Quantum and Classical Algorithms for Approximate Submodular Function - - PowerPoint PPT Presentation

Quantum and Classical Algorithms for Approximate Submodular Function Minimization

Yassine Hamoudi, Patrick Rebentrost, Ansis Rosmanis, Miklos Santha

arXiv: 1907.05378

1. Approximate Submodular Function Minimization 2. Quantum speed-up for Importance Sampling

Approximate Submodular Function Minimization

1

• 4

Submodular Function

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ ∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

• 4

Submodular Function

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Example: area covered by cameras

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

A B

• 4

Submodular Function

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Example: area covered by cameras

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

A B + i + i

• 5

Submodular Function

A B

|cut(A)| = 2 |cut(B)| = 5

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Example: size of a cut

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

• 5

Submodular Function

A B i

|cut(A)| = 2 |cut(B)| = 5 |cut(A+i)| = 4 |cut(B+i)| = 6

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Example: size of a cut

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

• 6

Submodular Function

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Other examples:

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

• F(S) = h(|S|) is submodular iff h is concave

• 6

Submodular Function

A submodular function is a set function satisfying the diminishing returns property:

F : 2[n] → ℝ

Other examples:

∀A ⊂ B ⊂ [n] and i ∉ B, F(A ∪ {i}) − F(A) ≥ F(B ∪ {i}) − F(B)

• F(S) = h(|S|) is submodular iff h is concave
• rank of a set of vectors
• entropy of random variables
• coverage functions
• …

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

(time = #queries to the oracle )

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

(Grotschel, Lovasz, Shrijver 1981)

find such that

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

Exact Minimization: F(S⋆) = min

S⊂[n] F(S)

S⋆

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

• Lee, Sidford, Wong 2015:

(Grotschel, Lovasz, Shrijver 1981)

˜ O(n3) ˜ O(n2 log M)

M = max |F(S)|

• r

where

(lower bound: Ω(n))

find such that find such that

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

Exact Minimization: F(S⋆) = min

S⊂[n] F(S)

S⋆ F(S⋆) ≤ min

S⊂[n] F(S) + ϵ

S⋆ ε-Approx. Minimization:

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

• Lee, Sidford, Wong 2015:

(Grotschel, Lovasz, Shrijver 1981)

˜ O(n3) ˜ O(n2 log M)

M = max |F(S)|

• r

where

(lower bound: Ω(n))

find such that find such that

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

Exact Minimization: F(S⋆) = min

S⊂[n] F(S)

S⋆ F(S⋆) ≤ min

S⊂[n] F(S) + ϵ

S⋆ ε-Approx. Minimization:

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

• Lee, Sidford, Wong 2015:

(Grotschel, Lovasz, Shrijver 1981)

˜ O(n3) ˜ O(n2 log M)

M = max |F(S)|

• r

where

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n5/3/ϵ2)

(lower bound: Ω(n))

find such that find such that

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

Exact Minimization: F(S⋆) = min

S⊂[n] F(S)

S⋆ F(S⋆) ≤ min

S⊂[n] F(S) + ϵ

S⋆ ε-Approx. Minimization:

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

• Lee, Sidford, Wong 2015:

(Grotschel, Lovasz, Shrijver 1981)

˜ O(n3) ˜ O(n2 log M)

M = max |F(S)|

• r

where

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n5/3/ϵ2)

• Our result:

˜ O(n3/2/ϵ2) ˜ O(n5/4/ϵ5/2)

(classical) (quantum)

• r

(lower bound: Ω(n))

find such that find such that

Evaluation oracle access: given S obtain F(S).

