confirm w/ TEM gravimetric

  • State requirements

– Some may require TEM gravimetric reduction

P.26

TSI

Asbestos Dust Sampling

ASTM Method D 5756-02

– Microvac collection – 25 or 37 mm air sampling cassette w/ plastic tube – Quantitative TEM analysis

P.26

slide-17
SLIDE 17

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 16

TSI

Soil Sampling

  • Protocols not well established

– Consider sampling techniques, locations, analytical methods, interpretation of results – Sampling should represent surface area & depth for soil in question – Use of grid often used

  • Example of method used at USEPA Ft. Chaffee

project

P.26-27

TSI

Analyzing to 1st Positive

Pros Cons Saves time and money

  • Laboratory knows

samples from same HA

  • No sample results to

confirm material is same

P.27

Also called „Positive Stop‟

TSI

Analyzing Bulk Samples

Polarized Light Microscopy

  • Visual Estimation Technique
  • Gravimetric Reduction
  • Point Count Technique

P.27-28

TSI

Analyzing Bulk Samples

Transmission Electron Microscopy

  • Basic Method
  • Gravimetric

Reduction

P.28

TSI

Sample Analysis Results

  • Total amount of

asbestos in each layer

  • Each type and

percent of asbestos identified in each layer

  • Field (inspector‟s) sample

number & description

  • Laboratory sample number &

description or appearance

  • Each layer‟s description/ name
  • Non-asbestos materials and

percentages

  • Name and signature of analyst
  • Analytical method used and

laboratory quality control certifications

P.29

TSI

Asbestos Analysis Results

Chrysotile Amosite Crocidolite Actinolite Tremolite Anthophylite

P.29

slide-18
SLIDE 18

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 17

TSI

Quality Assurance

Laboratory Accreditation

Use nationally recognized program

Expiration Date ?

P.30

TSI

Quality Assurance

Comparing Quality Assurance Split Sample Results Variation in Analysis Level of Concern

One sample analyzed as ACM, other sample non-ACM Major concern - must have additional analysis from same or different labs Type

  • f

asbestos indicated in samples are different This is a concern that should be investigated further and remedied. Percent (%)

  • f

asbestos varies between samples Some degree should be expected.

P.30

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Secti tion 3 Perso rsonal Prote rotecti tive ve Equipme ment

TSI

Respiratory Hazards

  • P. 31

Categories of Respiratory Hazards Oxygen Deficiency Toxic Contaminants Asbestos Types of Toxic Contaminants Particulates Gases Vapors Asbestos TSI

Respiratory Hazards

  • P. 31

Controlling Respiratory Hazards

Assess the hazard Bulk Sampling Air Sampling Reduce or eliminate the hazard Work practices & engineering controls Provide respiratory protective equipment Proper respirators & filters

TSI

Use of Respirators

When do I not have to wear a respirator?

  • 1. Wet methods used
  • 2. NEA exists
  • 3. ACM removed intact

P.31

When do I have to wear a respirator?

  • 1. ACM not removed intact
  • 2. Wet methods not used
  • 3. Exposure above PEL/ no NEA exists
slide-19
SLIDE 19

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 18

TSI

Types of Masks & APF’s

  • OSHA has Assigned Protection

Factors for each respirator face piece

  • Filtering facepiece (Dust mask) not for

asbestos use

  • P. 31

X

TSI

Types of Masks & APF’s

Half-Mask Air-Purifying

  • PF=10
  • P. 32

TSI

Types of Masks & APF’s

Full Facepiece Air-Purifying

  • PF=10 (qualitative), 50 (quantitative)
  • P. 32

TSI

Types of Masks & APF’s

Powered Air-Purifying

  • PF=1000
JDH Systems, Inc.
  • P. 32

TSI

Types of Masks & APF’s

Full facepiece supplied air w/ SCBA escape

  • PF=1000+
  • P. 32

TSI

Respirator Selection

P.32

  • OSHA varies based on material

– Class I - Asbestos Standard – Class II & III Respiratory Standard

  • Recommend following Class I

requirements

– Always legal – Best protection – 0.01 f/cc in mask

slide-20
SLIDE 20

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 19

TSI

Respirator Selection

P.33

Required Respirator for Class I Activities Air Levels Half-Mask Air Purifying Full Facepiece Air-Purifying Any exposure up to 0.1 f/cc Powered Air-Purifying (PAPR) Full Facepiece Supplied Air 0.1 f/cc -1.0 f/cc Full Facepiece Supplied Air Over 1.0 f/cc

  • Class I requirements – most stringent

TSI

Maximum Use Concentration & Respirators for non-Class I work MUC = Respirator‟s APF x 0.1 f/cc

(Asbestos 8-Hr TWA PEL)

Highest allowable use level for Class II & III Recommend at least 0.01 f/cc inside mask

  • P. 33

TSI

Respirator Selection

  • P. 33

Respirator (Class II & III Activities) MUC (APF x PEL) Recommended Use Concentration (APF x 0.01 f/cc) Half-Mask Air Purifying 1.0 f/cc (10 x 0.1 f/cc) 0.1 f/cc (10 x 0.01 f/cc) Full Facepiece Air-Purifying w/ Qualitative Fit Test 1.0 f/cc (10 x 0.1 f/cc) 0.1 f/cc (10 x 0.01 f/cc) Full Facepiece Air-Purifying w/ Quantitative Fit Test 5.0 f/cc (50 x 0.1 f/cc) 0.5 f/cc (50 x 0.01 f/cc) Powered Air-Purifying (PAPR) Full Facepiece 100.0 f/cc (1000 x 0.1 f/cc) 10.0 f/cc (1000 x 0.01 f/cc)

