Reconstruction II Neural Networks in Monte Carlo Rendering Philipp - - PowerPoint PPT Presentation

Realistic Image Synthesis SS2018

Reconstruction II

Philipp Slusallek Karol Myszkowski Gurprit Singh

• 1

Neural Networks in Monte Carlo Rendering

Realistic Image Synthesis SS2018

Previous Lecture

2

Realistic Image Synthesis SS2018 3

Slide from Kartic Subr

Depth of field

4

Slide from Jakko Lehtinen

1 scanline


5

Slide from Jakko Lehtinen

Screen x Lens u

6

Slide from Jakko Lehtinen

The trajectories of
 samples originating from a single
 apparent surface never intersect.


Visibility: SameSurface

7

Slide from Jakko Lehtinen

Realistic Image Synthesis SS2018 8

Hachisuka et al. [2008]

Realistic Image Synthesis SS2018 9

Hachisuka et al. [2008]

Realistic Image Synthesis SS2018 10

Sen and Darabi [2012]

Realistic Image Synthesis SS2018 11

Pixels,Random Params,Features

The algorithm computes the statistical dependency of (c-f) on the random parameters in (b)

Sen and Darabi [2012]

Realistic Image Synthesis SS2018

Gaussian Filtering

12

Paris et al. [2009]

Realistic Image Synthesis SS2018

Bilateral Filtering

13

Paris et al. [2009]

Realistic Image Synthesis SS2018 14

Bilateral vs Gaussian Filtering

Paris et al. [2009]

Realistic Image Synthesis SS2018

À la Carte

15

• Introduction to Multi-Layer perceptrons (Neural Networks)
• Machine Learning for Filtering Monte Carlo Noise [Kalantari et al. 2015]

Realistic Image Synthesis SS2018

Motivation

16

Bako et al. [2017]

Realistic Image Synthesis SS2018

History of Neural Networks

• In 1943, McCulloch and Pitts created a computational

model for neural networks

• In 1975, Werbos's back propagation algorithm generally

accelerated the training of multi-layer networks.

• In 1980s, Recurrent Neural Networks were developed

17

Realistic Image Synthesis SS2018

Multi-Layer Perceptrons

18

Realistic Image Synthesis SS2018

Classifiers

19

yj = f(wjxj + bj)

Realistic Image Synthesis SS2018

Classifiers

20

yj = f(wjxj + bj)

Realistic Image Synthesis SS2018

Complex Classifiers

21

Complex classifier

yj = f(wjxj + bj)

Realistic Image Synthesis SS2018

Complex Classifiers

22

Complex classifier What features can produce this decision rule ?

Realistic Image Synthesis SS2018

Perceptron Classifier

23

x1

x2 x3 x4 x5

. . .

1 Classifier

Realistic Image Synthesis SS2018

Perceptron Classifier

24

x1

x2 x3 x4 x5

. . .

Classifier

y = f(w1x1 + w2x2 + ... + w0)

1

w1 w2 w0

Output

Realistic Image Synthesis SS2018 25

x1

1

Multi-layer Perceptron

Realistic Image Synthesis SS2018 26

x1

1

X X X

f f f

Multi-layer Perceptron

Realistic Image Synthesis SS2018 27

x1

1

w11 w21 w31

w30 w20 w10

X X X

f f f

Multi-layer Perceptron

Realistic Image Synthesis SS2018 28

x1

1

w11 w21 w31

w30 w20 w10

X X X

f f f

w11 w21

w30 w20 w10

w31

x1 x1 x1

+ + +

Multi-layer Perceptron

Realistic Image Synthesis SS2018 29

x1

1

w11 w21 w31

w30 w20 w10

X X X

f f f

w11 w21

w30 w20 w10

w31

x1 x1 x1

+ + +

y2 y1

y3

= = =

f f f

( ( ( ( ( (

Multi-layer Perceptron

Realistic Image Synthesis SS2018 30

w1

w2 w3

X

Output

x1

1

w11 w21 w31

w30 w20 w10

X X X

f f f

w11 w21

w30 w20 w10

w31

x1 x1 x1

+ + +

y2 y1

y3

= = =

f f f

( ( ( ( ( (

Multi-layer Perceptron

Realistic Image Synthesis SS2018 31

w1

w2 w3

w1

w2 w3

X

Output

x1

1

w11 w21 w31

w30 w20 w10

X X X

f f f

w11 w21

w30 w20 w10

w31

x1 x1 x1

+ + +

y1 y2

y3

y1 y2

y3

= = =

f f f

( ( ( ( ( ( Input features Hidden layers Output layers

Multi-layer Perceptron

Realistic Image Synthesis SS2018

Multi-layer Perceptron

32

w1

w2 w3

w1

w2 w3

X

Output

x1 1

w11 w21 w31 w30 w20 w10

X X X

f f f

w11 w21

w30 w20 w10

w31

Input features Hidden layers Output layers "Features" are outputs of perceptrons Perceptrons Matrix of first layer weights Matrix of second layer weights

Realistic Image Synthesis SS2018

Features of MLPs

33

Input features

Perceptron: Step function with linear decision boundary

Realistic Image Synthesis SS2018

Features of MLPs

34

Layer 1

2-layer:

"Features" are now decision boundaries (partitions) All linear combination of those partitions give complex partitions These outputs are now input features to the next layer

Realistic Image Synthesis SS2018

Features of MLPs

35

Layer 1 Layer 2 These complex outputs become the features for the new layer

Realistic Image Synthesis SS2018

Features of MLPs

36

Layer 1 Layer 2 Deep Neural Networks

Realistic Image Synthesis SS2018

Computational Graph representation of Neural Networks

37

Realistic Image Synthesis SS2018

Neural Networks

38

ReLU

W1 x1

N × 1 N × N

Fully connected layers

Realistic Image Synthesis SS2018

Neural Networks

39

ReLU Fully connected layers

W1 x1 x2

N × 1 N × N N × 1

Realistic Image Synthesis SS2018

Neural Networks

40

ReLU Fully connected layers ReLU ...