• 7

Submodular Function Minimization

Exact Minimization: F(S⋆) = min

S⊂[n] F(S)

S⋆ F(S⋆) ≤ min

S⊂[n] F(S) + ϵ

S⋆ ε-Approx. Minimization:

(time = #queries to the oracle )

Submodular functions can be minimized in polynomial time

• Lee, Sidford, Wong 2015:

(Grotschel, Lovasz, Shrijver 1981)

˜ O(n3) ˜ O(n2 log M)

M = max |F(S)|

• r

where

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n5/3/ϵ2)

• Our result:

˜ O(n3/2/ϵ2) ˜ O(n5/4/ϵ5/2)

(classical) (quantum)

• r
• Axelrod, Liu, Sidford 2019:

˜ O(n/ϵ2)

(classical) (lower bound: Ω(n))

• 8

Lovász Extension

Discrete Optimization

F : 2[n] → ℝ

Set function:

• 8

Lovász Extension

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

F : 2[n] → ℝ

Set function:

• 8

Lovász Extension

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

n = 2

F({1}) = 10 F({2}) = 6 F({1,2}) = 3 F(Ø) = 0 F : 2[n] → ℝ

Set function:

(1,1)

• 8

Lovász Extension

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

(0,0) (1,0) (0,1)

n = 2

F({1}) = 10 F({2}) = 6 F({1,2}) = 3 F(Ø) = 0

[0,1]2

F : 2[n] → ℝ

Set function:

(1,1)

• 8

Lovász Extension

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

(0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

n = 2

F({1}) = 10 F({2}) = 6 F({1,2}) = 3 F(Ø) = 0 F : 2[n] → ℝ

Set function:

(1,1)

• 8

Lovász Extension

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

(0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

n = 2

F({1}) = 10 F({2}) = 6 F({1,2}) = 3 F(Ø) = 0 F : 2[n] → ℝ

Set function:

• 9

Lovász Extension

F : 2[n] → ℝ

Set function:

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

The Lovász extension is:

(1,1) (0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

• 9

Lovász Extension

F : 2[n] → ℝ

Set function:

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

The Lovász extension is:

• Piecewise linear

(1,1) (0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

• 9

Lovász Extension

F : 2[n] → ℝ

Set function:

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

• Convex iff F is submodular (Lovász 1983)

The Lovász extension is:

• Piecewise linear

(1,1) (0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

• 9

Lovász Extension

F : 2[n] → ℝ

Set function:

Discrete Optimization Continuous Optimization

f : [0,1]n → ℝ

Lovász extension:

• Convex iff F is submodular (Lovász 1983)

The Lovász extension is:

• Piecewise linear

(1,1) (0,0) (1,0) (0,1) F(Ø) F({2}) F({1,2}) F({1})

• Evaluable using n queries to F.

• 10

Submodular Function Minimization

Exact Minimization: ε-Approx. Minimization:

• Lee, Sidford, Wong 2015:
• Chakrabarty, Lee, Sidford, Wong 2017:
• Our result:
• Axelrod, Liu, Sidford 2019:

Cutting plane method

• n the Lovász extension

Stochastic Subgradient Descent

• n the Lovász extension

• 11

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. (not necessarily differentiable)

• 11

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x.

x

(not necessarily differentiable)

f(x)

g(x)

• 11

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x.

x

(not necessarily differentiable)

f(x)

g(x)

• 11

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x.

x

(not necessarily differentiable)

f(x)

g(x)

Stochastic Subgradient at x: random variable satisfying

˜ g(x) E[˜ g(x)] = g(x) ˜ g(x) w.p. 1/2 ˜ g(x) w.p. 1/2

• 12

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x. (not necessarily differentiable) Stochastic Subgradient at x: random variable satisfying

E[˜ g(x)] = g(x) ˜ g(x)

(projected) Stochastic Subgradient Descent

• 12

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x. (not necessarily differentiable) Stochastic Subgradient at x: random variable satisfying

E[˜ g(x)] = g(x)

C xt

˜ g(x)

(projected) Stochastic Subgradient Descent

• 12

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x. (not necessarily differentiable) Stochastic Subgradient at x: random variable satisfying

E[˜ g(x)] = g(x)

C xt

˜ g(x) −η˜ g(xt)

(projected) Stochastic Subgradient Descent

• 12

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x. (not necessarily differentiable) Stochastic Subgradient at x: random variable satisfying

E[˜ g(x)] = g(x)

C xt

˜ g(x) −η˜ g(xt)

xt+1

projection

(projected) Stochastic Subgradient Descent

If has low variance then the number of steps is the same as if we were using g(x).

