Red Hat Ceph Storage Free Test Drive Environment Introduction Karan Singh Sr. Storage Architect Red Hat Taco Scargo Sr. Solution Architect Red Hat Agenda Quick Introduction to Ceph Introduction to Red Hat Storage Test Drive Program

SLIDE 1

Red Hat Ceph Storage

Free Test Drive Environment Introduction

SLIDE 2

Karan Singh

Sr. Storage Architect

Red Hat Taco Scargo

Sr. Solution Architect

Red Hat

SLIDE 3

Agenda

Quick Introduction to Ceph
Introduction to Red Hat Storage Test Drive Program
Launching your Test Lab
Using your Test Lab

SLIDE 4

Ceph Introduction & Architecture

SLIDE 5

What is Ceph ?

Open Source
Software Defined Storage Solution
Self Managing, Self Healing
Massively Scalable
No Single Point of failure
Unified Storage Platform ( Block , Object and File Storage )

SLIDE 6

What’s needed for Ceph ?

#1 Standard Servers with bunch of Disks #2 Networking between these servers #3 Linux Operating System ( RHEL / Debian ) #4 Ceph Packages

SLIDE 7

Ceph Stack

SLIDE 8

Red Hat Ceph Storage Test Drive

Learning by Doing

Absolutely Free
Ceph playground
10 Node Ceph Lab on AWS
Self paced , instruction led

http://bit.ly/ceph-test-drive

SLIDE 9

How to get there ?

Step – 1 : Signup here http://bit.ly/ceph-test-drive Step – 2 : Login and Select your SDS technology

SLIDE 10

1. Step by Step setup instructions
2. Launch Lab by clicking ‘Start Lab’ , Will take ~15 minutes to spin up AWS resources
3. Get public IP to connect and starting using it

Launch Your Test Lab

SLIDE 11

Administration / Calamari - mgmt 10.100.0.72/External IP mon1 10.100.2.11 mon2 10.100.2.12 OSD node1 10.100.1.11 OSD node2 10.100.1.12 OSD node4 10.100.1.14

CLUSTER NETWORK

client1 10.100.2.14 mon3 10.100.2.13

SSD HDD HDD HDD

OSD node3 10.100.1.13

PUBLIC NETWORK

SSD HDD HDD HDD SSD HDD HDD HDD SSD HDD HDD HDD

Lab Environment

SLIDE 12

LAB Login Information

Once LAB is created, click on “Addl.. Info” (Right side)
Grab your Management Node Public IP, this is the IP you will login to gain access

SLIDE 13

Try our different Modules

Click “IN SESSION”
Select from a range of classes

SLIDE 14

Resources

https://www.redhat.com/en/technologies/storage/ceph http://ceph.com/