W1 W2 x1 x2

N × 1 N × N N × 1 N × N

Realistic Image Synthesis SS2018

Neural Networks

41

ReLU Fully connected layers ReLU ...

W1 W2 x1 x2

N × 1 N × N N × 1 N × N

N represents number of pixels in an image

data

Realistic Image Synthesis SS2018

Neural Networks

42

ReLU Fully connected layers ReLU ...

W1 W2 x1 x2 *

max ReLU Computational Graph Unstructured data

Realistic Image Synthesis SS2018

Neural Networks

43

Fully connected layers ReLU ReLU ...

W1 W2 x1 x2

Computational Graph

*

max ReLU

*

max ReLU ... Unstructured data

Realistic Image Synthesis SS2018

Two-layer model

44

*

max ReLU

*

max ReLU Fully connected layers

What can be a loss function ?

R R .

W1 W2

Realistic Image Synthesis SS2018

Two-layer model

45

*

max ReLU

*

max ReLU Fully connected layers Reference R R .

W1 W2

What can be a loss function ?

Realistic Image Synthesis SS2018

Two-layer model

46

*

max ReLU

*

max ReLU Fully connected layers R R .

W1 W2

What can be a loss function ?

Reference

Realistic Image Synthesis SS2018 47

Fully connected layers

*

max ReLU

*

max ReLU L2 Loss R R .

W1 W2

What can be a loss function ?

Two-layer model

Reference

Realistic Image Synthesis SS2018

Two-layer model

48

Reference max ReLU L2 Loss R R .

W1 W2

• 2

What can be a loss function ?

Realistic Image Synthesis SS2018

Two-layer model

49

max ReLU L2 Loss R R .

W1 W2

What can be a loss function ?

Reference

• 2

Realistic Image Synthesis SS2018

Two-layer model: Back propagation

50

Source link

Realistic Image Synthesis SS2018

Two-layer model: Back propagation

51

Random initialization Global cost minimum Gradient Descent Algorithm for back propagation

Realistic Image Synthesis SS2018

Back Propagation

52

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

53

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

54

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

55

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

56

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

57

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

58

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

59

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Back Propagation

60

Slides courtesy: Stanford Online Course

Realistic Image Synthesis SS2018

Machine Learning for Filtering Monte Carlo Noise

61

Kalantari et al. [SIGGRAPH 2015]

Realistic Image Synthesis SS2018

Reconstruction / Denoising

62

,

Pixel neighborhood Filter weights

Realistic Image Synthesis SS2018

Filter weights

63

Pixel neighborhood Filter weights For cross Bilateral filters:

Realistic Image Synthesis SS2018 64

Pixel neighborhood Filter weights For cross Bilateral filters:

Filter weights

Realistic Image Synthesis SS2018

For cross Bilateral filters:

65

Pixel neighborhood Filter weights

Filter weights

Sen and Darabi [2012]

Realistic Image Synthesis SS2018

For cross Bilateral filters:

66

Filter weights

Pixel screen coordinates Mean sample color value Scene features

Realistic Image Synthesis SS2018 67

Filter weights

What are the optimal parameters ? For cross Bilateral filters: Pixel screen coordinates Mean sample color value Scene features

Realistic Image Synthesis SS2018

Neural Network Approach

• Feed-forward Neural network
• Best part: We can learn weights in a training phase
• Back propagation: Important for training weights
• For Back propagation, the Loss function should be

differentiable and

• all the intermediate functionals should be differentiable.

68

Realistic Image Synthesis SS2018

One Hidden-layer model

69

Relative Mean Square Error:

Realistic Image Synthesis SS2018

One Hidden-layer model

70

Relative Mean Square Error:

???

Realistic Image Synthesis SS2018

One Hidden-layer model

71

Relative Mean Square Error:

Realistic Image Synthesis SS2018

Results

72

Realistic Image Synthesis SS2018

Results

73

Realistic Image Synthesis SS2018

Results

74

Realistic Image Synthesis SS2018 75

Recurrent Autoencoder for Interactive Reconstruction

Chaitanya et al. [2017]

Realistic Image Synthesis SS2018

Recurrent Neural Networks

76

Source link

Realistic Image Synthesis SS2018

Recurrent Neural Networks

77

Source link

Realistic Image Synthesis SS2018

Recurrent Autoencoder [Chaitanya et al. 2017]

78

Realistic Image Synthesis SS2018

Recommended Reading

79

• Machine Learning for Filtering Monte Carlo Noise [Kalantari et al. 2015]
• Recurrent Autoencoder for Interactive Reconstruction [Chaitanya et al. 2017]
• Kernel-Predicting CNNs for Monte Carlo Denoising [Bako et al. 2017]

Realistic Image Synthesis SS2018

References & Bonus

• Ian Goodfellow: Deep Learning
• Deep Dream Generator (Google)
• Deep Mind (Google)

80

Image by Google Deep Dream
