Recycling the big picture Colin Loveday Tarmac UK EAPA Madrid Mature Road Systems Established network Construction reducing Maintenance dominant EAPA Madrid Valuable Asset UK principal network 85 billion

slide-1
SLIDE 1

EAPA Madrid

Recycling – the big picture Colin Loveday – Tarmac UK

slide-2
SLIDE 2

EAPA Madrid

Mature Road Systems

  • Established network
  • Construction reducing
  • Maintenance dominant
slide-3
SLIDE 3

EAPA Madrid

Valuable Asset

  • UK principal network £85

billion

  • Only 5% of total network
  • £100s Billion
  • Much of it is asphalt!
slide-4
SLIDE 4

EAPA Madrid

Pressures on the road owner

  • Money
  • Sustainability
  • Climate change
slide-5
SLIDE 5

EAPA Madrid

Money

  • Unfortunately

they don’t have any

  • Hopefully that will

change!

slide-6
SLIDE 6

EAPA Madrid

Sustainability growing in importance

  • Sustainability business as usual
  • Focussing on priorities

– Sustainable consumption and production – Climate change and energy – Protecting our natural resources and enhancing our environment – Creating sustainable communities and a fairer world

  • Clearer direction for the supply chain
slide-7
SLIDE 7

EAPA Madrid

“achieving four objectives at the same time:

  • Effective protection of the environment
  • Prudent use of natural resources
  • Social progress which recognises the

needs of everyone

  • Maintenance of high and stable levels of

economic growth and employment”(OGC)

slide-8
SLIDE 8

EAPA Madrid

  • Embed sustainability and carbon considerations in HA decision making

processes through the delivery and application of research on:

Action Plan 2009-10

  • whole life

sustainability and carbon

  • application of HA

carbon management strategy

slide-9
SLIDE 9

EAPA Madrid

  • Information collated via carbon

calculation tool will underpin our carbon management strategy.

  • Measuring footprint has enabled us to

understand the sources of our emissions.

  • Subsequently identify emission

reductions, savings and set targets.

Carbon management

slide-10
SLIDE 10

EAPA Madrid

  • Defining climatic changes
  • Assessing and prioritising risks
  • Examining adaptation options

– Cost benefit analysis – Timescales for adaptation

  • Adaptation plans
  • Implement adaptation measures

Climate Change Adaptation Strategy

slide-11
SLIDE 11

EAPA Madrid

Asphalt

  • Flexible
  • Practical
  • Versatile
  • Self healing
  • Smooth Quiet
  • Durable
  • AND………..
slide-12
SLIDE 12

EAPA Madrid

Recyclable

  • Asphalt is 100% recyclable as asphalt
slide-13
SLIDE 13

EAPA Madrid

Recycling asphalt

  • Hot
  • Warm
  • Cold
  • Emulsion
  • Foam
  • In situ
  • Repave
  • Retread
slide-14
SLIDE 14

EAPA Madrid

But surely, concrete is recyclable?

  • Only up to a point
  • It’s ‘Downcyclable’
  • Concrete is

recyclable as aggregate

  • That is not good in

carbon terms

slide-15
SLIDE 15

EAPA Madrid

asPECT Embodied Carbon Tool

slide-16
SLIDE 16

EAPA Madrid

WHOLE LIFE CARBON ASSESSMENT PRODUCT

asPECT – LCA assessment of CO2e

1) Raw Materials 2) Transport 3) Processing 5) Component Production 4) Transport 6) Transport to Site 7) Laying & Compacting Use 10) End of Life 8) Scheme Specific Works

APPLICATION

9) Maintenance

slide-17
SLIDE 17

EAPA Madrid

CO2e Installed – average value

kgCO2e/t % % Aggregate 6 13 11 Filler 1 2 2 Bitumen 16 33 29 Energy –dry/heat 20 42 36 Energy–mix/other 5 10 9 TOTAL 48 100 Delivery 30Km 3 6 Installation TOTAL INSTALLED 4 7 55 100

slide-18
SLIDE 18

EAPA Madrid 18

  • Now that we know hot asphalt is about 45kg

CO2e per tonne we can start comparing  Asphalt with asphalt  Asphalt with other things

Carbon Benchmarking

slide-19
SLIDE 19

EAPA Madrid 19

Let’s try orange juice

slide-20
SLIDE 20

EAPA Madrid 20

Nice healthy natural product

slide-21
SLIDE 21

EAPA Madrid 21

Tesco make this really easy

slide-22
SLIDE 22

EAPA Madrid 22

Carbon Benchmarking

 Hot asphalt 45kg CO2e/tonne  Orange juice 1600kg CO2e/tonne

slide-23
SLIDE 23

EAPA Madrid

Carbon Benchmarking

  • Bitumen is 260 kg/tonne
  • Cement is 930 kg/tonne
  • Asphalt approximately 50kg/tonne
  • Concrete around 100 kg/tonne
slide-24
SLIDE 24