• 12

Stochastic Subgradient Descent

Convex function f : C → ℝ on a convex set C. Subgradient at x: slope g(x) of any line that is below the graph of f and intersects it at x. (not necessarily differentiable) Stochastic Subgradient at x: random variable satisfying

˜ g(x) E[˜ g(x)] = g(x)

C xt

˜ g(x) −η˜ g(xt)

xt+1

projection

(projected) Stochastic Subgradient Descent

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

• each coordinate g(x)i can be computed with two queries to F

• subgradient descent requires steps to get an ε-minimizer of f

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

O(n/ϵ2)

• each coordinate g(x)i can be computed with two queries to F

(Jegelka, Bilmes 2011) and (Hazan, Kale 2012)

A stochastic subgradient for g(x) can be computed in time:

• subgradient descent requires steps to get an ε-minimizer of f

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

˜ g(x)

O(n/ϵ2)

• each coordinate g(x)i can be computed with two queries to F

(Jegelka, Bilmes 2011) and (Hazan, Kale 2012)

A stochastic subgradient for g(x) can be computed in time:

• subgradient descent requires steps to get an ε-minimizer of f

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

˜ g(x)

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n2/3)

O(n/ϵ2)

• each coordinate g(x)i can be computed with two queries to F

(Jegelka, Bilmes 2011) and (Hazan, Kale 2012)

A stochastic subgradient for g(x) can be computed in time:

• subgradient descent requires steps to get an ε-minimizer of f

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

˜ g(x)

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n2/3)

• Our result:

˜ O(n1/2) ˜ O(n1/4/ϵ1/2)

(classical) (quantum)

• r

O(n/ϵ2)

• each coordinate g(x)i can be computed with two queries to F

(Jegelka, Bilmes 2011) and (Hazan, Kale 2012)

A stochastic subgradient for g(x) can be computed in time:

• subgradient descent requires steps to get an ε-minimizer of f

For the Lovász extension f, there exists a subgradient g(x) such that:

• 13

Stochastic Subgradient for the Lovász extension

˜ g(x)

• Chakrabarty, Lee, Sidford, Wong 2017:

˜ O(n2/3)

• Our result:

˜ O(n1/2) ˜ O(n1/4/ϵ1/2)

(classical) (quantum)

• r
• Axelrod, Liu, Sidford 2019:

˜ O(1)

O(n/ϵ2)

• each coordinate g(x)i can be computed with two queries to F

(Jegelka, Bilmes 2011) and (Hazan, Kale 2012)

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

̂ u = (0, … , 0 , sgn(ui)∥u∥1 , 0 , … , 0)

pi = |ui| ∥u∥1

i-th coordinate

where i is sampled with probability

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

̂ u = (0, … , 0 , sgn(ui)∥u∥1 , 0 , … , 0)

pi = |ui| ∥u∥1

i-th coordinate

where i is sampled with probability

E[ ̂ u] = ∑

i

|ui| ∥u∥1 sgn(ui)∥u∥1 ⋅ ⃗ e i = ∑

i

ui ⋅ ⃗ e i = u

Unbiased:

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

̂ u = (0, … , 0 , sgn(ui)∥u∥1 , 0 , … , 0)

pi = |ui| ∥u∥1

i-th coordinate

where i is sampled with probability

E[ ̂ u] = ∑

i

|ui| ∥u∥1 sgn(ui)∥u∥1 ⋅ ⃗ e i = ∑

i

ui ⋅ ⃗ e i = u

Unbiased: 2nd moment:

E[∥ ̂ u∥2

2] = ∑ i

|ui| ∥u∥1 sgn(ui)2∥u∥2

1 = ∥u∥2 1

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

̂ u = (0, … , 0 , sgn(ui)∥u∥1 , 0 , … , 0)

pi = |ui| ∥u∥1

i-th coordinate

where i is sampled with probability

E[ ̂ u] = ∑

i

|ui| ∥u∥1 sgn(ui)∥u∥1 ⋅ ⃗ e i = ∑

i

ui ⋅ ⃗ e i = u

Unbiased: 2nd moment:

E[∥ ̂ u∥2

2] = ∑ i

|ui| ∥u∥1 sgn(ui)2∥u∥2

1 = ∥u∥2 1

For the Lovász extension: u = g(x) and ||g(x)||1 = O(1) (low variance)

(Jegelka, Bilmes 2011)

First attempt to construct :

• 14

Stochastic Subgradient for the Lovász extension

˜ g(x)

For any non-zero vector u ∈ Rn, define the random variable

̂ u = (0, … , 0 , sgn(ui)∥u∥1 , 0 , … , 0)

pi = |ui| ∥u∥1

i-th coordinate

where i is sampled with probability

E[ ̂ u] = ∑

i

|ui| ∥u∥1 sgn(ui)∥u∥1 ⋅ ⃗ e i = ∑

i

ui ⋅ ⃗ e i = u

Unbiased: 2nd moment:

E[∥ ̂ u∥2

2] = ∑ i

|ui| ∥u∥1 sgn(ui)2∥u∥2

1 = ∥u∥2 1

For the Lovász extension: u = g(x) and ||g(x)||1 = O(1) (low variance)

Hard to sample

(Importance sampling)

✗

(Jegelka, Bilmes 2011)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1)

(T = parameter to be optimized)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1) xT ⟶ ̂ g(xT)

(T = parameter to be optimized)

Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1) xT ⟶ ̂ g(xT) xT+1 ⟶ ̂ g(xT) + ˜ d(xT, xT+1)

(T = parameter to be optimized)

xT+2 ⟶ ̂ g(xT) + ˜ d(xT, xT+2) Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮ ⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1) xT ⟶ ̂ g(xT) xT+1 ⟶ ̂ g(xT) + ˜ d(xT, xT+1) x2T−1 ⟶ ̂ g(xT) + ˜ d(xT, x2T−1)

(T = parameter to be optimized)

xT+2 ⟶ ̂ g(xT) + ˜ d(xT, xT+2) Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮ ⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1) xT ⟶ ̂ g(xT) xT+1 ⟶ ̂ g(xT) + ˜ d(xT, xT+1) x2T−1 ⟶ ̂ g(xT) + ˜ d(xT, x2T−1)

⋯

x2T ⟶ ̂ g(x2T)

(T = parameter to be optimized)

xT+2 ⟶ ̂ g(xT) + ˜ d(xT, xT+2) Second attempt:

• 15

Stochastic Subgradient for the Lovász extension

(Chakrabarty, Lee, Sidford, Wong 2017)

Tool: there is an unbiased estimate of that can be computed efficiently when is sparse.

˜ d(x, y) d(x, y) = g(y) − g(x) x − y

Our construction:

x0 ⟶ ̂ g(x0) x1 ⟶ ̂ g(x0) + ˜ d(x0, x1) x2 ⟶ ̂ g(x0) + ˜ d(x0, x2)

⋮ ⋮

xT−1 ⟶ ̂ g(x0) + ˜ d(x0, xT−1) xT ⟶ ̂ g(xT) xT+1 ⟶ ̂ g(xT) + ˜ d(xT, xT+1) T independent

samples

T independent

samples

x2T−1 ⟶ ̂ g(xT) + ˜ d(xT, x2T−1)

⋯

x2T ⟶ ̂ g(x2T)

(T = parameter to be optimized)

⋯

Quantum speed-up for Importance Sampling

2

Problem

• 17

discrete probability distribution D = (p1,…,pn) on [n]. Input: Output: T independent samples i1,…,iT ~ D. Evaluation oracle access Classical Quantum

U(|i⟩|0⟩) = |i⟩|pi⟩ i ↦ pi

Cost = # queries to the evaluation oracle

Importance Sampling with a Classical Oracle Binary Tree

• 18

Importance Sampling with a Classical Oracle Binary Tree

p1 + p2 p3 p1 + p2 + p3 p4 + p5 p1 p2 p4 p5

• 18

Importance Sampling with a Classical Oracle Binary Tree

Preprocessing time: O(n) Cost per sample:

O(log n)

p1 + p2 p3 p1 + p2 + p3 p4 + p5 p1 p2 p4 p5

• 18

Importance Sampling with a Classical Oracle Binary Tree

Preprocessing time: O(n) Cost per sample:

O(log n)

Cost for T samples: O(n + T log n)

p1 + p2 p3 p1 + p2 + p3 p4 + p5 p1 p2 p4 p5

• 18

Importance Sampling with a Classical Oracle Binary Tree

Preprocessing time: O(n)

Alias Method

Cost per sample:

O(log n)

Cost for T samples: O(n + T log n)

Preprocessing time: O(n) Cost per sample:

O(1)

Cost for T samples: O(n + T)

p1 + p2 p3 p1 + p2 + p3 p4 + p5 p1 p2 p4 p5

• 18

(Walker 1974, Vose 1991)

Importance Sampling with Quantum State preparation

• 19

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 19

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 19

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 19

⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 1. Prepare with Amplitude Amplification on V, and measure it.

∑

i

pi |i⟩

• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 1. Prepare with Amplitude Amplification on V, and measure it.

∑

i

pi |i⟩

• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing time: O(

n)

Cost per sample:

O( npmax)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 1. Prepare with Amplitude Amplification on V, and measure it.

∑

i

pi |i⟩

• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing time: O(

n)

Cost per sample:

O( npmax)

Cost for T samples: O(

n + T npmax)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 1. Prepare with Amplitude Amplification on V, and measure it.

∑

i

pi |i⟩

• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing time: O(

n)

Cost per sample:

O( npmax)

Cost for T samples: O(

n + T npmax)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

= O(T n)

Importance Sampling with Quantum State preparation

V(|0⟩|0⟩) ⟼ 1 n ∑

i∈[n]

|i⟩|0⟩

• 1. Compute with quantum Maximum Finding

pmax = max {p1, …, pn}

• 2. Construct the unitary
• 1. Prepare with Amplitude Amplification on V, and measure it.

∑

i

pi |i⟩

• 19

= 1 npmax (∑

i

pi |i⟩)|0⟩ + …|1⟩ ⟼ 1 n ∑

i∈[n]

|i⟩( pi pmax |0⟩ + 1 − pi pmax |1⟩)

Preprocessing time: O(

n)

Cost per sample:

O( npmax)

Cost for T samples: O(

n + T npmax)

Our result: O(

Tn)

Preprocessing: Sampling (repeat T times):

(Grover 2000)

= O(T n)

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Element 1 2 3 4 5 6 7 Probability

p1 p2 p3 p4 p5 p6 p7

Distribution D

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Element 1 2 3 4 5 6 7 Probability

p1 p2 p3 p4 p5 p6 p7

Element 1 3 4 Probability

p1 PHeavy p3 PHeavy p4 PHeavy

Distribution D Distribution DHeavy

p

i

≥ 1 / T

PHeavy = ∑

i∈Heavy

pi

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Element 1 2 3 4 5 6 7 Probability

p1 p2 p3 p4 p5 p6 p7

Element 1 3 4 Probability Element 2 5 6 7 Probability

p1 PHeavy p3 PHeavy p4 PHeavy p2 PLight p5 PLight p6 PLight p7 PLight

Distribution D Distribution DHeavy Distribution DLight

p

i

≥ 1 / T pi < 1/T

PHeavy = ∑

i∈Heavy

pi PLight = ∑

i∈Light

pi

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Element 1 2 3 4 5 6 7 Probability

p1 p2 p3 p4 p5 p6 p7

Element 1 3 4 Probability Element 2 5 6 7 Probability

p1 PHeavy p3 PHeavy p4 PHeavy p2 PLight p5 PLight p6 PLight p7 PLight

Distribution D Distribution DHeavy Distribution DLight

Use the Alias method

p

i

≥ 1 / T pi < 1/T

PHeavy = ∑

i∈Heavy

pi PLight = ∑

i∈Light

pi

Importance Sampling with a Quantum Oracle

Our result: O(

Tn) for obtaining T independent samples from D = (p1,…,pn).

