QT WEBCHANNEL BRIDGING THE GAP BETWEEN HTML AND QT Milian Wolff / www.kdab.com OUTLINE Motivation Qt WebChannel Outlook MOTIVATION QT WEBKIT 1 Qt WebKit Bridge PUBLISH A C++ QOBJECT QWebFrame *frame = myWebPage->mainFrame();

slide-1
SLIDE 1

QT WEBCHANNEL

BRIDGING THE GAP BETWEEN HTML AND QT

/ Milian Wolff www.kdab.com

slide-2
SLIDE 2

OUTLINE

Motivation Qt WebChannel Outlook

slide-3
SLIDE 3

MOTIVATION

slide-4
SLIDE 4

QT WEBKIT 1

Qt WebKit Bridge

slide-5
SLIDE 5

PUBLISH A C++ QOBJECT

QWebFrame *frame = myWebPage->mainFrame(); frame->addToJavaScriptWindowObject("foo", myObject); /* ... */

slide-6
SLIDE 6

PUBLISH A QT QUICK 1 OBJECT

import QtWebKit 1.0 ... { QtObject { id: myObject, WebView.windowObjectName: "foo" // more properties, signals, functions... } WebView { javaScriptWindowObjects: [myObject /*, ...*/] } }

slide-7
SLIDE 7

ACCESSING AN OBJECT FROM JAVASCRIPT

foo.someSignal.connect(function(arg1 /*, arg2, ...*/) { /*...*/ }); foo.someProperty = foo.someOtherProperty + 1; var ret = foo.someMethod(1, "asdf", [1, 2], {asdf: "bar"});

slide-8
SLIDE 8

QT WEBKIT BRIDGE

easy to use efficient synchronous API

  • nly for Qt WebKit 1

no support for Qt Quick 2

slide-9
SLIDE 9

QT WEBKIT 2 & BEYOND

slide-10
SLIDE 10

QT WEBCHANNEL

slide-11
SLIDE 11

HOW?

serialize Qt MetaObject send to HTML process via IPC create JavaScript object with mirrored API transmit signals, method calls, property changes

slide-12
SLIDE 12

DEMO

slide-13
SLIDE 13

SETUP

slide-14
SLIDE 14

PUBLISH A C++ QOBJECT

QWebChannel channel; channel.registerObject(QStringLiteral("foo"), foo); /* ... */ channel.connectTo(someClient);

slide-15
SLIDE 15

PUBLISH A QT QUICK 2 OBJECT

import QtWebChannel 1.0 import QtWebKit 3.0 import QtWebKit.experimental 1.0 QtObject { id: foo, WebChannel.id: "foo" // more properties, signals, functions... } WebView { experimental.webChannel.registeredObjects: [ foo /*, ... */ ]; }

slide-16
SLIDE 16

ACCESSING AN OBJECT FROM JAVASCRIPT

<script type="text/javascript" src="qrc:///qtwebchannel/qwebchannel.js"></script> // in your window.onload handler or similar: new QWebChannel(navigator.qtWebChannelTransport, function(channel) { // connection to server succeeded, objects available via: var foo = channel.objects.foo; // use them like before: foo.someSignal.connect(function(arg1 /*, arg2, ...*/) { /*...*/ }); foo.someProperty = foo.someOtherProperty + 1; // big difference: async return values foo.someMethod(1, "asdf", [1, 2], {asdf: "bar"}, function(ret) { /* method call returned */ }); });

slide-17
SLIDE 17

QT WEBCHANNEL TRANSPORTS

class QWebChannelAbstractTransport : public QObject { Q_OBJECT public: explicit QWebChannelAbstractTransport(QObject *parent = 0); virtual ~QWebChannelAbstractTransport(); public Q_SLOTS: virtual void sendMessage(const QJsonObject &message) = 0; Q_SIGNALS: void messageReceived(const QJsonObject &message, QWebChannelAbstractTransport *transport); };

existing implementations: Qt WebKit 2 IPC Qt WebEngine IPC Qt WebSockets

slide-18
SLIDE 18

SIDE-EFFECT

works in any JavaScript runtime with WebSockets: desktop browsers mobile browsers (e.g. via Qt WebView) node.js Qt Quick 2

slide-19
SLIDE 19

C++ SERVER

// setup WebSocket server QWebSocketServer server(QStringLiteral("QWebChannel Server"), QWebSocketServer::NonSecureMode); server.listen(QHostAddress::LocalHost, 12345); // wrap WebSocket clients in QWebChannelAbstractTransport objects // see: qtwebchannel/examples/webchannel/standalone WebSocketClientWrapper clientWrapper(&server); // setup the channel and connect to WebSocket clients QWebChannel channel; QObject::connect(&clientWrapper, &WebSocketClientWrapper::clientConnected, &channel, &QWebChannel::connectTo);

slide-20
SLIDE 20

JAVASCRIPT CLIENT

var socket = new WebSocket("ws://localhost:1234"); socket.onopen = function() { new QWebChannel(socket, function(channel) { /* ... */ }); }

slide-21
SLIDE 21

DEMO

slide-22
SLIDE 22

QT QUICK 2 CLIENT

import QtWebChannel 1.0 import "qrc:///qtwebchannel/qwebchannel.js" as JSClient import Qt.WebSockets 1.0 WebSocket { id: socket url: "ws://127.0.0.1:12345" // mimick HTML WebSocket API function send(message) { sendTextMessage(message); } property var onmessage;

  • nTextMessageReceived: { onmessage({data:message}); }

// create WebChannel once connected

  • nStatusChanged: if (socket.status == WebSocket.Open) {

new JSClient.QWebChannel(socket, webChannelInitialized); } // try to connect to server active: true }

slide-23
SLIDE 23

DEMO

slide-24
SLIDE 24

DEMO

slide-25
SLIDE 25

TIPS & TRICKS

minimize IPC traffic share a single WebChannel with multiple WebViews block updates if WebViews are invisible

  • nly publish "safe" objects

keep memory overhead in mind

slide-26
SLIDE 26

QT WEBCHANNEL

easy to use very versatile asynchronous API serialization overhead

slide-27
SLIDE 27

OUTLOOK

Qt WebEngine Qt WebView for Android, iOS further simplify usage improved multi-client support more language bindings

slide-28
SLIDE 28

THE END

QUESTIONS? FEEDBACK?

/ Milian Wolff www.kdab.com

git clone git@gitorious.org:qt/qtwebchannel.git