EAPA Madrid

Recoverable Carbon

kgCO2e/t % % Aggregate 6 13 11 Filler 1 2 2 Bitumen 16 33 29 Energy –dry/heat 20 42 36 Energy–mix/other 5 10 9 TOTAL 48 100 Delivery 30Km 3 6 Installation TOTAL INSTALLED 4 7 55 100

42% of embodied carbon recovered on recycling

slide-25
SLIDE 25

EAPA Madrid

Recoverable carbon

  • Recycled concrete is aggregate
  • Effective embodied carbon value 6kg/tonne
  • About 5% of embodied carbon recovered on recycling
slide-26
SLIDE 26

EAPA Madrid

Pavement Carbon

Design 1

Flexible

Design 2

Rigid/Reinforced

35mm SMA 5 35mm SMA 5 60mm EME2 27 200mm C32/40 (reinforced) 92 175mm EME2 200mm FC3 12 150mm FC3 9 TOTAL 44 TOTAL 106

80 MSA Design - CO2e/m2

slide-27
SLIDE 27

EAPA Madrid

Positive story?

  • Asphalt pavement 42% CO2e of

concrete pavement

  • 42% of asphalt CO2e recovered
  • n recycling
  • 5% of concrete CO2e recovered
  • n recycling
slide-28
SLIDE 28

EAPA Madrid

Rejoice!

  • Asphalt is 100% recyclable as

asphalt

slide-29
SLIDE 29

EAPA Madrid

European Asphalt Mine

  • UK 40 years 1.2 billion

tonnes

  • UK 100 years 2.5 billion

tonnes?

  • Europe 50 billion tonnes?
  • Enormous ‘linear quarry’
slide-30
SLIDE 30

EAPA Madrid

Maintenance Strategies

  • Recognise value of asphalt asset
  • Develop strategy for sustainable preservation of the asset
  • May involve more structural renewal
slide-31
SLIDE 31

EAPA Madrid

ALARM Survey

slide-32
SLIDE 32

EAPA Madrid

Pressures on Budget

  • Reactive Maintenance:
  • 27% (Ideal 16%)
  • England: 24%

London: 28% Wales: 29%

  • Premature Maintenance (trench reinstatement):
  • England 12%

London 15% Wales 11%

  • (2009 9%)

(2009 23%) (2009 24%)

  • Mitigating Insurance Claims:
  • England 19% London 22%

Wales 18%

  • (2009 19%) (2009 32%) (2009 17%)
slide-33
SLIDE 33

EAPA Madrid

Clearing the backlog England: 11.5 years London: 8.6 years Wales: 14.9 years

Av no of years before resurfacing(all roads) 20 40 60 80 100 120 England (excl London) London Wales 2004/5 2005/6 2006/7 2007/8 2008/9 2009/10

slide-34
SLIDE 34

EAPA Madrid

ALARM Conclusions

  • Inadequate funding
  • Maintenance increasingly superficial
slide-35
SLIDE 35

EAPA Madrid

Promote need for deeper maintenance

slide-36
SLIDE 36

EAPA Madrid

  • Defining climatic changes
  • Assessing and prioritising risks
  • Examining adaptation options

– Cost benefit analysis – Timescales for adaptation

  • Adaptation plans
  • Implement adaptation measures

Climate Change Adaptation Strategy

slide-37
SLIDE 37

EAPA Madrid

Some climate change is unavoidable…

Determined by current & future emissions Predetermined by historic emissions, inevitable

slide-38
SLIDE 38

EAPA Madrid

Is this the shape of the future?

slide-39
SLIDE 39

EAPA Madrid

The real challenge is water

20% increase in winter rainfall Damage within

slide-40
SLIDE 40

EAPA Madrid

Proactive maintenance

  • Without proper

maintenance we shall grind to a halt!

slide-41
SLIDE 41

EAPA Madrid

Proactive maintenence

  • 40 year design life?
  • Planned structural

enhancement of 2.5% of network per annum

  • Planned recycling of asphalt

‘asset’

  • Protection against climate

change

slide-42
SLIDE 42

EAPA Madrid

Preserve recyclability

slide-43
SLIDE 43

EAPA Madrid

Preserve recyclability 109 years later

slide-44
SLIDE 44

EAPA Madrid

By Products and Waste into asphalt

Slag Glass Paper IBA

slide-45
SLIDE 45

EAPA Madrid

Ensure reuse at end of working life

Make sure that over enthusiastic use of other industry’s waste does not shorten life expectancy of our product

  • r compromise recyclability.
slide-46
SLIDE 46

EAPA Madrid

Summary

  • Full recyclability of asphalt is a great positive.
  • Asphalt in the road is a huge asset
  • Carbon footprint of asphalt is a positive story.
  • Sustainability pressures are growing.
  • Superficial maintenance is not sustainable
  • Proactive structural maintenance is good economically and

environmentally

  • Don’t compromise future recyclability
slide-47
SLIDE 47

EAPA Madrid

Shout about it!

  • Asphalt is 100%

recyclable as asphalt

slide-48