• 20

Element 1 2 3 4 5 6 7 Probability

p1 p2 p3 p4 p5 p6 p7

Element 1 3 4 Probability Element 2 5 6 7 Probability

p1 PHeavy p3 PHeavy p4 PHeavy p2 PLight p5 PLight p6 PLight p7 PLight

Distribution D Distribution DHeavy Distribution DLight

Use the Alias method Use Quantum State Preparation

p

i

≥ 1 / T pi < 1/T

PHeavy = ∑

i∈Heavy

pi PLight = ∑

i∈Light

pi

Importance Sampling with a Quantum Oracle

• 21

Preprocessing:

Importance Sampling with a Quantum Oracle

• 21
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.

Preprocessing:

Importance Sampling with a Quantum Oracle

• 21
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.

Preprocessing:

• 2. Compute PHeavy =

∑

i∈Heavy

pi

Importance Sampling with a Quantum Oracle

• 21
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

• 2. Compute PHeavy =

∑

i∈Heavy

pi

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 21
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

• 2. Compute PHeavy =

∑

i∈Heavy

pi

Importance Sampling with a Quantum Oracle

• 22

Sampling (repeat T times):

Importance Sampling with a Quantum Oracle

• 22

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

Importance Sampling with a Quantum Oracle

• 22

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.

Importance Sampling with a Quantum Oracle

• 22

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 23
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

Cost: Cost: Cost: Cost:

• 2. Compute PHeavy =

∑

i∈Heavy

pi

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 23
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

Cost: Cost: Cost:

O( nT)

Cost:

since |Heavy| ≤ T

• 2. Compute PHeavy =

∑

i∈Heavy

pi

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 23
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

Cost: Cost: Cost:

O( nT)

Cost:

O(T) since |Heavy| ≤ T

• 2. Compute PHeavy =

∑

i∈Heavy

pi

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 23
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

Cost: Cost: Cost:

O( nT) O(T)

Cost:

O(T) since |Heavy| ≤ T

• 2. Compute PHeavy =

∑

i∈Heavy

pi

• 4. Apply the preprocessing step of the Quant. State Preparation method on DLight.

Importance Sampling with a Quantum Oracle

• 23
• 1. Compute the set Heavy ⊂ [n] of indices i such that pi ≥ 1/T, using Grover Search.
• 3. Apply the preprocessing step of the Alias Method on DHeavy.

Preprocessing:

Cost: Cost: Cost: O(

n) O( nT) O(T)

Cost:

O(T) since |Heavy| ≤ T

• 2. Compute PHeavy =

∑

i∈Heavy

pi

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T)

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where ≤ 1 T ⋅ PLight

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Total expected cost:

≤ 1 T ⋅ PLight

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Total expected cost: O(T ⋅ PLight ⋅

npmax) ≤ 1 T ⋅ PLight

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Total expected cost: O(T ⋅ PLight ⋅

npmax) = O(T ⋅ PLight ⋅ n T ⋅ PLight ) ≤ 1 T ⋅ PLight

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Total expected cost: O(T ⋅ PLight ⋅

npmax) = O(T ⋅ PLight ⋅ n T ⋅ PLight ) ≤ 1 T ⋅ PLight = O ( nTPLight)

Cost per sample:

Importance Sampling with a Quantum Oracle

• 24

Flip a coin that is head with probability PHeavy :

Sampling (repeat T times):

• Head: sample i ~ DHeavy with the Alias Method.
• Tail: sample i ~ DLight with Quantum State Preparation.

O(1)

Total cost: O(T) Cost per sample:

pmax = max{ pi PLight : i ∈ Light} O( npmax) where

Total expected cost: O(T ⋅ PLight ⋅

npmax) = O(T ⋅ PLight ⋅ n T ⋅ PLight ) ≤ 1 T ⋅ PLight = O ( nTPLight) = O ( nT)

Conclusion

• Can we prepare T copies of the state

in time .

arXiv: 1907.05378

Open questions:

• Can we obtain a quantum speedup for exact/

approximate submodular function minimization?

• Can we improve the lower bound for exact/

approximate submodular function minimization?

∑

i∈[n]

pi |i⟩ O( nT)