Class II & III, not Class I

TSI

Types of Filters

P.34

  • HEPA = 99.97% @ 0.3 µm
  • Purple or magenta colors
  • NIOSH approved
  • Proper rating

TSI

Types of Filters

P.34

NIOSH Oil Mists/ Solvents Resistance Rating N Not resistant R Resistant up to 1 shift P Oil proof, resistant over 1 shift TSI

Types of Filters

P.34

NIOSH Efficiency Rating 95 95% of particles 99 99% of particles 100 99.97% of particles @ 0.3 µm

slide-21
SLIDE 21

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 20

TSI

Types of Filters

P.34

Filters Approved for Asbestos

N 100 Acceptable (evaluate airborne oil mists/ solvents) R 100 Acceptable (evaluate airborne oil mists/ solvents)

P 100 Recommended (no evaluation needed)

TSI

User Seal Checks

  • Every time
  • Negative pressure check

– Close off inlets – Inhale collapsing facepiece slightly – Seal should hold for 10 seconds

  • Positive pressure check

– Close off exhalation valve – Exhale gently 10 seconds w/o leakage

P.34-35

TSI

Fit Tests

  • Annually
  • Exercises
  • Qualitative

– 4 solutions – Advantages/ disadvantages

  • Quantitative

– 3 methods – Fit factor values

  • Acceptable methods
  • P. 35-36

TSI

Respirator Care

  • Cleaning

– Warm soapy water wash – Clean water rinse – Air Dry

  • Maintenance

– Routine inspections – Repair w/ qualified personnel & parts

  • Storage

– Protect from damage – Plastic bag

  • P. 36-37

TSI

Protective Clothing

  • Keeps asbestos off body
  • Usually disposable
  • Required above PEL or no NEA
  • Wearing requirements

– Don prior to entering regulated area – Remove in decon

  • Dirty/ Equipment Room w/ 3 or 5 stage decon
  • Dropcloth outside work area on small/ intact projects

P.37

TSI

Protective Clothing

Removal procedure:

  • Proceed to

decontamination area

  • HEPA vac suit using

buddy system

  • Take suit off inside-out,

rolling suit down body

  • Dispose of suit as

asbestos waste

P.37

slide-22
SLIDE 22

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 21

TSI

Other PPE

  • Head protection
  • Eye & face protection
  • Foot Protection
  • Hand protection

P.37

TSI

Proper respirator use? TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Section 4 Medical Surveillance

TSI

Medical Surveillance Triggers

  • Respirator Approval
  • Doctor’s or physician’s

authorization required

  • Prior to wearing respirator
  • Medical surveillance program

required

  • 30 Days of Class III work or

exceeding PEL

  • W/in 10 days of 30th day

P.38

TSI

Exam Content

  • Respirator approval

– Physician‟s signature

  • Medical surveillance program

P.38

Exam Component Initial Annual Medical questionnaire/history Comprehensive Abbreviated Comprehensive medical evaluation determined by licensed physician Yes Yes Pulmonary function tests Yes Yes Chest X-rays interpreted by a B reader Usually, up to physician

Usually every 2-5 yrs, up to Dr.

TSI

Exam Results

  • Reports signed by physician
  • Surveillance exams conducted in

accordance w/ 29 CFR 1926.1101

  • Kept for 30 years past last date of

employment

  • Available upon request
  • Example form p. 39

P.38

slide-23
SLIDE 23

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 22

TSI

www.TSItraining.com

Call 1-866-666-8438 Fax 1-866-813 -9804

Secti tion 5 Uti tilizing zing the the Surve rvey y Info Informati rmation

TSI

Evaluating Survey Results

  • 1. Identified homogeneous areas
  • 2. Material & sampling locations
  • 3. Quantities
  • 4. Laboratory results
  • 5. Assessment
  • 6. Inspector’s name &

accreditation

P.40

TSI

Regulatory Application

  • P. 40

Regulated Levels

  • f Asbestos

Amount of Asbestos in Homogeneous Area None Detected (0%) Trace up to 1.0% Greater than 1% AHERA 40 CFR Part 763 subpart E No No Yes NESHAPS 40 CFR Part 61 subpart M No No Yes OSHA 29 CFR 1926.1101 No Yes Yes Ohio, Indiana, Illinois, New York, and most other states No No Yes Quantities and type of ACM vary between state regulations

TSI

Federal Asbestos Regulations

OSHA (29 CFR 1926.1101)

  • All asbestos jobs covered
  • Class I – Removal of TSI & surfacing
  • Class II – Removal of all materials except TSI &

surfacing

  • Class III – any repairs up to 1 glovebag or disposal bag
  • Class IV – cleanup where ACM is contacted but not

disturbed

  • Unclassified operations
  • PACM - Presumed Asbestos-Containing Material.
  • P. 41

TSI

Federal Asbestos Regulations NESHAP (40 CFR Part 61 Subpart M)

– Category I NF (pliable) – Category II NF (brittle, rigid) – RACM – basically any currently or will become friable material – Notification requirements – Emission control procedures – Disposal requirements

  • P. 41

TSI

Federal Asbestos Regulations AHERA (40 CFR Part 763 Subpart E)

– All LEA‟s - public or private, not-for –profit school system consisting of grades K-12. – Manage/ abate all asbestos containing building material (ACBM) – Response actions include all friable asbestos abatement projects conducted in a school building or on exterior mechanical components

  • P. 41
slide-24
SLIDE 24

Asbestos Building Inspector Refresher 1/5/2010 Training Services International 23

TSI

State Asbestos Regulations

  • Various trigger levels and

requirements

  • P. 41

TSI

THE END
